Page 2
The Bluetooth trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by ZTE Corporation is under license. Other trademarks and trade names are the property of their respective owners. ZTE Corporation reserves the right to make modifications on print errors or update specifications in this manual without prior notice.
Contents let’s get started..........................1 lost or stolen?..........................1 using your phone safely.......................2 battery care and safety......................5 charger care and safety.......................6 getting to know your phone ......................8 inserting and removing the SIM ....................11 inserting and removing a memory card ..................12 using the battery ........................13 inserting the battery ......................13 removing the battery ......................13 charging the battery......................14...
Page 4
receiving a call........................18 adjusting the volume......................18 hands-free........................18 call options ........................18 sending messages ......................18 viewing messages ........................19 adding a new contact.........................20 using your phone as memory .....................20 main function list ..........................21 input what you want, how you want… ..................28 appendix ............................29 care and maintenance........................29 health and safety ........................30 declaration of RoHS compliance....................32...
let’s get started Thanks for choosing the Lisbon from Orange. It’s a GSM dual band GPRS digital mobile phone, which we’ll simply call ‘phone’ from now on. If you’d like your phone to live a long and fruitful life, please read this guide carefully and keep it for future reference.
using your phone safely on the road Using a phone while driving is illegal in many countries. Please follow local laws and drive safely at all times. near sensitive electronics Don’t use your phone near sensitive electronic equipment – particularly medical devices such as pacemakers –...
Page 7
in hospital Your phone may interfere with the normal operation of medical equipment. Follow all hospital regulations and turn it off when you’re asked to by posted warnings or medical staff. at a petrol station Don’t use your phone at petrol stations. In fact, it’s always best to switch off whenever you’re near fuels, chemicals or explosives.
Page 8
broken antenna Don’t use your phone if the antenna is damaged, as it could cause injury. around children Keep your mobile out of children’s reach. It should never be used as a toy and it might not be good for their health. original accessories Only use the original accessories supplied with your phone or those approved by the manufacturer.
emergency calls To make an emergency call your phone must be turned on and in an area where there’s network coverage. Dial the national emergency number (in the UK: 999) and press ‘send’. Explain exactly where you are and don’t hang up until help has arrived. battery care and safety Keep the battery in a cool, ventilated place and out of direct sunlight.
If the battery becomes hot, changes colour or shape at any time (when in use, charging or even while in storage) please stop using it immediately and replace. Keep the battery dry. Damp or wet conditions can cause it to overheat or corrode. Don’t leave the battery in direct sunlight or anywhere really hot, like in a car on a summer’s day.
Page 11
vibrating surface. And charging your phone near – or on – a TV or radio could interfere with transmission. Don’t use the charger if the power cable is damaged. It may cause a fire or give someone an electric shock. Keep water well away from the charger.
getting to know your phone Receiver Navigation key /OK key Display In idle mode: Up/down to scroll through shortcuts. Go left for Write message. Go right for Contacts. Press straight down to choose/OK shortcut. Microphone Send key Power Key Press to hang up or reject an Press to make or receive a call.
Page 13
Camera Speaker Side keys Adjust the volume note: In this user guide, ‘press’ means pressing the key and then releasing. ‘Hold’ means pressing and holding the key for two seconds or more.
Page 14
Descriptions of icons on the status bar Icons Descriptions Icons Descriptions Signal strength Battery charge level Calling or call in progress You have missed calls Call holding Call forwarding You have an unread SMS You have new voicemail You have an unread MMS Alarm on Call alert on ring only Call alert on vibrate only...
inserting and removing the SIM Your phone needs a valid SIM card to work (…To keep it simple, we’ll just call it ‘SIM’ from now on). Your network connection data and your SIM address book are saved on the SIM. So, to avoid damaging your SIM or losing data, try not to touch the metal surface when you’re handling it –...
inserting and removing a memory card Note: Removing or inserting a memory card when your phone is turned on could not only damage it and your phone, but also destroy any data saved on the card. Turn off your mobile phone, remove the battery and disconnect any external power. Slide the metal clasp back, and then open.
using the battery inserting the battery Open the battery cover on the back of your phone. Align the battery's contact points with those of the phone and gently press the battery down into place. Replace the battery cover clicking it back into position.
charging the battery The rechargeable Li-ion battery that comes with your phone is ready to use, but is not charged. That’s easy to do. We’ll show you how below. The first three times you use the battery, make sure it’s completely drained before recharging.
Page 19
Input phone lock code: If you’ve set a lock code. Input SIM PIN: If you’ve set a PIN for your SIM. Note: The PIN is supplied with your SIM. Please replace it with your own PIN code as soon as possible. Enter the wrong PIN three times, and your SIM will be locked.
using your phone Select ‘Menu’ to enter the main menu… Music Sent messages Call history Games and Applications Music store Delete messages Organiser Games Audio player Broadcast messages Calendar Calculator Contacts Templates Tasks Unit converter Media Album Message settings Alarm Currency converter Images Orange World...
descriptions of common functions making and receiving calls making a call Direct dial: In idle mode, select to display the dialling keyboard and click the numeric keys to input the number. Select to dial. Dialling from the Contacts: In idle mode, select to enter ‘Contacts’, then select your contact and press the Send key to dial.
receiving a call Someone’s calling? Press the Send key to answer. adjusting the volume During a conversation, you can raise or lower the volume by using the side keys. And in idle mode, you can use the side keys to adjust the keypad volume. hands-free Select ‘H-Free’...
Writing your message: If you want to add a picture, sound, video… select ‘Options’ followed by ‘Add picture’, ‘Add sound’ or ‘Add video’ or whatever you want. If you want to send a multimedia message, please select ‘Switch to MMS’. After editing the message, select ‘Send’...
adding a new contact In idle mode, select ‘Menu’ and go to ‘Contacts’. If you’d like to add a new contact to your phone memory, simply select ‘Add new contact’. Then you can enter all the details you want. If you’d prefer to add a new contact to the SIM memory, select ‘Options’...
main function list In idle mode, click ‘Menu’ to enter the main menu. Those marked with ‘*’ need support from network operators. Function Description Operation Music Store Log on to Music Store. Music Music Store Audio Player Play the audio file. Music Audio Player View contacts...
Page 26
Function Description Operation Preferred Select the preferred storage as phone or Contacts Move the highlight to Add storage SIM. new contact Options Phonebook settings Preferred storage Assign up to 8 phone numbers to keys 2-9. Speed dial Contacts Move the highlight to Add In idle mode, hold the key number that new contact Options...
Page 27
Function Description Operation Check memory Check the memory status for text messages Messaging Message settings Text status on your SIM card and phone. message Memory status Preferred Save messages on the SIM card or phone. Messaging Message settings Text storage message Preferred storage Broadcast...
Page 28
Function Description Operation Call waiting Activate this if you want to be prompted Settings Call settings Call waiting about incoming calls. Call divert Divert incoming calls to another designated Settings Call settings Call divert number. Call barring Set the outgoing call restriction or incoming Settings Call settings Call barring...
Page 29
Function Description Operation Settings Security settings Fixed dial When this is activated, you can only call numbers on the fixed dial list. Fixed dial ® ® ® Bluetooth Exchange data with other Bluetooth Settings Connectivity Bluetooth devices. Also listen to music or talk ®...
Page 30
Function Description Operation Sound Record audio files. Media players Sound recorder recorder FM radio Listen to FM broadcasts. Media players FM radio Profiles Personalise your phone settings, such as Profiles Select Profile ringtone, volume, etc. according to where you (General/Meeting, etc.) Activate are and what you’re doing.
Page 31
note: When copying files from a PC to a memory card, make your life easier by putting them in the relevant folder. For example, music files should go in the ‘Audio’ folder and video files in the ‘Videos’ folder.
input what you want, how you want… With your phone you can write in: capitals (ABC); lower case (abc); numbers (123) or even in symbols! Here’s how to make those choices… Display virtual Press to display the virtual keyboard. keyboard Switch input method Press to change the input method.
appendix care and maintenance Your phone is a delicate device. The following advice will help you to keep it looking good and performing well… Use a soft dry cloth to clean your phone, battery and charger. Don’t use liquids such as alcohol, dilution agents or benzene.
health and safety SAR certification information The Lisbon meets international guidelines for exposure to radio waves. Your phone is a radio transmitter and receiver. It’s designed not to exceed the limits for exposure to radio waves recommended by international guidelines. The guidelines were developed by ICNIRP, an independent technical standards body, and include margins designed to assure the protection of all persons, regardless of age and health.
Page 35
important safety information For your own health and safety, please follow the radio frequency (RF) radiation exposure guidelines and keep your phone no less than 1.5cm away from your body. Failure to do this could mean that your RF exposure exceeds the guideline limits. how to limit your radio frequency (RF) exposure The World Health Organization (WHO) gives the following advice to people who want to limit their exposure to RF radiation…...
We’re determined to reduce the impact we have on the environment and take responsibility for the earth we live on. So this document allows us to formally declare that the Lisbon, manufactured by ZTE CORPORATION, fully complies with the European Parliament’s RoHS (Restriction of Hazardous Substances) Directive 2002/95/EC, with...
disposal of your old phone 1. When the wheelie bin symbol is attached to a product, it means the product is covered by the European Directive 2002/96/CE. 2. All electrical and electronic products should be disposed of separately from normal household waste via designated collection points provided by government or local authorities.
It is hereby declared that following designated product: Product Type: GSM Dual-band Digital Mobile Phone Model No.: Lisbon from Orange (ZTE-G X670) complies with the essential protection requirements of Low Voltage Directive 2006/95/EC (previous 73/23/EEC), Electromagnetic Compatibility Directive 2004/108/EC (previous 89/336/EEC), Radio and Telecommunication Terminal Equipment Directive (EC Directive 1999/05/EC) and their amendments.
Page 39
Art.3.2 Radio EN301511 This declaration is the responsibility of the manufacturer: ZTE Corporation ZTE Plaza, Keji Road South, Hi-Tech, Industrial Park, Nanshan District,Shenzhen, Guangdong, 518057, P.R.China Authorised person signing for the company: Xu feng Quality Director Of ZTE Corporation Name in block letters & position in the company Shenzhen, 22 Dec.
limited warranty statement Article 1 The guarantee for the Orange ‘Lisbon’ device (referred to as ‘Device’ from now on) is valid for 24 (twenty four) months from the date the Device was purchased. The guarantee is valid for six (6) months for the following consumable parts and accessories: batteries, chargers, desk stands, headsets, cables and covers.
Page 41
a) Damage caused by using the Device outside of the instructions of the manufacturer and other documentation which is enclosed with the Device, as well as damages caused by using with other products of another non-approved manufacturer; b) Damage caused by accidents, improper and wrong usage, floods, fire, earthquakes and superficial damages which include, but are not limited to, scratches, dents, broken plastic and alike;...
Page 42
Part(s) repaired or replacement product during the Warranty Period will be warranted for the remainder of the original Warranty Period or for sixty (60) days from the date of repair or replacement, whichever is longer. Article 4 The guarantee stops being valid if: - the information from the invoice and/or the guarantee are erased or altered;...
Page 43
Damage or faults caused by an external force. Damage or faults caused by liquids. Damage or faults caused by liquid or dry chemical substances (such as petrol, acids, corrosive materials) and dust, dirt or other foreign objects. Damage or faults caused by external heat or fire. (Damage by internal heat is covered if it did not occur for an external reason.) Superficial damage that happened for external reasons, including dents, shabbiness, scratches on the enclosure, discolouration, cracks, peeling of metal or plastic parts of...
problems and their solutions Symptoms Possible Causes Solutions The battery is flat Charge the battery Phone won’t turn on Poor contact Reinstall the battery Phone turns itself off Battery very low Charge the battery Deceasing of battery Replace the battery performance Poor standby time Weak network signal...
