SSD Slot: Slot for REDMAG 1.8" SSD Media.
•
User Key 1: Initiates user defined camera function. Undefined by Default.
•
User Key 2: Initiates user defined camera function. Undefined by Default.
•
User Key 1 + User Key 2 : Press both keys to Eject (unmount) REDMAG 1.8" SSD Media
•
Focus / Record Button: Touch for Auto Focus, fully depress to Start or Stop Record.
•
Media Indicator LED: Indicates status of media:
o LED Off = No Media
o LED Green = Ready to Record
o LED Red Constant = Recording
o LED Red Slow Blink = Recording, 25% Media Left
o LED Red Fast Blink = Recording, 5% Media Left
o LED Yellow = Finalizing
o LED Yellow Blinking = Media Access (Format etc...)
Version 3.0
955-0003_V3.0, REV-A
©2011-2012 RED.COM INC.
21
