OPERATING MANUAL
Center of Gravity
Tilt in Space Wheelchair
FREEDOM DESIGNS, INC.
2241 Madera Rd., Simi Valley, CA 93065
(800)331-8551
(805) 582-0077 FAX (888) 582-1509
www.freedomdesigns.com
06/01/08
Advertisement
Table of Contents
Related Manuals for Freedom Designs CGX
Summary of Contents for Freedom Designs CGX
- Page 1 Before using this wheelchair Center of Gravity read this entire manual and save for future reference Tilt in Space Wheelchair OPERATING MANUAL FREEDOM DESIGNS, INC. 2241 Madera Rd., Simi Valley, CA 93065 (800)331-8551 (805) 582-0077 FAX (888) 582-1509 www.freedomdesigns.com 06/01/08...
-
Page 3: Introduction
Authorized Dealers or our Customer Service Department at: (800) 331-8551 Again, thank you for your purchasing a Freedom Designs, Inc. Freedom CGX ™ This manual revised on May 15, 2008 Serial #___________________________________ Reference Phone Numbers:... -
Page 4: Table Of Contents
Tilting Seat Maintenance Warnings: Components and Options 12-15 Transport Option Anti-Tip Devices Armrests Cushions & Sling Seats Fasteners Footrests Pneumatic Tires Positioning Belts Power Drive Push Handles FREEDOM DESIGNS, INC. 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 www.freedomdesigns.com... - Page 5 Quick Release Axles Large Drive Wheels Wheel Locks Modified Seating Systems Upholstery Fabric Initial Inspection Checklist Specifications Features Unfolding the Freedom CGX Folding the Freedom CGX Main Frame 21-25 1. Anti-Tips 2. Wheels & Tires Footrest 4. Quick Release Axles...
-
Page 6: General Warnings
If you do not understand any of the instructions in this manual, call your authorized Freedom Designs, Inc. dealer. Note: Where they apply, you will also find “Warnings” in other sections of this manual. Heed all warnings in this section. -
Page 7: Environmental Conditions
Transport Option installed. If your chair is not equipped with the Transport Option: The Freedom CGX™ wheelchairs do not meet federal standards for motor vehicle seating. 1. NEVER let anyone sit in this chair while in a moving vehicle. -
Page 8: Transport Option
Consult your doctor, nurse, or therapist to find out what axle and caster position is best for you. b. Consult your authorized Freedom Designs, Inc. dealer BEFORE you modify or adjust this chair. Be aware that you may need to make other changes to correct the center of balance. -
Page 9: Dressing Or Changing Clothes
Wheelies “Wheelies”, (tilting the wheelchair backward to its balance point), are extremely dangerous as the chair may tip over. Freedom Designs, Inc. recommends that “wheelies” not be attempted. Obstacles Obstacles and road hazards (such as potholes and broken pavement), can damage your chair and may cause a fall, tip-over, or loss of control. -
Page 10: Moving Backward
Lean or press your body UPHILL. This will help adjust for a change in the center of balance caused by the slope or side hill. b. Keep pressure on the handgrips to control your speed on a down 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 FREEDOM DESIGNS, INC. www.freedomdesigns.com... -
Page 11: Transfer
slope. If you go too fast, you may lose control. c. Ask for help any time you are in doubt. 9. For your safety, ramps at home and work must meet all legal requirements for your area. We recommend: a. Width: At least four feet wide. WARNING: b. -
Page 12: Stairs And Escalators
169 lbs. This constitutes the range of sizes for which the wheelchairs are suitable for occupancy in a motor vehicle. 4. The Freedom CGX™ picture (right) shows the location of the wheelchair securement points. 5. Use only with Wheelchair Tiedown and Occupant Restraint Systems (WTORS) that have been installed in accordance with the manufacturer’s instructions and... -
Page 13: Descending A Curb Or Single Step
Descending a Curb or Single Step Follow these steps to help a rider descend a curb or single step going down BACKWARD: 1. Stay at the rear of the chair. 2. Several feet before you reach the edge of the curb or step, turn the chair around and pull it backward. -
Page 14: Tilting Seat
Anti-Tip Device Anti-tip tubes help keep your chair from tipping over backward in most normal conditions. Freedom Designs, Inc. recommends that the anti-tip tubes be used at all times and may not be removed from the wheelchair. 1. If modifications or adjustments are done to the wheelchair, anti-tip tubes must be used to prevent tipping backward. -
Page 15: Armrests
Cushions & Sling Seats 1. Freedom Designs, Inc. sling seats and standard foam cushions are not designed for the relief of pressure. 2. If you suffer from pressure sores, or if you are at risk that they will occur, you may need a special seating system or a device to control your posture. -
Page 16: Power Drive
Power Drive Freedom Designs, Inc. does not recommend the attachment of power drives to the Freedom CGX™ wheelchair. 1. The attachment of power drives to the wheelchair is considered a modification or alteration to the frame, thus voiding the warranty. -
Page 17: Wheel Locks
1. Do not change the seating system of your chair UNLESS you consult your authorized Freedom Designs, Inc. supplier first. 2. Use of a seating system not approved by Freedom Designs, Inc. may affect the folding mechanism of this chair. -
Page 18: Initial Inspection Checklist
2. Remove all the loose packing from the box. 3. Carefully remove all of the components. 4. Examine the exterior of the Freedom CGX™ and the components for any nicks, dents, scratches or other damage. 2241 Madera Rd. -
Page 19: Specifications
Freedom CGX ™ Specifications Center of Gravity Tilt in Space—Rigid Frame Frame Configuration 31” (does not include anti-tips) Frame Length Narrow: 10” - 14”, Medium: 12” - 16”, Wide: 14” - 18” Seat Width Short: 10”-14”, Medium: 12” - 16”, Long: 14” - 18”... -
Page 20: Features
Freedom CGX Features 1. Frame Seating 2. Seat Frame Footrest Assembly 3. Backpost Tilt Mechanism 4. Backpost Pivot Plate Anti Tip Lever 5. Backpost Trigger Mechanism Rear Wheel 6. Caster Wheel Quick Release Axle 7. Caster Fork Wheel lock 2241 Madera Rd. -
Page 21: Unfolding The Freedom Cgx
CGX™ Unfolding the Freedom For ease of transporting and lifting, the chair back can easily be unfolded and folded. Always engage the wheel locks by pushing forward or pulling back on the levers before unfolding the chair. (see page 35). -
Page 22: Folding The Freedom Cgx
2. Flip back the armrests to the upright position. 3. Pull up on the trigger mechanism for the back posts and push the backposts to the flat posi- tion over the seat rails. 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 FREEDOM DESIGNS, INC. www.freedomdesigns.com... -
Page 23: Main Frame
Anti-Tip Device Flip-up, removable anti-tip levers come standard on the Freedom CGX™ The anti-tip levers are preset at the factory. The anti-tips may be adjusted vertically (see “Anti-Tip Adjustment”, page 27). They can also be flipped up out of the way or removed. -
Page 24: Footrest
To change the angle of the footboard, use an allen wrench and loosen the flat head screws on the top of the footboard. When the desired angle or depth is reached, tighten both screws. FREEDOM DESIGNS, INC. 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 www.freedomdesigns.com... -
Page 25: Quick Release Axles
Quick Release Axle Step 3 The Freedom is equipped with double lock CGX™ quick release axles that release with the push of a button. This double lock quick release mechanism allows the large drive wheels to be easily removed for transportation or storage. -
Page 26: Flip Back Armrests
Casters The Freedom is shipped with 3”, 5”, 6”, or CGX™ 7” polyurethane casters with caster forks or a variety of 5” or 6” wheels. FREEDOM DESIGNS, INC. 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 www.freedomdesigns.com... -
Page 27: Wheel Locks
Main Frame Wheel Locks The Freedom comes standard with push CGX™ or pull to lock wheel locks or hub locks. Push or Pull to Lock Wheel Locks To lock wheels in place: Grasp the lever of the wheel lock with your hand. -
Page 28: Freedom Cgx Adjustments
Adjustments CGX Folding Back The Freedom comes standard with a CGX™ folding back. Pull Up 1. To fold the back down, pull upward on the trigger while pushing backposts forward toward seat. 2. To place the backpost to the upright position, pull backposts up until trigger snaps into place. -
Page 29: Caster Fork Adjustment
Adjustments Caster Fork Adjustment Interchanging casters can easily be done with dual hole caster forks. Currently, 5” & 6” casters are available for use. To adjust, loosen the bolt and remove the caster. Change the caster and/or position the caster upward or downward in pre- drilled holes on the caster fork. -
Page 30: Seat Tilt Adjustment
Changing Frame and Seat Width The seat and frame can be widened in 1” increments. The frame can be widened independ- ently to allow for additional lateral stability. 2241 Madera Rd. Simi Valley, CA. 93065 800-331-8551 Fax 888-582-1509 FREEDOM DESIGNS, INC. www.freedomdesigns.com... -
Page 31: Cleaning
Tighten securely. Cleaning It is important for optimum performance to clean and maintain your Freedom CGX™ We recommend that the frame finish be cleaned with mild soap and water. Maintenance 1. In order to operate the Freedom properly and safely, routine maintenance will extend CGX™... -
Page 32: Troubleshooting
Troubleshooting All Freedom CGX™ wheelchairs leave the factory inspected and adjusted for immediate use, (aside from the unfolding procedure). This troubleshooting chart offers some sugges- tions regarding the use of your wheelchair. Some areas may require more investigation to find the most suitable solution for a specific problem. A complete inspection, safety check, and servicing should be made by an authorized dealer at least once a year. -
Page 33: Summary
Remember: the entire Operating Manual should be read before your new chair is used. For any questions, please call your authorized Free- dom Designs, Inc. dealer or Freedom Designs, Inc. customer service at 1-800-331-8551. (Always lock the push to lock wheel locks before adjusting the wheelchair). -
Page 34: Warranty
Freedom Designs, Inc. will repair or replace parts as required, provided that the authoriza- tion for such a return has been acquired by an established Freedom Designs, Inc. dealer and that the parts in question are returned by the Freedom Designs, Inc. dealer, fully insured with freight pre-paid, to Freedom Designs, Inc., 2241 Madera Road, Simi Valley,... -
Page 35: Index
Index 12,21,27 Anti-tip Device Warnings: Falls & Tip-Overs Armrests Warnings: For Safe Use Armrest Adjustments Warnings: Components Backposts & Options Backpost Pivot Plate Warranty Casters Weight Limitation Caster Forks Wheelies Wheel Locks 7, 9,14,15,17,19, Center of Balance 20, 25,27, 28, 31 Cleaning Climbing a Curb or Step Wheel Lock Adjustments... - Page 36 FREEDOM DESIGNS, INC. 2241 Madera Road ● Simi Valley, California 93065 (805) 582-0077 ● (800) 331-8551 ● FAX (888) 582-1509 Website: www.freedomdesigns.com...
