- Page 1 TD 408 VIDEO DISTRIBUTION AMPLIFIER OPERATING INSTRUCTIONS v2.0...
-
Page 2: Table Of Contents
CONTENTS Safety precautions........................2 Preface...........................3 Features ..........................3 Precautions ..........................3 Controls and connectors......................4 Front panel ........................4 Rear panel ........................4 Connections ...........................5 Specifications .........................5 Installation ..........................6 Jumper settings .......................6 Trimmer adjustments .......................6 SAFETY PRECAUTIONS In order to prevent any fatal accidents WARNING: caused by misoperation or mishandling of the THIS APPARATUS MUST BE EARTHED video distribution amplifier, be fully aware of all the following precautions. -
Page 3: Preface
PREFACE PRECAUTIONS The TD 408 is a high quality video • Use only the power source specified on the distribution amplifier with eight video outputs. rating label located on rear of the cabinet. Internal jumpers allows the distribution of one •... -
Page 4: Controls And Connectors
CONTROLS AND CONNECTORS FRONT PANEL REAR PANEL Ser.No: MODEL No. TD 408 FUSE (1) Power switch. (4) Power cord. (2) Fuse socket. (5) Video output connectors. (3) Video input connectors. -
Page 5: Connections
Be sure to disconnect the power plug from the AC outlet before connecting to other equipment. • Also refer to the instruction manual of the equipment to be connected. Ser.No: MODEL No. TD 408 FUSE AC MAINS SPECIFICATIONS Video input 1-2Vpp/75Ω, BNC Video output 1-2Vpp/75Ω, BNC... -
Page 6: Installation
INSTALLATION JUMPER SETTINGS VIDEO INPUT JUMPER Video Output 1-1 OUT1 - J201 VIDEO INPUT JUMPER Video Output 2-1 OUT2 - J211 VIDEO INPUT JUMPER Video Output 1-2 OUT3 - J221 VIDEO INPUT JUMPER Video Output 2-2 OUT4 - J231 VIDEO INPUT JUMPER Video Output 1-3 OUT5 - J241... -
Page 7: Trimmer Adjustments
VIDEO INPUT JUMPER Video Output 1-4 OUT7 - J261 VIDEO INPUT JUMPER Video Output 2-4 OUT8 - J271 TRIMMER ADJUSTMENTS LINEAR GAIN TRIMMER ADJUSTMENT VIDEO OUT 1-1 TP201 VIDEO OUT 2-1 TP211 VIDEO OUT 1-2 TP221 VIDEO OUT 2-2 TP231 VIDEO OUT 1-3 TP241 VIDEO OUT 2-3... - Page 8 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 E-mail: sales@astel-cctv.com Web: www.astel-cctv.com...
