Support for disks
-
MIDI-DVD,DVD, DVD-R, SVCD, VCD, CD, CD-R, CD-RW, MP3,MP4.
Karaoke support various functions
-
Function of presetting the song and helps to preset 99 songs.
-
The list of new songs.
-
Favorite songs.
-
Language is displayed in Vietnamese and English.
-
Reserve the song and clear the reserved song.
-
Adjust the song's key and tempo appropriate with each voice.
-
Increase/decrease the song's melody as desired.
-
Install greetings/lines on the screen in Vietnamese.
-
Score and applause as preference
Qualitative picture, transparent and clear sound
-
Decoding technique MPEG1, MPEG2 and MPEG3, DIVX(Code3.11-5.0).
*
Note: not support absolutely 100% for DIVX formats.
-
High quality sound with digital effect.
-
High quality video background (MPEG2).
Other special features:
- Unique VOCAL/CHORUS technique with the lively effect of vocal/chorus
- USB interface: play picture and audio data of all formats MP3,MP4,WMA,WAV...
captions
USER'S MANUAL
AR-36L
SPECIAL FEATURES
-
DVD disc can play up to 135', including 8 languages and 32 different
- MPEG-2 helps compress picture with high quality sound; creates the great, lively
audio and picture as in the theaters.
Advertisement
Table of Contents
Related Manuals for Arirang AR-36L
Summary of Contents for Arirang AR-36L
- Page 1 USER’S MANUAL AR-36L SPECIAL FEATURES Support for disks MIDI-DVD,DVD, DVD-R, SVCD, VCD, CD, CD-R, CD-RW, MP3,MP4. Karaoke support various functions Function of presetting the song and helps to preset 99 songs. The list of new songs. Favorite songs. Language is displayed in Vietnamese and English.
-
Page 2: Name Of Each Part
NAME OF EACH PART Front panel: USB port Key volume Micro port Keys of numbers Reserve the song Keys Displayed Power to control screen Micro volume Display screen: Rear panel: 5.1 channel audio port... -
Page 3: Basic Connection
* Accessories: 01 Midi Karaoke disc 01 User’s manual 01 Vietnamese song book 01 Remote control 01 Pair of AAA batteries 01 Set of AV cable (03 wires) BASIC CONNECTION Subwoofer Speaker Rear speaker (right) Rear speaker (left) 5.1 channel Amplifier Front speaker (left) Front speaker (right) Center speaker... -
Page 4: Remote Control
REMOTE CONTROL 1. iFUN: turn on/off the cheer scoring 2. SETUP: set the device’s configuration 3. MUTE: turn on/off the volume of device 4. ANGLE/ADD SONG: + MIDI: add song to the list of favorite songs + DVD: select view angle (supported by disk) 5. - Page 5 + MIDI: set Karaoke feature +DVD/VCD: enter to main MENU, on/off PBC (VCD2.0) 9. MALE: select male tone when the song being played (MIDI) 10. STEP/RESTART: + MIDI: replay the song being played + DVD/VCD: slowly play each picture 11. SLOW/SELECTED SONG: + MIDI: List of reserved songs + DVD: Slowly play pictures (x2/x4/x8/x16/x32) 12.
-
Page 6: Configuration Setting
CONFIGURATION SETTING * Press SETUP key on the remote control to start setting: 1. Language installation: Language: set language for the device Caption: caption language (supported by DVD disk) Voice-over: voice-over language (supported by DVD disk) Disc language: default language in disc play (supported by DVD disk) 2. - Page 7 + Automatic + NTSC + PAL Angle: Turn on/off the effect of view angle (supported by DVD disk) 3. Audio installation: Digital output: digital audio output + Off + BTS: Stereo output + LPCM: Coaxial output Downmix: + LT/RT (supported Dolby Prologic by amplifier) + Stereo + 5.1 Channel Dual mono:...
- Page 8 4. Karaoke installation: Micro setting: + Off + Automatically Micro volume: increase/decrease micro volume Echo: increase/decrease the effect of echo Key: increase/decrease the key Scoring: select the way to score + Off + Normal + Automatically Scale: + Non professional + Normal + Professional 5.
- Page 9 EQ: Adjust the timbre, support for 5 timbres Effect: default setting in 8 sound effects Configure Surround Delay: the delay of rear speaker 0ms-25ms Center Delay: the delay of center speaker 0ms-5ms 6. Children lock: Change: Set the code to lock children from seeing the movie that is not suitable for their ages (supported by DVD disk) Limit: Set limit to lock children + Kid safe: Highest...
- Page 10 Melody: on/off the song melody Cheer scoring (iFUN): on/off Background picture: DVD/blue Set the favorite song: the number of favorite songs is stored Drive lock: lock the drive in MIDI use Coin Function: on/off the mode of coin use DVD/VCD/CD PLAY 1.
-
Page 11: Basic Operation
7. Slowly play (DVD/VCD): + Press “SLOW” key to slowly play + Press “PLAY” key to return to normal play mode 8. Zoom in picture (DVD/VCD): can zoom in picture up to 3 times. Depending on the play mode, “ZOOM” key has different effects. Press up/down/left/right key to move + In the mode of normal play, “ZOOM”... - Page 12 3. Adjust the key: + Can change low/high key of the song when pressing KEY +/- 4. Adjust the tempo: + Can change fast/slow tempo of the song when pressing TEMPO +/- 5. Select Male/female tone: press Male/Female key to select male/female tone 6.
-
Page 13: Usb Connection
- Select the song fast without “Song Book”, press SEARCH key to display the song list including many different languages Vietnamese, Chinese, English. To select the song of a country, press LANGUAGE (AUDIO) key to move to the song list of that country. + For searching the song as per the first characters (abc) of its title, press number keys on the remote control corresponding to the alphabet to start searching + For example, to search for the song with the first character of its title is K ... - Page 14 * Plug USB in USB port supported in front side of the device. The device automatically identifies the internal data, use up/down/left/right key to select the data format, press ENTER to play - Audio: Audio (*.mp3/*.wma) - Image: Picture (*.jpg) - Video: Movie (*.dat/*.avi) * Note: The device only identifies the USB when it has no disk inside SETTING IN MIDI KARAOKE DISC...
-
Page 15: Troubleshooting
TROUBLESHOOTING TECHNICAL PROBLEMS SPECIFIC REPAIR Not eject the disk tray - The power-source cable not plug in Plug the power-source cable in The device not playing - Not have disc in drive - Put disc in drive - Disc placed in opposite side - Select the correct disc side - Disc is too dirty or scratched - Clean disc or change disc... -
Page 16: Specifications
SPECIFICATIONS Voltage: 90 – 240VAC 50/60Hz Power Consumption: 17W Weight: 3.5Kg Compatible with: DVD Midi Karaoke/DVD/DVD-R/SVCD/ VCD/CD-R/ CD-RW/Mp3/WMA/Mp4 & Jpeg Video 1VP-P (750) 1VP-P (750) S-Video 0.286 VP-P (750) Output 1VP-P (750) Component 0.7 VP-P (750) 0.7 VP-P (750) Audio L/R,5.1CH 2Vrms(max) Input Microphone 1,2...
