SLIVE -U Manual

SLIVE Self-powered AM/FM/WB Radio with
Flashlight and USB Smart Phone Charger
SLIVE-4U
Thank you for purchasing our product.
Please read the instruction manual before use.
This manual contains important information and must be retained.
To avoid casualties and property losses by inappropriate usage of this
product, please read and follow the instruction and guidance.
• To reduce the risk of fire or shock hazard,
do not expose this product to rain
• Do not place this product near fire,
heat or any high temperature circumstances
• Do not place this product directly under sunlight
• Do not touch this product with wet hand or expose it to water
• Do not expose this product in dusty and smoky environment
• Do not expose this product in environments that contain
corrosive gas such as sulfurous acid gas, sulfured hydrogen,
chlorine and ammonia, etc
• Do not use this product in extreme heat; also avoid using it when
temperature is excessively low or volatile
• Do not place this product in unstable surface or area
• Do not stare into LED or view LED directly with optical instruments
• Only use recommended batteries
• Batteries should not be inserted with wrong polarities
• Do not heat, disassemble, short-circuit or dispose battery in fire
• Do not use different types of batteries;
new and used AAA batteries should not be mixed
• Take out batteries if not using the product for more than a month
• Battery overheating, leaking, or rupture could cause injuries
EXCEPTION CLAUSE:
• SLIVE or SLIVE direct is free from responsibility for damages or
incidents caused by earthquake, thunder, flood, windstorm,
fire, third party action, accident, or inappropriate usage.
• SLIVE or SLIVE direct is free from responsibility for damages
resulted from not following the operation guidance in the
instruction manual.
V O
L U
M E
O F
F

1. FEATURES

• AM(530KHz-1700KHz),FM(88MHz-108MHz),
WB(162.400MHz 162.425MHz 162.450MHz 162.475MHz
162.500MHz 162.525MHz 162.550MHz,7 channels)
• Output: 100mW
• Emergency Light
• Super bright LED light
• Emergency siren
• Build-in rechargeable battery
• IS-Power Technology
• USB Device Charger
• Dimension: 133mm × 77mm×40mm
• Net Weight: 247g
• Optional power source: 3 AAA batteries (not included)
• Optional Accessories: USB cable

2. CONTROL LOCATION

FM ANTENNA
SIREN SWITCH
AM/FM/WB SWITCH
LED SWITCH
VOLUME SWITCH
V O
LU
M E
O F
F
LED LIGHT
SPEAKER
POWER INDICATIOR LIGHT
AM FM INDICATIOR LIGHT
TUNNING
HAND STRAP HOLE
HAND STRAP
USB DEVICES CHARGING PLUG
USB PLUG
EARPHONE JACK

3. POWER SOURCE

Any one option of power source alone could power this product.
HAND CRANK POWER WITH BUILD-IN BATTERY
Crank the handle to charge build-in battery or USB device
1. Pull out the cranking handle
2. Crank handle to start charging
3. The optimal speed is 150RPM per minute
4. Volume switch should be off
5. LED light switch should be off
6. Siren switch should be off
NOTE:
In order to maximize the build-in battery lifetime,
battery should be recharged at least twice a year.
Recharge the battery before draining all the energy from the battery.
USB DEVICE CHARGER
1. When the product is charged by USB device charger,
power indicator light will turn red when it is charging.
When charging completes, power indicator light will turn green
2.When LED switch is set to "AUTO" and device disconnected from
external power(power outage):
LED will be turned on automatically. Also,
LED will be turned off automatically after 10 minutes.
CRANK HANDLE
RECHARGEABLE BATTERY COVER
BATTERY SWITCH
BATTERY COVER
