Page 1 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each adjustment before driving, etc.
Page 2: Table Of Contents
TABLE OF CONTENTS For your information....... 8 Operation of Reading this manual ....12 each component How to search......13 Pictorial index ......14 3-1. Key information Keys........90 For safety and security 3-2. Opening, closing and locking the doors Smart key system ....
Page 3 4-5. Using the driving support Driving systems Cruise control ....194 Dynamic radar cruise 4-1. Before driving control......198 Driving the vehicle..... 142 Driving mode select Cargo and luggage.... 153 switches......213 Vehicle load limits ..... 156 Driving assist systems ..215 Trailer towing.....
Page 4 TABLE OF CONTENTS 5-4. Other interior features Interior features Sun visors and vanity mirrors ......267 Clock........268 5-1. Using the air conditioning Outside temperature system and defogger display ......270 Automatic air conditioning Power outlets..... 271 system......242 Seat heaters/seat Rear window and outside ventilators ......
Page 5 Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers... 380 the vehicle exterior..302 If your vehicle has to Cleaning and protecting be stopped in an the vehicle interior... 306 emergency....... 381 6-2.
Page 6 TABLE OF CONTENTS Vehicle specifications Index 8-1. Specifications What to do if... (Troubleshooting)..... 478 Maintenance data (fuel, oil level, etc.) ..430 Alphabetical index ...... 484 Fuel information ....439 Tire information ....442 8-2. Customization Customizable features ..455 8-3.
Page 7 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 8: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 9 ● Usage of data collected through Safety Connect (U.S. mainland only) If your Toyota has Safety Connect and if you have subscribed to those ser- vices, please refer to the Safety Connect Telematics Subscription Service Agreement for information on data collected and its usage.
Page 10 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 11 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 12: Reading This Manual
Reading this manual CAUTION: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 13: How To Search
How to search ■ Searching by name • Alphabetical index ..P. 484 ■ Searching installation position • Pictorial index....P. 14 ■ Searching by symptom or sound • What to do if... (Troubleshooting) ..P. 478 ■ Searching by title • Table of contents .....P. 2 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 14: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ......... . . P. 111 Locking/unlocking .
Page 15 Pictorial index Windshield wipers ....... . . P. 183 Precautions against winter season ..... P. 236 Precautions against car wash .
Page 16 Pictorial index ■ Instrument panel Engine switch........P. 159 Starting the engine/changing the modes .
Page 17 Pictorial index Multi-information display ......P. 80 Display ..........P. 80 When the warning messages are displayed .
Page 18 Pictorial index ■ Switches Driving position memory switches ....P. 120 Emergency flasher switch ......P. 380 PCS OFF switch .
Page 19 Pictorial index Audio remote control switches Paddle shift switches ......P. 166 Telephone switches Talk switch “DISP”...
Page 20 Pictorial index ■ Interior SRS airbags ........P. 34 Inside lock buttons .
Page 21 Pictorial index Power outlets ........P. 271 Power outlet .
Page 22 Pictorial index Auxiliary box ........P. 260 Moon roof switches .
Page 23 For safety and security 1-1. For safe use Before driving...... 24 For safety drive ....26 Seat belts ......28 SRS airbags......34 Front passenger occupant classification system ..44 Safety information for children ......50 Child restraint systems..51 Installing child restraints..
Page 24: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 25 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 26: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 27 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 129, 131) CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ●...
Page 28: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 29 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 30 If your seat belts cannot be fastened securely because they are not long enough, a personalized seat belt extender is available from your Toyota dealer free of charge. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 31 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 32 Seat belt pretensioners If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. ■ Adjustable shoulder anchor Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 33 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 34: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 35 1-1. For safe use SRS airbag system components Front impact sensors Side impact sensors (rear) Knee airbags Driver airbag Side impact sensors (front Driver’s seat belt buckle doors) switch Seat belt pretensioners and SRS warning light force limiters Front passenger’s seat belt Front passenger airbag buckle switch Front side airbags...
Page 36 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 37 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 38 1-1. For safe use CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 39 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes are damaged or cracked, have them replaced by your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 40 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 41 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 42 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 43 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ●...
Page 44: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for the front passenger. CTY11AX056 SRS warning light Seat belt reminder light...
Page 45 1-1. For safe use Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat...
Page 46 1-1. For safe use ■ Child restraint system with infant “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag Devices...
Page 47 1-1. For safe use ■ There is a malfunction in the system “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 48 1-1. For safe use CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 49 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 50: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 51: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 52 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/con- Forward facing  Convertible   vertible seat seat Booster seat ...
Page 53 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 54 1-1. For safe use CAUTION ■ When children are in the vehicle Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 55: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 56 1-1. For safe use Installation with LATCH system Adjust the head restraint to the downmost position. (P. 125) Widen the gap between the seat cushion and seatback slightly. Rear left seat only: Slide the rear center seat belt to the side to prevent it from getting pinched in the lower anchor- age.
Page 57 1-1. For safe use  Type B Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: symbol child restraint system indicates the...
Page 58 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 59 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 60 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 61 1-1. For safe use ■ Booster seat Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 62 1-1. For safe use Child restraint systems with a top tether strap Adjust the head restraint to the downmost position. (P. 125) Secure the child restraint sys- tem using the seat belt or LATCH anchors. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 63 1-1. For safe use CAUTION ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (P. 30) ■...
Page 64 1-1. For safe use CAUTION ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child’s shoulder. The belt should be kept away from the child’s neck, but not so that it could fall off the child’s shoulder.
Page 65: Exhaust Gas Precautions
Keep the trunk lid closed. ● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 66: 1-2. Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 67 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system  For vehicles sold in the U.S.A. FCC ID: NI4TMIMB-3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 68: Alarm
1-2. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote control or mechanical key.
Page 69 1-2. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type alarm system. ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ●...
Page 70: Theft Prevention Labels (U.s.a.)
1-2. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 71: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......72 Gauges and meters .... 77 Multi-information display ..80 Fuel consumption information ......86 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 72: Instrument Cluster Warning Lights And
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 73 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Brake system warning Slip indicator (P. 390) light (P. 388) (U.S.A.) Brake system warning Open door warning light light (P. 388) (P. 391) (Canada) Charging system warn- Low fuel level warning...
Page 74 There may be a mal- function in a system if the lights do not come on, or do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate a malfunction.
Page 75: Indicators
2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Automatic high beam (P. 169) indicator (P. 176) (if equipped) Headlight indicator Eco drive mode indicator (P. 172) (P. 213) (U.S.A.) Tail light indicator Sport mode indicator...
Page 76 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 77: Gauges And Meters
2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on where the vehicle is sold. Tachometer Displays the engine speed in revolutions per minute Multi-information display Presents the driver with a variety of driving-related data (P. 80) Speedometer Displays the vehicle speed Fuel gauge...
Page 78 2. Instrument cluster Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances independently.
Page 79 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter ■ The meters and display illuminate when The engine switch is in IGNITION ON mode. ■ The brightness of the instrument panel lights ●...
Page 80: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of driv- ing-related data. ● Distance to empty (P. 81) ● Average fuel economy (P. 81) ● Current fuel economy (P. 82) ● ECO Drive Level (P. 82) ●...
Page 81 2. Instrument cluster Trip information ■ Switching the display Items displayed switched pressing “DISP” button. ■ Distance to empty Displays the estimated maxi- mum distance that can be driven with the quantity of fuel remaining. • This distance computed based on your average fuel con- sumption.
Page 82 2. Instrument cluster ■ Current fuel economy Displays the current rate of fuel consumption. ■ ECO Drive Level Suggests driving level based on acceleration. All green suggests the status of the most Eco-friendly driv- ing. All blue suggests the status of the least Eco-friendly driv- ing.
Page 83 2. Instrument cluster Setting up the displays ■ Customizable items Item Default setting Customized setting Digital speedometer Units (vehicles without English Metric a navigation system) Turn-by-turn naviga- tion (vehicles with a navigation system) Eco Driving Indicator Light ■ Changing the settings While the vehicle is stopped, press the “DISP”...
Page 84 2. Instrument cluster Press and hold the “DISP” but- ton to select the desired setting. Press and hold the “DISP” but- ton after selecting the “EXIT” by pressing the “DISP” button. The display goes back to step ■ System check display After turning the engine switch to IGNITION ON mode, “SYSTEM CHECK”...
Page 85 2. Instrument cluster CAUTION ■ The information display at low temperatures Allow the interior of the vehicle to warm up before using the liquid crystal information display. At extremely low temperatures, the information display monitor may respond slowly, and display changes may be delayed. For example, there is a lag between the driver’s shifting and the new gear number appearing on the display.
Page 86: Fuel Consumption Information
2. Instrument cluster Fuel consumption information Fuel consumption information can be displayed on the audio system screen. Audio system Trip information Press “APPS” button and select “Eco” to display the “Trip Informa- tion” screen. If the “Trip Information” screen does not appear, select “Trip Information”.
Page 87 2. Instrument cluster Past record Press “APPS” button and select “Eco” to display the “Past Record” screen. If the “Past Record” screen does not appear, select “Past Record”. Previous fuel economy record Current fuel economy Best recorded fuel economy Update the past record data Reset the past record data “Trip Information”...
Page 88 2. Instrument cluster AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 89: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........90 3-2. Opening, closing and locking the doors Smart key system ....93 Wireless remote control ......108 Doors ........ 111 Trunk......... 114 3-3. Adjusting the seats Front seats ......118 Driving position memory ......
Page 90: 3-1. Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle. Electronic keys • Operating the smart key system (P. 93) • Operating the wireless remote control function (P. 108) Mechanical keys Key number plate Using the mechanical key To take out the mechanical key, push the release button and take the key out.
Page 91 ■ If you lose your mechanical keys New genuine mechanical keys can be made by your Toyota dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 92 ■ When an electronic key is lost If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that was provided with your vehicle. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 93: Smart Key System
3-2. Opening, closing and locking the doors Smart key system Function summary The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (P.
Page 94 3-2. Opening, closing and locking the doors Unlocking and locking the doors Grip the driver’s door handle to unlock the door. Some models, grip the passenger’s door handle to unlock all the doors. Make sure to touch the sensor on the back of the handle.
Page 95 3-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Right side antenna outside the cabin (if equipped) Antennas inside the cabin Antenna outside the trunk Antenna inside the trunk Left side antenna outside the cabin AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 96 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected)  Type A  Type B When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft.
Page 97 3-2. Opening, closing and locking the doors ■ Alarms and warning indicators An alarm sounds and warning message displays shown on the multi-informa- tion display are used to protect against unexpected accidents or theft of the vehicle resulting from erroneous operation. When a warning message is dis- played, take appropriate measures based on the displayed message.
Page 98 3-2. Opening, closing and locking the doors Alarm Situation Correction procedure The engine switch was turned to ACCESSORY mode while the driver's Turn the engine switch door was open (The close driver's door driver’s door. opened when engine switch was in Interior alarm sounds ACCESSORY mode.) continuously...
Page 99 3-2. Opening, closing and locking the doors Interior Exterior Correction Situation buzzer buzzer procedure An attempt was made to exit Turn the vehicle with the electronic Continuous engine switch Once key and lock the doors without (5 seconds) off and lock the first turning the engine switch doors again.
Page 100 3-2. Opening, closing and locking the doors ■ Switching the door unlock function (some models) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 101 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 102 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system, wireless remote control and engine immobi- lizer system from operating properly.
Page 103 3-2. Opening, closing and locking the doors ■ Note for the entry function ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 104 3-2. Opening, closing and locking the doors ■ Note for locking the doors ● Touching the door lock sensor while wearing gloves may delay or prevent lock operation. Remove the gloves and touch the lock sensor again. ● If the door handle becomes wet while the electronic key is within the effec- tive range, the door may lock and unlock repeatedly.
Page 105 3-2. Opening, closing and locking the doors ■ When the vehicle is not driven for extended periods ● To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the vehicle. ● The smart key system can be deactivated in advance. (P. 455) ■...
Page 106 3-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● If the battery becomes low, an alarm will sound in the cabin when the engine stops. (P. 97) ●...
Page 107 (P. 95) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 108: Wireless Remote Control
3-2. Opening, closing and locking the doors Wireless remote control Function summary The wireless remote control can be used to lock and unlock the vehi- cle. Locks all the doors Check that the door is securely locked. Unlocks all the doors Pressing the button unlocks the driver’s door.
Page 109 3-2. Opening, closing and locking the doors ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: once; Unlocked: twice) Trunk: A buzzer sounds to indicate that the trunk has been opened. ■...
Page 110 P. 350 ■ Confirmation of the registered key number The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. ■ Customization Settings (e.g. wireless remote control system) can be changed. (Customizable features: P. 455) ■...
Page 111: Doors
3-2. Opening, closing and locking the doors Doors Unlocking and locking the doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switches. ◆ Entry function P. 93 ◆ Wireless remote control P.
Page 112 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door. The door cannot be locked if the engine switch is in ACCESSORY or IGNITION ON mode, or the electronic key is left inside the vehicle.
Page 113 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems The following functions can be set or canceled: For instructions on customizing, refer to P. 455. Function Operation All doors are automatically locked Speed linked door locking function when vehicle speed is approxi- mately 12 mph (20 km/h) or higher.
Page 114: Trunk
3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. Opening the trunk from inside the vehicle Press the opener switch. Opening the trunk from outside the vehicle ■...
Page 115 3-2. Opening, closing and locking the doors Luggage security system The trunk opener switch can be temporarily disabled to protect lug- gage stored in the trunk against theft. Turn the main switch in the glove box off to disable the trunk opener.
Page 116 3-2. Opening, closing and locking the doors ■ In case the trunk opener is not actuated Pull down the rear armrest and open the door behind it. Pull the loop of wire to unlock the trunk lid. This is used in case the trunk lid cannot be unlocked due to a discharged battery or other trouble.
Page 117 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 118: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure  Driver’s seat  Passenger’s seat Seat position adjustment switch Lumbar support adjustment switch (if equipped for passen- Seatback angle adjustment ger’s seat) switch Seat cushion length adjust- Seat cushion (front) angle ment switch (if equipped) adjustment switch (if equipped for passenger’s seat)
Page 119 3-3. Adjusting the seats ■ Power easy access system (vehicles with driving position memory) The auto away/return function enables easy access by activating when the driver attempts to enter or exit the vehicle. ● When the engine switch has been turned to IGNITION ON mode or the driver’s seat belt has been fastened, the driver’s seat will move forward.
Page 120: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat and outside rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The seat is automatically adjusted to allow the driver to enter and exit the vehicle easily.
Page 121 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be recorded and recalled by pressing a button. Two different driving positions can be recorded into memory. ■...
Page 122 3-3. Adjusting the seats ■ Recall procedure Check that the shift lever is in P. Turn the engine switch to IGNITION ON mode. Press button “1” or “2” to recall the desired position. ■ To stop the position recall operation part-way through Perform any of the following: ●...
Page 123 3-3. Adjusting the seats Memory recall function Each electronic key can be registered to recall your preferred driving position. ■ Registering procedure Record your driving position to button 1 or 2 before performing the following: Carrying only the key to which you want to link the driving position, shift the shift lever to P and then close the driver’s door.
Page 124 3-3. Adjusting the seats ■ Cancelation procedure Carry only the key to which you want to cancel the linked door unlock operation. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing the “SET”...
Page 125: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Rear seats (except center seat) Pull the head restraints up.
Page 126 3-3. Adjusting the seats ■ Installing the head restraints  Front seats Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. Lock release button ...
Page 127 3-3. Adjusting the seats CAUTION ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 128: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel The steering wheel can be adjusted to a comfortable position. Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically.
Page 129: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 130 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in on mode, the indica- tor illuminates.
Page 131: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear.
Page 132 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (vehicles with driving position memory) When the mirror select switch is in the L or R position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 133 3-4. Adjusting the steering wheel and mirrors CAUTION ■ Important points while driving Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. ●...
Page 134: Power Windows
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 135 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. ■...
Page 136 3-5. Opening, closing the windows and moon roof CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows ● The driver is responsible for all the power window operations, including the operation for the passengers.
Page 137: Moon Roof
3-5. Opening, closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 138 3-5. Opening, closing the windows and moon roof ■ The moon roof can be operated when The engine switch is in IGNITION ON mode. ■ Operating the moon roof after turning the engine off The moon roof can be operated for approximately 45 seconds after the engine switch is turned to ACCESSORY mode or turned off.
Page 139 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 140 3-5. Opening, closing the windows and moon roof ■ Moon roof open warning buzzer The buzzer sounds and a message is shown on the multi-information display when the engine switch is turned off and the driver’s door is opened with the moon roof open.
Page 141: Driving
Driving 4-1. Before driving 4-3. Operating the lights and wipers Driving the vehicle..... 142 Headlight switch....172 Cargo and luggage ... 153 Automatic High Beam ..176 Vehicle load limits ..... 156 Fog light switch ....181 Trailer towing..... 157 Windshield wipers and Dinghy towing ....
Page 142: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 159 Driving With the brake pedal depressed, shift the shift lever to D. (P. 165) Release the parking brake. (P. 170) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 143 4-1. Before driving Starting off on a steep uphill Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake. ■ Driving in the rain ● Drive carefully when it is raining, because visibility will be reduced, the win- dows may become fogged-up, and the road will be slippery.
Page 144 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer per- form the bedding down operation.
Page 145 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine running. This prevents the vehicle from creeping. ■...
Page 146 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle ● During normal driving, do not turn off the engine. Turning the engine off while driving will not cause loss of steering or braking control, but the power assist to these systems will be lost.
Page 147 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 148 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 149 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked ● Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle when it is in the sun. Doing so may result in the following: •...
Page 150 4-1. Before driving CAUTION Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 151 4-1. Before driving NOTICE ■ When driving the vehicle ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 152 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 153: Cargo And Luggage
(P. 156) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 154 4-1. Before driving Calculation formula for on your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 430) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb.
Page 155 4-1. Before driving CAUTION ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or passengers, possibly causing an accident.
Page 156: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 157: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 158: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 159: Driving Procedures Engine (Ignition)
4-2. Driving procedures Engine (ignition) switch Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal.
Page 160 4-2. Driving procedures Stopping the engine Stop the vehicle. Shift the shift lever to P. Set the parking brake. (P. 170) Press the engine switch. Driving-related data will be displayed on the multi-information display. (P. 84) Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal released.
Page 161 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P If the engine is stopped with the shift lever in a position other than P, a message indicating to shift the shift lever to P will be displayed on the multi-information display.
Page 162 If the engine does not start ● The engine immobilizer system may not have been deactivated. (P. 66) Contact your Toyota dealer. ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 163 When a message requesting the smart key system be inspected is dis- played on the multi-information display The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If the electronic key battery is depleted P. 350 ■...
Page 164 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 165: Automatic Transmission
4-2. Driving procedures Automatic transmission Shifting the shift lever While the engine switch is in IGNITION ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 166 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever or paddle shift switches can be operated as follows:  Shift lever Upshifting Downshifting  Paddle shift switches Upshifting Downshifting The initial shift range in S mode is set automatically to “4”...
Page 167 4-2. Driving procedures Selecting shift ranges in the D position To drive using temporary shift range selection, operate the “-” paddle shift switch. The shift range can then be selected by operating the “-” and “+” paddle shift switches. Changing the shift range allows restric- tion of the highest gear, preventing upshifting and enabling the level of engine braking force to be selected.
Page 168 S This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 169: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The lever will return to its original position after operation. Right turn Lane change to the right (move the lever partway and release The right hand signals will flash 3 times. Lane change to the left (move the lever partway and release The left hand signals will flash 3 times.
Page 170: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully U.S.A. Canada depress the parking brake pedal with your left foot while depress- ing the brake pedal with your right foot. (Depressing pedal again releases the parking brake.) ■ Usage in winter time P.
Page 171: Horn
4-2. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
Page 172: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows:  Type A The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION...
Page 173 4-3. Operating the lights and wipers  Type B The headlights, parking lights, daytime running lights and so on turn on automatically (when the engine switch IGNITION mode). The side marker, park- ing, tail, license plate, daytime running lights instrument panel lights turn on.
Page 174 4-3. Operating the lights and wipers ■ Daytime running light system ● Vehicles with halogen headlights: To make your vehicle more visible to other drivers, the headlight high beam turn on automatically (at a decreased inten- sity) whenever the engine is started and the parking brake is released. Day- time running lights are not designed for use at night.
Page 175 4-3. Operating the lights and wipers ■ Automatic headlight leveling system (if equipped) The level of the headlights is automatically adjusted according to the number of passengers and the loading condition of the vehicle to ensure that the headlights do not interfere with other road users. ■...
Page 176: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary. Activating the Automatic High Beam system Put the headlight switch in the “AUTO”...
Page 177 4-3. Operating the lights and wipers High beam automatic turning on or off conditions When all of the following conditions are fulfilled, high beam will be automatically turned on (after approximately 1 second): ● Vehicle speed is above approximately 25 mph (40 km/h). ●...
Page 178 4-3. Operating the lights and wipers ■ The Automatic High Beam can be operated when The engine switch is in IGNITION ON mode. ■ Camera sensor detection information ● High beam may not be automatically turned off in the following situations: •...
Page 179 • The driver believes that the high beam may be causing problems or dis- tress to other drivers or pedestrians nearby. ■ If the Automatic High Beam indicator flashes It may indicate a malfunction in the system. Contact your Toyota dealer. ■ Customization The automatic high beam can be deactivated.
Page 180 Do not modify the vehicle. ● Do not replace windshield with non-genuine windshield. Contact your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 181: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog.  Type A Turns the front fog lights Turns the front fog lights ...
Page 182 4-3. Operating the lights and wipers  Type B Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 183: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Intermittent wiper with interval adjuster (if equipped)  Type A Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper opera- tion Temporary operation Increases the intermittent wind-...
Page 184 4-3. Operating the lights and wipers  Type B Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency...
Page 185 4-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped)  Type A With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper...
Page 186 4-3. Operating the lights and wipers  Type B With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed. Rain-sensing wiper operation Low speed wiper operation High speed wiper...
Page 187 4-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when The engine switch is in IGNITION ON mode. ■ Effects of vehicle speed on wiper operation (vehicles with rain-sensing windshield wipers) With low speed windshield wiper operation selected, wiper operation will be switched from low speed to intermittent wiper operation only when the vehicle is stationary.
Page 188 ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 189: Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Close all the doors and windows, and turn the engine switch off. ● Confirm the type of fuel. ■...
Page 190: Refueling
4-4. Refueling CAUTION ■ When refueling the vehicle Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. ● After exiting the vehicle and before opening the fuel door, touch an unpainted metal surface to discharge any static electricity.
Page 191: Opening The Fuel Tank
4-4. Refueling Opening the fuel tank cap With the doors unlocked, press the center of the rear edge of the fuel filler door. Push until you hear a click and take your hand away to slightly open the fuel filler door. Then open the door fully by hand.
Page 192 4-4. Refueling ■ If the fuel filler door cannot be opened Remove the cover inside the trunk and pull the lever to unlock the fuel filler door. Then press the center of the rear edge of the fuel filler door to open it. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 193 CAUTION ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 194: Using The Driving Support
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Display Indicators Set speed Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control.
Page 195 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 196 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 197 4-5. Using the driving support systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 198: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions Dynamic radar cruise control supplements conventional cruise control with a vehicle-to-vehicle distance control. In vehicle-to-vehicle dis- tance control mode, the vehicle automatically accelerates or deceler- ates in order to maintain a set following distance from vehicles ahead. Vehicle-to-vehicle distance but- Display Indicators...
Page 199 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will be displayed. Press the button again to deacti- vate the cruise control. Accelerate or decelerate the vehicle to the desired speed, and push the lever down to set...
Page 200 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 201 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance Pressing the button changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short Preceding vehicle mark The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 202 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the cruise control. The speed setting is also canceled when the brakes are applied. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 203 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 204 4-5. Using the driving support systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 205 4-5. Using the driving support systems Selecting conventional constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to dirt etc.
Page 206 AUTO mode [rain-sensing windshield wipers] or the high speed wiper oper- ation). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 207 If the warning message remains on even after the above actions have been performed, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 208 4-5. Using the driving support systems ■ Certification  For vehicles sold in the U.S.A. FCC ID: HYQDNMWR004 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 209 4-5. Using the driving support systems CAUTION ■ Before using dynamic radar cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes etc.
Page 210 4-5. Using the driving support systems CAUTION ■ To avoid inadvertent cruise control activation Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for dynamic radar cruise control Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 211 4-5. Using the driving support systems CAUTION ■ When the sensor may not be correctly detecting the vehicle ahead Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (P.
Page 212 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 213: Driving Mode Select Switches
4-5. Using the driving support systems Driving mode select switches The driving modes can be selected to suit driving condition. Normal mode Use for normal driving. While in Eco drive mode or sport mode, press the switch to change the driving mode to normal mode.
Page 214 4-5. Using the driving support systems Sport mode Use sport mode when increased acceleration response and precise handling is desired, for example, when driving on mountain roads. When the “SPORT” switch is pressed, the “SPORT” indicator comes on in the instrument cluster. ■...
Page 215: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 216 4-5. Using the driving support systems When the TRAC/VSC systems are operating The slip indicator light will flash while the TRAC/VSC systems are operating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels.
Page 217 TRAC has been disabled and “TRAC OFF” indicator light comes on even if the TRAC/VSC OFF switch has not been pressed TRAC cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, VSC and TRAC systems ●...
Page 218 4-5. Using the driving support systems CAUTION ■ The ABS does not operate effectively when ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). ● The vehicle hydroplanes while driving at high speed on wet or slick roads. ■...
Page 219 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 220: Pcs (Pre-Collision System)
4-5. Using the driving support systems  PCS (Pre-Collision System) When the radar sensor detects possibility of a frontal collision, the pre-collision system such as the brakes and seat belts are automatically engaged to lessen impact as well as vehicle dam- age.
Page 221 4-5. Using the driving support systems Disabling pre-collision system Enabled Disabled The “PCS” warning light turns on when pre-collision system is dis- abled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and determines whether a collision is imminent based on the position, speed, and heading of the obstacles.
Page 222 4-5. Using the driving support systems ■ The pre-collision system is operational when The pre-collision system off switch is not pressed and the following conditions are met: ● Pre-collision seat belts (operating conditions A): • Vehicle speed is greater than about 19 mph (30 km/h). •...
Page 223 4-5. Using the driving support systems ■ Conditions that may trigger the system even if there is no possibility of a collision ● When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 224 ■ When there is a malfunction in the system “PCS” warning light will flash and warning messages will be displayed. (P. 390) Have the vehicle inspected by your Toyota dealer immediately. ■ Certification  For vehicles sold in the U.S.A.
Page 225 If the sensor moves even slightly off position, the system may become inaccurate or malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. ● Do not disassemble the sensor.
Page 226 4-5. Using the driving support systems CAUTION ■ Cautions regarding the assist contents of the system By means of alarms and brake control, the pre-collision system is intended to assist the driver in avoiding collisions through the process of LOOK- JUDGE-ACT.
Page 227: (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 228 The outside temperature is extremely high or low ● The sensor voltage has become abnormal If a message continues to be displayed, have the vehicle inspected by your Toyota dealer. ■ Certification for the Blind Spot Monitor system  For vehicles sold in the U.S.A.
Page 229 If the sensor moves even slightly off position, the system may mal- function and vehicles that enter the detection area may not be detected. If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Toyota dealer. ● Do not disassemble the sensor.
Page 230 4-5. Using the driving support systems The Blind Spot Monitor function detection areas The areas that vehicles can be detected in are outlined below. The range of the detection area extends to: Approximately 11.5 ft. (3.5 m) from the side of the vehicle The first 1.6 ft.
Page 231 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The BSM main switch is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ■ The Blind Spot Monitor function will detect a vehicle when ●...
Page 232 4-5. Using the driving support systems ■ Conditions under which the Blind Spot Monitor function may not func- tion correctly ● The Blind Spot Monitor function may not detect vehicles correctly in the fol- lowing conditions: • During bad weather such as heavy rain, fog, snow etc. •...
Page 233 4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehi- cle’s existence through flashing the outside rear view mirror indicators and sounding a buzzer.
Page 234 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 235 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians etc.
Page 236: 4-6. Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 237 4-6. Driving tips Before driving the vehicle Perform the following according to the driving conditions: ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
Page 238 4-6. Driving tips Selecting tire chains Use the correct tire chain size when mounting the tire chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3 mm) in diameter 0.39 in. (10 mm) in width 1.18 in. (30 mm) in length Cross chain: 0.16 in.
Page 239 NOTICE ■ Repairing or replacing snow tires Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 240 4-6. Driving tips AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 241: Interior Features
Interior features 5-1. Using the air conditioning 5-3. Using the storage system and defogger features Automatic air conditioning List of storage features ..256 system......242 • Glove box...... 257 Rear window and • Console box....258 outside rear view mirror •...
Page 242: Using The Air Conditioning System And Defogger Automatic Air Conditioning System
5-1. Using the air conditioning system and defogger Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting.  Front control panel (type A) Front control panel (type B)  AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 243 5-1. Using the air conditioning system and defogger Driver’s side temperature con- Outside air or recirculated trol mode Windshield defogger SYNC mode Driver’s side temperature dis- Cooling and dehumidification play function on/off Fan speed display Fan speed control Air outlet display Front passenger’s side tem- Automatic mode perature display...
Page 244 5-1. Using the air conditioning system and defogger Using the automatic air conditioning system ■ Using automatic operation Touch The air conditioning system begins to operate. Air outlets and fan speed are automatically adjusted according to the temperature setting. Touch (driver’s side) to increase the temperature and touch (driver’s side) to decrease the temperature.
Page 245 5-1. Using the air conditioning system and defogger ■ Changing the rear seat temperature settings (vehicles with a rear control switch) Turn clockwise to increase the temperature and turn counterclockwise to decrease the temperature. ■ Confirming automatic operation status During automatic operation, the operation status of fan speed, air outlet mode, outside/recirculated air mode and whether the A/C is on or off can be confirmed on the display by touching The display will return to its previous state after a few seconds.
Page 246 5-1. Using the air conditioning system and defogger To adjust the temperature setting, touch (driver’s side) to increase the temperature and touch (driver’s side) to decrease the temperature. The temperature for the driver’s, front passenger’s and rear seats (vehi- cles with a rear control switch) can be adjusted separately when: •...
Page 247 5-1. Using the air conditioning system and defogger Defogging the windshield Press dehumidification function operates and fan speed increases. Set the outside/recirculated air mode button to the outside air mode if the recirculated air mode is used. (It may switch automatically.) To defog the windshield and the side windows early, turn the air flow and temperature up.
Page 248 5-1. Using the air conditioning system and defogger Air flows mainly to the feet. Air flows to the feet and the wind- shield defogger operates. Switching between outside air and recirculated air modes Press The mode switches between (outside air mode) and (recircu- lated air mode) each time the button is pressed.
Page 249 5-1. Using the air conditioning system and defogger  Front side outlets Direct air flow to the left or right, up or down. Turn the knob to open or close the vent.  Rear outlets Direct air flow to the left or right, up or down.
Page 250 5-1. Using the air conditioning system and defogger ■ Outside/recirculated air mode ● When driving on dusty roads such as tunnels or in heavy traffic, set the out- side/recirculated air mode to the recirculated air mode. This is effective in preventing outside air from entering the vehicle interior.
Page 251 5-1. Using the air conditioning system and defogger ■ Handling of the air conditioning panel The operating section of the air conditioning panel uses capacitive touch sen- sors. In the following cases, incorrect operation or non-response may occur. ● If the operating section is dirty or has liquid attached to it, incorrect operation or non-response may occur.
Page 252: Rear Window And Outside Rear View Mirror Defoggers
5-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mir- rors. On/off The defoggers will automatically turn off after 15 to 60 minutes.
Page 253: Using The Interior Lights
5-2. Using the interior lights Interior lights list Outer foot lights (if equipped) Ambient lights (if equipped) (P. 255) Rear personal/interior lights (P. 254) Front door courtesy lights Front personal/interior lights (P. 254) AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 254: Personal/Interior Light Main Switch
5-2. Using the interior lights Personal/interior light main switch Turns the lights on/off Turns the lights on/off linked to door position Personal/interior lights ■ Front Turns the light on/off ■ Rear Turns the light on/off If the lights are turned on by the personal/interior light main...
Page 255: Ambient Lights
5-2. Using the interior lights Ambient lights (if equipped) Each time the “MOOD” switch is pressed, brightness level changes. ■ Illuminated entry system The lights automatically turn on/off according to engine switch mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed.
Page 256: Using The Storage
5-3. Using the storage features List of storage features Auxiliary boxes (P. 260) Cup holders (P. 259) Glove box (P. 257) Console box (P. 258) CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 257: Glove Box
5-3. Using the storage features Glove box Open (pull up the lever) Lock with the mechanical key Unlock with the mechanical key CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
Page 258: Console Box
5-3. Using the storage features Console box Lift the lid while pulling up the lever to release the lock. ■ When using the console box lid as an armrest Slide the console box lid forward as needed. Slide the lid forward while pulling up the lever.
Page 259: Cup Holders
5-3. Using the storage features CAUTION ■ Caution while driving Keep the console box closed. In the event of sudden braking, an accident may occur due to an occupant being struck by the open console box or the items stored inside. Cup holders ...
Page 260: Auxiliary Boxes
5-3. Using the storage features CAUTION ■ Items unsuitable for the cup holders Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury.
Page 261 5-3. Using the storage features  Type C Opening Push the tray forward until it locks. Closing Push the tray forward to release the lock and the tray will automati- cally close. ■ When placing small items on top of the tray The tray can be opened while small items are placed on it.
Page 262 If the LED indicators flash even though the surface of the tray is not hot, the wireless charger may be malfunctioning. Consult your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 263 Certification for the wireless charger  For vehicles sold in the U.S.A. This device complies with Part 18 of the FCC Rules. Toyota Motor Sales, U.S.A., Inc. 19001 S. Western Avenue Torrance, CA 90501  For vehicles sold in Canada This ISM device complies with Canadian ICES-001.
Page 264 5-3. Using the storage features CAUTION ■ Caution regarding interference with electronic devices (vehicles with a wireless charger) ● People with implantable cardiac pacemakers, cardiac resynchronization therapy-pacemakers or implantable cardioverter defibrillators should main- tain a reasonable distance between themselves and the wireless charger. The radio waves may affect the operation of such devices.
Page 265: Trunk Features
5-3. Using the storage features Trunk features Grocery bag hooks Cargo net (if equipped) AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 266 5-3. Using the storage features NOTICE ■ To prevent damage to the hooks Do not apply too much load to the hooks. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 267: Other Interior Features
5-4. Other interior features Sun visors and vanity mirrors Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 268: Clock
5-4. Other interior features Clock The clock can be adjusted by pressing the buttons.  Type A Adjusts the hours Pressing and holding the button adjusts hours forward quickly 1 hour at a time. Adjusts the minutes Pressing and holding the button adjusts the minutes forward quickly by 1 minute at a time.
Page 269 5-4. Other interior features ■ The clock is displayed when The engine switch is in ACCESSORY or IGNITION ON mode. ■ When disconnecting and reconnecting battery terminals  Type A The time display will automatically be set to 12:00 AM. ...
Page 270: Outside Temperature Display
■ When “---F” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 271: Power Outlets
5-4. Other interior features Power outlets The power outlets can be used for 12 V accessories that run on less than 10 A. ■ Console box AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 272 5-4. Other interior features ■ Instrument panel  Type A  Type B ■ Rear armrest (if equipped) AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 273 5-4. Other interior features ■ The power outlets can be used when The engine switch is in ACCESSORY or IGNITION ON mode. NOTICE ■ To avoid damaging the power outlets Close the power outlet lids when the power outlets are not in use. Foreign objects or liquids that enter the power outlets may cause a short cir- cuit.
Page 274: Seat Heaters/Seat Ventilators
5-4. Other interior features   Seat heaters /seat ventilators The seat heaters warm the seats and the seat ventilators main- tain good airflow by blowing air through the seats. Seat heaters/ventilators ■ Front seats  Vehicles with ventilator Press the knob to release it, and turn the knob to the desired temperature setting.
Page 275 5-4. Other interior features ■ Rear seats ON/OFF The indicator illuminates when the seat heater is turned on. ■ The seat heaters/seat ventilators can be used when The engine switch is in IGNITION ON mode. ■ Automatic operation of the seat ventilator for the passenger's seat When a passenger leaves the passenger seat while the seat ventilation turns on, the seat ventilator automatically turns off.
Page 276 5-4. Other interior features CAUTION ■ Burns ● Use caution when seating the following persons in a seat with the seat heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 277: Armrest
5-4. Other interior features Armrest Fold down the armrest for use. NOTICE ■ To prevent damage to the armrest Do not apply too much load on the armrest. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 278: Rear Sunshade
5-4. Other interior features  Rear sunshade The rear sunshade can be raised and lowered by pressing the switch shown below. Extends/retracts the rear sun- shade ■ The rear sunshade can be used when The engine switch is in IGNITION ON mode. ■...
Page 279 5-4. Other interior features CAUTION ■ When the rear sunshade is being raised or lowered Do not place fingers or other objects in the fastener section or in the open- ing. They may get caught, causing injury. NOTICE ■ To prevent battery discharge Do not operate the rear sunshade when the engine is not running.
Page 280: Trunk Storage Extension
5-4. Other interior features Trunk storage extension Long objects can be loaded into the vehicle by utilizing the trunk space and rear seat area. Fold down the armrest. Push down the handle and open the armrest door. The armrest door can be locked unlocked using mechanical key.
Page 281: Coat Hooks
5-4. Other interior features Coat hooks The coat hooks are provided with the rear assist grips. CAUTION ■ Items that cannot be hung on the coat hook Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 282: Assist Grips
5-4. Other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. CAUTION ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 283: Garage Door Opener
5-4. Other interior features  Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices.  The garage door opener (HomeLink Universal Transceiver) is manu- ...
Page 284 5-4. Other interior features  ■ Programming the HomeLink Point the remote control for the device 1 to 3 in. (25 to 75  mm) from the HomeLink control buttons. Keep the indicator light on the  HomeLink in view while pro- gramming.
Page 285 5-4. Other interior features Test the operation of the ® HomeLink by pressing the newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 286 5-4. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the  heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door opener motor.
Page 287  the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button  The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 288 5-4. Other interior features ® Operating the HomeLink   Press the appropriate HomeLink button. The HomeLink indicator  light on the HomeLink transceiver should turn on.  The HomeLink continues to send a signal for up to 20 seconds as long as the button is pressed.
Page 289 5-4. Other interior features ■ Before programming ● Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the  HomeLink ■ Certification for the garage door opener  For vehicles sold in U.S.A. FCC ID: NZLWZLHL4 NOTE: This device complies with Part 15 of the FCC Rules.
Page 290: Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Connect service is subject to such then-applicable Terms and Conditions.
Page 291 After you have signed the Telematics Subscription Service Agree- ment and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” button in your vehicle for further subscription details. AVALON (U)_(OM41456U)
Page 292 Safety Connect. ● Safety Connect is available beginning Fall 2009 on select Toyota models. Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection availabil- ity, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 293 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunction (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services ■...
Page 294 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. ■ Emergency Assistance Button (“SOS”) In the event of an emergency on the road, push the “SOS”...
Page 295 5-4. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. ■ Exposure to radio frequency signals The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 296: Compass
5-4. Other interior features  Compass The compass on the inside rear view mirror indicates the direc- tion in which the vehicle is heading. ■ Operation To turn the compass on or off, press the switch for more than 3 seconds.
Page 297 5-4. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 298 5-4. Other interior features ■ Circling calibration When “C” appears on the dis- play, drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed. If there is not enough space to drive in a circle, drive around the block until the direction is dis- played.
Page 299 5-4. Other interior features NOTICE ■ To avoid the compass malfunctions Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass ●...
Page 300 5-4. Other interior features AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 301 Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..302 Cleaning and protecting the vehicle interior... 306 6-2. Maintenance Maintenance requirements ....309 General maintenance..311 Emission inspection and maintenance (I/M) programs......315 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 302: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 303 6-1. Maintenance and care ■ When using a car wash If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In that case, follow the fol- lowing correction procedures to wash the vehicle: ●...
Page 304 Precaution regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 305 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 306: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 307 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 308 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 309: Maintenance Maintenance Requirements
Toyota recommends the following main- tenance: General maintenance General maintenance should be performed on a daily basis. This can be done by yourself or by a Toyota dealer. Scheduled maintenance Scheduled maintenance should be performed at specified intervals according to the maintenance schedule.
Page 310 ■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 311: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 312 6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope and the Automatic transmission “Park” shift lever is in P, is the vehicle mechanism securely stopped? •...
Page 313 6-2. Maintenance Items Check points • Do the head restraints move Head restraints smoothly and lock securely? • Do the indicators and buzzers Indicators/buzzers function properly? Lights • Do all the lights come on? • Moves smoothly? • When parked on a slope and the Parking brake parking brake is on, is the vehicle securely stopped?
Page 314 6-2. Maintenance Vehicle exterior Items Check points • Do doors/trunk operate Doors/trunk smoothly? • Does the engine hood lock system Engine hood work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 315: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 316: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions
“Toyota Super Long Life Coolant” is pre-mixed with 55% coolant and 45% deionized water. • Funnel (used only for adding cool- ant) • “Toyota Genuine Motor Oil” or equivalent Engine oil level (P. 323) • Rag or paper towel • Funnel (used only for adding...
Page 317 6-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (P. 352) as original • Bulb with same number and watt- age rating as original Light bulbs (P. 361) • Phillips-head screwdriver • Flathead screwdriver • Wrench ...
Page 318 6-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 319: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. CAUTION ■...
Page 320: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ◆ Front ◆ Rear AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 321 6-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following precautions to reduce the possibility of death or serious injury: ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 322: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Engine oil filler cap (P. 324) Radiator (P. 328) Engine oil level dipstick Electric cooling fans (P. 323) Condenser (P. 328) Brake fluid reservoir Engine coolant reservoir (P. 329) (P. 326) Fuse box (P. 352) Washer fluid tank (P.
Page 323 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 324 6-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 325 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 326 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. AVALON (U)_(OM41456U)
Page 327 6-3. Do-it-yourself maintenance CAUTION ■ When the engine is hot Do not remove the engine coolant reservoir cap or the radiator cap. (P. 425) The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. NOTICE ■...
Page 328 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION ■...
Page 329 6-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” line “MIN” line ■ Adding fluid Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items...
Page 330 6-3. Do-it-yourself maintenance Battery Check the battery as follows. ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 331 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. CAUTION ■...
Page 332 6-3. Do-it-yourself maintenance CAUTION ■ Where to safely charge the battery Always charge the battery in an open area. Do not charge the battery in a garage or closed room where there is insufficient ventilation. ■ How to recharge the battery Only perform a slow charge (5 A or less).
Page 333 6-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi-information display, washer tank may be empty. Add washer fluid. CAUTION ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 334: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the Front same interval as tire inspection. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 335 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 337) ◆ Initializing the tire pressure warning system ■...
Page 336 6-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system Park the vehicle in a safe place and turn the engine switch off. Initialization cannot be performed while the vehicle is moving. Adjust the tire inflation pressure to the specified cold tire inflation pressure level.
Page 337 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not reg- istered, the tire pressure warning system will not work properly.
Page 338 6-3. Do-it-yourself maintenance ■ Low profile tires (18-inch tires) Generally, low profile tires will wear more rapidly and tire grip perfor- mance will be reduced on snowy and/or icy roads when compared to standard tires. Be sure to use snow tires or tire chains on snowy and/or icy roads and drive carefully at a speed appropriate for road and weather conditions.
Page 339 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 340 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 341 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 342: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 437) AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 343 ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 344 6-3. Do-it-yourself maintenance ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ● Check only when the tires are cold. If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 345: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 346 6-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 347 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 348: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch off. Open the glove box. (P. 257) Remove the glove box cover. Press the tabs and remove the filter cover.
Page 349 6-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (For scheduled maintenance information, please refer to the “Schedule maintenance guide”...
Page 350: Electronic Key Battery
6-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 Replacing the battery Take out the mechanical key. Remove the cover.
Page 351 6-3. Do-it-yourself maintenance ■ Use a CR2032 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 352: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch off. After a system failure, see “Fuse layout and amperage ratings” for details about which fuse to check.
Page 353 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type C: Contact your Toyota dealer. Type A Type B ...
Page 354 6-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment  Fuse block  Fuse block on the back of the cover Fuse Ampere Circuit METER-IG2 Gauge and meters 50 A Electric cooling fans H-LP CLN 30 A No circuit 50 A Air conditioning system 140 A...
Page 355 6-3. Do-it-yourself maintenance Fuse Ampere Circuit ST/AM2 30 A Starter system H-LP LH-LO, H-LP RH-LO, headlights H-LP-MAIN 30 A (low beam) ABS NO.1 50 A Vehicle stability control system 10 EPS 80 A Electric power steering 11 S-HORN 7.5 A S-HORN 12 HORN 10 A...
Page 356 6-3. Do-it-yourself maintenance Fuse Ampere Circuit 27 EFI-MAIN NO.1 30 A EFI NO.2, EFI NO.3, A/F sensor 28 SMART No circuit 29 ETCS 10 A Electronic throttle control system 30 TOWING 20 A No circuit Multiport fuel injection system/sequential 31 EFI NO.1 7.5 A multiport fuel injection system, electronic controlled transmission...
Page 357 6-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit H-LP LVL 7.5 A Automatic headlight leveling system S/HTR RR 20 A Rear seat heater Outside rear view mirrors, glove box light, ECU-ACC air conditioning system, multiplex com- munication system RR P/OUTLET 15 A Power outlets...
Page 358 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Stop/tail lights, multiport fuel injection system/sequential multiport fuel injection system, vehicle stability control system, 14 STOP 7.5 A anti-lock brake system, electronic con- trolled transmission, high mounted stop- light, smart key system, shift lock control system 15 AM1 7.5 A...
Page 359 6-3. Do-it-yourself maintenance Fuse Ampere Circuit Parking lights, side marker lights, stop/tail 33 TAIL 10 A lights, rear turn signal lights, back up lights, license plate lights, fog lights Switch illumination, air conditioning sys- tem, glove box light, interior lights, per- sonal lights, audio system, navigation system, rear sunshade, seat heater, 34 PANEL...
Page 360 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 361) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 361: Light Bulbs
Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 438) AVALON (U)_(OM41456U)
Page 362 6-3. Do-it-yourself maintenance Bulb locations ■ Front Headlight low beam (halogen bulb) Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams) Headlight high beam (vehicles with discharge bulbs for low beams) Fog light (if equipped) Front turn signal/parking light AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 363 6-3. Do-it-yourself maintenance ■ Rear Rear turn signal light Back-up light License plate light AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 364 6-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beam (halogen bulb) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set.
Page 365 6-3. Do-it-yourself maintenance ■ Headlight high beam and daytime running light (vehicles with halogen bulbs for low beams)/Headlight high beam (vehicles with discharge bulbs for low beams) Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise.
Page 366 6-3. Do-it-yourself maintenance ■ Fog light (if equipped) To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
Page 367 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector.
Page 368 6-3. Do-it-yourself maintenance Reinstall the fender liner and the fender liner bolt. Reinstall the fender liner clips. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 369 6-3. Do-it-yourself maintenance ■ Front turn signal/parking light To allow enough working space, turn steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replac- ing the left side light bulb.
Page 370 6-3. Do-it-yourself maintenance Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 371 6-3. Do-it-yourself maintenance ■ Rear turn signal light Open trunk remove the luggage trim cover clip. Pull the hook while depress- ing the button. Partly remove the luggage trim cover. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 372 6-3. Do-it-yourself maintenance Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 373 6-3. Do-it-yourself maintenance ■ Back-up light Open trunk remove the clips. Then partly remove trunk panel cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 374 6-3. Do-it-yourself maintenance ■ License plate light Remove the cover. To prevent damaging the vehi- cle, wrap the flathead screw- driver with a tape. Remove the lens. Insert a properly sized screw- driver into the hole of the lens, and pry off the lens as shown in the illustration.
Page 375 ■ Replacing the following bulbs If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (discharge bulb) ● Daytime running lights (vehicles with discharge headlights) ● Side marker lights ●...
Page 376 The daytime running lights (vehicles with discharge headlights), stop/tail lights, high mounted stoplight and outer foot lights each consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 377 6-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. When it is unavoidable to hold the glass portion, use and hold with a clean dry cloth to avoid getting moisture and oils on the bulb.
Page 378 6-3. Do-it-yourself maintenance CAUTION ■ Discharge headlights (if equipped) ● Contact your Toyota dealer before replacing the discharge headlights (including light bulbs). ● Do not touch the discharge headlight’s high voltage socket when the head- lights are turned on. An extremely high voltage of 30000 V will be discharged and could result in death or serious injury by electric shock.
Page 379: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..380 If your vehicle has to be stopped in an emergency ...... 381 7-2. Steps to take in an emergency If your vehicle needs to be towed ......382 If you think something is wrong ......
Page 380: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signals will flash. To turn them off, press the switch once again.
Page 381: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 382: If Your Vehicle Needs
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a lift-type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 383 7-2. Steps to take in an emergency Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels.
Page 384 7-2. Steps to take in an emergency Using a flatbed truck If your Toyota is transported by a flatbed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 385 7-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle when towing using a wheel-lift type truck When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
Page 386: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle.
Page 387: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 388: If A Warning Light Turns On Or A Warning Buzzer Sounds
If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 389 Low engine oil pressure warning light Indicates that the engine oil pressure is too low. Have the vehicle inspected by your Toyota dealer immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident.
Page 390 7-2. Steps to take in an emergency Warning light Warning light/Details Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steer- ing) system “PCS” warning light Indicates a malfunction in the pre-collision system The warning light will operate as follows, even when the system is not malfunctioning: •...
Page 391 7-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light goes off. Warning light Warning light/Details Correction procedure Open door warning light (warning buzzer) Check that all the doors and Indicates that a door or the the trunk are closed.
Page 392 • Flat tire (P. 400) pressure adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire pres- by your Toyota dealer.
Page 393 7-2. Steps to take in an emergency : Open door warning buzzer: A buzzer will sound if the vehicle reaches a speed of 3 mph (5 km/h) or more with any door open. : Driver’s seat belt buzzer: The driver’s seat belt buzzer sounds to alert the driver that his or her seat belt is not fastened.
Page 394 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 395 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 396 ■ If both the ABS and the brake system warning lights remain on Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 397 7-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 398 7-2. Steps to take in an emergency CAUTION TPMS (tire pressure warning system) malfunctions may occur for a vari- ety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS (tire pressure warning system) from functioning properly.
Page 399: If A Warning Message Is Displayed
Multi-information display If any of the warning message is shown again after its correction pro- cedure has been performed, contact your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 400: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 334 CAUTION ■ If you have a flat tire Do not continue driving with a flat tire.
Page 401 7-2. Steps to take in an emergency Location of the spare tire, jack and tools Luggage floor cover Jack Jack handle Spare tire Tool tray Wheel nut wrench AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 402 7-2. Steps to take in an emergency CAUTION ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 403 7-2. Steps to take in an emergency Taking out the jack and jack handle Remove luggage floor cover. Remove the jack. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 404 7-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. (P. 403) Remove the tool tray. Loosen the center fastener that secures the spare tire. CAUTION ■ When storing the spare tire Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 405 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 406 7-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 407 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 408 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 409 7-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 410 7-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 411 7-2. Steps to take in an emergency CAUTION ■ When using the compact spare tire ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. ●...
Page 412 When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. AVALON (U)_(OM41456U)
Page 413: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 159), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
Page 414 ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 419) ● There may be a malfunction in the steering lock system. Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function...
Page 415: If The Shift Lever Cannot Be Shifted From P
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 416: If The Electronic Key Does Not Operate Properly
7-2. Steps to take in an emergency If the electronic key does not operate properly If communication between the electronic key and vehicle is interrupted (P. 102) or the electronic key cannot be used because the battery is depleted, the smart key system and wire- less remote control cannot be used.
Page 417 A message indicating how to start the engine will be displayed on the multi-information display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 418 7-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 419: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 420 ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. AVALON (U)_(OM41456U)
Page 421 7-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. ●...
Page 422 7-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any other than the intended terminal.
Page 423: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “F” and “L” lines on the reservoir.
Page 424 (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 425 7-2. Steps to take in an emergency CAUTION ■ When inspecting under the hood of your vehicle Observe the following precautions. Failure to do so may result in serious injury such as burns. ● If steam is seen coming from under the hood, do not open the hood until the steam has subsided.
Page 426: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the front wheels.
Page 427 7-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the front wheels and depressing the accelerator pedal more than necessary. ● If the vehicle remains stuck even after these procedures are performed, the vehicle may require towing to be freed.
Page 428 7-2. Steps to take in an emergency AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 429 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..430 Fuel information ....439 Tire information ....442 8-2. Customization Customizable features ..455 8-3. Items to initialize Items to initialize ....461 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 430: (Fuel, Oil Level, Etc.)
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 195.3 in. (4960 mm) Overall width 72.2 in. (1835 mm) Overall height 57.5 in. (1460 mm) Wheelbase 111.0 in. (2820 mm) Front 62.6 in. (1590 mm) Tread Rear 62.2 in.
Page 431 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is located on the top left of the instrument panel.
Page 432 8-1. Specifications Engine Model 3.5L 6-cylinder (2GR-FE) Type 6-cylinder V type, 4-cycle, gasoline 3.70  3.27 in. (94.0  83.0 mm) Bore and stroke Displacement 210.9 cu. in. (3456 cm Valve clearance Automatic adjustment (engine cold) Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only...
Page 433 8-1. Specifications ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 434 8-1. Specifications Cooling system Capacity 9.7 qt. (9.2 L, 8.1 Imp. qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 435 If replacement is necessary, contact your Toyota dealer. NOTICE ■ Automatic transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle. AVALON (U)_(OM41456U)
Page 436 8-1. Specifications Brakes Pedal clearance 1.43 in. (36.4 mm) Min. 0.04  0.24 in. (1.0  6.0 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm)  10 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.116 DOT 3...
Page 437 8-1. Specifications Tires and wheels  Type A Tire size P215/55R17 93V Front Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold Rear tire inflation pressure) 33 psi (230 kPa, 2.3 kgf/cm or bar) 17  7 J Wheel size Wheel nut torque 76 ft•lbf (103 N•m, 10.5 kgf•m)
Page 438 8-1. Specifications Light bulbs Light bulbs Bulb No. Type Headlights  Low beam (discharge bulbs) Low beam (halogen bulbs) 9005 High beam 9005  Fog lights Front turn signal/parking lights 7444NA 28/8 Exterior Side marker lights Side turn signal lights WY5W Rear turn signal lights Back-up lights...
Page 439: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 440 ■ Recommendation of the use of gasoline containing detergent additives ● Toyota recommends the use of gasoline that contains detergent additives to avoid the build-up of engine deposits. ● All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or keep clean intake systems, per EPA's lowest additives concen- tration program.
Page 441 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 442: Tire Information
8-1. Specifications Tire information Typical tire symbols  Full-size tire  Compact spare tire AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 443 8-1. Specifications Tire size (P. 445) DOT and Tire Identification Number (TIN)(P. 444) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators(P. 334) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 444 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 445 8-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits)
Page 446 8-1. Specifications Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 447 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Require- ments in addition to these grades.
Page 448 8-1. Specifications ■ Temperature A, B, C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissi- pate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 449 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum...
Page 450 8-1. Specifications Tire related term Meaning The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb weight weight or accessory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim A metal support for a tire or a tire and tube...
Page 451 8-1. Specifications Tire related term Meaning A pneumatic tire in which the ply cords that extend to the beads are laid at alternate Bias ply tire angles substantially less than 90 degrees to the centerline of the tread The tire structure, except tread and sidewall Carcass rubber which, when inflated, bears the load The breaking away of pieces of the tread or...
Page 452 8-1. Specifications Tire related term Meaning A tire designated by its manufacturer as pri- Light truck (LT) tire marily intended for use on lightweight trucks or multipurpose passenger vehicles The maximum load that a tire is rated to carry Load rating for a given inflation pressure The load rating for a tire at the maximum per- Maximum load rating...
Page 453 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the...
Page 454 8-1. Specifications Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
Page 455: Customization
Toyota dealer. Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Customizing vehicle features It is possible to customize certain vehicle features using the audio system.
Page 456 8-2. Customization Default set- Customized Item Function ting setting Operation signal (Emergency flashers) Operation signal — O (Buzzer) Operation buzzer vol- Smart key Level 5 Off to level 7 O O system wire- less Time elapsed before remote automatic door lock control ...
Page 457 8-2. Customization Default set- Customized Item Function ting setting Driver's door unlocked in All doors one step, all Unlocking using a key unlocked in — O doors one step. unlocked in two steps Speed-detecting auto- Door lock matic door lock function ...
Page 458 8-2. Customization Default set- Customized Item Function ting setting Light sensor sensitivity Level 3 Level 1 to 5 Automatic 0 seconds Time elapsed before light con- headlights automatically trol system 30 seconds 60 seconds  P. 172) turn off after doors are closed 90 seconds Daytime...
Page 459 8-2. Customization Default set- Customized Item Function ting setting Interior lights illumina- — O tion control Time elapsed before 15 seconds 7.5 seconds interior lights turn off 30 seconds Center console spot light — O Operation when — O doors are unlocked Operation after —...
Page 460 8-2. Customization Default set- Customized Item Function ting setting Automatic condi- A/C auto switch opera- tioning sys- Auto Manual tion  P. 242) Touch but- ton (on the center Button sensor sensitivity Level 3 Level 1 to 3 — O panel) ...
Page 461: 8-3. Items To Initialize
8-3. Items to initialize Items to initialize The following items must be initialized for normal system opera- tion after such cases as the maintenance being performed on the vehicle: Item When to initialize Reference Message indicating mainte- • After the maintenance is per- P.
Page 462 8-3. Items to initialize AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 463: For Owners
For owners Reporting safety defects for U.S. owners......464 Seat belt instructions for Canadian owners (in French) ....... 465 SRS airbag instructions for Canadian owners (in French) ....... 467 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 464: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 465: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 466 ATTENTION ■ Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité périodiquement. Contrôlez qu’elles ne sont pas entaillées, effilochées et que leurs ancrages ne sont pas desser- rés. N’utilisez pas une ceinture de sécurité défectueuse avant qu’elle ne soit remplacée.
Page 467: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. ◆...
Page 468 ◆ Coussins gonflables latéraux et rideau SRS Coussins gonflables avant latéraux SRS Peuvent aider à protéger le torse des passagers avant Coussins gonflables arrière SRS latéraux Participent à la protection du haut du corps des occupants assis aux places arrière extérieures Coussins gonflables rideau SRS Participent principalement à...
Page 469 Composants du système de coussins gonflables SRS Capteurs d’impact avant Capteurs d’impact latéral (arrière) Coussins gonflables Coussin gonflable conducteur genoux Capteurs d’impact latéral (por- Contacteur de boucle de cein- tes avant) ture de sécurité conducteur Prétensionneurs de ceintures Témoin d’alerte SRS de sécurité...
Page 470 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des coussins gonflables régule le déploiement de ces derniers sur la base des informations qu’il reçoit des capteurs, etc., indiqués ci-des- sus dans le schéma illustrant les composants du système.
Page 471 ATTENTION ■ Précautions concernant les coussins gonflables SRS Respectez les précautions suivantes avec les coussins gonflables SRS. Autrement, des blessures graves, voire mortelles, pourraient s’ensuivre. ● Le conducteur et les passagers du véhicule doivent porter correctement leur ceinture de sécurité. Les coussins gonflables SRS sont des dispositifs supplémentaires à...
Page 472 Installez dans un siège de sécurité enfant les nourris- sons et les enfants trop petits pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement atta- chés.
Page 473 ATTENTION ■ Précautions concernant les coussins gonflables SRS ● Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas contre le tableau de bord. ● Ne laissez pas un enfant rester debout devant le coussin gonflable SRS passa- ger avant ou bien s’asseoir sur les genoux du passager avant.
Page 474 Si les parties renfermant les coussins gonflables SRS, telles que la garni- ture du volant et les garnitures de montants avant et arrière, sont abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 475 Modification et mise au rebut des éléments du système de coussins gonflables SRS Consultez impérativement votre concessionnaire Toyota avant de mettre votre véhicule au rebut ou de procéder à l'une des modifications suivantes. Les coussins gonflables SRS peuvent être défaillants ou se déployer (se gonfler) accidentellement, provoquant la mort ou de graves blessures.
Page 476 AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 477: What To Do If
Index What to do if... (Troubleshooting) ....478 Alphabetical index ..... 484 For details of equipment related to the audio/navigation system, refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”. AVALON (U)_(OM41456U) I n f o r ma t i o n P r o v i d e d b y :...
Page 478 You lose your keys ● If you lose your mechanical keys, new genuine mechanical keys can be made by your Toyota dealer. (P. 91) ● If you lose your electronic keys, the risk of vehicle theft increases significantly. Contact your Toyota dealer immediately. (P. 92) The doors cannot be locked or unlocked ●...
Page 479 What to do if... (Troubleshooting) The rear door cannot be opened ● Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock.
Page 480 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Did you press the engine switch while firmly depressing the brake pedal? (P. 159) ● Is the shift lever in P? (P. 162) ●...
Page 481 What to do if... (Troubleshooting) The windows do not open or close by operating the power window switches ● Is the window lock switch pressed? The power window except for the one at the driver’s seat cannot be operated if the window lock switch is pressed. (P. 134) The engine switch is turned off automatically ●...
Page 482 What to do if... (Troubleshooting) An alarm is activated and the horn sounds ● Did anyone inside the vehicle open a door during setting the alarm? The sensor detects it and the alarm sounds. (P. 68) To stop the alarm, turn the engine switch to IGNITION ON mode or start the engine.
Page 483 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire ● Stop the vehicle in a safe place and replace the flat tire with the spare tire. (P. 400) The vehicle becomes stuck ● Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow.
Page 484: Alphabetical Index
Alphabetical index Alphabetical index Alarm .......... 68 A/C ..........242 Alarm ........68 Air conditioning filter ..... 348 Warning buzzer ....388 Automatic air conditioning Anchor brackets ......55 system ........ 242 Antennas (smart key system) ....95 (Anti-lock Brake System)..215 Anti-lock Brake System Function ........
Page 485 Alphabetical index Back-up lights Care ........302, 306 Replacing light bulbs..... 373 Aluminum wheels ....303 Wattage ........ 438 Exterior ......... 302 Battery ........330 Interior ........306 Battery checking ....330 Seat belts......307 If the vehicle battery Cargo capacity......156 is discharged ......
Page 486 Alphabetical index Child-protectors....... 112 Cooling system Child safety ........ 50 Engine overheating....423 Airbag precautions....36 Cruise control Battery precautions..331, 422 Cruise control ....... 194 Child restraint system ..... 51 Dynamic radar cruise How your child should control ........ 198 wear the seat belt ....
Page 487 Alphabetical index Do-it-yourself maintenance ..316 Door courtesy lights Eco Drive Indicator....144 Wattage ........ 438 Eco drive mode......213 Doors ........111 EDR (Event data recorder)..10 Automatic door locking Electric Power Steering and unlocking system..113 (EPS) ........215 Door glasses......
Page 488 Alphabetical index If the warning light turns Engine coolant......326 on ........388 Capacity........ 434 If the warning message Checking....... 326 is displayed......399 Preparing and checking If you have a flat tire ..... 400 before winter ...... 236 If you think something Engine coolant temperature is wrong ......
Page 489 Alphabetical index Front turn signal lights ... 169 Flat tire........400 Replacing light bulbs .... 369 Floor mats ........24 Turn signal lever ....169 Fluid Wattage ........ 438 Automatic transmission..435 Fuel ........... 432 Brake ........436 Capacity........ 432 Washer .........
Page 490 Alphabetical index Head restraints ......125 I/M test ........315 Headlights ........ 172 Identification Automatic high beam .... 176 Engine ........431 Discharge headlights Vehicle........431 precautions......378 Ignition switch Light switch ......172 (engine switch)...... 159 Replacing light Illuminated entry system ..255 bulbs....
Page 491 Alphabetical index License plate lights ....172 Keyless entry ......93 Light switch......172 Smart key system ....93 Replacing light bulbs .... 374 Wireless remote control ..108 Wattage ........ 438 Keys ..........90 Light bulbs Battery-saving function ..101 Replacing......
Page 492 Alphabetical index Maintenance Navigation system Do-it-yourself maintenance... 316 Noise from under vehicle ... 8 General maintenance ... 311 Maintenance data ....430 Maintenance requirements ... 309 Odometer ........77 Resetting the message indicating maintenance Engine oil......432 is required......310 Opener Malfunction indicator lamp..
Page 493 Alphabetical index Paddle shift switches ....166 Radar cruise control (dynamic Parking brake......170 radar cruise control) ..... 198 Operation ......170 Radiator........328 Parking brake engaged Rear personal lights....254 warning buzzer ....388 Rear seat heaters ....275 Parking lights......
Page 494 Alphabetical index Seats......... 118 Safety Connect ......290 Adjustment......118 Seat belts........28 Adjustment precautions ..119 Adjusting the seat belt .... 29 Child seats/child restraint Automatic Locking system installation....55 Retractor....... 30 Cleaning ....... 306 Child restraint system Driving position memory ..120 installation ......
Page 495 Alphabetical index Service reminder indicators ..72 Snow tires ........ 239 Shift lever ......... 165 Spare tire........400 Automatic transmission..165 Inflation pressure ....437 If the shift lever Storage location....401 cannot be shifted from P ..415 Spark plug........ 434 Shift lock system .....
Page 496 Alphabetical index Switches Paddle shift switches .... 166 BSM (Blind spot monitor) PCS OFF switch ....221 switch ......... 227 Power door lock switch..111 Compass switch....296 Power window switches..134 Cruise control switch..... 194 Rear sunshade switch ..278 “DISP”...
Page 497 Dinghy towing ....... 158 Function ........ 335 Emergency towing ....382 Initializing ......335 Trailer towing ......157 Installing tire pressure TOYOTA PARKING ASSIST warning valves and MONITOR transmitters......335 TRAC (Traction Control) ..215 Registering ID codes .... 337 Transmission ......
Page 498 Alphabetical index Trunk......... 114 Internal trunk release lever ... 115 USB port Luggage security system ..115 Smart key system ....94 Trunk features....... 265 Vanity lights Trunk handle......114 Vanity lights ......267 Trunk light ......115 Wattage ........ 438 Trunk opener main switch..
Page 499 Alphabetical index Weight Warning buzzers Cargo capacity...... 156 Approach warning....204 Load limits ......156 Brake system ......388 Weight ........430 Downshifting ......168 Wheels........345 Seat belt reminder ....391 Replacing wheels ....345 Warning lights......73 Size........437 ABS........
Page 500: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 319 P. 114 P. 191 Hood lock release Tire inflation lever pressure P. 319 P. 437 Fuel tank capacity 17.0 gal. (64.35 L, 14.2 Imp. gal.) (Reference) Fuel type Unleaded gasoline only P.

Toyota 2015 Avalon Owner's Manual

1-1. for Safe Use

1-2. Theft Deterrent System

Instrument Cluster

Instrument Cluster Warning Lights and

Operation of each Component

3-1. Key Information

3-2. Opening, Closing and

3-3. Adjusting the Seats

3-4. Adjusting the Steering

3-5. Opening, Closing

Driving

4-1. before Driving

Driving Procedures Engine (Ignition)

4-3. Operating the Lights and

Refueling

Using the Driving Support

4-6. Driving Tips

Interior Features

Using the Air Conditioning System and Defogger Automatic Air Conditioning System

Using the Interior Lights

Using the Storage

Other Interior Features

Maintenance and Care Cleaning and Protecting

Maintenance Maintenance Requirements

Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

When Trouble Arises

7-1. Essential Information

7-2. Steps to Take in an

8-1. Specifications

Customization

8-3. Items to Initialize

For Owners

Quick Links

Related Manuals for Toyota 2015 Avalon

Summary of Contents for Toyota 2015 Avalon
