Support for disks
-
MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,MP3,MP4
Karaoke support various functions
-
Function of presetting the song and helps to preset 20 songs.
-
The list of new songs.
-
Favorite songs.
-
Language is displayed in English.
-
Reserve the song and clear the reserved song
-
Adjust the key and tempo appropriate with each voice.
-
Increase/decrease the song's melody as desired.
-
Install greetings/lines on the screen in Vietnamese.
-
Score and applause as preference.
Qualitative picture, transparent and clear sound
-
Decoding technique MPEG1, MPEG2 and MPEG3, DIVX(Code3.11-5.0).
* Note: not support absolutely 100% for DIVX formats.
-
High quality sound with digital effect.
-
High quality video background (MPEG2).
Other special features:
-
Unique VOCAL/CHORUS technique with the lively effect of vocal/chorus
-
Play picture and audio data of all formats MP3,MP4,WMA,WAV...
USER'S MANUAL
AR-18 DELUXE
SPECIAL FEATURES
-
DVD disc can play up to 135', including 8 languages and 32 different
captions
- MPEG-2 helps compress picture with high quality sound; creates the great,
lively audio and picture as in the theaters.
Advertisement
Table of Contents
Related Manuals for Arirang AR-18 DELUXE
Summary of Contents for Arirang AR-18 DELUXE
-
Page 1: Special Features
USER’S MANUAL AR-18 DELUXE SPECIAL FEATURES Support for disks MIDI-DVD,DVD,DVD-R,SVCD,VCD,CD,CD-R,CD-RW,MP3,MP4 Karaoke support various functions Function of presetting the song and helps to preset 20 songs. The list of new songs. Favorite songs. Language is displayed in English. Reserve the song and clear the reserved song Adjust the key and tempo appropriate with each voice. -
Page 2: Name Of Each Part
NAME OF EACH PART Front panel 1. POWER key: Turn on/off power 2. MIC 1/MIC 2: Use to plug in Microphone 3. VOL MIC1/MIC2: increase/decrease the volume of MIC 4. ECHO VOL: increase/decrease the effect of echo 5. Displayed screen: display the disc state being played and other functions 6. - Page 3 1. Power-source cable: plug in AC 90/220V power source 2. OPTICAL: optical audio port-used to connect to optical audio input of digital amplifier. Only have effect on DVD, VCD…not have effect on MIDI Karaoke disc 3. COAXIAL: coaxial audio port-used to connect to coaxial audio input of digital amplifier. Only have effect on DVD, VCD…not have effect on MIDI Karaoke disc 4.
-
Page 4: Remote Control
REMOTE CONTROL 1. OPEN/CLOSE: use to load/eject the disc tray 2. REW/FRW: + MIDI: Fast forward/rewind 10 pages when searching for a song + DVD/VCD: fast browse pictures (x2/x4/x8/x16) 3. STOP: stop the program being played 4. PLAY/PAUSE: Play/Pause the program being played 5. - Page 5 6. MELODY/STEP: + MIDI: Turn on/off the melody of the song + DVD/VCD: step forward each frame 7. OK: confirm the previous operation 8. Move: use to move and select function in installation process or in searching for a song 9.
- Page 6 30. VOCAL/M/F: + MIDI: select Male/Female tone, turn on/off singer’s voice (must be supported by the song) + DVD/VCD: select audio output 31. RESERVE (PROG): input the code and press RESERVE (PROG) to reserve the song (maximum of 20 songs) 32.
-
Page 7: Use The Remote Control
USE THE REMOTE CONTROL 1. Install the battery: Check for installing in right polarity +/- 2. Battery life: + Battery life depends on more or less use + If the remote control does not work or work s in very close area with the device, the user should replace the battery + Use AAA battery 3. -
Page 8: Basic Connection
BASIC CONNECTION Connect to TV Video port (yellow) Component video cable Audio port (red and white) Scoring port connected to MIC OUT of Amplifier S-Video cable Connect to 5.1ch Amplifier Subwoofer Speaker - Connect to digital Amplifier Dolby Digital (Digital Theater Rear speaker (left) Rear speaker (right) - Page 9 * Play CD disc: The user will recognize CD disc through logo. * MIDI Karaoke disc: MIDI disc contains a great amount of songs including: Vietnamese, English, Chinese…MIDI Karaoke disc for model AR-18 Deluxe has chorus, vocal, lyric and function to adjust fast/slow tempo that is very convenient for new singer * Note: The device only reads MIDI disc released by MASECO Company.
- Page 10 3. To Previous/Next Track/Chapter: When title of DVD disk has a lot of Chapters or VCD disk has a lot of Tracks, move to other Chapters or Tracks by the following way: + Press to move to next Chapter/Track + Press to move to previous Chapter/Track + For VCD/CD disk, when in stop mode, select Track by number keys to play.
- Page 11 10. Key of function list (Menu DVD): only have effect if supported Menu function by disc + Press MENU key to select the function list + Press key to select item + Press “ENTER” or “PLAY” to select + Press “MENU” key to return to main Menu PLAY MIDI KARAOKE DISC 1.
- Page 12 7. New song: + List of new songs updated in new VOL of MIDI disc + Select song, press PLAY/ENTER to play, press RESERVE to store (approximately 20 songs) + Press STOP key to exit 8. Melody: + Press MELODY to increase/decrease the song melody + On screen displays a lot of MELODY modes: Strong/Mild/None/Standard to select 9.
- Page 13 Language Title/Singer List of songs SET KARAOKE FUNCTION - This function only has effect on MIDI Karaoke disc, press SETUP and input PASSWORD “0000” + Use key to select the function section + Press ENTER to establish the setting value + Press STOP to return to main menu and reserve the parameters changed - FANFARE: fanfare signal - MIN SCORE FOR DISPLAY SCORE: the lowest score when the song ends.
- Page 14 + NEXT: move to line 1 or line 2 to install + EXIT: exit * Note: reserve before exiting - For example: to install 2 lines with the text “MASECO ARIRANG”, press SETUP key-> Code: ”0000” -> Press Down key select GREETING MESSAGE-> Press OK.
-
Page 15: Installation
INSTALLATION - Press SETUP when the device has no disc inside or is playing (DVD/VCD/CD/MP3), use key press ENTER to select items in the installation - Press SETUP again or select EXIT to exit the installation 1. General setup: - PIC MODE: set picture mode + AUTO: set automatic mode + FILM: high scanning mode + VIDEO: set high resolution mode... - Page 16 - SCREEN SAVER: set the screen saver, only perform when the device is on STOP/PAUSE mode - MAIN PAGE: return to the main setting screen. 2. Speaker setup: - DOWNMIX: this function changes the audio mixing method at output to suitable for Amplifier or TV + LT/RT: select left/right 2-channel output + STEREO: select separate 2- channel output...
- Page 17 - SPDIF OUTPUT: select audio output suitable with Amplifier + OFF: use normal AV cable to connect with Amplifier Stereo + SPDIF/RAW: connect to digital Amplifier through Coaxial/Optical port + SPDIF/PCM: connect to Amplifier Stereo having support of Coaxial port + OP MODE: have two modes to select LINE OUT/RF REMOD - DUAL MONO: change mode of output audio + STEREO: separate 2- channel output...
- Page 18 - TV DISPLAY: select mode of screen display suitable with TV + NORMAL/PS: display in normal mode 4:3PS, lost picture when displaying in 16:9 mode + NORMAL/LB: display in normal mode 4:3LB but not lost picture when displaying in 16:9 mode + WIDE: only display in 16:9 mode - TV TYPE: set color system...
-
Page 19: Troubleshooting
TROUBLESHOOTING Technical problems Repair No source of supply Check the power-source cable Not read disc when press PLAY The device cannot read disks that are not in DVD, Press PLAY but then stop immediately VCD or CD format Dirty disc No picture Check the disk placed in the device with right surface... -
Page 20: Specifications
SPECIFICATIONS Voltage: 110 – 220VAC-50/60Hz Power Consumption: 23W Weight: 5.0Kg Compatible with: DVD Midi Karaoke/DVD/DVD-R/SVCD/ VCD/CD-R/ CD-RW/Mp3/WMA/Mp4 & Jpeg Video 1VP-P (750) 1VP-P (750) S-Video 0.286 VP-P (750) Output 1VP-P (750) Component 0.7 VP-P (750) 0.7 VP-P (750) Audio L/R,5.1CH 2Vrms(max) Input Microphone 1,2...
