Ordering Information
Distribution
Family
Lamp Type
BSL
8
8 = Wall Mount
T = T8
Specifications
Features
. Housing: die-formed 20ga. cold rolled steel
2. End Set: die-cast metal with baked powder coat finish
3. Lamping: one T8 lamp
4. Configuration: 4', 8' and 2' module lengths or continuous rows
5. Ballasts: electronic 20V or 277V
Finish
High-quality white powder coat with textured matte finish.
Custom colors available. Consult factory.
Mounting
Flexible mounting locations.
Electrical
All luminaires are factory pre-wired to module ends with quick-wire
connectors.
Joints & Intersections
Self-aligning joining system with hands-free pre-joining wire access.
Labels
UL, CSA standards.
Lighting Systems
Weight = 3.0 lb./ft
No. of Lamps
Housing
T
01
LN
01 = Light
LN = Perforated
Baselyte-BSL18
Light T8 Wall Mount Semi-Indirect
Module Length
Wiring
04 = 4'
1 = cct.
08 = 8'
3 = cct. w/EC/NL
12 = 2'
5 = cct. w/EM Battery
7 = cct. w/Dimming
8 = cct. w/cct.
Thru wire
Note: Please consult
wiring section of spec
sheets for more
wiring options.
Ordering Instructions
Individual Fixtures
. Determine the number of individual modules required
2. Order one end set per module
3. Order one non-power mount per module
4. Order one power mount per module
Continuous Rows*
. Determine run length
2. Order the appropriate number and length of modules for complete run
3. Order one end set for each run
4. Order one non-power mount for each module
5. Order one power mount per run
6. Order one joiner per module minus one (e.g. 3 modules requires 2 joiners)
*Note: Some runs may require additional power mounts. Please see the
'Run Configuration' table on the next page for more details.
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier
a Genlyte Company
63 Airport Road, Fall River, MA 02720 • (508) 679-83 • Fax (508) 674-470
We reserve the right to change details of design, materials and finish.
© 2005 Genlyte Group LLC • 0205 Rev.
Voltage
Ballast
C = Custom Color
1 = 20V
E = Standard
W = Standard
2 = 277V
<20% THD
F = Standard
<20% THD
w/fusing
G = <0% THD,
Instant Start
H = <0% THD,
Instant Start
w/fusing
J = <0% THD,
Program Start
K = <0% THD,
Program Start
w/fusing
Type:
www.lightolier.com
Finish
White
