Summary of Contents for BenQ XL2410T
- Page 1 LCD Monitor User Manual XL2410T Welcome Downloaded from ManualMonitor.com Manuals...
-
Page 2: Copyright
Copyright Copyright © 2010 by BenQ Corporation. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of BenQ Corporation. -
Page 3: Table Of Contents
How to detach the stand base .......................13 Using the monitor wall mounting kit ..................14 Getting the most from your BenQ monitor ..............15 How to install the monitor on a new computer ................16 How to upgrade the monitor on an existing computer ..............17 How to install on Windows 7 system ...................18... -
Page 4: Getting Started
1. Getting started When unpacking please check you have the following items. If any are missing or damaged, please contact the place of purchase for a replacement. BenQ LCD Monitor Monitor Base Quick Start Guide Manual CD NVIDIA Driver CD... - Page 5 Video Cable: D-Sub Video Cable: DVI-D Dual Link Video Cable: HDMI (Optional accessory for models with HDMI inputs, sold separately) Mouse (Optional) Mouse pad (Optional) Consider keeping the box and packaging in storage for use in the future when you may need to transport the monitor.
-
Page 6: Getting To Know Your Monitor
2. Getting to know your monitor Front view 1. Control buttons 2. Power button Back view 3. AC Power Input jack 4. Height release 5. Cable clip 6. DVI-D socket 7. D-Sub socket 8. HDMI socket 9. Lock switch 10.Headphone jack •... -
Page 7: How To Assemble Your Monitor Hardware
3. How to assemble your monitor hardware If the computer is turned on you must turn it off before continuing. Do not plug-in or turn-on the power to the monitor until instructed to do so. 1. Attach the monitor base. Please be careful to prevent damage to the monitor. - Page 8 You might want to adjust the monitor stand height. See Adjusting the monitor stand height on page 11 more information. You should position the monitor and angle the screen to minimize unwanted reflections from other light sources. 2. Connect the PC video cable Either Do not use both DVI-D cable and D-Sub cable on the same PC.
- Page 9 To Connect the DVI-D Dual Link Cable Connect the plug of the DVI-D Dual Link cable to the monitor video socket. Connect the other end of the cable to the computer video socket. Tighten all finger screws to prevent the plugs from accidently falling out during use.
- Page 10 Turn on the computer too, and follow the instructions in Section 4: Getting the most from your BenQ monitor on page 15 to install the monitor software. To extend the service life of the product, we recommend that you use your computer's power management function.
-
Page 11: Adjusting The Monitor Stand Height
Adjusting the monitor stand height If you prefer to lower the monitor stand height, pull the monitor downward while holding both left and right sides of the monitor. Avoid placing hands near the bottom of the monitor stand as the descending stand might cause personal injuries. -
Page 12: Rotating The Monitor
Rotating the monitor 1. Pivot the display. Before rotating the monitor with a portrait viewing orientation, the display has to be rotated 90 degrees. Go to Start and Control Panel on your computer, select the properties or controller of the graphics processing units (GPU) on your computer. -
Page 13: Viewing Angle Adjustment
Viewing angle adjustment You may position the screen to the desired angle with -5° to +20° monitor tilt, 90° (left and right total) monitor swivel, and 130 mm monitor height. 130 mm How to detach the stand base 1. Prepare the monitor and area. Turn off the monitor and the power before unplugging the power cable. -
Page 14: Using The Monitor Wall Mounting Kit
Using the monitor wall mounting kit The back of your LCD monitor has a VESA standard mount with 100mm pattern, allowing the installation of a wall mount bracket. Before starting to install a monitor wall mounting kit, please read the precautions carefully. Precautions: •... -
Page 15: Getting The Most From Your Benq Monitor
4. Getting the most from your BenQ monitor To gain the most benefit from your new BenQ color LCD flat screen monitor, you should install the custom BenQ LCD Monitor driver software as provided on the BenQ LCD Monitor CD-ROM. -
Page 16: How To Install The Monitor On A New Computer
BenQ LCD Monitor is the first ever monitor to be connected to it. If you are adding the BenQ LCD Monitor to an existing computer that has already had another monitor connected to it (and has monitor driver software installed), you should not be following these instructions. -
Page 17: How To Upgrade The Monitor On An Existing Computer
The BenQ LCD Monitor driver for your model may well function perfectly with other versions of Windows, however, as at the time of writing, BenQ has done no testing of this driver on other versions of Windows and cannot guarantee its operation on those systems. -
Page 18: How To Install On Windows 7 System
4. Click the tab and the button. Driver Update Driver 5. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer. 6. In the window, select the option Update Driver Software Browse my computer for driver software 7. -
Page 19: How To Install On Windows Vista Systems
5. Click the tab and the button. Driver Update Driver 6. Insert the BenQ LCD Monitor CD-ROM into a CD drive on the computer. 7. In the window, select the option Update Driver Software Browse my computer for driver software 8. -
Page 20: How To Install On Windows Xp System
The Monitor Properties window will display. If the driver provider is listed as BenQ, and the model matches that of your new monitor, the proper drivers are already installed, and you need do nothing further. Cancel out of these property windows. -
Page 21: How To Watch 3D Content On Your Monitor
• Watching 3D content for a long period of time may increase health risks. For small children, the elderly, the pregnant women or people who have high blood pressure or other health concerns, consult a doctor before watching 3D content. Getting the most from your BenQ monitor Downloaded from ManualMonitor.com Manuals... -
Page 22: Picture Optimization
If you wish, you can always adjust the screen geometric settings manually using geometry menu items. To assist you in this endeavour, BenQ has provided a screen test image utility which you can use to check for screen color, grayscale and line gradient display. -
Page 23: How To Adjust Your Monitor
6. How to adjust your monitor The control panel 1 2 3 4 : Adjusts vertical position, phase, horizontal position and pixel clock automatically. AUTO key: Activates OSD main menu and return to the previous menu or exit OSD. MENU key: For Up/Increase adjustment. -
Page 24: Hot Key Mode
Hot key mode The monitor keys perform as hot keys to provide direct access to particular functions whenever the menu isn't currently displaying on-screen. Smart Scaling hot key Press the key to display the Smart Scaling indicator. Further press the will increase the display size, while the key will decrease the display size. -
Page 25: Main Menu Mode
Main menu mode You can use the OSD (On Screen Display) menu to adjust all the settings on your monitor. Available menu options may vary depending on the input sources, functions and settings. Press the key to display the following main OSD menu. MENU There are 5 main OSD menus: 1. -
Page 26: Display Menu
Display menu Available menu options may vary depending on the input sources, functions and settings. 1. Press the key to display the main MENU menu. 2. Press the keys to select DISPLAY Mode: Standard and then press the DISPLAY ENTER Auto Adjustment to enter the menu. - Page 27 H. Position Adjusts the horizontal 0 to 100 Press the keys to position of the screen image. adjust the value. V. Position Adjusts the vertical position 0 to 100 of the screen image. Pixel Clock Adjusts the pixel clock 0 to 100 frequency timing to synchronize with the analog input video signal.
-
Page 28: Picture Menu
Picture menu Available menu options may vary depending on the input sources, functions and settings. 1. Press the key to display the main MENU menu. 2. Press the keys to select PICTURE Mode: Standard and then press the PICTURE ENTER Brightness to enter the menu. - Page 29 - Press to enter the Color menu Color ENTER Color Temperature Normal: Allows video and Press the keys to still photographs to be select this option. viewed with natural coloring. This is the factory default color. Bluish: Applies a cool tint to the image and is factory pre-set to the PC industry standard white color.
-
Page 30: Picture Advanced Menu
Picture Advanced menu Available menu options may vary depending on the input sources, functions and settings. 1. Press the key to display the main MENU menu. 2. Press the keys to select PICTURE ADVANCED Mode:Standard and then press the PICTURE ADVANCED Picture Mode Standard ENTER key to enter the menu. - Page 31 Item Function Operation Range Picture Mode • Standard Selects a picture mode that Press the keys to best suits the type of images change the settings. • FPS shown on the screen. • User Game-1 • Standard - for basic PC •...
- Page 32 Display Mode This feature is provided to • Overscan Press the keys to allow aspect ratios other change the settings. • Full than 16:9 to be displayed • Aspect without geometric distortion. • 1:1 The options under • Overscan - Slightly •...
- Page 33 Smart Scaling Resizes the display. 0 to 100 Press the keys to (available when You can press the Smart change the settings. the Display Scaling hot key to resize the Mode is set to display by a digit number. 17", 19"W, or Alternatively, press and hold 1:1) the Smart Scaling hot key to...
- Page 34 Color Format Determines the color space Press the key to • RGB ENTER (RGB or YUV) based on the select this option. Press the • YUV following detected video keys to change signal: the settings. • D-Sub (VGA) from PC: The default Color Format is RGB.
-
Page 35: Audio Menu
Audio menu Available menu options may vary depending on the input sources, functions and settings. 1. Press the key to display the main MENU menu. 2. Press the keys to select AUDIO AUDIO Mode: Standard and then press the key to enter ENTER Volume the menu. -
Page 36: System Menu
System menu Available menu options may vary depending on the input sources, functions and settings. 1. Press the key to display the main MENU menu. 2. Press the keys to select SYSTEM Mode: Standard and then press the SYSTEM ENTER Input to enter the menu. - Page 37 - Press to enter the menu. OSD Settings ENTER OSD Settings Language Sets the OSD menu • English Press the keys to language. change the settings. • French • German • Italian • Spanish • Polish The language options • Japanese displayed on your OSD •...
- Page 38 OSD Lock Prevents all the monitor • YES Press the keys to settings from being change the settings. • NO accidentally changed. When this function is activated, the OSD controls and To unlock the OSD controls hotkey operations will be when the OSD is preset to be locked, press and hold disabled.
-
Page 39: Troubleshooting
7. Troubleshooting Frequently asked questions (FAQ) The image is blurred: Read the instructions on the link "Adjusting the Screen Resolution" on the CD, and then select the correct resolution, refresh rate and make adjustments based on these instructions. How do you use a VGA extension cable? Remove the extension cable for the test. -
Page 40: Need More Help
• Increase the volume (volume may be muted or too low) on the external speakers. Need more help? If your problems remain after checking this manual, please contact your place of purchase or e-mail us at: Support@BenQ.com. Troubleshooting Downloaded from ManualMonitor.com Manuals...
