WHAT'S IN THE PACKAGE

The IRT730K comes in a soft pouch inside a box along with a "K" type bead thermocouple
probe, a "9V" battery and this user's manual.

PRODUCT OVERVIEW

Fig. 1 shows all controls, indicators, connectors and other physical features of the IRT730K.
Fig. 2 shows all possible indications on the unit's LCD. Familiarize yourself with the positions of
all controls and connectors and the meaning of all display indications and icons before moving
on to the Setup Instructions and Operating Instructions.
1. Laser pointer
2. Infrared sensor
3. Measurement trigger
4. Battery compartment
5. Jack for spade-type
thermocouple probe
6. MODE button
7. / (laser/backlight) button
8. °C/°F button
9. LCD
10. Laser identification/certification/
warning/safety labels
(on left side of unit);
see below
4
9
8
7
6
Fig. 1. All controls, indicators, connectors
and other physical features of the IRT730K
10
1
2
3
4
5
