For safety, please read this manual carefully.
ATTENTION: To reduce electric danger, do not open the device cover, and the user may not tamper with its inside.
Consult a professional about repair.
CAUTION
A lightning with arrow head in a triangle to warn the user that there is "a dangerous high-
voltage current" inside the product. The current is so strong enough to cause electric shock.
An exclamation mark in a triangle to warn the user that there are important instructions for use
or maintaining of the peripherals.
1. Please read this manual thoroughly before using.
2.
Keep this manual for consulting, when necessary.
3. To reduce the risk of fire or electric shock, keep the device away from rain or humidity.
4. To avoid electric shock, do not use the jack with bare or open wires, unless otherwise they are
completely coated.
5.
Do not plug the power-source cable in with a wet hand.
6.
Keep away from water, humid and very hot places.
7.
Care should be taken to prevent the power-source cable from being trodden or stepped on.
8.
Carefully prevent water or foreign matters from dropping into the device.
9. Clean with soft towel without using any highly corrosive chemicals.
10. Turn off the power source when the device is not in use; unplug the device when it is not used
for a long time.
11. Use the power source under the instructions herein or found on the device.
SAFETY MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR-909HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Arirang AR-909HD

  • Page 1 SAFETY MANUAL For safety, please read this manual carefully. ATTENTION: To reduce electric danger, do not open the device cover, and the user may not tamper with its inside. Consult a professional about repair. CAUTION A lightning with arrow head in a triangle to warn the user that there is “a dangerous high- voltage current”...
  • Page 2 1. Start 1.1 Accessories Remote control Song Book User’s manual 2 AA batteries AV cable HDMI cable Angel to receive signals from the remote control:...
  • Page 3: Front Panel

    1.2 Overview FRONT PANEL 1. Power 10. Fast forward 2. Micro 1,2 port 11. Memory card slot 3. Adjust Micro volume 12. USB port 4. Infrared eye 13. Make the list of songs/Store a song 5. Number keys 14. Choose TV color system NTSC/PAL 6.
  • Page 4 1. USB port to computer 7. Component video signal port 2. Coaxial digital audio-port 8. Karaoke scoring port 3. Optical digital audio-port 9. Surround 5.1 audio-port 4. HDMI port 10. Internet port 5. USB port to peripherals 11. Hard disk drive tray 6.
  • Page 5: Connection Diagram

    * Connection with computer: use standard cable Mini-USB Connect to cable, press power to start. Use the devices to connect computer with hard disk drive of AR-909HD as the normal USB devices on computer. 2. Install and use 2.1 Install...
  • Page 6 Function Illustration Description Explanation Color system: Select TV color system Video signal output: Select video signal output YCbCr/HDMI Resolution: Select TV resolution through Component and HDMI port Proportion: Screen proportion HDMI color setting: Select color system through HDMI Picture Set pictures port Depth of HDMI color: Select the depth of color through...
  • Page 7 Displayed language: Set the displayed language Disk voice-over: Select VO language in DVD play Disk caption: Select Language languages secondary language in DVD play Disk menu: Select main menu language in DVD play SPDIF: Select the audio signal through Optical/Coaxial port HDMI: Select the audio signal through HDMI port Sampling frequency: Select...
  • Page 8 Default code 9999 Code: Change the code Level: Select the limited Select the level of DVD disk Children function of lock locking DVD disk Replay: Turn on/off replay function of stored song at previous time Screen fit: Select frame size Background picture: Change interface background Set system...
  • Page 9 2. Adjust the song volume and tone: - VOLUME +/- key: Increase/decrease the volume - MELODY +/- key: Increase/decrease the song melody Melody Male/female 3. Adjust key, tempo, male/female tone: volume tone - KEY +/- key: Increase/decrease the song key - TEMPO +/- key: Adjust fast/slow tempo for the song - MALE/FEMALE key: Select male/female tone 4.
  • Page 10 For example, to search for the song “Khát vọng”  select K character  Press Page DN key to select the next page, select the song in the left column 2.4 Play movie formats: Support for formats MPEG1/2,AVI,DAT,VOB,WMV,MKV,MP4,M2TS,M2T,TS,FLV…...
  • Page 11 Press OSD key to turn on/off the control panel. key to select, to change Title Track order and number key to input the desired duration, press ENTER to confirm Select sound channel Select caption Select the view angle (Disk must have support) 2.5 Play audio formats: Support for formats: MP3,WMA,WAV,AAC,FLAC…...
  • Page 12 2.6 Play picture formats: Support for formats: BMP,JPG,PNG,GIF,TIF...
  • Page 13 RETURN key MELODY + key MALE key Return to previous page On/off background music Rotate picture MELODY - key FEMALE key On/off showing picture On/off the transition effect 2.7 Play text formats: Helps see the contents of text file Support for format: TXT 2.8 Game Games are pre-installed in the device, use the remote control of the device to contro...
  • Page 14: Specifications

    SPECIFICATIONS Voltage AC 90-240V – 50/60Hz Power Consumption 22W Dimension 430(D) x 315(R) x 90(C) mm Weight 2.9 Kg Compatible with VCD/SVCD/DVD/Audio CD/MP3 Video MPEG1/2,AVI,DAT,VOB,WMV,MKV,MP4,M2TS,M2T,TS,FLV Audio MP3,WMA,WAV,AAC,FLAC Photo BMP,JPG,PNG,GIF,TIF Video output HDMI 1.3,Composite,Component Audio output 5.1Ch,Optical,Coaxial Input Score in,USB 2.0 Host,Slave USB,SD card Reader SATA 01 internal SATA interface Subtitle format...
