Axon POS3600 Series User Manual

Point – of - sale hardware system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
June 2008 Revision 1.2b
Point – of - Sale
Hardware System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS3600 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Axon POS3600 Series

Summary of Contents for Axon POS3600 Series

  • Page 1 User Manual June 2008 Revision 1.2b Point – of - Sale Hardware System...
  • Page 2 Copyright 2008 June All Rights Reserved Manual Version 1.2b P/N: 48201273 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS 1. To disconnect the machine from the electrial power supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. 2.

  • Page 4: Legislation And Weee Symbol

    CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components.

  • Page 5: Revision History

    Revision History Revision Description Revision Date Number Initial release 2007 March System Disassembly updated 2007 May Cover page updated Connector Pin Definition updated 2007 September 1.2a Cash Drawer Power Setting Correction 2007 September Cash Drawer Power Setting Correction Updated specification with Second Display options 1.2b 2008 June...

  • Page 6: Table Of Contents

    Table of Contents Item Checklist ........................7 1.1. Standard Items......................7 1.2. Optional Items......................7 System View........................8 2.1. Front View.........................8 2.2. Side View........................8 2.3. Rear View .........................9 2.4. Bottom View......................9 2.5. I/O View ........................10 Driver Installation ......................11 3.1. Driver List ....................... 11 3.2.

  • Page 7: Item Checklist

    1. Item Checklist Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. The following contents should be found in the carton: Standard Items 1.1. a. Driver CD b. System c.

  • Page 8: System View

    2. System View Front View 2.1. Power LED Power Switch Button Side View 2.2. Tilt Angle 65° ~ -25° Ventilation slots Pole type VFD Small Footprint...

  • Page 9: Rear View

    Rear View 2.3. Rear I/O Bottom View 2.4. Rubber Foot VESA mounting holes...

  • Page 10: I/O View

    I/O View 2.5. Line in Line out USB (4) DC Jack Cash COM (4) Parallel Drawer Note: The maximum current that can be drawn from each COM port is 500 mA.

  • Page 11: Driver Installation

    3. Driver Installation Driver List 3.1. Folder/File File Description <CD>:\POS360_B78.htm B78 Driver List <CD>:\COMMON\INTEL\Chipset Chipset Driver <CD>:\COMMON\INTEL\USB 20 USB 2.0 Driver <CD>:\COMMON\INTEL\VGA\i85x VGA Driver <CD>:\COMMON\POS_Touch POSTouch Driver <CD>:\COMMON\Ac97_codec\Realtek\ALC202A Audio Driver <CD>:\COMMON\Lan_driver\R8139_810x 10/100Mb LAN Driver -The following procedures are for Windows 2000/XP, other platforms are similar. Chipset Driver Installation 3.2.
  • Page 12 e. Click the “Finish” button and restart your system.

  • Page 13: Usb 2.0 Driver Installation Os Requirements

    USB 2.0 Driver Installation 3.3. OS Requirements USB 2.0 requirements Windows USB 2.0 drivers are provided in Service Pack 1 (SP1) for Windows XP, which is available through Windows Update. Windows USB 2.0 drivers are available through Windows Update or Service 2000 Pack 4.
  • Page 14 d. Select “Device” “Update Driver…”. e. Click the ”Next” button on the Welcome window. Select “Search for a suitable…”and click g. Select “Specify a location” and click the the “Next” button on the Install Hardware “Next” button on the Locate Driver Files Device Drivers window.

  • Page 15: Vga Driver Installation

    Click the “Finish” button to complete this k. Finished. process. VGA Driver Installation 3.4. a. Click the “Win2K_XP” on the My b. Click the “v14.19.50” on the My Computer window. Computer window. c. Select “win2K_xp141950” on the d. Click the “Next” button on the Intel(R) v14.19.50 window.

  • Page 16: Postouch Driver Installation

    e. Click the “Next” button on the Intel(R) f. Click the “Yes” button on the Intel(R) Graphics Media Accelerator Driver Graphics Media Accelerator Driver window. window. g. Select “Yes, I want to restart my computer now” and click the “Finish” button on the Intel(R) Graphics Media Accelerator Driver window.
  • Page 17 c. Click the ”next” button on the “Wellcome” d. Select “Install the software automatically” window. and click the ”Next” button on the “URTC1000” window e. Click the “Next” button on the “License f. Click the “Next” button on the “Install Agreement”...

  • Page 18: Audio Driver Installation

    i. Click the :Next” button on the “Ready to j. Click the “Continue Anyway” button on Install” window the URTC-1000 window k. Click the “Finish” button on the l. Click the “OK” button to reboot your “Installation Successful” window . computer Audio Driver Installation 3.6.

  • Page 19: 10/100Mb Lan Driver Installation

    Click “Next” button on the Realtek AC’97 Click “Yes” button on the Digital Signature Audio Setup window. Not Found window. Click “Finish” button on the Realtek AC’97 Audio Setup window. 10/100Mb LAN Driver Installation 3.7. a. Double click ”Setup” on the My b.
  • Page 20 c. Click the ”OK” button and restart your system.

  • Page 21: Peripherals Installation

    4. Peripherals Installation Magnetic Card Reader Installation 4.1. The MSR unit is tested and can be supplied at your request. This MSR is removed during transportation and can be connected by the user. There are two types of MSR Module: RS232 type and keyboard type.

  • Page 22: Cash Drawer Installation

    Cash Drawer Installation 4.2. You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. 4.2.1. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 4.2.2. Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 23 Bit 1: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow closing the Cash Drawer Bit 0: Reserved Note: Please follow the Cash Drawer control signal design to control the Cash Drawer. 4.2.3. Cash Drawer Control Command Example Use Debug.EXE program under DOS or Windows98 Command Cash Drawer...

  • Page 24: System Disassembly

    5. System Disassembly Replacing HDD 5.1. a. Loosen the thumb screws (2) to remove b. Disconnect the IDE cable the front side stand cover. c. Remove the screws (4) to release the d. Remove the screws(4) (two from each HDD holders from the front side stand side) to release the HDD holders(2) from cover the HDD...

  • Page 25: Replacing The Cf Card Holder (Optional)

    Replacing the CF Card Holder (Optional) 5.2. a. Loosen the thumb screws (2) to b. Disconnect the IDE cable and remove remove the front side stand cover. the screws(3) to replace the CF card holder. Replacing Mainboard & I/O Board 5.3.

  • Page 26: Replacing Inverter Board & Touch Screen Board

    e. Remove the screws (6) to release the f. Disconnect the power button cable metal cover from the stand base g. Remove the screws(4), and slide the mainboard in the direction as shown by the arrow. Replacing Inverter Board & Touch Screen Board 5.4.
  • Page 27 c. Remove the screws(4) and separate the d. Remove the screws (2) and disconnect back cover from the display head. the cables (3). e. Remove the screws (2) and disconnect the cables(2).

  • Page 28: Specification

    6. Specification Motherboard CPU Support Intel Celeron M ULV 600MHz/ 1GHz Chipset Intel 852GM + ICH4 System Memory 256MB DDR RAM, up to 2GB Graphic Memory Shared system memory up to 64MB LCD Panel LCD Size 12.1"TFT 15" TFT Brightness up to 400 cd / m²...
  • Page 29 Peripherals Customer Display Pole mounted type (VFD/ LCD type) Magnetic Card Reader 3 Tracks ( RS-232 (COM6) / PS2 interface ) Second Display 7" wide, 8.4", 10.4" or 12.1" LCD Second Display Environment Operating Temperature 5°C ~ 35°C ( 41°F ~ 95°F ) Storage Temperature -20°C ~ 55°C (-4°F ~ 140°F) Operating Humidity...

  • Page 30: Jumper Settings

    7. Jumper Settings B78 Motherboard...

  • Page 31: Connectors

    Connectors 7.1. Connector Function Connector Function Audio Line Out IDE1 Primary IDE Connector Audio Line In PRN1 Parallel Port CN13 COM5 for Touch PWR1 +19V Power Adapter CN15 CPU FAN Connector RJ11_1 Cash Drawer Connector CN16 Hardware Reset RJ45_1 LAN (On Board) CN18 USB2 RJ45_2...
  • Page 32 7.2.4. COM3 & COM 4 Power Setting Function ◎1-2 COM3 PIN10_RI COM3 PIN10_+5V COM3 PIN10_+12V ◎7-8 COM4 PIN10_RI COM4 PIN10_+5V 9-10 COM4 PIN10_+12V 11-12 7.2.5. Card Reader Setting ◎Docking Function On Board JP11 (1-2) JP11 (3-4) 7.2.6. LCD ID Setting Panel LVDS Resolution...

  • Page 33: Connectors Pin Definition

    7.2.7. COM2 RS232 / 485 / 422 Setting ◎RS232 Function RS485 RS422 JP9 (1-2) JP9 (3-4) JP9 (4-6) JP9 (5-7) JP9 (7-8) JP9 (9-10) JP10 (1-2) JP10 (3-4) JP10 (5-6) JP10 (7-8) JP10 (9-10) JP10 (11-12) Note: OPEN SHORT Connectors Pin Definition 7.3.
  • Page 34 CN13: COM5 Pin 1 DCD# Pin 2 Pin 3 Pin 4 DTR# Pin 5 Pin 6 DSR# Pin 7 RTS# Pin 8 CTS# Pin 9 Pin 10 CN15: CPU FAN Connector Pin 1 Pin 2 Feedback Pin 3 CN18: USB 2 Pin 1 +5V_USB1 Pin 2...
  • Page 35 CN20: Inverter Connector Pin 1 +12V_INV Pin 2 +12V_INV Pin 3 +12V_INV Pin 4 +12V_INV Pin 5 Back-Light Enable Pin 6 Pin 7 Pin 8 Back-Light Enable Pin 9 Pin 10 Pin 11 Pin 12 CN21: POS Card Reader Connector Pin 1 Pin 2 Pin 3...
  • Page 36 Pin 15 Pin 16 Pin 17 Pin 18 Pin 19 Pin 20 RJ45_2: COM2 RS422 (Pin11~20) Pin 11 Pin 12 RS422_TX- Pin 13 Pin 14 RS422_TX+ Pin 15 Pin 16 RS422_RX+ Pin 17 Pin 18 RS422_RX- Pin 19 Pin 20 RJ45 to DB9 Cable for COM Ports RJ45 Pin 1...
  • Page 37 RJ45_2: COM3(Pin21~30), COM4(Pin31~40) Pin 21 Pin 22 RS232_3_DCD# Pin 23 RS232_3_DSR# Pin 24 RS232_3_RX# Pin 25 RS232_3_RTS# Pin 26 RS232_3_TX# Pin 27 RS232_3_CTS# Pin 28 RS232_3_DTR# Pin 29 Pin 30 RS232_3_RI Pin 31 Pin 32 RS232_4_DCD# Pin 33 RS232_4_DSR# Pin 34 RS232_4_RX# Pin 35 RS232_4_RTS#...

  • Page 38: Bios Settings

    8. BIOS Settings BIOS Setup Utility 8.1. The BIOS setup defines how the system is configured. You need to run this program the first time you configure this product. You may need to run it again if you change the configuration.
  • Page 39 Standard CMOS Features Use this menu for basic system configuration. Advanced BIOS Features Use this menu to set the Advanced Features available on the system. Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize the system’s performance.
  • Page 40 Save & exit setup Save CMOS value changes to CMOS and exits setup. Exit without saving Ignores all CMOS value changes and exits setup.
