Mooer Super Tiny Twin Owner's Manual

Owner's Manual
Precautions
* PLEASE READ CAREFULLY BEFORE PROCEEDING *
Power Supply
Please connect the designated AC adapter to an AC outlet of the correct
voltage.
Please be sure to use only an AC adapter which supplies 9V DC, center
minus.
Unplug the AC power adapter when not using or during electrical storms.
Connections
Always turn off the power of this and all other equipment before connecting
or disconnecting, this will help prevent malfunction and / or damage to other
devices. Also make sure to disconnect all connection cables and the power
cord before moving this unit.
Location
To avoid deformation, discoloration, or other serious damage, do not
expose this unit to the following conditions:
Direct sunlight
Heat sources
Magnetic fields
Extreme temperature or humidity
Excessive dusty or dirty location
High humidity or moisture
Strong vibration or shock
Interference with other electrical devices
Radios and televisions placed nearby may experience reception
interference. Operate this unit at a suitable distance from radios and
televisions.
Cleaning
Clean only with a soft, dry cloth. If necessary, slightly moisten the cloth.
Do not use abrasive cleanser, cleaning alcohol, paint thinners, wax,
solvents, cleaning fluids, or chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into this unit.
Take care not to drop the unit, and do not subject it to shock or excessive
pressure.
Main Features
Very Small and exquisite, can be hung at waist
2×3" speakers, 2×0.8 watts output
4 Drive Sounds & 3 DSP Effects
80 Drum Rhythms & Tuning Function
1/8" PHONES Jack & 1/8" AUX In Jack
DC 9V Adapter or AA/LR6 battery (x6) Power Supply
Power On
Plug the cable of AC Adapter (9V, 300mA, center minus) into the [DC 9V]
Jack, or using batteries (AA/LR6 x 6), then use the Power Switch to turn the
device on.
For installing batteries
Note: When the batteries are getting low, the display will show to
indicate this situation.
Panel Instruction & Basic Operation
Top Panel
7 3 4 8 2
6 5 10
01 PLAY/STOP Button with LED: Press this button to start/stop the
drum rhythm. Hold this button to enter/exit Tap Tempo function.
02 DRUM/TUNER Knob with Button: Press the button to switch
between 3 Drum items. Rotate the knob to adjust Drum parameters.
03 DRIVE Switch: Select effects between Clean/Overdrive/Distortion
/Metal.
04
GAIN Knob: Adjust the gain of the DRIVE effects.
05 TONE Knob: Adjust the brightness of the sound.
06 EFFECTS Knob: Select DSP effects (between Chorus/Tremolo/
Reverb) and adjust modulation rate or reverb level (turn clockwise to
increase).
07
VOLUME Knob: Control the output volume.
08 Display: Instruct the information of Drum Rhythm or tuner.
09 "
INPUT Jack: 1/4 mono audio jack, for connecting guitar.
10
AUX In Jack: 1/8 stereo audio jack, for connecting external "
music players.
Side Panel
11
PHONES Jack:
1/8" stereo audio jack, for connecting
headphones.
14
12
POWER Switch:
Turn on/turn off the power.
13
DC 9V Jack:
For power supply, use a 9-volt DC
11
regulated AC adapter
positive on the barrel
12
1
the center).
14 HOOK:
13
For hanging Super Tiny Twin at waist.
9
(plug polarity is
and negative in
