MicW Audio iShotgun Manual For Use And Maintenance

special
microphones
iShotgun
The perfect microphone
for Camcorder, Cameras and mobile devices
Perfect for
ENG • Interview • Podcast • Video/Film Production

Introduction

Welcome to the MicW iSeries of professional micro-
phones. MicW have been producing high quality
microphones for measurement and recording applica-
tions since 1998.
The iSeries has now applied this wealth of knowledge
and technology to mobile devices such as smartpho-
nes, DLSR cameras and camcorders.
The iShotgun is a super-cardioid shotgun mic for
professional use.

Features:

™
- Highly directional
- Compact and elegant design
- Rugged aluminum body and lightweight
- No battery required
ash
- Many accessories included

Diagrams

0
10 350
20 %!" 340
30 330
40
50
$!"
60
70
80
90
100
110
120
130
140
150 210
160 200
170 190
180
20
10
0
-10
-20
Hz
20 200
320
310
300
Polar Pattern
290
500
280
1k
270
5k
260
10k
250
240
230
220
Frequency response
2000 20000

Applications

The iShotgun, as well as the whole iSeries, has
been tested with the following devices:
iPhone • iPad • iPod touch •
Samsung Galaxy • HTC Desire •
Motorola XT Series • Canon 5D, 7D •
Sony Al-pha 6 and 7 Series • Nikon
D7000 • Panasonic X900M / X909 /
V707 • Sony CX250 / CX570 /
CX730 • Canon HFD10 • Computers
with Microphone Input...
Power Supply* comes straight from the connector,
there is no need for an extra battery.
Product Reliaility*
The microphone is supplied with a pre-polarized capsule
which is tested in a high temperature and high humidity
environment for more than 24 hours.
* Every device must supply PlugIn-Power
* It is recommended that you use "Airplane Mode" for recording.
Type
Electret Condenser
Operation Interference tube
Polar pattern Super cardioid
Sensitivity (± 3 dB) 8 mV/Pa (- 42 dB)
Frequency Response 100 Hz - 18 kHz
S/N ratio
> 65 dB
Impedance < 2,2 kOhm
Power supply Plug and Play
Operating temperature -20°C - +50°C
Diameter 8,0 mm
Size
length 13,6 mm
Weight 20 g
3,5 mm • 4-pole
Connector
headphone jack
