- Page 1 TD 204 VIDEO DISTRIBUTION AMPLIFIER Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Safety precautions........................2 Preface...........................3 Features ..........................3 Precautions ..........................3 Controls and connectors......................4 Connections ...........................5 Specifications .........................5 SAFETY PRECAUTIONS In order to prevent any fatal accidents WARNING: caused by misoperation or mishandling of the THIS APPARATUS MUST BE EARTHED video switcher, be fully aware of all the following precautions. -
Page 3: Preface
PREFACE PRECAUTIONS • The TD 204 is a high quality double video Use only the power source specified on the distribution amplifier. External slide switch rating label located on rear of the cabinet. • allows the distribution of one video input to... -
Page 4: Controls And Connectors
CONTROLS AND CONNECTORS FRONT PANEL REAR PANEL FUSE Ser.No: MODEL No. TD 204 (1) Power switch. (4) Slide switch. (2) Fuse socket. (5) Video input connectors. (3) Power cord. (6) Video output connectors. -
Page 5: Connections
AC outlet before connecting to other equipment. • Also refer to the instruction manual of the equipment to be connected. FUSE Ser.No: MODEL No. TD 204 AC MAINS SPECIFICATIONS Video input 1-2Vpp/75Ω, BNC Video output 1-2Vpp/75Ω, BNC Video bandwidth 10MHz±3dB...
