Page 2: Table Of Contents
ENSURE ALL WIRING IS SAFE AND CORRECT BEFORE USE. (THIS SYMBOL ALSO UNIVERSALLY FLAGS PLEASE RETAIN ALL FACTORY PACKAGING ELECTRICAL HAZARDS) FOR ANY FUTURE POSTAL TRANSIT. DO NOT OPEN THE AMPLIFIER; LEAVE ALL INTERNAL SERVICE OPPERATIONS TO A QUALIFIED TECHNICIAN. MATRIX AMPLIFICATION REV.1.15... -
Page 3: Features And Innovations
• 4 Channel Model. 4 channels of amplification provided in a case size which would normally only offer 2 channels; Optimising the use of available racking space in complex amplifier instillations. • MATRIX AMPLIFICATION REV.1.15... -
Page 4: Specifications
Note: Our policy of continuous improvement may lead to the above specifications being exceeded prior to documentation being updated. MATRIX AMPLIFICATION REV.1.15... -
Page 5: Basic Schematics
Note: The Diagrams shown here for channels A and B, also apply for channels C and D. Modes: Output Connections: CHANNEL B CHANNEL A OUTPUT B OUTPUT A 2+ 2- 2+ 2- NO CONNECTION ! CHANNEL B MATRIX AMPLIFICATION REV.1.15... -
Page 6: Interface Elements
These indicators light briefly during the power up cycle and also light should a fault occur. Illumination of the protect indicators, shows that the output of the amplifier has been disconnected by means of an internal relay to protect connected speaker systems from being damaged by the fault. MATRIX AMPLIFICATION REV.1.15... -
Page 7: Rear Panel
Speakon connectors to make connections Cable testers which allow you to hook up both ends of the cable and confirm correct wiring are available and purchasing one as a standard tool for debugging and partial safety assurance is recommended. MATRIX AMPLIFICATION REV.1.15... - Page 8 This should be 13 amps for the models listed in this manual. However, if there is any reason to believe that a malfunction caused the fuse to blow, stop using the equipment immediately and take the amplifier to an authorised service engineer for servicing. MATRIX AMPLIFICATION REV.1.15...
- Page 9 For use with Tweeters directly, High Pass should be selected. For use with Bass drivers or Subwoofer systems, Low Pass should be selected. Note: The Diagrams Shown here for channels A and B, also apply for channels C and D. MATRIX AMPLIFICATION REV.1.15...
-
Page 10: Recommended Usage
4 or 8 ohms depending on the model used. Also note the custom wiring required for connecting the speakers in bridged mode. Using Standard connections will result in exceptionally poor performance. MATRIX AMPLIFICATION REV.1.15... - Page 11 Note: The Diagrams Shown here for channels A and B, also apply for channels C and D. CHANNEL B CHANNEL A OUTPUT B OUTPUT A 2+ 2- 2+ 2- NO CONNECTION ! CHANNEL B MATRIX AMPLIFICATION REV.1.15...
-
Page 12: Cables, Making Your Own
Keep cable runs short where possible, however be sure allow a little bit of slack in the length of cable used to make the lead. Stretched, overstressed cables tend to break at the most inconvenient moments. MATRIX AMPLIFICATION REV.1.15... -
Page 13: Cable Connections
DF = 430 - 127 (86) DF – Damping Factor est. DF – Damping Factor est. DF – Damping Factor est. wires AWG wires AWG wires AWG Rec Minimum: Rec Minimum: Rec Minimum: Rec Minimum: Rec Minimum: Rec Minimum: Rec Minimum: MATRIX AMPLIFICATION REV.1.15... - Page 14 NEVER Pair together (-) negative/'ground' cables from different ● amplifiers, this will result in amplifier malfunction and can easily result in permanent damage to speaker systems, amplifiers and associated equipment. MATRIX AMPLIFICATION REV.1.15...
-
Page 15: Trouble Shooting
- especially in bridge mode If any of these, or other symptoms persist, Please contact us with the details below for help, advice and service: Contact Details: Address: MATRIX AMPLIFICATION LIMITED, Matrix Amplification, Little Castle Farm, Email: support@matrix-amplification.com Pen-Y-Park Road,... -
Page 16: Warranty
Warranty work can only be performed at our authorised distributors or at Matrix Amplification Limited. We will remedy the defect and ship the product from the service centre or our own factory within a reasonable time after receipt of the defective product. All expenses in remedying the defect, including freight costs from ourselves to you (within mainland UK) will be borne by us.
