Owner/Operator Manual
932037 - 724
932038 - 5520
932039 - 624
932505 - 724
932507 - 520
932508 - 624
Coller l'autocollant du
model &
modèle et du numéro de
serial number
série dans cet encadré.
label from
Transferir aquí la etiqueta
del modelo y número de
serie del registro del
U.S. Patents Pending
00295500A 7/04
Supersedes 00295500
Printed in USA


   Related Manuals for Ariens SNO-THRO 932037 - 724

   Summary of Contents for Ariens SNO-THRO 932037 - 724

  • Page 1

    Sno-Thro Owner/Operator Manual Models 932037 - 724 932038 - 5520 932039 - 624 932505 - 724 932507 - 520 932508 - 624 Transfer Coller l’autocollant du model & modèle et du numéro de serial number série dans cet encadré. label from Transferir aquí...

  • Page 2

    Facsimile PRODUCENTA – (920) 756-2407 We the undersigned, ARIENS COMPANY, certify that: Nous, soussignés ARIENS COMPANY, certifions que : Der Unterzeichnete, ARIENS COMPANY, bescheinigt, dass: La sottoscritta società ARIENS COMPANY certifica che: Nosotros, los abajo firmantes, ARIENS COMPANY, certificamos que: Undertegnede, ARIENS COMPANY, bekrefter at: Undertecknad, ARIENS COMPANY, intygar att: Allekirjoittanut, ARIENS COMPANY, vakuuttaa, että: My, niźej podpisani, ARIENS COMPANY,...

  • Page 3

    – Vibrasjonsmåling ved brukerens hender – Vibrationsmätning vid förarens händer – Tärinä kuljettajan käsissä – Pomiar wibracji (m/sec ) na rękach operatora Ariens Company Brillion, WI 54110-0157 USA Signature Signature Unterschrift Firma Firma Signatur Namnteckning Allekirjoitus Podpis...

  • Page 4: Table Of Contents

    INTRODUCTION • Record Engine Model and Serial number here. PRODUCT REGISTRATION The Ariens dealer must register the product at the time of purchase. Registering the product will help the company process warranty claims or contact you with the latest service information.

  • Page 5: Safety

    4. Review recommended lubrication, maintenance and adjustments. 5. Review Limited Warranty Policy. 6. Fill out a Product Registration Card and return the card to the Ariens Company or go to SAFETY WARNING: POTENTIALLY HAZARDOUS SITUATION! If not avoided, COULD RESULT in death or serious injury.

  • Page 6: Required Operator Training, Safety Decals And Locations

    REQUIRED OPERATOR TRAINING Original purchaser of this unit was instructed by the seller on safe and proper operation. If unit is to be used by someone other than original purchaser; loaned, rented or sold, ALWAYS provide this manual and any needed safety training before operation.

  • Page 7: Safety Rules

    2. DANGER! ROTATING PARTS! ONLY use clean-out tool to clear blockages. NEVER use your hands. High speed impeller rotates below discharge opening. Wait for all moving parts to stop before OS6610 removing clogs or servicing. 3. DANGER! ROTATING PARTS. Keep clear of auger while engine is running.

  • Page 8

    Never direct discharge towards persons or property that may be injured or damaged by thrown objects. Use extreme caution on gravel surfaces. Stay alert for hidden hazards or traffic. Adjust Runners so Scraper Blade does not contact gravel. DO NOT throw snow any higher than necessary.

  • Page 9: Assembly

    This product is equipped with an internal combustion type engine. DO NOT use unit on or near any unimproved, forest-covered or brush covered land unless exhaust system is equipped with a spark arrester meeting applicable local, state or federal laws. A spark arrester, if it is used, must be maintained in effective working order by operator.

  • Page 10

    1. Wing Knob 3. Lower Handlebar 2. J-Bolt 4. Upper Handlebar Figure 4 Install Discharge Chute and Chute Crank (932037, 039, 505, 507, 508) (Figure 5, 6, and 7) NOTE: See Figure 5 for the items to install on the unit. 1.

  • Page 11

    Figure 7 Discharge Chute (932038) 1. Grease discharge chute ring if not already greased (Figure 8). 2. Remove mounting hardware from top of engine. 3. Install discharge chute by positioning the chute ring under retainer clip on chute seat. 4. Secure chute support bracket to studs on top of engine with mounting hardware removed in step 2.

  • Page 12: Controls And Features, Snow Blower Overview

    CONTROLS AND FEATURES Figure 9 1. Traction Drive Clutch Bail 2. Speed Selector 3. Chute Crank (932037, 039, 505, 507, 508) 4. Muffler Guard (932037, 039, 505, 507, 508) 5. Discharge Chute Deflector 6. Discharge Chute 7. Impeller 8. Auger 9.

  • Page 13: Operation

    WARNING: AVOID INJURY. Read and understand the entire Safety section before proceeding. WARNING: To avoid injury to hands and feet, always disengage clutches, shut off engine, and wait for all movement to stop before unclogging or working on snow thrower. Keep hands and feet away from auger and impeller.

  • Page 14

    1. Choke Closed position: chokes off air to engine for easier start. 2. Choke Open position: allows for normal operation. IMPORTANT: Gradually open choke after engine starts. OS1300 Throttle The throttle controls the engine speed. To increase or decrease the engine speed, adjust to: 1.

  • Page 15: Filling Fuel Tank, Pre-start

    Axle Lock Pin (Figure 10) Wheel Unlocked Wheel Locked Figure 10 Use the axle lock pin to lock or unlock the right wheel. Lock the right wheel to increase traction; unlock the right wheel to allow for easier turning of the unit. Scraper Blade The scraper blade allows the back of the housing to keep better contact with the surface...

  • Page 16: Starting And Shut Off

    4. Adjust Runners Check and adjust Runners (see Service and Adjustments). Allow 1/8 in. (3 mm) between scraper blade and hard, smooth surface(s). Allow 1-1/4 in. (30 mm) between scraper blade and uneven or gravel surfaces. 5. Check Engine Fuel & Crankcase Oil WARNING: AVOID INJURY.

  • Page 17: Maintenance, Snow Removal

    Tips for Operation Snow is best removed as soon as possible after snow fall. Ariens Dealers will provide any service or adjustments which may be required to keep your unit operating at peak efficiency. Should engine service be required, contact an Ariens dealer or an authorized engine manufacturer's service center.

  • Page 18: Maintenance Schedule, Check Tire Pressure

    1. Remove filler plug (Figure 11). Lubricant • • 2. Add lubricant if required. Allow oil to drain IMPORTANT: Use only Ariens special gear lubricant L-2 (Part Number 00008000). GB - 18 must be at least up to bottom of lubricant filler hole with unit resting on a level- surface.

  • Page 19: Service And Adjustments

    GENERAL LUBRICATION IMPORTANT: Wipe each fitting clean before and after lubrication. IMPORTANT: DO NOT allow grease or oil to get on friction disc, friction plate or belts. NOTE: Apply Stens Mix Hi-Temp Grease or equivalent to the lubrication fittings. See Service Parts.

  • Page 20: Scraper Blade, Shear Bolts, Speed Selector Adjustment

    3. Reposition scraper blade flush with runners and tighten lock nuts. SHEAR BOLTS IMPORTANT: Use only Ariens shear bolts for replacement. Use of any other type of shear bolt may result in severe damage to unit. Occasionally a foreign object may enter the...

  • Page 21: Attachment Drive Belt Replacement

    2. Pull shift rod and adjustment pivot pin out of speed selector lever. 3. Place the speed selector lever in the fastest forward speed position. 4. Pull the shift rod straight down towards the ground as far as it will go. 5.

  • Page 22: Replace Attachment Drive Belt

    1. Housing Bolt 5. Chute Crank Holes 6. Chute Strap 2. Belt Cover 7. Chute Strap 3. Pinion and Gear Mounting Hardware 4. Spring Clip Pin 8. Bottom Cover Figure 18 Replace Attachment Drive Belt 1. Place new belt onto lower pulley and while holding brake out of way, tip unit together.

  • Page 23: Traction Drive Belt Replacement

    TRACTION DRIVE BELT REPLACEMENT NOTE: Housing and frame must be tipped apart and attachment drive belt removed from engine sheave in order to change traction drive belt (Figures 18 and 19). CAUTION: Always support Sno- Thro frame and blower housing when loosening the cap screws holding them together.

  • Page 24: Traction Drive Clutch Adjustment

    c. To decrease the distance between the clutch bail and handlebar, move the idler away from the attachment belt. d. Tighten idler adjustment nut. e. Check clutch bail measurement. 6. Check Brake When the clutch bail is disengaged, the brake must contact the attachment belt. When the clutch bail is engaged, the brake must be more than 1/16 in.

  • Page 25

    1. Traction Clutch 6. Speed Selector Cable 2. Shift Rod 7. Cotter Pin and Clevis 3. Attachment Control Cable 8. Traction Drive Clutch Arm 4. Mounting Nuts 9. Adjustment 5. Attachment Barrel Clutch Arm Figure 23 FRICTION DISC REPLACEMENT OS6780 1.

  • Page 26: Storage

    9. Reinstall one nut to keep the inside bearing cap in place. 10. Remove bearing cap/bushing and washer from right side of unit. 11. Reinstall nuts on screws through side frame to keep screws in place. 12. Slide friction disc assembly and hex shaft to the right until the left end of shaft is clear of left bearing.

  • Page 27: Troubleshooting, Service Parts, Accessories

    3. Mechanical jam in blower 4. Polluted fuel supply. 5. Faulty spark plug. Engine 1. See Engine Manual. problems. See your authorized Ariens dealer to add the additional accessories available to your Sno-Thro. Part No. 73203100 Slicer Bar* 72200600 120 Volt Starter Kit...

  • Page 28

    PROBLEM PROBABLE CAUSE Does not 1. Friction disc not adjusted properly. operate in 2. Traction belt not Forward/ functioning. Reverse. Small rubber 1. Friction disc wear. beads collect in frame. Unit throws 1. Shear bolts broken. snow poorly 2. Auger is frozen in place. or does not throw snow.

  • Page 29: Specifications

    Model Number 932037 Description Engine - Tecumseh OH195SA LH195SP Power Max - HP (Kw/ 7.0 (5.22) Fast Idle Speed- RPM (min Displacement - in. (cc) Electric Start Fuel Tank Capacity - qt. 3.5 (3.3) Snow Clearing Width - in. (cm) 24 (61.0) Chute Rotation Angle...

  • Page 30

    GB - 30...

  • Page 31

    Ariens Company 655 West Ryan Street P.O. Box 157 Brillion, WI 54110-0157 920-756-2141 Fax 920-756-2407
