MicW Audio H825 User Manual

User's Manual
H825
Headworn microphones
www.micwaudio.com

OPERATIONAL SAFETY

H-Series microphones use pre-polarized
capsules that are tested both at high
temperatures and in very humid
conditions for over 24 hours prior to
factory release. The microphones are
very resistant to temperature and
humidity. They can be safely operated
in temperatures ranging from -17℃ to
+60℃ and in up to 95% humidity.
• On Air Presentation

DIRECTIONAL CHARACTERISTICS

The H825 is an omnidirectional
microphone.
0
345
15
330
30
315
45
300
285
270
255
240
10db
135
225
150
210
195 165
180
H825 Polar Pattern

INTRODUCTION

We have been producing high quality
microphones for test, measurement
and studio recording for over 10 years.
Our unique knowledge of diaphragm
technology has enabled us to offer you a
range of extremely high quality products
for a variety of audio applications.
The H-Series is MicW's new professional
headworn range. With its micro-miniature

POWER SUPPLY

The H-Series has been designed with
a Microdot connector. MicW also
provides several breakout adaptors
(see Microphone Installation) for a wide
range of wireless systems or XLR input

applications.

• Stage and Theater

FREQUENCY RESPONSE

Typical frequency responses are shown in
the following charts .
20
10
60
0
75
-10
90
-20
105
-30
120
20
1kHz
Typical Frequency Response of H825 at 5cm
200 2000 20000
from the source
capsule and well designed single-ear
mount, it delivers a great intengibility,
regardless of the position of the capsule
relative to the sound source.
APPLICATIONS
The omnidirectional H825 is designed for
applications such as broadcast narration,
live & stage performances, other high
quality speech requirements that require
a head-worn microphone with superior
noise rejection and a smooth, natural-
sounding frequency response.
With optional adapters, the microphone
can be used with virtually any
manufacturer's wireless beltpack system.
• TV show

MICROPHONE INSTALLATION

✽ Mic placement
