Summary of Contents for LifeSource UB-328

Page 1 Blood Pressure Monitor Trilingual Instruction Guide – MODEL UB-328...
Page 2 Remove and replace batteries if monitor is not used for more than six months. Alkaline batteries recommended. The UB-328 is designed to be used at home, by those who are eighteen (18) years and older, to monitor blood pressure (systolic and diastolic) and pulse rate.
Page 3 A&D Medical has been manufacturing high quality healthcare products for over 20 years. We are committed to providing you and your family with monitoring devices that provide the utmost in accuracy and convenience. LifeSource - Designed for Life.
Page 5 The symbol shown while measurement is in progress. It blinks while detecting the pulse. An irregular heartbeat or body movement may have occurred. Refer to page E-7 for more information on irregular heartbeats. Previous measurement stored in MEMORY. Appears when battery voltage is insufficient Battery Low for device to function.
Page 6 SYSTOLIC PRESSURE DIASTOLIC PRESSURE PULSE RATE BATTERY HOLDER COVER MEMORY BUTTON START BUTTON CASE CUFF...
Page 7 This results in a faster measurement providing greater comfort to the user. The UB-328 provides accurate readings on wrists with a circumference between 5.3 and 7.7" (13.5 and 19.5 cm). The unit requires two "AAA" (1.5 volt) batteries to operate (alkaline batteries recommended).
Page 8 Tips for Blood Pressure Monitoring: Relax for about 5 minutes before measurement. Do not smoke or ingest caffeine at least 30 minutes prior to measurement. Remove constricting clothing and place cuff on bare wrist. Unless your physician recommends otherwise, use left wrist to measure pressure.
Page 9 After the cuff is fully inflated, it will automatically start to deflate and symbol will appear to indicate that measurement is in progress. Once the pulse is detected, the symbol will flash with each pulse beat. When measurement is complete, the systolic and diastolic pressure and pulse rate readings are displayed.
Page 10 The UB-328 Blood Pressure Monitor provides a blood pressure and pulse rate measurement even when an irregular heartbeat occurs. The Irregular Heartbeat symbol will appear in the display window in the event an Irregular Heartbeat has occured during measurement. An irregular heartbeat is defined as a heartbeat that varies by 25% from the average of all heartbeat intervals during the blood pressure measurement.
Page 11 The UB-328 automatically stores up to 30 blood pressure and pulse measurements in its memory. Measurements stored in memory are assigned an index number in the order of the newest to the oldest. The oldest reading displays as "n01". The M symbol in lower left corner of the display screen indicates that you are viewing a previous measurement stored in memory.
Page 12 Blood pressure is the force exerted by blood against the walls of the arteries. Systolic pressure occurs when the heart contracts; diastolic pressure occurs when the heart expands. Blood pressure is measured in millimeters of mercury (mmHg). Blood pressure is affected by many factors: age, weight, time of day, activity level, climate, altitude and season.
Page 13 The following standards for assessing high blood pressure (without regard to age or gender) have been established as a guideline. Please note that other risk factors (e.g. diabetes, obesity, smoking, etc.) need to be taken into consideration and may affect these figures. Consult with your physician for an accurate assessment. Normal Prehypertension Stage 1 Hypertension...
Page 14 Hypertension (high blood pressure) is the diagnosis given when readings consis- tently rise above normal. It is well known that hypertension can lead to stroke, heart attack or other illness if left untreated. Referred to as a “silent killer” because it does not always produce symptoms that alert you to the problem, hypertension is treatable when diagnosed early.
Page 15 Why are my readings different between home and at a doctor’s office? Your blood pressure readings taken in a doctor’ s office or hospital setting may be elevated as a result of apprehension and anxiety. This response is known as white coat hypertension.
Page 16 The most important method to get an accurate blood pressure measurement is consistency. To get the most benefit out of your monitor, it is important to establish a “baseline measurement.” This helps build a foundation of measurements that you can use to compare against future readings. To build this baseline measurement, devote two weeks for consistent blood pressure monitoring.
Page 17 Problem Probable cause Nothing appears in Batteries are drained. the display, even when the power is Battery terminals are not turned on. in the correct position. The cuff does not Battery voltage is too low. inflate. Low battery symbol blinks. [If the batteries are drained completely, the mark does not appear.] The unit does not...
Page 18 ......UB-328 ......Oscillometric .
Page 19 For more information regarding use, care or servicing of your blood pressure monitor, contact: A&D Medical A division of A&D Engineering, Inc. 1555 McCandless Drive Milpitas, CA 95035 LifeSource Health Line (Toll-Free): 1-888-726-9966 www.LifeSourceOnline.com For Canadian Residents, please contact: Auto Control Medical 6695 Millcreek Drive, Unit 5...
Page 20 1555 McCandless Drive Milpitas, CA 95035 www.LifeSourceOnline.com Pressure Rating Indicator is a trademark and LifeSource is a registered trademark of A&D Medical. Pressure Rating Indicator is patent pending. ©2005 A&D Medical. All rights reserved. Specifications subject to change without notice.
