- Page 1 SERVICE MANUAL EM4820 CAFE CREMA EM4820 CAFE CREMA Issue: A Page 1 of 16...
- Page 2 ISSUE: DATE: 10 March 2011 EM4820 CAFE CREMA Issue: A Page 2 of 16...
-
Page 3: Spare Parts List
POD Filter 381h5-12-n Single Filter 381H2-12-A-2 Double Filter 38143-12-2 FILTER-HANDLE ASSEMBLY (comprising Filter Spring 381hh-14-2-n Handle Insert C1837AS-27A EM482011 Handle Head C1837AS-42A Screw 33000-16-3*8-1C-N Handle C1837AS-26A Tamp & Spoon 141h7-14-6-N EM482012 EM4820 CAFE CREMA Issue: A Page 3 of 16... - Page 4 Cleaning Tool C1837AS-66A EM482014 Steam Pin 381pl-30-n 151 Pin 381hh-13-n Screw 33000-55-3*12-N Wire Clip 12112-06-2 40000-110BPG- Power Cord ASFOF End Wire terminal 36000-14-CE21 Power lid C1837AS-24A Screw 33000-44-3*10-1-N Silicone Tube 51000-03-n EM4820 CAFE CREMA Issue: A Page 4 of 16...
- Page 5 33000-44-3*6-N Control Panel C1837AS-03A Screw 33000-44-4*6-N Dial Surround C1837AS-30A Dial Blade C1837AS-61A Dial Insert C1837AS-28A General Terminals 36000-04-CON Silicone Cap 51303-05-N Heating Element 271HI-01-D-N Water Tube C1837AS-59A Thermostat 20000-01-120S-2 thermostat 20000-01-175S-2 EM4820 CAFE CREMA Issue: A Page 5 of 16...
- Page 6 C1837AS-63A Directional Shaft C1837AS-62A Spring 38HC-08-2-N Touch Cap 151K6-01-B-N Shower Head C1837AS-11A Silicone Seal C1837AS-55A EM482015 Shower C1837AS-57A Screw 33000-139-4*12-N Buffer Tank Cover 12143-15-2 Buffer Tank 12143-14-2 Button Rear Casing 111H2-08N-2-E EM4820 CAFE CREMA Issue: A Page 6 of 16...
- Page 7 Screw 33000-16-4*22-N Interior Cover B C1837AS-05A Connecting Tube 151HH-12-GR EM482016 Steamer C1837AS-43A Steamer Spacer C1837AS-40A Steamer Support C1837AS-08A Screw 33000-44-3*15-N Interior Cover A C1837AS-19A Base C1837AS-23A Base Plate C1837AS-14A Screw 33000-68-4*12-N EM4820 CAFE CREMA Issue: A Page 7 of 16...
- Page 8 Temperature Switch Holder 38143-18-N Temperature Switch E802-068012A Shockproof Plate B 52P01-01-2B-2-H-N Grounding Label 62000-09-6-n Milk Jug 381H2-5023-I-H Power Cord Elbow 523Q1-02-B-N Steamer Handle C1837AS-52A Embeded Connector C1837AS-54A Screw 33000-14-3*8-N Screw 33000-55-3*10-N Screw 33000-44-4*16-N EM4820 CAFE CREMA Issue: A Page 8 of 16...
- Page 9 Item No. of Sunbeam Supplier’s Code Description Parts Part No. Plumbing Ass 2# A1837AS-02A Screw 33000-64-3*12-N Screw 33000-44-3*12-N Button PCB Ass 251H2-01A-SAA-N Mylar Sheet C1837-70A EM4820 CAFE CREMA Issue: A Page 9 of 16...
- Page 10 EM4820 CAFE CREMA Issue: A Page 10 of 16...
-
Page 11: Exploded View Drawing
EXPLODED VIEW DRAWING EM4820 CAFE CREMA Issue: A Page 11 of 16... - Page 12 EXPLODED VIEW DRAWING EM4820 CAFE CREMA Issue: A Page 12 of 16...
- Page 13 EXPLODED VIEW DRAWING EM4820 CAFE CREMA Issue: A Page 13 of 16...
- Page 14 EXPLODED VIEW DRAWING EM4820 CAFE CREMA Issue: A Page 14 of 16...
- Page 15 EXPLODED VIEW DRAWING EM4820 CAFE CREMA Issue: A Page 15 of 16...
-
Page 16: Circuit Diagram
CIRCUIT DIAGRAM EM4820 CAFE CREMA Issue: A Page 16 of 16...
