Dahua Smart Box series Quick Start Manual page 3

○
1
Draw out the HDD bracket
When you remove the HDD, please refer to the following figure to pull the spring up and then
remove the HDD.
The rear panel is shown as in Figure 2.
Please refer to the following sheet for detailed information.
SN Icon
1 VIDEO IN
○
2
Make sure the HDD metal
surface is facing up and then put
the HDD into the bracket
horizontally
. After the HDD is in
the proper position, the columns
on the two sides can lock the
screw holes of the HDD to secure
it.
Figure 1
Figure 2
Name
Video input
○
3
Put the HDD into the
device.
Note
Connect to analog camera, video input
signal.
3
