Freedom Designs Freedom 2 Operating Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
□
With transport package
□
Without transport package
Supplier:
This manual must be given to
the rider of this wheelchair
Rider:
Before using this wheelchair
read this entire manual and save
for future reference
®
Freedom 2 Kids
OPERATING MANUAL
FREEDOM DESIGNS, INC.
2241 Madera Rd., Simi Valley, CA 93065
Freedom 2
By FREEDOM DESIGNS, INC.
(800)331-8551
(805) 582-0077 FAX (888) 582-1509

Advertisement

loading
Need help?

Need help?

Do you have a question about the Freedom 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Freedom Designs Freedom 2

Summary of Contents for Freedom Designs Freedom 2

  • Page 1 □ Without transport package Freedom 2 Supplier: This manual must be given to the rider of this wheelchair Freedom 2 Kids Rider: Before using this wheelchair read this entire manual and save for future reference By FREEDOM DESIGNS, INC. OPERATING MANUAL FREEDOM DESIGNS, INC.

  • Page 3: Introduction

    Introduction Congratulations on your purchase of the Freedom Designs, Inc. Freedom 2 or Freedom 2 Kids wheelchair. These chairs combine state-of-the-art technology with durability and function to meet all of your changing needs. This Operating Manual will provide you with a detailed guide for proper assembly as well as instructions on the care of your new wheelchair.

  • Page 4: Table Of Contents

    Climbing Stairs Descending Stairs Maintenance Warnings: Components and Options 13-17 Transport Option Anti-Tip Tubes 13-14 Armrests Cushions & Sling Seats Fasteners Pneumatic Tires 14-15 Footrests Positioning Belts Power Drive Push Handles Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...
  • Page 5 15-16 Rear Wheels Rear Wheel Locks Modified Seating Systems Upholstery Fabric Initial Inspection Checklist Specifications Features Unfolding the Freedom 2 / Freedom 2 Kids 21-23 Folding the Freedom 2 / Freedom 2 Kids 24-26 Main Frame 27-36 Anti-Tips Tires Latch-Style Swing Away Hangers...

  • Page 6: General Warnings

    The weight limit for the Freedom 2 and Freedom 2 Kids is a 250 lb. person. If the person exceeds the weight limit, damage to your chair, a fall, tip-over or loss of control may cause severe injury to the rider or others.

  • Page 7: Adjustments

    1. At night, or when lighting is poor, use reflective tape on your chair and clothing. 2. Due to your low position, it may be hard for drivers to see you. Make eye contact with drivers before you go forward. When in doubt, yield until you are sure it is safe.

  • Page 8: Motor Vehicle Safety

    2. Tell the rider what you plan to do and explain what you expect the rider to do. This will put the rider at ease and reduce the risk of an accident 3.

  • Page 9: Warnings: Falls & Tip-Overs

    Wheelies “Wheelies”, (tilting the wheelchair backward to its balance point), are extremely dangerous, as the chair may tip over. Freedom Designs, Inc. recommends that “wheelies” not be attempted. Freedom Designs, Inc.

  • Page 10: Obstacles

    1. NEVER reach or lean if you must shift your weight sideways or rise up off the seat. 2. NEVER reach or lean if you must move forward in your seat to do so. Always keep your buttocks in contact with the backrest.

  • Page 11: Moving Backward

    1. Do not use your chair on a slope steeper than 10%. (A 10% slope means: one foot in elevation for every ten feet of slope length). 2. Always go as straight up and as straight down as you can. (do not “cut the corner” on a slope or ramp).

  • Page 12: Transfer

    Use” (Pages 11 – 13). 2. Do not try to climb or descend a curb or step alone UNLESS you are a skilled rider of this chair and you are sure you have the strength and balance to do so.

  • Page 13: Stairs And Escalators

    1. NEVER use this chair on stairs UNLESS you have someone to help you. Doing so is likely to cause a fall or tip-over. 2. Persons who help you should read and follow the warnings “For Attendants”, (page 6) and the “For Safe Use”, (pages 11—13).

  • Page 14: Descending A Curb Or Single Step

    Follow these steps to help the rider climb a curb or single step going FORWARD 1. Stay behind the chair. 2. Face the curb and tilt the chair up on the rear wheels so that the front casters clear the curb or step.

  • Page 15: Maintenance

    1. Inspect and maintain this chair strictly per chart on page 41. 2. If you detect a problem, make sure to service or repair the chair before use. 3. At least once a year, have a complete inspection, safety check and service of your chair made by an authorized Freedom Designs, Inc.

  • Page 16: Armrests

    1. Freedom Designs, Inc. sling seats and standard foam cushions are not designed for the relief of pressure. 2. If you suffer from pressure sores, or if you are at risk that they will occur, you may need a special seat system or a device to control your posture. Consult your doctor, nurse or therapist to find out if you need such a device for your well-being.

  • Page 17: Pneumatic Tires

    1. Do not use this chair if any of the tires is under or over inflated. Check weekly for proper inflation level, as listed on the tire sidewall. 2. Low pressure in a rear tire may cause the wheel lock on that side to slip AND allow the wheel to turn when you do not expect it.

  • Page 18: Quick Release Axles

    1. The farther you move the rear axles FORWARD, the more likely it is that your chair will tip over backward. 2. Consult your doctor, nurse or therapist to find the best rear axle setup for your chair. 3. Adjust the rear wheel locks after you make any change to the rear axles.

  • Page 19: Upholstery Fabric

    1. Sling fabric will weaken with age and use. Look for fraying or thin spots, stretching of fabrics at rivet holes. 2. “Drooping Down” into your chair will weaken fabric and result in the need to inspect and replace the seat more often.

  • Page 20: Initial Inspection Checklist

    Initial Inspection Checklist The Freedom 2/Freedom 2 Kid is shipped in the following fashion: 1. The main frame with backposts, casters, tires, with quick release axles, armrests*, footplates or footboard and anti-tip tubes. (Refer to the Unfold instructions in this manual).

  • Page 21: Specifications

    Freedom 2 & Freedom 2 Kids Specifications Frame Configuration: Standard Folding Seat Width + 9” Overall Width 23” - 25” Overall Depth Freedom 2 21” - 25” Freedom 2 Kids 9” Overall Width Folded (not including wheels & wheel locks) (not including wheels) 13”...

  • Page 22: Features

    Freedom 2 / Freedom 2 Kids Features 12 14 Base Frame 11. Backpost Trigger Mechanism Swing Away Front Rigging 12. Sling Seat Cross Brace 13. Sling Back Flip Up Foot Plates 14. Cushion Swing Away Removable Armrest 15. Caster Wheel Anti-tip Tubes 16.

  • Page 23: Unfolding The Freedom 2 / Freedom 2 Kids

    Unfolding is accomplished by applying even pressure on the seat rails and pushing down. Note: The cross braces need to be opened to their maximum point where the stops rest on the saddle receivers on rail. Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...
  • Page 24 Unfolding the Freedom 2/ Freedom 2 Kids Continued………... Place the swing away/removable or “T” armrests in their receivers. Place optional cushion on hook/loop strips on seat sling. Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...

  • Page 25: Unfolding The Freedom 2 / Freedom 2 Kids

    Unfolding the Freedom 2/ Freedom 2 Kids Continued………... 5. To attach the swing away hanger (Freedom 2 & Freedom 2 Kids), line up the pivot saddle with it’s receiver on the frame and insert downward. Swing hanger inward until it locks into place.

  • Page 26: Folding The Freedom 2 / Freedom 2 Kids

    (See pages 30-33). Pull back on the hanger release lever for either the latching swing away or pop-up hanger and lift the hanger off. (Freedom 2 & Freedom 2 Kids) Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...
  • Page 27 4. Lift and remove armrests. (The chairs can fold without removing the armrests). Swing arm: Lift out of receiver tube. “T” arm: Push lever rearward and lift arm out of receiver socket. Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...

  • Page 28: Folding The Freedom 2 / Freedom 2 Kids

    Grip seat sling in the front and back and lift upward until chair folds flat laterally. Disengage wheel lock, push the quick release axle button and pull off wheel off of the frame Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...

  • Page 29: Main Frame Anti-Tips

    1. When the anti-tip tubes are in the downward position, swivel the anti-tip tube and turn inward to lock in an upright position. 2. When the anti-tip tubes are in the upright position, swivel the anti-tip tube and turn outward to lock in a downward position Flip-up anti-tip tube adjustment: 1.

  • Page 30: Latch-Style Swing Away Hangers

    1. To swing away the hanger, place your hand on the hanger release lever. 2. Pull back on the lever towards the chair. This will enable the hanger to swing away for ease of transfer. 3. To remove the hanger, lift the hanger upward until the pivot saddle is out of it’s receiver on the frame.

  • Page 31: Main Frame

    75° or 90° 1. To swing away the hanger, place your hand on the hanger release lever. 2. Pull back on the lever towards the chair. This will enable the hanger to pop-up and swing away for ease of transfer.

  • Page 32: Flip-Up Individual Footplates

    Main Frame continued….. Flip-up Individual Footplates The Freedom 2 or Freedom 2 Kids is shipped with individual flip-up footplates (molded composite or angle adjustable aluminum) attached or a solid foot- board unattached. Adjustment of the individual flip-up footplates are as follows:...

  • Page 33: Angle Adjustable Footboard

    To attach the footboard to the frame, place the footboard clamps on the frame. Set the clamps at the desired height. Insert the receiver into the clamps and tighten the 2 hex head screws on each side. Freedom Designs, Inc.
  • Page 34 To change the angle of the footboard, use an allen wrench and loosen the flat head screws on the top of the footboard. When the desired angle or depth is reached, tighten both screws. Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...

  • Page 35: Angle Adjustable Footboard

    Set the desired height and tighten. The lowest point of the footrest plate should be at least 2 1/2” from the ground to ensure the proper clearance. Warning: In all footplate and hanger adjust- ments, be sure that all screws are tightened securely for your safety.

  • Page 36: Swing Away/Removable Armrests

    Main Frame continued….. Swing Away/Removable Armrests The Freedom 2 or Freedom 2 Kids is shipped with swing away/removable armrests. To remove armrests, grasp armrest and lift out of receiver. These armrests are tubular with foam grips. Optional Arms “T” Arm To remove the “T”...

  • Page 37: Seat And Back Sling

    Main Frame continued….. Seat and Back Sling The Freedom 2 or Freedom 2 Kids comes standard with seat and back sling upholstery. This upholstery is made of ballistic nylon for durability and long wear. The seat sling is tension adjustable for growth.

  • Page 38: Wheel Lock Options

    Main Frame continued….. Wheel lock Options The Freedom 2 or Freedom 2 Kids also offers wheel lock options of: rear mount pull to lock, rear mount push to lock, wheel lock extensions and hub locks. Hub Lock* 1. To lock the wheels, push the Hub Lock lever.

  • Page 39: Freedom 2 / Freedom 2 Kids Adjustments

    Freedom 2 / Freedom 2 Kids Adjustments Swing Away Arm To adjust the height of the armrests, loosen the hex head bolts and move the receiver clamp to desired height. Tighten the hex head bolts securely. “T” Arm To adjust the height of the “T” arm, rotate lever outward.

  • Page 40: Caster Fork Adjustments

    Freedom 2 / Freedom 2 Kids Adjustments continued……….. Caster Fork Adjustment Interchanging casters can easily be done with dual hole caster forks. Currently, 3”, 5” , 6” and 7” casters are available for use. A smaller fork is used with the 3” caster only. To adjust, loosen the bolt and remove the caster.

  • Page 41: Rear Axle Adjustments

    1. Center of gravity adjustment may be accomplished by moving the rear axle forward or backward on the axle plate. 2. Rear axle plates are available for 0º, 3º and 6º camber angle. 3. Seat height and/or angle may be changed by changing the position of the axle plate upward or downward.

  • Page 42: Cleaning

    Freedom 2 Kids. We recommend that the frame finish be cleaned with mild soap and water. Maintenance 1. In order to operate the Freedom 2 or Freedom 2 Kids properly and safely, routine maintenance will extend the life and efficiency of your wheelchair.

  • Page 43: Troubleshooting

    Troubleshooting All Freedom 2 and Freedom 2 Kids wheelchairs leave the factory inspected and adjusted for immediate use, (aside from the unfolding procedure). This troubleshooting chart offers some suggestions regarding the use of your wheelchair. Some areas may require more investigation to find the most suitable solution for a specific problem.

  • Page 44: Summary

    Summary Congratulations on your Freedom 2 or Freedom 2 Kids purchase. Following is a brief sum- mary to refer to if you have any questions. Remember: the entire Operating Manual should be read before your new chair is used. For any questions, please call your authorized Freedom Designs, Inc.

  • Page 45: Index

    Latch Style Hangers & Options Leaning Warranty 27-36 Main Frame Weight Limitation 13, 40 Maintenance Wheelies Modifications Wheel Locks 16,19,20,36,38 Modified Seating Systems Wheel Lock Adjustments Motor Vehicle Safety Wheel Lock Options Freedom Designs, Inc. Freedom 2 / Freedom 2 Kids...

  • Page 46: Warranty

    Freedom Designs, Inc. will repair or replace parts as required, provided that the authorization for such a return has been acquired by an established Freedom Designs, Inc. dealer and that the parts in question are returned by the Freedom Designs, Inc. dealer, fully insured with freight pre -paid, To Freedom Designs, Inc., 2241 Madera Road, Simi Valley, CA.
