LC-6500N
EXERCISE BIKE
Console Assembly
AK17-00098-0001 Eng/Eng
AK17-00098-0002 Eng/Met
AK17-00098-0003 Ger/Met
AK17-00098-0006 Jap/Met
AK17-00098-0007 Frn/Met
AK17-00098-0004 Spn/Met
AK17-00098-0005 Swe/Met
AK17-00098-0008 Itl/Met
AK17-00098-0009 Dut/Met
Seat
0017-00009-0746
Seat w/Seatpost
AK18-00183-0000
Seatpost
AK18-00157-0000
Seat Pin w/Molded Knob
OK17-01208-0000
Cap
OK17-01018-0000
Leg Levelers(2)
0017-00009-0795
9 Volt Battery
0017-00003-0757
Shroud w/Decal(LT)
AK18-00079-0001
Pedal w/Strap(LT)
AK17-00189-0002
Foot(2)
OK17-01033-0000
1 of 2
GE09-00008-XXXX
SN # 450-474, 718107-727066
Overlay Bezel
AK18-00087-0001 Eng/Eng
AK18-00087-0002 Eng/Met
AK18-00087-0003 Ger/Met
AK18-00087-0006 Jap/Met
AK18-00087-0007 Frn/Met
AK18-00087-0004 Spn/Met
AK18-00087-0005 Swe/Met
AK18-00087-0008 Itl/Met
AK18-00087-0009 Dut/Met
Handlebar
AK17-00091-0000
Stabilizer Bar
SK18-00070-0000
Console Case
OK18-01243-0001
Front Cap
OK18-01156-0001
Shroud w/Decal(RT)
AK18-00078-0001
Pedal w/Strap(RT)
AK17-00189-0001
Revision Date: 8/24/98
Advertisement
Related Manuals for Life Fitness LC-6500N
Summary of Contents for Life Fitness LC-6500N
- Page 1 LC-6500N EXERCISE BIKE Console Assembly AK17-00098-0001 Eng/Eng AK17-00098-0002 Eng/Met AK17-00098-0003 Ger/Met AK17-00098-0006 Jap/Met AK17-00098-0007 Frn/Met AK17-00098-0004 Spn/Met AK17-00098-0005 Swe/Met AK17-00098-0008 Itl/Met AK17-00098-0009 Dut/Met Seat 0017-00009-0746 Seat w/Seatpost AK18-00183-0000 Seatpost AK18-00157-0000 Seat Pin w/Molded Knob OK17-01208-0000 OK17-01018-0000 Leg Levelers(2) 0017-00009-0795 Foot(2)
- Page 2 LC-6500N EXERCISE BIKE Poly V-Belt 0017-00009-0735 Pulley w/Shaft AK17-00036-0001 Crankarm w/Sprocket SK18-00019-0001 Crankarm (only) OK18-01281-0000 Tabbled Lockwasher OK18-01280-0000 Master Link Assembly GK18-00004-0002 GE09-00008-XXXX SN # 450-474, 718107-727066 Main Cable Assembly AK17-00143-000 Freewheel Gear Assembly AK41-00023-0000 Alternator Control Assembly AK17-00103-0000 Drive Chain...
