Aiwa VX-D1420 Service Manual

Aiwa VX-D1420 Service Manual

Integrated color tv /video cassette recorder
Hide thumbs Also See for VX-D1420:
Table of Contents

Advertisement

Quick Links

This SERVICE MANUAL is exclusive with KAL model.
The A is indicated for KAL model after the Model Name on the Spec. Plate.
The specification for KAL model and K model is common. But, there are slightly differences between the 2
models on the Electric Circuit and Structure Parts.
SERVICE MANUAL
INTEGRATED COLOR TV /VIDEO
CASSETTE RECORDER
POWER REQUIREMENTS ............
POWER CONSUMPTION ..............
WEIGHT .........................................
DIMENSIONS .................................
PICTURE TUBE .............................
TUNER SYSTEM ...........................
CHANNEL COVERAGE .................
TV SYSTEM ...................................
HORIZONTAL RESOLUTION .......
OPERATING TEMPERATURE ......
VIDEO RECORDING SYSTEM .....
VIDEO SIGNAL SYSTEM ..............
VIDEO HEAD .................................
USABLE CASSETTES ...................
SPECIFICATIONS
230V AC, 50Hz
55W
Standby 6W
Approx.12.8 kg (28.16 lbs.)
435 mm (W) x 384.5 mm (D) x
370.5 mm (H)
(17 1/4 x 15 1/4 x 14 5/8 in.)
14 in. (34 cm "V"), 90 degree
deflection
Frequency synthesized tuners
UHF: 21 to 69
I
240 lines
5°C to 40°C
Rotary 2 head helical scanning system
PAL colour signal, 625 lines, 50 fields
Azimuth 2 heads
VHS video cassettes
S/M Code No. 09-005-345-2N2
VX-D1420
BASIC TAPE MECHANISM : OVD-6S
TAPE SPEED ...................................
RECORDING/PLAYBACK TIME .....
VIDEO INPUT ...................................
VIDEO OUTPUT ..............................
VIDEO S/N .......................................
AUDIO INPUT ..................................
AUDIO OUTPUT ..............................
AUDIO TRACK .................................
•
Design and specifications are subject to change without
notice.
KAL
PAL
SP: 23.39 mm/sec.
LP: 11.69 mm/sec.
NTSC (playback SP only)
33.35 mm/sec.
PAL
SP: 5 hours max. with E-300 tape
LP: 10 hours max. with E-300 tape
NTSC (playback SP only)
3 hours 30 minutes max. with T-210
tape
1.0Vp-p, 75 ohm, unbalanced
1.0Vp-p, 75 ohm, unbalanced
53dB (nominal)
SCART: –3.8 dBs, 50K ohm
RCA: –3.8 dBs, 50K ohm
SCART: –3.8 dBs less than 1K ohm
1 track (mono)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-D1420 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa VX-D1420

Summary of Contents for Aiwa VX-D1420

  • Page 1 VX-D1420 This SERVICE MANUAL is exclusive with KAL model. The A is indicated for KAL model after the Model Name on the Spec. Plate. The specification for KAL model and K model is common. But, there are slightly differences between the 2 models on the Electric Circuit and Structure Parts.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS ................................COVER TABLE OF CONTENTS ..............................A1-1 SERVICING NOTICES ON CHECKING ..........................A2-1 DISASSEMBLY INSTRUCTIONS REMOVAL OF MECHANICAL PARTS AND P.W. Boards ....................B1-1, B1-2 REMOVAL OF DECK PARTS ............................B2-1~B2-5 REMOVAL OF ANODE CAP ............................B3-1 KEY TO ABBREVIATIONS ..............................

  • Page 3: Servicing Notices On Checking

    SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES 6. AVOID AN X-RAY As for the places which need special attentions, they are Safety is secured against an X-ray by considering about indicated with the labels or seals on the cabinet, chassis the cathode-ray tube and the high voltage and parts.

  • Page 4: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF MECHANICAL PARTS 1-3: TV/VCR BLOCK (Refer to Fig. 1-3) Remove the 2 screws 1. AND P.W. Boards Disconnect the following connectors: 1-1: BACK CABINET (Refer to Fig. 1-1) (CP351, CP755, CP354, CP401, CP501 and CP502). Remove the 2 screws 1.
  • Page 5 DISASSEMBLY INSTRUCTIONS 1-5: DECK SHIELD PLATE (Refer to Fig. 1-5) Remove the 2 screws 1. Remove the 4 screws 2. Remove the screw 3. Remove the Deck Shield Plate in the direction of arrow (A). Remove the screw 4. Remove the Shield Plate Bottom in the direction of arrow (B). Deck Chassis Deck Shield Plate Syscon PWB...

  • Page 6: Removal Of Deck Parts

    DISASSEMBLY INSTRUCTIONS 2. REMOVAL OF DECK PARTS NOTE When you install the Tape Guide L, install as shown in the 2-1: TOP BRACKET (Refer to Fig. 2-1) circle of Fig. 2-3-B. (Refer to Fig. 2-3-B) Remove the 2 screws 1. Slide the 2 supports 2 and remove the Top Bracket.
  • Page 7 DISASSEMBLY INSTRUCTIONS 2-6: LINK ASS'Y (Refer to Fig. 2-6) 2-9: TENSION ASS'Y (Refer to Fig. 2-9-A) Set the Link Ass'y to the Eject position. Move the Inclined S Ass'y to the back side. Remove the (A) side of the Link Ass'y first, then remove Remove the Tension Spring.
  • Page 8 DISASSEMBLY INSTRUCTIONS 2-11: S REEL/T REEL (Refer to Fig. 2-11) NOTE Remove the S Reel and T Reel. Do not touch the Pinch Roller. (Use gloves.) Remove the 2 Polyslider Washers 1. When you install the Pinch Roller Block, install as shown in the circle of Fig.
  • Page 9 DISASSEMBLY INSTRUCTIONS 2-15: AHC ASS'Y/CYLINDER UNIT ASS'Y (Refer to Fig. 2-15) Middle Gear Unlock the support 1 and remove the AHC Ass'y. E-Ring Remove the 3 screws 2. Remove the Cylinder Unit Ass'y. Main Cam NOTE Pinch Roller Cam When you install the Cylinder Unit Ass'y, tighten the screws from (1) to (3) in order while pulling the Ass'y Joint Gear toward the left front direction.
  • Page 10 DISASSEMBLY INSTRUCTIONS 2-19: LOADING GEAR S/T ASS'Y (Refer to Fig. 2-19-A) 2. When you install the Clutch Actuator, install as shown in the circle of Fig. 2-19-C. (Refer to Fig. 2-19-C) Remove the E-Ring 1 and remove the Main Loading Gear.

  • Page 11: Removal Of Anode Cap

    DISASSEMBLY INSTRUCTIONS 3. After one side is removed, pull in the opposite direction to 3. REMOVAL OF ANODE CAP remove the other. Read the following NOTED items before starting work. NOTE After turning the power off there might still be a potential Take care not to damage the Rubber Cap.

  • Page 12: Key To Abbreviations

    KEY TO ABBREVIATIONS Audio/Control H.SW Head Switch Automatic Color Control Hertz Audio Erase Integrated Circuit Automatic Frequency Control Intermediate Frequency Automatic Fine Tuning Indicator AFT DET Automatic Fine Tuning Detect Inverter Automatic Gain Control Killer Amplifier Left Antenna Light Emitting Diode A.PB Audio Playback LIMIT AMP...
  • Page 13 KEY TO ABBREVIATIONS SYNC Synchronization SYNC SEP Sync Separator, Separation Transistor TRAC Tracking TRICK PB Trick Playback Test Point UNREG Unregulated Volt Voltage Controlled Oscillator Video Intermediate Frequency Vertical Pulse, Voltage Display V.PB Video Playback Variable Resistor V.REC Video Recording Visual Search Fast Forward Visual Search Rewind Voltage Super Source...

  • Page 14: Service Mode List

    SERVICE MODE LIST This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter SERVICE MODE, Unplug AC cord till lost actual clock time. Then press and hold Vol (-) button of main unit and remocon key for more than 2 seconds.

  • Page 15: Preventive Checks And Service Intervals

    PREVENTIVE CHECKS AND SERVICE INTERVALS The following standard table depends on environmental conditions and usage. Unless maintenance is properly carried out, the following service intervals may be quite shortened as harmful effects may be had on other parts. Also, long term storage or misuse may cause transformation and aging of rubber parts. Time 1,000 1,500...
  • Page 16 PREVENTIVE CHECKS AND SERVICE INTERVALS CLEANING NOTE 2. TAPE RUNNING SYSTEM After cleaning the heads with isopropyl alcohol, do not When cleaning the tape transport system, use the run a tape until the heads dry completely. If the heads gauze moistened with isopropyl alcohol. are not completely dry and alcohol gets on the tape, 3.

  • Page 17: Note For The Replacing Of Memory Ic

    NOTE FOR THE REPLACING OF MEMORY IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. NOTE: Initial Data setting will not be possible if clock has been set.

  • Page 18: Servicing Fixtures And Tools

    SERVICING FIXTURES AND TOOLS (For 2 head 1 speed model, (For 2 head 2 speed model) JG002B Adapter JG005 Post Adjustment 4 head model) VHS Alignment Tape JG002E Dial Torque Gauge Screwdriver VHS Alignment Tape JG001C (TTV-P2) (10~90gf•cm) Part No. SV-TG0-030-000 JG001E (TTV-P2) JG001D...

  • Page 19: Preparation For Servicing

    PREPARATION FOR SERVICING How to use the Servicing Fixture Unplug the connector CP351 and CP755 then remove the TV/VCR Block from the set. Unplug the connector CP810, CP820 and CP850, then remove the Main PWB from the VCR Block. Connect as shown in the below figure using the Service Fixture. •...
  • Page 20 PREPARATION FOR SERVICING Servicing Position for Main PWB (In case of needing to check on Main PWB) • It's possible to get the Servicing Position without the extension Jig if you arrange the unit as shown below. (But L503 connection can not be done, Degauss circuit will not operate.) L503 (2 Pin) VHS Tape Main PWB...

  • Page 21: Vcr Test Tape Interchangeability Table

    VCR TEST TAPE INTERCHANGEABILITY TABLE There are two types of the new alignment tape CH-1B (for NTSC) and CH-2 (for PAL). On each tape four signals (1) - (4) are recorded for the times and in the order shown below. (1) : 8min.

  • Page 22: Mechanical Adjustments

    MECHANICAL ADJUSTMENTS 1. CONFIRMATION AND ADJUSTMENT 1-2: CONFIRMATION AND ADJUSTMENT OF TENSION POST POSITION Read the following NOTES before starting work. Set to the PLAY mode. • Place an object which weighs between 450g~500g on Adjust the Tension Adjust until the edge of the Tension the Cassette Tape to keep it steady when you want to Arm is positioning within 0.5mm range from the make the tape run without the Cassette Holder.

  • Page 23: Confirmation And Adjustment Of Tape Running Mechanism

    MECHANICAL ADJUSTMENTS 1-4: CONFIRMATION OF VSR TORQUE 2. CONFIRMATION AND ADJUSTMENT OF TAPE RUNNING MECHANISM Operate within 4~5 seconds after the reel disk begins to turn. Tape Running Mechanism is adjusted precisely at the Install the Torque Gauge (JG002F) and Adapter (JG002B) factory.
  • Page 24 MECHANICAL ADJUSTMENTS 2-2: CONFIRMATION AND ADJUSTMENT OF AUDIO/ 2-3: TAPE RUNNING ADJUSTMENT CONTROL HEAD (X VALUE ADJUSTMENT) When the Tape Running Mechanism does not work well, Confirm and adjust the height of the Reel Disk. adjust the following items. (Refer to item 1-1) Confirm and adjust the position of the Tension Post.

  • Page 25: Mechanism Adjustment Parts Location Guide

    MECHANICAL ADJUSTMENTS 3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE 1. Tension Adjust X value adjustment driver hole 2. Tension Arm P4 Post 3. Guide Roller T Brake Spring 4. P1 Post T Reel 5. Audio/Control Head S Reel D1-4...

  • Page 26: Electrical Adjustments

    ELECTRICAL ADJUSTMENTS 1. ADJUSTMENT PROCEDURE Read and perform these adjustments when repairing the CH-2 circuits or replacing electrical parts or PWB assemblies. CAUTION When replacing IC's or transistors, use only specified 6.5H silicon grease (G746). CH-1 (To prevent the damage to IC's and transistors.) Fig.
  • Page 27 ELECTRICAL ADJUSTMENTS 2-8: WHITE BALANCE 1. RF AGC DELAY NOTE: Adjust after performing CUT OFF adjustment. 2. VIDEO LEVEL Place the set with Aging Test for more than 15 minutes. 3. FM LEVEL Receive the white 100% signal from the Pattern 4.
  • Page 28 ELECTRICAL ADJUSTMENTS 2-11: VERTICAL LINEARITY 2-14: OSD HORIZONTAL NOTE: Adjust after performing adjustments in section 2-10. Using the remote control, set the brightness and contrast to normal position. Receive the cross hatch signal from the Pattern Activate the adjustment mode display of Fig. 1-1 and Generator.
  • Page 29 ELECTRICAL ADJUSTMENTS 2-16: SUB CONTRAST 2-19: TEXT CONTRAST Activate the adjustment mode display of Fig. 1-1 and Activate the adjustment mode display of Fig. 1-1 and press the channel button (4) on the remote control to press the channel button (4) on the remote control to select "PICTURE".

  • Page 30: Electrical Adjustment Parts Location Guide

    ELECTRICAL ADJUSTMENTS 3. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (VCR SECTION) TP1001 C1003 TP4002 TP4001 TU601 TUNER IF PIN L608 (PATTERN SIDE) IC601 CP603 J4501 TP1002 3 pin TU1001 J4501 TP4501 SYSCON PWB L6006 IC6001 CP6001 IF PWB D2-5...
  • Page 31 ELECTRICAL ADJUSTMENTS (TV SECTION) J801 TP801 CRT PWB VR502 T501 FOCUS VOLUME FB401 SCREEN VOLUME TP401 MAIN PWB D2-6...

  • Page 32: Purity And Convergence Adjustments

    ELECTRICAL ADJUSTMENTS 4. PURITY AND CONVERGENCE 4-3: STATIC CONVERGENCE ADJUSTMENTS NOTE Adjust after performing adjustments in section 4-2. NOTE Receive the crosshatch pattern from the color bar Turn the unit on and let it warm up for at least 30 generator.

  • Page 33: Troubleshooting Guide

    TROUBLESHOOTING GUIDE (TV SECTION) (In case that there isn't a normal tension for time to do ( 1 ) that a power supply doesn't standby CD9001 every terminal) enter Is there output on the Voltage of C507 is Investigate R501 and F501. secondary of T501 it normal? dimensions or not?
  • Page 34 TROUBLESHOOTING GUIDE (In case that there is a normal tension for time to do ( 2 ) that a power supply doesn't standby CD9001 every terminal) enter Is the voltage 5V for Investigate D1006 . IC1006 36th pin or not? Is the voltage of IC1006 Investigate D1008.
  • Page 35 TROUBLESHOOTING GUIDE A voice isn't though an image appears Whether does a signal Whether does a signal Investigate IC4001 11th pin. come to IC352 6th pin come to IC601 1st pin or not? or not? Investigate IC601 peripheral circui. Investigate R517, D505 and Is the voltage of IC352 D509.
  • Page 36 TROUBLESHOOTING GUIDE A color doesn't adhere to it Whether is wave form of Investigate X601. IC601 38th pin normal or not? Whether is wave form of IC602 19th pin,20th pin and Investigate IC601. 21th pin normal or not? Investigate CRT PWB and a peripheral circuit.
  • Page 37 TROUBLESHOOTING GUIDE An image doesn't appear Is the voltage DC 5V for Investigate IC602 3rd pin. IC601 43th pin or not? Whether is a luminance signal early in IC602 Investigate IC601. 42th pin or not? Whether is a luminance Investigate IC4001. signal early in IC4001 52th pin or not? R, G, B signal out from...
  • Page 38 TROUBLESHOOTING GUIDE An only horizontal line appears Is the voltage DC 25V for Investigate C429 and D411 . IC401 6th pin or not? Investigate CRT, IC401 and a Is the voltage DC 25V for peripheral circuit. IC401 2nd pin or not? Whether does a video Investigate IC601.
  • Page 39 TROUBLESHOOTING GUIDE (VCR SECTION) PLAY SHUTS OFF Insert a cassette and push PLAY button. Does Playback change to Check TAPE LOADING, CAPSTAN Stop about 3 seconds DD UNIT and CYLINDER UNIT. later? Does Playback Check REEL SENSOR and change to Stop about CAPSTAN BELT.
  • Page 40 TROUBLESHOOTING GUIDE NO PLAYBACK PICTURE Is there voltage at pins Does E-E appear on the Check Power circuit. 12, 36 and 61of IC4001 5V? Monitor TV? Is there PB Y/C signal Check IC4001 and the connection of at TP4002 ? the CYLINDER.
  • Page 41 TROUBLESHOOTING GUIDE NO COLOR DURING PLAYBACK Does FM ENVELOPE Check IC4001. appear at TP4002? Check R4040, Q4006 and Does CHROMA signal peripheral circuit. appear at pin 52 of IC4001? Does CHROMA Check C4075, R4050 and the signal appear at pins peripheral circuit.
  • Page 42 TROUBLESHOOTING GUIDE PLAYBACK PICTURE IS NOISY (EVEN AFTER CLEANING HEADS) Is FM signal at TP4002 Replace CYLINDER UNIT. more than 200mVp-p? Is VIDEO waveform at pin Check pin 52 of IC4001 and 52 of IC4001 1Vp-p and peripheral circuit. are there any noise? Check pins 79 and 78 and Is there FM signal at pin 79 peripheral circuit.
  • Page 43 TROUBLESHOOTING GUIDE NO COLOR DURING SELF RECORDING AND PLAYBACK Does VCR signal Check J4501, J701 and VIDEO appear at pin 31 or 30 or input circuit. 28 of IC4001? Refer to section "NO COLOR DURING PLAYBACK". E-11...
  • Page 44 TROUBLESHOOTING GUIDE NO NORMAL AUDIO IN PLAYBACK MODE Is sound head on E-E ? Refer to section "NO E-E". Check AUDIO HEAD for debris of stains. Does Audio appear at Check that the connector from pin 11 of IC4001? AUDIO HEAD is fully inserted to CP4005.
  • Page 45 TROUBLESHOOTING GUIDE CAPSTAN DD MOTOR NOT ROTATING In playback, is the voltage at pin 5 of Check POWER circuit. CP1004 12V? Is the voltage at pin 8 of CP1004 5V? In playback, check the voltage at pin 3 of CP1004 is 2V or at Replace IC1006.
  • Page 46 TROUBLESHOOTING GUIDE AUDIO CAN NOT BE RECORDED Is there BIAS at pin 4 Is the voltage at pin 2 Check POWER BLOCK. of L4005 5V? of IC4001? L4005 is broken or shorted. Check peripheral circuit. Is there AUDIO signal at Check the circuit of 21 PIN and pins 7 or 8 or 9 of IC4001? TUNER.
  • Page 47 TROUBLESHOOTING GUIDE CASSETTE IN AND DOWN BUT UNIT HAS NO FUNCTIONS Does mode indicator Check LOADING MOTOR and the appear in Display? peripheral parts. Does VCR operate with Check IC1006. the remote control? Check OPERATION PWB. E-15...
  • Page 48 TROUBLESHOOTING GUIDE RECORDING MECHANISM WORKS, BUT NO VIDEO RECORDED FROM INPUT JACK OR TUNER Does video signal Check the circuit from VIDEO input appear at pin 28 or jack to IC4001 and from Tuner Pack 30 or 31 of IC4001? to IC4001.
  • Page 49 TROUBLESHOOTING GUIDE NO E-E (NO VIDEO AND AUDIO FROM TUNER) Is the voltage at pin Check Power PWB. 7 of TU601 5V? Is the voltage at pin 9 of TU601 30V? Is there waveform at pins Check IC601. 4 and 5 of TU601? Check TU601.
  • Page 50 TROUBLESHOOTING GUIDE CYLINDER NOT ROTATING DURING PLAYBACK AND RECORDING Check P. CON 12V line and Is the voltage at pin 2 of POWER BLOCK. CP1005 about DC12V? In playback, is the voltage at pin 5 of CP1005 about Check IC1006. DC1.2V? Check CYLINDER MOTOR.
  • Page 51 TROUBLESHOOTING GUIDE AUDIO SHAKES Replace AUDIO HEAD. Is AUDIO HEAD scratched? Does pin 9 of IC1006 output a 3.0Vp-p square Replace CAPSTAN DD MOTOR. wave? In playback, is the voltage Check peripheral components at pin 4 of CP1004 2.8V? of IC1006. Check AUDIO BLOCK.
  • Page 52 TROUBLESHOOTING GUIDE CASSETTE TAPE IS NOT ACCEPTED Does WORM GEAR of Check WORM GEAR of CASSETTE LOADING CASSETTE LOADING BLOCK. BLOCK activate? When cassette is not inserted ,is EOT BOT Check EOT, BOT, PHOTO PULSE at pin 2 of CP1006 SENSOR, pins 25 and 26 of IC1006.
  • Page 53 TROUBLESHOOTING GUIDE WHEN INSERTING CASSETTE, IT EJECTS IMMEDIATELY Does this same problem Defective CASSETTE or appear when using CASSETTE LOADING BLOCK. another cassette tape? When inserting a cassette, Replace EOT PHOTO does Emitter of EOT return TRANSISTORS. to LOW? Is pin 26 of IC1006 LOW? Check R1056 circuit.
  • Page 54 TROUBLESHOOTING GUIDE FF/REW DO NOT WORK When the FF/REW is pushed, Check pin 71 of IC1006 lines. does the PULSE appear at Replace IC1006. pin 71 of IC1006? Is the voltage change at Check pin 7 of CP1004 and pin 7 of CP1004 when peripheal circuit.
  • Page 55 TROUBLESHOOTING GUIDE TAPE LOADING IS OK, BUT UNLOADS IMMEDIATELY Is the voltage at pin 2 of Check Power circuit. Does CYLINDER rotate ? CP1005, UNREG 12V? Replace CYLINDER UNIT. Does TP4001 feed Does PG PULSE HEAD SWITCHING appear at pin 104 of PULSE signal 30Hz? IC1006? Replace IC1006.
  • Page 56 TROUBLESHOOTING GUIDE PLAYBACK PICTURE JITTERS VERTICALLY Does tracking noise appear in the picture? By adjusting the manual tracking UP/DOWN Check P/B ENVELOPE. buttons, will the noise disappear in the picture? Are GUIDE POSTS Adjust GUIDE POST height. the right height? Is PG SHIFTER Adjust PG SHIFTER.
  • Page 57 TROUBLESHOOTING GUIDE PLAYBACK PICTURE JITTERS HORIZONTALLY Is FG output level at pin Replace CYLINDER UNIT. 3 of CP1005 5Vp-p? Is the voltage at pin 5 of Replace IC1006. CP1005 1.2V? Replace CYLINDER UNIT. AUTO TRACKING DOES NOT OPERATE By manual tracking, does Check YCA, H/AMP circuit and the DC level at pin 13 of CYLINDER UNIT.
  • Page 58 TROUBLESHOOTING GUIDE WHEN PLAYBACK, FAST FORWARD OR REWIND MODE IS ACTIVATED, UNIT STOPS IMMEDIATELY Refer to section "CAPSTAN DD Does CAPSTAN DD MOTOR NOT ROTATING". MOTOR rotate? Is CAPSTAN BELT normal? Replace CAPSTAN BELT. Does REEL SENSOR PULSE Check Reel Sensor of Q1001 and signal appear at pin 69 of R1006.
  • Page 59 TROUBLESHOOTING GUIDE PLAYBACK PICTURE SHAKES Is FG Pulse output Replace CYLINDER MOTOR. level at pin 3 of CP1005 about 5Vp-p? Does pin 104 of IC1006 output Replace IC1006. a 5Vp-p square wave? In playback, is the voltage at pin 5 of CP1005 about 1.2V? Replace CYLINDER MOTOR.

  • Page 60: Ic Descriptions

    IC DESCRIPTIONS OEC0096B PORT PIN NAME DESCRIPTION SVSS SVSS Ground. CTLREF CTLREF OUT Output terminal for AMP REFERENCE. CTL(+) CTL(+) I/O Input and output terminal of Control Head. CTL(-) CTL(-) I/O Input terminal of Control Head. CTLBIAS CTLBIAS Input terminal of Control Bias. CTLFB CTLFB Input terminal for Control Feedback.
  • Page 61 IC DESCRIPTIONS OEC0096B PORT PIN NAME DESCRIPTION P61/RP1 VCR POWER_ON-H OUT For control of the user VCR-power switch ON/OFF. P60/RP0 CENT_LED OUT Output terminal for center LED control. P37/TMO TAB_SW Input terminal for judge the tape if it has TAB or not. P36/BUZZ CTL_MONITOR OUT Output terminal for control Monitor.
  • Page 62 IC DESCRIPTIONS OEC0096B PORT PIN NAME DESCRIPTION P85/COMP/B OUT Output sigmal of B for OSD. P86/EZTTRG CYL_SPEED_UP OUT Output terminal for correct cylinder during SLOW. P87/DPG Input terminal for DRUM PG signal. A.DFG Input terminal for DRUM FG signal. VIDEO_FF VIDEO_H.SW OUT Output terminal of signal Video head switching.

  • Page 63: Servo Timing Chart

    SERVO TIMING CHART IC1006 (OEC0096B) DPG 103 PIN DFG 104 PIN 24 Cycle CH 1 H. SW. P 105 PIN CH 2 V-SYNC (E-E) 15 PIN REC CTL (REC) 7 PIN V-SYNC (TRICK PB) 109 PIN • WAVEFORM CHANGES DEPENDED ON THE TAPE SPEED F2-1...

  • Page 64: System Switch Mode

    SYSTEM SWITCH MODE SLOW : SETTING SPEED TO SERVO : CAPSTAN FWD ROTATING LOADING DIRECTION DIRECTION : MECHANICAL MOVEMENT AND CAPSTAN ROTATING (FWD) : CAPSTAN RVS ROTATING : MECHANICAL MOVEMENT (NO CAPSTAN ROTATING) DIRECTION EJECTION UNLOADING STP3 R. SLOW F. SLOW PB/STP STP2 FF/REW...

  • Page 65: Semiconductor Base Connections

    SEMICONDUCTOR BASE CONNECTIONS DIODE CATHODE CATHODE ANODE ANODE 1SS133T-77 11E1-EIC 10ELS2N-TA1B2 SID1050CM EQ-552-F1T GBL06L-6177 MTZJ33B T-77 11EQS04N-TA1B2 21DQ09N-TA2B1 MTZJ5.6B T-77 11EQS04N-TA2B5 EG-01C RB721QT-77 11EQS04TA1B2 EG01Z-V0 SB10-03A3 11ES1N-TA1B2 RMPG06J-G3 1N4005E-6580-G23 RU2AM V1 RD12FB-T7 RU2YX-V1 28PIN 24PIN 100PIN 16PIN 8PIN 24PIN ET106 LA7567B HA118217F MM1234...
  • Page 66 SEMICONDUCTOR BASE CONNECTIONS TRANSISTOR 2SA1371(D,E)-AE DTC114TSTP 2SC4217(D,E)-RAC 2SA1037AKT146R,S RPI-352Q01R 2SD2499 2SA608KF-NP-AA DTC114ESTP 2SC2412KT146 R,S 2SB698(E,F)-AA DTC124EKT147 2SB892(S,T)-AE DTA124EKAT146 2SC1815Y(TPE2) DTC114EKAT146 2SC2271(D,E)-AE DTC114EKT147 2SC2909(S,T)-AA DTC114TKAT146 2SC3000-AA DTC143TKAT146 2SC3331(S,T,U)-A DTC144EKT147 2SC945(C)-T(P,Q) 2SD734(E,F)-AA PNA2604M010R RPI-301 G - 2...

  • Page 67: Micon/Operation

    TV BLOCK DIAGRAM V. OUTPUT IC401 LA78040 RECORD LUMINANCE SIGNAL TUNER VIDEO SIGNAL THERMAL DEFLECTION SIGNAL PROTECTION PLAYBACK LUMINANCE SIGNAL PUMP RECORD COLOR SIGNAL TUNER AUDIO SIGNAL R. SIGNAL PLAYBACK COLOR SIGNAL AUDIO SIGNAL(REC) G. SIGNAL AUDIO SIGNAL (PB) B. SIGNAL CHROMA IC601 Q405...
  • Page 68 Y/C/AUDIO/HEAD AMP BLOCK DIAGRAM VPS/PDC IC4002 LC74793/JM RECORD LUMINANCE SIGNAL SYNC IN PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL X'tal IN PLAYBACK COLOR SIGNAL TUNER VIDEO SIGNAL AUDIO SIGNAL(REC) AUDIO SIGNAL (PB) TUNER AUDIO SIGNAL Q4006 BUFFER Y/C/AUDIO/CCD/H.AMP IC4001 HA118217F Q4008 X4001 4.433619MHz BUFFER...
  • Page 69 MICON/OPERATION BLOCK DIAGRAM SYSCON/TIMER/SERVO SW1001 IC1006 OEC0096B DEGAUSS_H DEGAUSS_H TAB SW POWER FAIL POWER_FAIL (DC) AT+5.6V MS SEN-A EXT_IN_L EXT_IN_L IF/21PIN/ MS_SEN A MO_SYNC IN IN/OUT/ Q1009 MO_SYNC POWER AV_1 MS SEN-B AV_2 MS_SEN B Q1003 TUNER_MUTE TU_AUDIO_MUTE_H Q1002 C SYNC V.SYNC MS SENS CTL SENSOR SW...
  • Page 70 IF/21PIN/IN/OUT/POWER BLOCK DIAGRAM IC6001 LA7567B TU1001 MO_SYNC MICON/ OPERATION RECORD LUMINANCE SIGNAL CP6001 PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL PLAYBACK COLOR SIGNAL TU AUDIO TUNER VIDEO SIGNAL TU VIDEO REC_TU_V AUDIO SIGNAL(REC) Q6005 AUDIO SIGNAL (PB) TUNER AUDIO SIGNAL PRE AMP REC_TU_AU R.
  • Page 71 T'TEXT BLOCK DIAGRAM Q861 MONITOR_V BUFFER 21_B IF/21PIN/ IN/OUT 21_R /POWER 21_G D852 21_Y TRIPLE ANALOG MPXER IC853 MM1234 DECODER DATA SLICER IC851 ET106 IC852 Q855 ET317 BUFFER VIDEO TSIG SSIG Q852 CSIG GREEN GREEN TDATA 13 TDATA BUFFER TEXT_B TCLK 11 X851 12 TCLK...

  • Page 72: Printed Wiring Boards (Operation/Deck

    PRINTED WIRING BOARDS OPERATION SOLDER SIDE SW795 W814 R763 W004 C351 C353 C751 B702 W806 CD750_2 CD351_2 R772 R351 SW797 SW796 SW791 SW794 SW750 D791 R771 OS753 D797 W002 R762 R766 SW792 SW793 D796 D793 W807 C355 W812 C702 R761 R754 W804 R773...

  • Page 73: Operation Schematic Diagram

    OPERATION SCHEMATIC DIAGRAM (OPERATION PWB) FROM/TO 21PIN I/O CD750_2 (CP755) CH2A014A REMOCON OUT AT+5V POWER ON LED OTPB LED KEY A T-REC LED REC LED KEY B ON TIMER LED L005 Vout HF57T18.5*10*10 R771 R772 R773 R774 OS753 PIC-28143TH5 1K 1/4W 1.5K 1/4W 2.7K 1/4W 5.6K 1/4W...

  • Page 74: Deck Schematic Diagram

    DECK SUB SCHEMATIC DIAGRAM (DECK PWB) LOADING MOTOR M101 S105 BOT SENSOR Q101 S106 RPT-38PB113 S101 S102 S103 S104 FROM/TO MICON CP101 52044-0445 LDM+ LDM- PWB550 VE8851 CAUTION: SINCE THESE PARTS MARKED BY ATTENTION: LES PIECES REPAREES PAR UN ETANT NOTE: NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME THE DC VOLTAGE AT EACH PART WAS...
  • Page 75 PRINTED WIRING BOARDS SYSCON W936 C4201 R1011 C1005 C4204 C4203 C604 W803 C4113 C637 R647 C6023 W915 R6021 C6001 Q356 IC4002 C6007 C5536_1 Q351 R4052 R6002 R1091 R5516_1 R356 C4107 R6016 C6009 C370 IC5502_1 C4103 R4053 C5531_1 C366 C1092 R905 R887 C6010 C1096...

  • Page 76: Printed Wiring Boards Syscon If

    PRINTED WIRING BOARDS SYSCON W001 R6001_1 W821 C6002 CF6008 W003 C6003_1 CF6001 L6008 L6001 CF6007 W004 W005 C6004 IC6001 C6011 W009 C6014 CF6005...
  • Page 77 PRINTED WIRING BOARDS SYSCON W936 C4201 R1011 C1005 W001 C4204 C604 C4203 W803 R6001_1 W821 C4113 C6002 C637 C6023 R647 CF6008 W915 R6021 W003 C6001 C6003_1 Q356 CF6001 IC4002 L6008 L6001 C6007 C5536_1 CF6007 Q351 R6002 R4052 W004 R1091 R5516_1 R6016 C6009 R356...

  • Page 78: Y/C/Audio/Head Amp Schematic Diagram

    Y/C/AUDIO/HEAD AMP SCHEMATIC DIAGRAM BUFFER Q4008 (SYSCON PWB) 2SC2412K L4002 100uH 0305 FROM/TO POWER Y/C_VIDEO BUFFER Q4006 REC_TU_V R4040 2SA1037AK REC_TU_AU-L W988 Y/C_AUDIO W990 Q4007 R4055 2SC2412K Y/C_AUDIO V.ENV TP4002 L4008 R4053 R4054 JWF-50K-1 R4065 C4035 W947 P.CON+9V 560K 330K 1K 1/4W 0.01 B P.CON+5V_C...

  • Page 79: Micon Schematic Diagram

    MICON SCHEMATIC DIAGRAM (SYSCON PWB) D1006 FROM/TO POWER SB10-03A3 D1010 R1096 AT+5.6V SB10-03A3 SCL_B C1030 0.1 F MO_SYNC VCR_POWER_H AV_1 X1001 AV_2 10MHz C1060 C1076 FROM/TO Y/C/A/H.AMP 0.1 B AV_3 D_V_SYNC 6.3V P.CON+5V_D P.CON+5V_C V.REC_ST_H L1005 100uH REC_AFT VV_H CAP_VCO 2FSC_A REC_AGC_CTL C1047...

  • Page 80: Power Schematic Diagram

    POWER SCHEMATIC DIAGRAM (SYSCON PWB) FROM/TO Y/C/A/H.AMP P.CON+5V_C P.CON+9V P.CON+5V DRIVER Q1006 Y/C_VIDEO 2SB698 D1020 REC_TU_V AT+5.6V 5V REG. 5V REG. Y/C_AUDIO 11EQS04 IC1003 KIA7805API IC1004 KIA7805API REC_TU_AU-L R1065 FROM/TO MICON P.CON+5V[SENSOR] P.CON+5V_C AT+5.6V AT+12V CAP_VCO P.CON+5V SW (LDM) Q1007 MOTOR_GND DTC114TKA VCR_POWER_H...

  • Page 81: 21Pin/In/Out Schematic Diagram

    21PIN/IN/OUT SCHEMATIC DIAGRAM (SYSCON PWB) FROM/TO MICON ON_TIM/PLAY_LED FROM/TO SOUND AMP KEY_B SOUND_GND REC_LED SOUND_L+ T-REC_LED SP_OUT_L KEY_A OTPB_LED W857 REMOCON_IN POWER ON SW W822 STANDBY_H Q4201 DTC114EK TUNER_ON/OFF FROM/TO POWER AV_1 FRONT_V_IN D4202 AV_2 AT+5.6V C4201 EXT_IN_L 11ES1N TU_AUDIO_MUTE_H 0.001 CH P.CON+9V MONITOR_A-L_B...

  • Page 82: Chroma/If Schematic Diagram

    FROM/TO MICON CHROMA/IF SCHEMATIC DIAGRAM TEXT-H M.P.OFF_H_A AFC_OFF (SYSCON PWB) TEXT_Y VCR_POWER_H TV_POWER_H R659 HD_A R667 VD_A R.OUT G.OUT B.OUT DEGAUSS_H POWER_FAIL[DC] FROM/TO SOUND AMP TUNER_CTL R669 100 AGC_M POWER_FAIL[DC] SOUND+B Q611 W952 DTC143TKA SOUND_GND W953 IIC_OFF BUFFER AFT_M Q603 2SC2412K TEST POINT R673...

  • Page 83: Sound Amp Schematic Diagram

    SOUND AMP SCHEMATIC DIAGRAM (SYSCON PWB) SOUND AMP IC352 AN7523 HS352 763WAA0014 FROM/TO 21PIN I/O W812 FROM/TO CHROMA/IF SOUND_L+ SOUND_GND SOUND_GND R357_1 C372 SP_OUT_L SOUND+B 1 3W 1000 POWER_FAIL[DC] FROM/TO POWER R351 C356 MONITOR_A-L_A 2.2K C354 W939 1000 W810 TO SPEAKER CP354 CD354_1 SPEAKER...

  • Page 84: T'text Schematic Diagram

    T’TEXT SCHEMATIC DIAGRAM (SYSCON PWB) L857 100uH FROM/TO CHROMA/IF TEXT_SYNC W905 BUFFER Q861 2SC2412K FROM/TO POWER W876 MONITOR_V P.CON+9V D854 L851 AT+5.6V 10uH 11EQS04N C894 P.CON+5V_C P.CON+5V_A 16V KA C857 SYNC BUFFER R887 6.3V W914 W880 Q853 2SC2412K DECODER IC851 ET106 W850 FRAG2...

  • Page 85: Regulator Schematic Diagram

    REGULATOR SCHEMATIC DIAGRAM (SYSCON PWB) FROM/TO DEFLECTION CD9002 (CP403) CH01814A 9V REG IC9001 KIA7809API CD9003 CH01011A DRIVER 12.0 Q9001 2SB892 R9001 18K 1/4W FROM/TO TV POWER CD9001 (CP810) CH28112A R9007 FROM/TO POWER Q9002 2.2K 1/4W 5V REG. 2SC1815Y IC9003 AT+12V CP9002 (CP810) KIA7805API...

  • Page 86: If Schematic Diagram

    IF SCHEMATIC DIAGRAM (IF PWB) C6004 CF6005 TPS6.0MB C6005 0.01 B L6007 R6019_1 R6020 15uH 330 1/4W L6006 360K042 VIDEO NC 1.7 C6006 0.01 B L6001 C6007 L6003 W819 BUFFER Q6001 22uH W806 68P CH 2.7uH 2SA608KF-NP C6019 0.01 B C6015 0.01 B L6008...

  • Page 87: Printed Wiring Boards (Main/Crt/Power Sw

    PRINTED WIRING BOARDS MAIN/CRT/POWER SW SOLDER SIDE CP820 R509 W012 D410 Q509 R520 R423 Q405 W010 R524 Q501 W824 R456 CP810_1 W817 C416 C520 R460 D530 R518 R449 Q508 C417 C525 D534 C438 W043 Q503 R447 CP403 W816 C527_1 D512 D508 T401 C423...

  • Page 88: Tv Power Schematic Diagram

    TV POWER SCHEMATIC DIAGRAM (MAIN PWB) DEGAUSS_H FROM/TO DEFLECTION RELAY DRIVE Q504 D516 2SC1815Y DEGAUSS_H 1SS133 SOUND+B TV.POWER_H P.CON+125V POWER_FAIL AT+125V VCR.POWER_H RY501 SOUND_GND ALKS321 DEGAUSS C516 W830 COIL L503 500V 470P CP502 8F140018 R501 TV-50P-02-A1 W810 R517 D505 SOUND+B 2.2 7W 21DQ09N 0.22 3W...

  • Page 89: Deflection Schematic Diagram

    DEFLECTION SCHEMATIC DIAGRAM (MAIN PWB) V.OUTPUT IC401 LA78040 THERMAL PROTECTION PUMP UP TO DY 25.7 14.1 26.2 CP401 B05B-DVS W805 R427 R425 8.2K 1/4W 8.2K 1/4W L402 ELH5L4112 R413_1 R412 R416 4.7K 1/4W C410 C409 10K +-1% 27K 1/4W R448 0.01 M 0.001 M 1K 1W...

  • Page 90: Crt Schematic Diagram

    CRT SCHEMATIC DIAGRAM (CRT PWB) 132.9 104.1 132.8 132.5 TP801 FROM CHROMA/IF R802 CP850 (CD850) 12K 2W 8283_0512_00_000 J801_1 HPS3200-010501 R807 CUT OFF G.OUT 132.5 2.7K 1/4W R.OUT RED AMP B.OUT Q804_1 2SC4217 C809 TP802 270P B R811 R808 270 1/4W 2.7K 1/4W R805 12K 2W...

  • Page 91: Interconnection Diagram

    INTERCONNECTION DIAGRAM TM101 REMOCON SENSOR J351 OS753 IF PWB J701 PWB350 VE6778 Vout OPERATION PWB PWB030 TEXA19 HALL MAIN ROTOR SENSOR COIL MAGNET FG SENSOR HALL HALL SWITCH LOGIC CP1004 MOTOR GND I LIMIT CAPSTAN DD UNIT CAP.M/F/R DECK MECHA ASS’Y VCC(5V) M2001 SYSCON PWB...
  • Page 92 WAVEFORMS Y/C/AUDIO/HEAD AMP TV POWER MICON 6 20V 20µs/div 11 PB 16 POWER ON 21 POWER ON 26 PB 1 5V 0.1ms/div 2V 10ms/div 200mV 10µs/div 1V 50ns/div 50mV 0.5ms/div DEFLECTION 2 5V 50µs/div 7 20V 20µs/div 12 PB 17 POWER ON 27 PB 22 POWER ON 10mV 5ms/div...

  • Page 93: Waveforms

    WAVEFORMS POWER 31 REC 36 POWER ON 41 POWER ON 0.5V 10µs/div 0.5V 20µs/div 200mV 0.1µs/div 32 REC 42 POWER ON 37 POWER ON 200mV 10µs/div 0.5V 0.5ms/div 0.5V 20µs/div 33 REC 38 POWER ON 43 POWER ON 0.5V 10µs/div 0.5V 10ms/div 10mV 10µs/div CHROMA/IF...
  • Page 94 WAVEFORMS 21PIN IN/OUT 21PIN IN/OUT 46 POWER ON 52 POWER ON 0.5V 10µs/div 20mV 1ms/div 47 REC 0.5V 10µs/div 48 REC 100mV 0.5ms/div SOUND AMP 50 REC 0.5V 0.5ms/div T'TEXT POWER ON 200mV 50ns/div NOTE: The following waveforms were measured at the point of the corresponding balloon number in the schematic diagram.

  • Page 95: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW J801 PWB110 (CRT PWB) L503 V801 PWB070 (MAIN PWB) FB401 PWB340 (POWER SW PWB) SP352 SW501 PWB030 (OPERATION PWB) SP351 K1-1...
  • Page 96 MECHANICAL EXPLODED VIEW PWB350 (IF PWB) TU1001 ANT601 TU601 J4501 PWB120 (SUB POWER PWB) PWB010 (SYSCON PWB) K1-2...

  • Page 97: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY REF. NO. PART NO. DESCRIPTION Q'TY S5-54A-3G7-200 CABI,FRONT ASSY ---- FELT SHEET ---- SHIELD,CASE HEAD AMP ---- FELT SHEET ---- PLATE,EARTH-SYSCON ---- FELT SHEET S3-5WP-D06-800 BUTTON,REC S5-OP7-000-360 HOLDER,EOT SENSOR ---- HEAT SINK S5-1WS-A00-160 COVER,TRANS S7-1WP-A02-440 PLATE,JACK...

  • Page 98: Chassis Exploded View (Top View)

    CHASSIS EXPLODED VIEW (TOP VIEW) M2003 UN4001 H5001 H5002 M101 PWB550 (DECK PWB ASS'Y) NOTE: Applying positions AA, AB, AC and BA for the CLASS PART NO. MARK grease or oil are displayed for this section. GREASE G-555G Check if the correct grease or oil is applied for MG-33 each position.

  • Page 99: Chassis Exploded View (Bottom View)

    CHASSIS EXPLODED VIEW (BOTTOM VIEW) M2001 NOTE: Applying positions AA, AB, AC and BA for the CLASS PART NO. MARK grease or oil are displayed for this section. Check if the correct grease or oil is applied for GREASE G-555G each position.

  • Page 100: Chassis Replacement Parts List

    CHASSIS REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY REF. NO. PART NO. DESCRIPTION Q'TY ---- DECK ASSY A57054A420A S5-OP8-003-360 SPR,CAP BRAKE (S) S5-OP8-003-420 SPRING,LOCKER(S) S5-OA5-000-220 AHC ASS'Y S5-OP8-003-260 SPR,LINK S5-OP2-002-900 BELT,CAPSTAN (S) S5-OP8-003-280 SPR,DAMPER S5-OP9-007-100 LEVER,REC S5-OP8-003-300 SPR,RING S5-OP5-000-830 BASE,AC HEAD S5-OP8-003-370 SPR,SS BRAKE (S) S5-OP8-003-240 SPR,AC HEAD...

  • Page 101: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST REF.NO PART NO. DESCRIPTION REF.NO PART NO. DESCRIPTION C1032 87-016-088-040 CAP,E 220-6.3V SYSCON PWB ASS'Y C1033 87-010-404-080 CAP,E 4.7-50V C1037 S0-2LU-047-1M0 CAP,E 470-6.3V *** RESISTORS *** C1042 S0-2LU-047-1M0 CAP,E 470-6.3V C1047 87-010-378-080 CAP,E 10-16V R357 S3-X28-B01-0J0 RES,M 1-3W C1048 87-010-404-080...
  • Page 102 ELECTRICAL REPLACEMENT PARTS LIST REF.NO PART NO. DESCRIPTION REF.NO PART NO. DESCRIPTION D1006 S2-3U1-003-A30 DIODE,SB10-03A3 Q1015 89-324-122-080 TR,2SC2412KT D1007 87-020-465-010 DIODE,1SS133T Q1016 89-324-122-080 TR,2SC2412KT D1008 87-017-931-010 ZENER,MTZJ5.6B Q1017 S0-001-003-800 PHOTO TR,PNA2604M010R D1009 87-020-465-010 DIODE,1SS133T Q1021 89-324-122-080 TR,2SC2412KT D1010 S2-3U1-003-A30 DIODE,SB10-03A3 Q1022 89-110-372-080 TR,2SA1037AK...
  • Page 103 ELECTRICAL REPLACEMENT PARTS LIST REF.NO PART NO. DESCRIPTION REF.NO PART NO. DESCRIPTION L4504 87-003-102-010 COIL,10UH L5503 S2-1B7-310-2K0 COIL,1000UH L004 S2-A6A-8A0-A10 CORE,FERRITE HF57T18.5*10*10 L005 S2-A6A-8A0-A10 CORE,FERRITE HF57T18.5*10*10 *** JACKS *** *** JACKS *** J4501 S6-3G1-000-370 SOCKET,21PIN 035_0_9985_0 J351 S6-0G1-310-140 RCA JACK HTJ-035-28A *** SWITCHES *** J701 S6-021-010-200...
  • Page 104 ELECTRICAL REPLACEMENT PARTS LIST REF.NO PART NO. DESCRIPTION REF.NO PART NO. DESCRIPTION C514 S0-JLY-R7H-3K0 CAP,0.0022-2KV C516 87-012-376-010 CAP,CER 470PF-500V *** COILS *** C517 S0-JLY-R7G-3K0 CAP,0.0018-2KV C518 87-012-376-010 CAP,CER 470PF-500V B504 S2-4AT-036-550 CORE,BEADS BL01RN1-A63T6 C519 87-012-376-010 CAP,CER 470PF-500V B505 S2-4A8-407-C30 CORE,BL02RN2-R62T2 C520 87-010-271-080 CAP,E 1000-16V...
  • Page 105 ELECTRICAL REPLACEMENT PARTS LIST REF.NO PART NO. DESCRIPTION REF.NO PART NO. DESCRIPTION L801 S2-167-D10-1K0 COIL,100UH *** OTHERS *** *** CONNECTORS *** CD502 S6-CPU-201-2A0 CORD CONN CPU2012A CP850 S6-9E2-501-290 CONN,PWB SIDE IF PWB ASS'Y *** FUSES *** *** CAPACITORS *** CP803B S6-7R1-050-190 HOLDER,WIRE 51052-0500 C6002...
  • Page 106 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 737004 Printed in Singapore...

Table of Contents
