- Page 1 NATURAL GAS HOT WATER PRESSURE WASHER operation manual X-HW13008GENNG X-HW33008GENNG...
-
Page 3: Table Of Contents
table of contents Safety 6 Safety Rules 7 Safety Warnings Features 14 Features Installation 16 Location and Placement 17 Electrical 17 Gas Piping 18 Ventilation 19 Water Supply 20 High Pressure Connection 21 Inspecting and Verifying Conditions Preparation 23 Attire 23 Pre-Start 24 Unloader 24 Nozzle Review 25 Nozzle Connection 26 Dual Lance Assembly with Adjustable Pressure 26 Pre-Start Inspection Procedures Operation 27 ... -
Page 4: Pressure Washer
introduction Attention: Read through the complete manual prior to the initial use of your Pressure washer Using the Operator’s manual The operating manual is an important part of your pressure washer and should be read thoroughly before initial use, and referred to often to make sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury or damage to your pump. By knowing how best to operate this machine you will be better positioned to show others who may also operate the unit. You can refer back to the manual at any time to help troubleshoot any specific operating functions, so store it with the machine at all times. - Page 5 product identification Record Identification Numbers Pressure Washer If you need to contact an Authorized Dealer or Customer Service line (1- 866-770-1711) for information on servicing, always provide the product model and identification numbers. You will need to locate the model and serial number for the pump and record the information in the places provided below. Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:...
-
Page 6: Safety
safety Save these Instructions SAFETy RUlES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and/or a safety message to alert you to hazards. DANGER indicates a hazard which, if not avoided, will result in death ... - Page 7 safety WARNING Serious injury or death may occur from improper installation. Serious injury or death may occur from gas leaks. Serious injury or death may occur from normal sparks in the multiple ignition sources. Serious injury or death may occur if system safety’s are not properly maintained. • Installation of this unit including all gas piping must comply with all local, state and national codes. (Standards to be followed include the National Fuel Gas Code ANSI Z223.1/NFPA No. 54. In Canada; Refer to the CSA B149.1 Gas Installation Code). • Use appropriate fuel (natural gas or L.P.-Gas Vapor) for the machine you are using. • Do not connect gas lines to the pressure washer before testing gas piping pressure or there may be damage to the gas valve. • Do not adjust gas pressure above recommended levels. Excessive pressure may cause damage to the valve. • Liquid propane models are designed to run on vapor propane fuel. Do not use liquid fuel. • Do not replace or refill L.P.-Gas tank while unit is running. • If you smell gas, extinguish any open flame and test all joints with a soap solution. If the odor persists, turn off gas supply and call for service. • L.P.-Gas is heavier than air and will gravitate to the floor. Always provide adequate floor space and ventilation with L.P.-Gas systems and sniff floor area for gas before operating. Do not operate unit if smell exists. • Never leave operating machine unattended. • When servicing this machine, be especially careful to properly shut off gas supply. • Install the pressure washer where open flame or torch is permitted. • Always operate pressure washer in a well ventilated area free of flammable vapors, combustible materials including dust or gases. • Do not allow lint or dust to collect in burner area. • Do not use this pressure washer to spray flammable liquids! Flammable liquids can create fumes which can ignite. • This pressure washer has multiple safety devices which should never be altered, modified, removed or made inoperative. If a device fails, replace immediately with only genuine manufacturer replacement part.
- Page 8 safety WARNING Serious injury or death may occur from inhaling burner exhaust or dangerous vapors. • Installation of this unit including the ventilation of the combustion gases must comply with all local, state and national codes. (Standards to be followed include the National Fuel Gas Code ANSI Z223.1/ NFPA No. 54. In Canada; Refer to the CSA B149.1 Gas Installation Code). • Always make certain there is adequate ventilation (fresh outside air) for breathing and combustion. This will prevent the buildup of dangerous carbon monoxide gases. Beware of poorly ventilated areas, or areas with exhaust fans which can cause poor air exchange. • If you smell gas, shut off the gas supply to the appliance, extinguish any open flame, and test all joints with a soap solution. If the odor persists, call you gas supplier immediately. • Follow all safety instructions provided with the materials you are spraying. Use of a respirator may be required when working with some materials. Do not use this pressure washer to dispense hazardous materials. WARNING Serious injury may occur from touching the gasoline engine, muffler or heat exchanger. These areas can remain hot for some time after the pressure washer is shutdown. • Never allow any part of your body to contact the gasoline engine, muffler or heat exchanger. WARNING Serious injury may occur to the operator from moving parts on the pressure washer. • Do not operate the unit without all protective covers in place or make any adjustments without shutting off the pressure washer, relieving pressure and disconnecting the pressure washer from the power source. Allow pressure washer to cool down. Never assume the pressure washer is safe to work on just because it is not operating. It could restart at any time!
- Page 9 safety WARNING Serious injury or death could occur from high pressure spray penetrating the skin. • Keep clear of nozzle and spray! Never put your hand, fingers or body directly over the spray nozzle. • Do not direct discharge stream at persons or self. • This product is to be used only by trained operators. • Always keep operating area clear of all persons. • To reduce the risk of injury, close supervision is necessary when using this equipment near children. DO NOT allow children to operate this unit. • SEEK EMERGENCY MEDICAL CARE if the spray appears to have penetrated the skin! DO NOT TREAT AS A SIMPLE CUT! Be pre- pared to tell a physician exactly what kind of cleaning agents you were using by reading the Material Safety Data Sheet (MSDS) provided with your detergent. • High pressure hoses and fuel lines should be inspected daily for signs of wear. If evidence of failure exists, promptly replace all suspect hoses and fuel lines to prevent the possibility of injury from the high pressure spray. If a hose or fitting is leaking, NEVER PLACE YOUR HAND DIRECTLY ON THE LEAK. • Before using pressure washer, or when quick connecting high pres- sure hoses and spray nozzles, be certain the “collar” on the female quick connect is locked securely to prevent accidental discharge and that all quick coupler fittings are secure. • NEVER operate the gun with the trigger wired in the open position. To prevent accidental discharge, the trigger gun should be securely locked when not in use. • Before removing the spray nozzle or servicing the unit, ALWAYS shut off the unit and trigger the gun to release trapped pressure. (Even af- ter you shut off the unit, there is high pressure water left in the pump, hose and gun until you release it by triggering the gun.)
- Page 10 safety WARNING Serious injury may occur from a pressure washer malfunction or exploding accessories if incorrect system components, attachments or accessories are used. Serious injury or death may occur if attempting to start the pressure washer when the pumping system is frozen. • Never make adjustments to the factory set pressures. • If burner fails to shut off, turn off the gas supply and contact your serviceman. • Never exceed manufacturers maximum allowable pressure rating of attachments. • Do not allow any hoses to make contact with heat exchanger to prevent the possibility of bursting. Avoid dragging the hoses over abrasive surfaces such as cement. • Use only manufacturer recommended repair parts for your pressure washer. • In freezing temperatures, the unit must always be warm enough to ensure there is no ice formation in the pump. Do not start the pressure washer if it has been transported in an open or under heated vehicle without first allowing the pump to thaw. WARNING Serious injury or death could result from improper installation. Serious injury or death could occur if the pressure washer is not properly grounded. Your pressure washer is powered by electricity and may cause electric shock or electrocution if not used properly. Electrical shock may occur if pressure washer is not operated properly. Serious injury or death may occur from contact with electricity. Serious injury or death may occur if electrical repairs are attempted by unqualified persons.
- Page 11 safety • Installation of this unit including all electrical connections must comply with all local, state and national codes. (Standards to be followed include NFPA No. 70/NEC National Electrical Code.In Canada; Refer to the CSA C22.1 Canadian Electrical Code Part 1) • This unit must be connected to a grounded, permanent wiring system; or an equipment-grounding conductor must be run with the circuit conductors and connected to the equipment-grounding lead on the unit. • Make sure the pressure washer is connected to a properly grounded source which provides correct voltage and adequate fuse protection. Disconnect from power source when not in use or when making repairs. • Do not attempt to light the pilot manually as the electronic spark ignition lights the pilot automatically. • Never operate pressure washer with electrical enclosures open, removed or damaged. • Do not touch machine while standing in water or with wet hands. Never let the electrical supply or any connections lay in the water. • DO NOT direct spray on or into electrical installations of any kind! This includes electrical outlets, light bulbs, fuse boxes, transformers, the unit itself, etc. • DO NOT allow metal components of the pressure washer to come in contact with live electrical components. • Any electrical wiring or repairs performed on this pressure washer should be done by authorized service personnel in accordance with local and national electrical codes. • Before opening any electrical enclosure, always shut off the pressure washer, relieve pressure and disconnect the pressure washer from the power source. Allow pressure washer to cool down. Never assume the pressure washer is safe to work on just because it is not operating. It could restart at any time!
- Page 12 safety WARNING Serious injury or death may occur from detergents contacting or penetrating the skin. Serious injury can occur from loose debris being propelled at a high speed from the spray gun. Injury may occur if the operator loses his balance caused by the thrust of water traveling through the spray nozzle. Injury may occur from the pressure washer. • SEEK EMERGENCY MEDICAL CARE if you are using cleaning agents and the spray appears to have penetrated the skin! DO NOT TREAT AS A SIMPLE CUT! Be prepared to tell a physician exactly what kind of detergents you were using by reading the Material Safety Data Sheet (MSDS) provided with your detergent. • Never use any solvents or highly corrosive detergents or acid type cleaners with this pressure washer. • Protective equipment such as rubber suits, gloves and respirators are advisable, especially when using cleaning detergents. • Keep all detergents out of the reach of children! • ALWAYS wear protective goggles when operating the unit to shield the eyes from flying debris and detergents. • DO NOT direct spray toward fragile materials such as glass for shat- tering could occur. • Stay alert-watch what you are doing. Do not operate the unit when fatigued or under the influence of alcohol or drugs. • NEVER squeeze the trigger unless securely braced. • DO NOT overreach or stand on unstable support. • Wet surfaces can be slippery, wear protective foot gear and keep good footing and balance at all times. • NEVER trigger the gun while on a ladder or roof. • ALWAYS hold on firmly to the gun/lance assembly when starting and operating the unit. Failure to do so can cause the lance to fall and whip dangerously. • Know how to stop the pressure washer and bleed pressures quickly. Be thoroughly familiar with controls. • DO NOT leave pressurized unit unattended. Shut off the pressure washer and release trapped pressure before leaving. • DO NOT operate the unit if you see any oil or water leaks from the machine. DO NOT resume operation until the unit has been inspected and repaired by a qualified serviceman.
- Page 13 safety • Before servicing the unit: shut off the pressure washer, relieve pres- sure and disconnect the pressure washer from the power source. Allow pressure washer to cool down. Never assume the pressure washer is safe to work on just because it is not operating. It could restart at any time!
-
Page 14: Features
features Hg-series features Features Operator's Manual... - Page 15 features 1. Exhaust Outlet 2. Draft Diverter 3. Heat Exchanger 4. Pressure Switch 5. Pressure Trapping Unloader 6. Heat Dump Valve 7. High Pressure Pump 8. Gas Shut Off Valve 9. Gas Valve 10. High Pressure Outlet 11. Fork Truck Access 12. Nozzle Storage 13. Detergent Metering Valve 14. Pump Switch w/Indicator Light 15. Burner Switch w/Indicator Light 16. Detergent Strainer 17. Electrical Enclosure 18. Adjustable Thermostat 19. Electrical Junction Box 20. Float Tank w/Filter 21. Water Inlet 22. Gas Supply Inlet 23. Pressure Relief Valve 24. Decal- Nozzles 25. Decal- Electric Box Switches (Pump/Burner) 26. Decal- Operation 27. Decal- Detergent Valve 28. Decal- Warning/Caution 29. Decal- Warning: Risk of Injury/Exposed Pulleys 30. Decal- Warning: Hot Surfaces 31. Access Panel 32. High Pressure Hose 33. Trigger Gun 34. Trigger Safety Lock 35. Insulated Lance 36. Adjustable Pressure Dual Lance 37. High Pressure Nozzles...
-
Page 16: Installation
installation Installation lOCATION AND PlACEMENT 1. This unit should be installed indoors by a qualified serviceman in a non-freezing, dry environment away from damaging winds and rain. If any part of the unit becomes frozen, excessive pressure may build up in the unit which could cause it to burst resulting in possible serious injury to the operator or bystanders. Normal precautions should be taken so that excess moisture does not reach the electrical controls or the power unit. 2. It should be placed in an area away from flammable or combustible material. These types of material should be kept at least 20 feet away from the gas-fired units. 3. Avoid small areas and exhaust fans. Combustion becomes difficult and carbon monoxide may result in these areas. Allow enough space for servicing. Some codes will require certain distances from walls and flooring. Two feet away from the walls should suffice. 4. This unit should only be placed on a level surface to ensure proper lubrication for the water pump while operating. NEVER spray water directly on the unit. 5. DO NOT place unit in an area: a. where flammable gas vapors may be present. b. with insufficient ventilation. c. where there is evidence of oil or fuel leaks. DANGER • DO NOT PLACE UNIT IN AN AREA WHERE FLAMMABLE GAS VAPORS MAY BE PRESENT. A SPARK COULD CAUSE AN EXPLOSION OR FIRE! • DO NOT LOCATE THE UNIT IN FREEZING ENVIRONMENTS! WARNING • USE THIS PRODUCT ONLY IN WELL VENTILATED AREAS! THE EXHAUST CONTAINS CARBON MONOXIDE, A POISONOUS, ODORLESS AND INVISIBLE GAS. BREATHING THIS GAS CAN CAUSE SERIOUS INJURY, ILLNESS & POSSIBLE DEATH. -
Page 17: Electrical
installation ElECTRICAl DANGER • THIS UNIT MUST BE CONNECTED TO A PROPERLY GROUNDED OUTLET. 1. Installation of this unit should be performed by a qualified serviceman and all electrical installation must conform to all local, state and national codes, including NFPA No. 70 (NEC) National Electrical Code. In Canada; Refer to the CSA C22.1 Canadian Electrical Code Part 1. 2. This unit comes to you with the wires terminating in a junction box inside the cabinet. You must supply the incoming power source. 3. Ensure electrical supply is identical to the specifications listed on the pressure washer data plate. 4. Ensure all connections are secure and covers are replaced. GAS PIPING 1. Installation of this unit should be performed by a qualified serviceman and all gas piping must conform to all local, state and national codes, including the National Fuel Gas Code ANSI Z223.1/NFPA No. 54. In Canada; Refer to the CSA B149.1 Gas Installation Code. 2. Turn off gas and electricity before starting installation or service. 3. The gas line to the burner should be a separate supply from the meter because of the burner demand. Use new pipe and locate it with future service in mind. Use only black pipe or tubing suitable for gas applications and make sure the pipe is free from cutting burrs and defects. Use joint compound (not teflon tape) only on male fittings, leaving clean the first two threads to be engaged. DO NOT use compound on female threads where it can be pushed into the line and cause gas valve failure. RECOMMENDED PIPE SIZES FOR GAS SUPPLY LINE NATURAL GAS L.P.-GAS DISTANCE TO PIPE SIZE DISTANCE TO PIPE SIZE UNIT FROM UNIT FROM REGULATOR REGULATOR 0-50 Feet 1-1/2” 1PS... -
Page 18: Ventilation
50-00 Feet 2" PS 50-00 Feet -/2" PS 00-200 Feet 2-/2" PS 00-200 Feet -3/4" PS installation (Refer to illustration # for the following:) 4. Following the gas line from the meter or regulator, before the machine, install a manual main shut-off valve. (Refer to illustration below for the following:) 5. -
Page 19: Water Supply
installation 3. Install the recommended flue pipe per local, state and national codes, including the National Fuel Gas Code ANSI Z223.1/NFPA No. 54. In Canada; Refer to the CSA B149.1 Gas Installation Code. If the flue pipe exceeds 10 feet in length or contains more than two elbows, the natural draft may be eliminated and the burner will not ignite. DO NOT Ventilation: install a movable flue pipe damper. 4. If the unit is being installed in an enclosed room, provide adequate air . Installation of thi illustration #2 by a qualified se for combustion by installing openings to the room near the ceiling for draft diVerter national codes, ventilation and near the floor for burner combustion. These openings No. 54. In Cana burner exhaust should be sized using one square inch for each 1000 BTU per inch of diverter should b the machine. NOTE: There shou 5. If the building in which the unit is being installed seems unusually 2. -
Page 20: High Pressure Connection
installation 3. Be certain all connections are securely tightened. a. Water supply hose to the Water Inlet on the unit. b. Water supply hose to the Pressurized Water Supply. 4. Follow the incoming water requirements listed below: installation a. Water pressure must be between a minimum of 20 pounds per square inch (PSI) and a maximum of 65 PSI. illustration #4 b. Incoming GPM must be approximately one gallon more than the Hose connection ater supply hose which is a quality grade of garden hose outgoing GPM stated on the pressure washer I.D. Plate. (You can at least 3/4" ID and no longer than 50'. (See illustration #4) check GPM by timing how long it takes to fill a 5 gallon container.) ne end of the water supply hose to the water inlet of the unit. c. Incoming water temperature must not exceed 125°F. Excessive ... -
Page 21: Inspecting And Verifying Conditions
installation INSPECTING AND VERIFyING CONDITIONS 1. Check to ensure the building is not weakened by the installation of this unit and make sure the piping is secure. inspec 2. Check gas pressure and check all gas piping for leaks. a. Ensure all gas connections are made and close the valve before the . Che illustration #7 gas valve on the machine. unit maKing a manometer b. Immediately after opening the main valve, coat all piping and 2. Che connections with soapy water to check for gas leaks. Defective piping and fittings should be replaced immediately. c. After the meter and all piping have been checked for leaks, purge the air from the system by removing the test tapping plug and bleeding the line into a well-ventilated area to protect against potential fire hazard. d. If a commercial manometer is not available, make one by using a clear tube about 1/2 full of water and shape it like a U. With the main shut-off valve closed, connect a hose barb fitting into the test tapping, connect the hose and mark the water level as shown. e. Turn on the main gas valve and check the water column level by illustration #8 measuring water column measuring the distance the two water levels rose and dropped from starting level. This must not exceed 14” W.C. Start the unit and check pressure with burner running. The gas pressure at this point should be 3-7” W.C. for N.G. and 8-12” W.C. for L.P.-Gas. - Page 22 installation 3. Adjusting the gas regulator on the gas valve normally IS NOT necessary since it is preset at the factory; however, if it is necessary, follow these instructions: a. Using a 3/16” hex key wrench, remove plug from test port on gas valve inside the pressure washer and connect your manometer or test tube. b. While running the burner, use the screwdriver to adjust the gas pressure (clockwise to increase and counterclockwise to decrease). c. When finished, shut off the unit and manual shut-off valve, replace the adjustment cap, remove manometer or test tube and replace plug.
-
Page 23: Preparation
preparation preparation attire: Proper attire is essential to your safety. It is advised to utilize whatever means necessary to protect eyes, ears, and skin. Additional safety attire (such as respiratory mask) may be required when using detergent cleaning agents with Preparation this pressure washer. -
Page 24: Unloader
preparation UNlOADER The unloader has been preset at the factory and should only be adjusted by a trained serviceman. NOZZlE REVIEW Various nozzles may be quick connected into the end of the adjustable pressure dual lance to change the spray pattern or use the detergent feature. When using Quick- connects (Q.C.), be certain the connection is securely locked. If not, the high pressure water may shoot the nozzle from the lance, causing severe injury or serious damage. To determine spray fan, refer to the actual number stamped on the nozzle. The first two digits indicate the spray fan in degrees, i.e., 00=0°, 15=15°, 25=25°, 40=40°. 1. The 0° nozzle (RED): This is a blasting nozzle. It delivers a very con- centrated stream of water. Be cautious when using the straight narrow stream. It is not recommended for use on painted or wood surfaces, or items attached with adhesive backings. Uses: Removing weeds from sidewalk cracks, stubborn stains from concrete, masonry, alumi- num and steel, caked mud from equipment, and cleaning lawn mower undersides. 2. The 15° nozzle (YELLOW): This is a chiseling nozzle. The spray should be directed at a 45° angle to the surface and used like a scraper to remove paint, grease and dirt. Uses: Surface preparation (removing mildew stains and paint chips). 3. The 25° nozzle (GREEN ): a. This is a flushing nozzle. This pattern is best suited for flushing dirt, mud, and grime. Uses: Wet sweeping leaves from walk, curbs and driveways, cleaning stable floors, washing swimming pool bottoms, degreasing engines. b. On units with steam option, this nozzle is used for 250°F Wet Steam operation. This nozzle is sized for operation with the unloader and steam valve (where applicable) to provide high pressure wet steam. Replacement of this nozzle with an improperly sized nozzle may cause operational problems with the machine. 4. The 40° nozzle (WHITE ): This is a wash nozzle. This wide spray pattern disperses the water pressure over a large area and is recom- mended for moderate washing. Uses: Washing down aluminum siding, cleaning windows, washing vehicles, spraying sidewalks, driveways, and patios. -
Page 25: Quick Connect
dual lance to change the spray pattern or use the detergent feature. When d): This is a blasting nozzle. It delivers a very concentrated seVere inJury! trigger gun/dual lance y locked. Be cautious when using the straight narrow stream. It is using Quick- connects (Q.C.), be certain the connection is securely locked. -
Page 26: Dual Lance Assembly With Adjustable Pressure
preparation preparation dual lance assembly witH adJustable pressure: DUAl lANCE ASSEMbly WITH ADjUSTAblE PRESSURE . This unit features a adjustable pressure dual lance with adjustable pressure which allows the user to select a high or low pressure "fan" spray. Simply 1. This unit features a adjustable pressure dual lance with adjustable ... -
Page 27: Operation
operation Operating Instructions FlUSHING THE SySTEM 1. This unit has a steel coil which, after setting, will cause the water re- maining in the coil from the previous usage to turn brown or black. This water must be flushed from the system before start-up. This procedure should be performed without the gun and adjustable pressure dual lance installed. a. Verify the water supply is on. b. Move the pump switch to the “ON” position to start the pumping unit. c. Run the unit for 3-5 minutes. d. Turn off machine. e. Once the system is flushed, connect the trigger gun and adjustable pressure dual lance to the high pressure hose. CAUTION BE CERTAIN THE HOSE, GUN & LANCE ASSY. ARE NOT CONNECTED TO THE UNIT WHILE PRIMING THE PUMP. PRIMING ALLOWS MINERAL DEPOSITS TO BE RELEASED FROM THE SYSTEM WHICH WOULD OBSTRUCT OR DAMAGE THE GUN AND NOZZLE ASSEMBLY RESULTING IN COSTLY REPAIRS. COlD WATER OPERATION WARNING KEEP CLEAR OF NOZZLE! NEVER PLACE HAND OR FINGERS IN FRONT OF NOZZLE! DO NOT DIRECT DISCHARGE STREAM AT PEOPLE OR PETS! CAUTION DO NOT ALLOW SPRAY PATTERN TO REMAIN ON A FIXED AREA FOR AN EXTENDED PERIOD OF TIME. POSSIBLE DAMAGE MAY OCCUR TO THE AREA. -
Page 28: Hot Water Operation
operation 1. Refer to the “Safety Precautions” pgs. 7-11 before starting the unit. 2. Locate the Safety Decals on your unit and heed their warnings. 3. Ensure that the burner switch is in the “OFF” position. 4. Pointing the trigger gun in a safe direction, unlock the trigger gun and squeeze the trigger. Brace yourself for possible gun kickback when the pump starts. 5. Move the pump switch to the “ON” position to start the pumping unit. 6. Once the unit has started, perform the following procedures with the gun open: a. Inspect for system water and oil leaks. b. Inspect high pressure hoses for leaks. If a leak is found, DO NOT TOUCH HOSE AT LEAK!!! TURN UNIT OFF IMMEDIATELY! Replace hose before using the unit. See “Risk of Injection” warnings, pg. 7. Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. 7. At this point, the unit is operating as a cold water pressure washer. Trigger the gun several times and try adjusting the water pressure by rotating the grip on the dual lance. NEVER place hand or fingers in front of the nozzle or look directly into the nozzle! High pressure water creates a risk of severe injury! 8. Do not allow unit to operate in bypass mode (with trigger closed) for more than three minutes without triggering the gun. Failure to follow this simple rule can cause premature failure of pump packing seals, resulting in costly pump repair. 9. Your pressure washer can deliver high pressure spray and a variety of spray patterns using cold water. If you wish to use the hot water application or cleaning with detergents, see pg. 23 for the correct procedures. HOT WATER OPERATION 1. Follow the steps outlined for “COLD WATER OPERATION.” 2. Move the burner switch to the ON position. On initial start-up, water will begin turning hot in approximately 60 seconds and will reach maximum temperature in approximately 3 minutes, provided the trig- ger remains squeezed. The burner will stop firing when the trigger is released. 3. Set thermostat to the desired setting. At this point, the unit is operating as a hot water pressure washer. Be certain to be extremely cautious when adjusting the pressure and control- ling the trigger gun/dual lance assembly to avoid the possibility of burns. -
Page 29: Cleaning With Detergents
operation NOTICE The burner is equipped with a safety lock-off device. If the pilot fails to ignite within 60 seconds, the gas valve locks OFF. Simply release the trigger for approximately another 60 seconds and repeat. During operation, the burner may cease and start occasionally because of the thermostat setting. WARNING THE WATER TEMPERATURE COULD BECOME VERY HOT DURING HOT WATER OPERATION. BE CAUTIOUS WHEN ADJUSTING PRESSURE OR CONTROLLING THE TRIGGER GUN/ LANCE ASSEMBLY. ClEANING WITH DETERGENTS This feature is designed for use with mild detergents only. Since the cleaning solution travels through the heat exchanger coil, do not use corrosives as they will cause extensive damage as well as pose a considerable safety hazard. 1. Be certain to wear protective safety attire as stated on pg. 23. 2. Prepare detergent solution according to label directions. (Never pump acids, alkalines, abrasive fluids or solvents through the unit.) 3. Fully immerse the strainer end of the clear vinyl detergent hose into the detergent solution. 4. Adjust the amount of detergent desired by turning the detergent adjustment knob to the desired setting. 5. To apply solution, unlock the trigger gun and squeeze the trigger. In a few moments a detergent/water mixture will exit the nozzle. Start spraying the lower portion of the surface being cleaned and move up, using long overlapping strokes. Applying from the bottom up helps avoid streaking. Allow to soak briefly. Avoid working on hot surfaces or in direct sunlight to minimize the chances of the detergent drying, which may result in damaging surfaces. Be certain to clean a small section at a time. 6. To rinse, turn the detergent adjustment knob to the OFF position. It will take about 30 seconds to purge all detergent from the line. For best rinsing results, start at the top and work down. NOTICE If machine is equipped with remote box (es), read pg. 24 for informa- tion on detergent solenoid. -
Page 30: Shutdown
operation 7. Siphon a gallon of water through the detergent system after each use. This prevents the possibility of corrosion or detergent residue causing mechanical problems during the next use. NOTICE The detergent adjustment knob or detergent solenoid MUST by turned to the OFF position when not in use or when the strainer is not totally submerged in solution. If not, the pump will lose its prime resulting in no spray discharge at the nozzle. This condition will damage the pump over an extended time period. SHUTDOWN 1. If the burner switch is still on, turn it off. 2. Squeeze the trigger and discharge the water for a period of three minutes to cool the heat exchanger and high pressure hose. (Insufficient cool down period of the high pressure hose will cause excessive wear and eventual rupturing of the hose.) 3. Move the pump switch to the “OFF” position to stop the pumping unit. If machine has the time-delay shut-down option, wait for timer to time- out and shut machine off. See below for more information on time- delay shutdown. 4. Trigger the gun momentarily to relieve trapped pressure. -
Page 31: Options
operation OPTIONS REMOTE BOXES The remote box option allows the unit to be controlled from up to four remote workstations. The remote stations are wired in parallel to allow the operator to have full control of the unit from any station at anytime. Detergents are controlled by a chemical solenoid added to the main unit and control switches on the remote boxes. The maximum run for the remote wiring are as follows: 14 Gauge Wire - 200 feet 16 Gauge Wire -100 feet TIME-DELAY SHUTDOWN The time-delay shutdown option provides an adjustable automatic shutdown for the main unit. The factory presets the time-delay shutdown interval at 2 1/2 minutes. This option overrides the operation of the pump on/off switch for control of the pump motor shutdown. AUTO START/STOP The auto start/stop option provides an adjustable automatic shutdown and a pressure switch to restart the unit automatically when the gun is triggered. The factory presets the time-delay shutdown interval at 2 1/2 minutes. This option is not available with remote box option or flow- activated unloader option. STEAM - 250°F The 250°F steam option provides wet steam output from the unit. By adjusting the steam valve on the main control panel for the unit and using the included steam nozzle, 250°F steam is obtained. The sizing of the steam nozzle is critical to proper operation of the option. -
Page 32: Maintenance
maintenance Maintenance Instructions PREVENTATIVE MAINTENANCE LEAKS: Promptly eliminate any leaks found in the pumping system by removing suspect parts, applying thread sealant to the threads and reinstalling. NOTICE If using Teflon tape, be certain no tape gets inside any plumbing to prevent the possibility of a plugged spray nozzle. QUICK COUPLERS: There are o-ring seals inside the couplers which will deteriorate. To replace, simply install a replacement o-ring to correct the leak. (Additional o-rings can be purchased from your dealer.) NOZZLE: Water flow through the spray nozzle will erode the orifice, making it larger, resulting in a pressure loss. Nozzles should be replaced whenever pressure is less than 85% of the maximum. The frequency of replacement will depend upon such variables as mineral content in the water and number of hours the nozzle is used. PUMP: 1. Change the pump oil after the first 50 hours of operation. After initial change, every 3 months or 250 hour intervals are recommended. If oil appears dirty or milky, changes may be required in greater frequency. 2. Locate the pump oil drain hose. 3. Use an empty container to catch the oil and remove the plug from the drain line. 4. Let all the oil drain from the pump and replace drain plug. Dispose of used oil according to local, state and national regulations. 5. Fill the pump crankcase to the notch on the dipstick with pump oil SAE20 or 30 non-detergent. Do not overfill. BELT TENSION: Ensure unit is off. Remove the side panel or lift lid to inspect the v-belt for wear and tightness. If the v-belt needs to be replaced or tightened, follow the procedures listed. Replacement: 1. Loosen the four pump mounting bolts (A). 2. Loosen the two alignment nuts approximately one inch on the alignment bolts (B1 & B2). 3. Slide the pump toward the motor to loosen belts. 4. Remove and replace belt. -
Page 33: Quick Couplers
maintenance illustration #16 maintenance: illustration #16 maintenance QuicK couplers system by QuicK couplers he threads omptly eliminate any leaks found in the pumping system by moving suspect parts, applying thread sealant to the threads d reinstalling. umbing to g teflon tape, be certain no tape gets inside any plumbing to nt the possibility of a plugged spray nozzle. - Page 34 maintenance DELIME COIL: A loss in pressure may signify that the coil needs to be delimed. Do this procedure on a periodic basis. 1. Mix deliming powder/solution according to package directions. 2. Remove the nozzle from the wand. Place a nylon stocking over the wand assembly to collect debris, then place the wand assembly into the float tank. 3. Turn the switch to the “Pump” position. Water will circulate throughout the system and back into the float tank. Allow circulation to continue for 2-4 hours. 4. Turn the switch to the “Off” position. Drain and clean the float tank. Remove nylon stocking and clean wand assembly. 5. Flush the entire system with clean, fresh water, then replace nozzle into wand assembly. 6. Dispose of deliming solution according to local, state and national regulations. TEST VOLTAGE & AMP DRAW: Use a volt meter and amp meter to test the machine for correct voltage and amperage. If you do not have these instruments or do not know how to use them, this procedure should be performed by an authorized service technician.
-
Page 35: Winterizing
maintenance WINTERIZING For storage and transportation purposes in subfreezing ambient temperatures, it will be necessary to winterize this unit. This unit must be protected to the lowest incurred temperature for the following reasons: 1. If any part of the pumping system becomes frozen; excessive pressure may build up in the unit which could cause the unit to burst resulting in possible serious injury to the operator or bystanders. 2. The pumping system in this unit may be permanently damaged if frozen. FREEZE DAMAGE IS NOT COVERED BY WARRANTY. If you must store your unit in an area where the temperature may fall below 32°F, you can protect your unit by following one of the procedures listed below. AIR BLOWOUT: 1. Remove the nozzle from the wand assembly. Squeeze the trigger until water ceases to exit the wand assembly. 2. Connect an air fitting from an air hose to the strainer fitting in the float tank. 3. Run compressed air into the system to remove all water from the system. ANTIFREEZE SOLUTION: 1. Pour a 50/50 mixture of antifreeze and water into the float tank. 2. Place the detergent strainer into 100% antifreeze solution 3. Turn the switch to the “Pump” position. Allow antifreeze to siphon throughout the system until antifreeze solution exits the outlet. (To ensure the coil is winterized, antifreeze solution must exit the outlet. Add more 50/50 mixture to the float tank if necessary.) WARNING DO NOT STORE/OPERATE UNIT IN A FREEZING ENVIRONMENT! -
Page 36: Maintenance Chart
maintenance MAINTENANCE CHART PROCEDURE DAILY 3 6 9 12 MONTHS MONTHS MONTHS MONTHS Gas leak inspection Water leak inspection Oil leak inspection Quick-connect and hose inspection Check pump oil level Change pump oil* Check belt tension Replace high pressure nozzle Test water pressure Test water temperature *The pump oil must be changed after the first 50 hours of operation and every 250 hours or 3 months, whichever comes first. DEAlER MAINTENANCE CHART PROCEDURE 12 MONTHS Gas supply inspection Clean gas line drip legs Burner inspection Exhaust ventilation inspection Descale coil* Test Voltage & Amp Draw *Scale build-up will vary with mineral content in the water and amount of usage. Descaling can range from monthly to yearly maintenance. -
Page 37: Troubleshooting
troubleshooting Troubleshooting TROUblESHOOTING CHART SYMPTOM PROBABLE CAUSE REMEDY Motor will not run. Circuit overload. Determine if voltage is on. If not, check wall breaker or fuse. Secondary circuit overload. Check primary and secondary fuses on transformer. Motor overload. Reset thermal overload button on pump motor or thermal overload in electrical box. Contact Customer Service. No discharge at Water turned off. Check incoming water supply. nozzle when trigger Increase hose diameter and mechanism is provide adequate water supply squeezed. (20 PSI, 6 GPM). Low or fluctuating Inadequate water supply. Tighten all water intake pressure. Pump sucking air. (Prime connections. eliminated.) Eliminate leaks in intake line. High pressure detergent Close valve or submerge valve is open without the detergent hose into solution. end of the hose inserted ... - Page 38 troubleshooting SYMPTOM PROBABLE CAUSE REMEDY Detergent will not Detergent strainer is not Check, submerge if necessary. siphon. completely submerged in detergent solution. Detergent strainer Inspect, clean or replace. obstructed. Detergent hose cut, Inspect, clean or replace. obstructed or kinked. Detergent adjusting knob Open adjusting knob. Refer to turned to closed position. “Cleaning with Detergents”. Water flows back into Ball and spring in strainer Remove, clean or replace. detergent container. missing or corroded. Water flows from the Trigger gun is Repair or replace. nozzle when the trigger malfunctioning. gun is locked in the “OFF” position Before start-up, you Gas is leaking. Go to another location and smell gas around the call your gas supplier for machine. instructions, or if you cannot reach the supplier, call the fire department.
- Page 40 If you need assistance with the assembly or operation of this Pressure Washer please call 1-866-770-1711...
