- Page 1 TM-1010 PROGRESSIVE SCANNING HIGH RESOLUTION CAMERA (REV. 2) OPERATIONS & MAINTENANCE MANUAL JUN 1996 Covered by U.S. Pat. # 6259478 B1...
- Page 2 1.1 Features and Applications Frame memory and Digital output The TM-1010 is a state-of-the-art CCD camera which The TM-1010 has a built-in frame grabber and a frame uses a 1 inch 1K x 1K progressive scan interline memory. transfer CCD imager.
-
Page 3: Specifications
2. SPECIFICATIONS Imager Imager 1" Progressive scan interline transfer CCD Total pixels 1024 (H) x 1024 (V) Photosensitive pixels 1008 (H) x 1018 (V) 6 + 10 ob(H), 4 + 2 ob (V) Photosensitive area 9.1 (H) x 9.2 (V) mm Pixel size 9.0 (H) x 9.0 (V) µm Output sensitivity... - Page 4 TM-1010 1K X 1K HIGH RESOLUTION ASYNCHRONOUS RESET FULL FRAME SHUTTER CAMERA The TM-1010 is designed to accommodate a high resolution, ON-LINE inspection reset mechanism with full frame shutter. It takes external horizontal sync to lock the camera and VINIT pulse for resetting the camera asynchronously.
- Page 5 The shutter speed is the same as the external pulse width but the integration delays 9H from the leading edge. For immediate reset option, please contact PULNiX. One frame of video output will start from the rising edge of the pulse width control for progressive format.
- Page 6 Gamma Set to 1.0 (OFF) Down load Open w5 - W8 for chassis GND TM-1010 SIGNAL BOARD TOP Middle boards Layout and Adjustment Preset Set pedestal at 50 mV of video (analog) D/A reference TBD (Vin = V out) Jumpers...
- Page 7 Set at mechanical center Ext. sync input impedance Jumpers W5 and W6 (back side) select for 75 Ω TM-1010 POWER BOARD TOP termination. When it is open (factory set), it is 4.7 KΩ (high impedance). 5. Digital output connector An EIA-422 digital output is available from 31-pin high-rel, micro-miniature connector (Airborn MP221-031-243- 2200).
- Page 8 For the monitor information connect BNC output to multiscan or equivalent video equipment. Since the frame rate is 15 Hz, it is not easy to see the detail on a monitor. The analog output of TM-1010 is more likely to be monitored by oscilloscope for the waveform analysis. Analog signal monitoring is not using the full advantage of 10-bit signal processing.
- Page 9 Asynchronous reset mode (Select switch of the back panel for ASY...async) The TM-1010 outputs the progressive scanned When External VINIT is high ( 5V), the TM-1010 image with an electronic shutter in two different expects the async pulse input. It resets at the negative...
- Page 10 6 dB final image. This freeze mode is also used for 3 - down 9 dB integration control. At freeze mode, TM-1010 can be 4 - up 12 dB used to integrate (log exposure) by controlling INTEG 4 - down 16 dB control input on 12-pin connector (pin #11).
- Page 11 10. Digital output pulses Digital Video Differential line-driven, 10-bit parallel signal with EIA-422 format. 100Ω output termination impedance. Output from 31-pin connector. The mating connector: Airborne MP211-031-113-4300 Please consult digital cable information. eg. 50-1301, 30DG-02-10 (10-bit), 2m cable Line Data Valid (preliminary) Differential line-driven signal with EIA-422 format.
- Page 12 11. Connector and cable Digital output connector is optional. Mating connector ordering information: PULNiX part No. 15-1623 Airborn P/N: MP211-031-113-3400 Straight Backshell (cover): 15-1624 MM254-031-000-0000 Cable assembly: Digital cable 30DG-02-10 50-1301-05 12-pin connector and cable: Standard cable is 12P-02 (2m, 8 conductor cable) for power and external controls.
- Page 13 13. DIGITAL CABLE ASSEMBLY 30DG-02-10 (10-bit cable) P/N 50-1301-10 for TM-1010 Full function cable TM-1010 PIN CONFIGURATIONS Pin Signal Cable Pin Signal Cable CLK+ OR 1RED CLK- OR 1BLUE LDV+ GRY 1RED LDV- GRY 1BLUE TM-9700 31-pin connector FDV+ WHT 1RED...
- Page 14 ETX (End of Text = 03H) to end. One packet is 8 bit ASCII code. Freeze mode: STX, “M”, “0”, ETX When a packet is received by TM-1010 ( ETX:03H is 02H,4DH, 30H, 03H detected), it reads internal packet of the receiver buffer.
- Page 15 “R S” command camera response is, STX, ACK, “S”, [data] For detailed parameter, please contact PULNiX. Note: When RS-232C is active, back plate switches are over-written and not functioning. In order to activate back plate switches, power off and power...
