  • Page 1 HOT WATER PRESSURE WASHER operation manual X-HW2565AR X-HW3513AR X-HWE3513AR...
  • Page 2 table of contents...

  • Page 3: Table Of Contents

    table of contents Safety 6    Safety Rules 7    Safety Warnings Features 12    Features - Small Frame 14    Features - Large Frame Installation & Preparation 16  Attire 16  Set-Up 17  Engine/Burner Fuel Tank 18  Adjustable Pressure Dual Lance 18  Dual Lance Connection 19  Water Supply 19  Unloader 20  Thermal Relief Valve 20  Pre-Start Inspection Procedures Operation 21  Priming The Pump 21  Start-Up/Cold Water Operation 23  Hot Water Operation 23  Cleaning With Detergents 24 ...

  • Page 4: Pressure Washer

    introduction Attention: Read through the complete manual prior to the initial use of your Pressure washer Using the Operator’s manual The operating manual is an important part of your pressure washer and  should be read thoroughly before initial use, and referred to often to make  sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury  or damage to your pump. By knowing how best to operate this machine  you will be better positioned to show others who may also operate the  unit. You can refer back to the manual at any time to help troubleshoot any  specific operating functions, so store it with the machine at all times.
  • Page 5 product identification Record Identification Numbers Pressure Washer If you need to contact an Authorized Dealer or Customer Service line (1- 866-770-1711) for information on servicing, always provide the  product model and identification numbers. You will need to locate the model and serial number for the pump and  record the information in the places provided below.  Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:...

  • Page 6: Safety

    safety Save these Instructions SAFETy RUlES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol (      ) is used with a signal word (DANGER,  CAUTION, WARNING), a pictorial and/or a safety message to alert  you to hazards.  DANGER indicates a hazard which, if not avoided, will result in death ...
  • Page 7 safety WARNING Serious injury or death may occur from normal sparks in  the multiple ignition sources or engine/burner exhaust. Injury or death may occur as a result of improper fueling. Serious injury or death may occur from a ground fire  caused by a muffler spark. Serious injury or death may occur if system safety’s are  not properly maintained. • Always operate pressure washer in a well ventilated area free of  flammable vapors, combustible dust, gases or other combustible  materials. • Do not store the pressure washer near an open flame or any  equipment such as a stove, furnace, water heater, etc., which utilizes  a pilot light or sparking device. • Do not use this pressure washer to spray flammable material! • Do not smoke while filling burner fuel tank. • Never fill the fuel tanks while the pressure washer is running or hot.  Allow to cool two minutes before refueling. • Always refuel slowly to avoid the possibility of spilled fuel which may  cause a risk of fire. • Do not refuel indoors or in a poorly ventilated area. • Engine Fuel Tank: If using a Gasoline Engine, refuel with gasoline only.  Do not use diesel or fuel oil. • Burner Fuel Tank (Black): When refueling the Burner Fuel Tank, use  No. 1 or No. 2 fuel oil/diesel or kerosene. Do not use gasoline. • Do not operate the unit if gasoline or diesel fuel is spilled. Wipe the  pressure washer clean and move it away from the spill. Avoid creating  any ignition until the gasoline or diesel fuel has evaporated. • A spark arrester must be added to the muffler of this engine if it is  to be used on any forest covered, brush covered or grass covered  unimproved land. The arrester must be maintained in effective working  order by the operator. In the state of California, the above is required  by law. (Section 4442 of the California Public Resources Code.)  Other states may have similar laws. Federal laws apply on Federal  lands. • This pressure washer has a Safety Relief device which should never  be altered, modified, removed or made inoperative. If the device fails,  replace immediately with only genuine manufacturer replacement part.
  • Page 8 safety WARNING Serious injury or death may occur from inhaling engine/ burner exhaust or dangerous vapors. The engine  exhaust from this product contains chemicals known to  the State of California to cause cancer, birth defects, or  other reproductive harm. • Never operate this pressure washer in an enclosed area. Always make  certain there is adequate ventilation (fresh outside air) for breathing  and combustion. This will prevent the buildup of dangerous carbon  monoxide gases. Beware of poorly ventilated areas, or areas with  exhaust fans which can cause poor air exchange. • Follow all safety instructions provided with the materials you are  spraying. Use of a respirator may be required when working with  some materials. Do not use this pressure washer to dispense  hazardous detergents. WARNING Serious injury or death could occur from high pressure  spray penetrating the skin. • Keep clear of nozzle and spray! Never put your hand, fingers or body  directly over the spray nozzle. • Do not direct discharge stream at persons or self. • This product is to be used only by trained operators. • Always keep operating area clear of all persons. • DO NOT allow children to operate this unit! • SEEK EMERGENCY MEDICAL CARE if the spray appears to have  penetrated the skin! DO NOT TREAT AS A SIMPLE CUT!! • High pressure hoses and fuel lines should be inspected daily for signs  of wear. If evidence of failure exists, promptly replace all suspect  hoses and fuel lines to prevent the possibility of injury from the high  pressure spray. If a hose or fitting is leaking, NEVER PLACE YOUR  HAND DIRECTLY ON THE LEAK. • NEVER operate the gun with the trigger wired in the open position.  To prevent accidental discharge, the trigger gun should be securely  locked when not in use. • Before removing the spray nozzle or servicing the unit, ALWAYS shut  off the unit and trigger the gun to release trapped pressure. (Even af- ter you shut off the unit, there is high pressure water left in the pump,  hose and gun until you release it by triggering the gun.)
  • Page 9 safety WARNING Serious injury or death may occur from contact with  electricity. • DO NOT direct spray on or into electrical installations of any kind!  This includes electrical outlets, light bulbs, fuse boxes, transformers,  the unit itself, etc. • DO NOT allow metal components of the pressure washer to come in  contact with live electrical components. WARNING Serious injury may occur from touching the gasoline  engine, muffler or heat exchanger. These areas can  remain hot for some time after the pressure washer is  shutdown. • Never allow any part of your body to contact the gasoline engine,  muffler or  heat exchanger. WARNING Serious injury may occur from a pressure washer  malfunction or exploding accessories if incorrect system components, attachments or accessories are  used.  Serious injury or death may occur if attempting to start  the pressure washer when the pumping system is  frozen. • Never make adjustments to the factory set pressures. • Never exceed manufacturers maximum allowable pressure rating of  attachments. • Do not allow any hoses to make contact with heat exchanger to  prevent the possibility of bursting. Avoid dragging the hoses over  abrasive surfaces such as cement. • Use only manufacturer recommended repair parts for your pressure  washer. • In freezing temperatures, the unit must always be warm enough to  ensure there is no ice formation in the pump. Do not start the pressure  washer if it has been transported in an open or under heated vehicle  without first allowing the pump to thaw.
  • Page 10 safety WARNING Serious injury may occur to the operator from moving  parts on the pressure washer. • Before making any adjustments, be certain the engine is turned off  and the ignition cable(s) is removed from the spark plug(s). Turning  the machinery over by hand during adjustment or cleaning might start  the engine and machinery with it. • Do not operate the unit without all protective covers in place. WARNING Serious injury or death may occur from detergents con- tacting the skin. Serious injury can occur from loose debris being pro- pelled at a high speed from the spray gun. Injury may occur if the operator loses his balance  caused by the thrust of water traveling through the  spray nozzle. Injury may occur from the pressure washer. • SEEK EMERGENCY MEDICAL CARE if you are using cleaning  agents and the spray appears to have penetrated the skin! DO NOT  TREAT AS A SIMPLE CUT! Be prepared to tell a physician exactly  what kind of detergents you were using by reading the Material Safety  Data Sheet (MSDS) provided with your detergent. • Never use any solvents or highly corrosive detergents or acid type  cleaners with this pressure washer. • Protective equipment such as rubber suits, gloves and respirators are  advisable, especially when using cleaning detergents. • Keep all detergents out of the reach of children! • ALWAYS wear protective goggles when operating the unit to shield  the eyes from flying debris and detergents. • DO NOT direct spray toward fragile materials such as glass for shat- tering could occur. • Stay alert-watch what you are doing. Do not operate the unit when  fatigued or under the influence of alcohol or drugs. • NEVER squeeze the trigger unless securely braced. • DO NOT overreach or stand on unstable support. • Wet surfaces can be slippery, wear protective foot gear and keep  good footing and balance at all times.
  • Page 11 safety • NEVER trigger the gun while on a ladder or roof. • ALWAYS hold on firmly to the gun/lance assembly when starting and  operating the unit. Failure to do so can cause the lance to fall and  whip dangerously. • Know how to stop the pressure washer and bleed pressures quickly.  Be thoroughly familiar with controls. • DO NOT leave pressurized unit unattended. Shut off the pressure  washer and release trapped pressure before leaving. • DO NOT operate the unit if you see any fuel, oil or water leaks from  the machine. DO NOT resume operation until the unit has been in- spected and repaired by a qualified service person • NEVER run the engine with the governor disconnected or operate at  excessive speeds. • Place unit in a clean, dry, flat area for servicing. Before servicing the  unit: turn the unit off, relieve the water pressure from the trigger gun,  and allow the unit to cool down. Service in clean, dry, flat area. If ap- plicable, block wheels to prevent unit from moving. • Do not move the unit by pulling on the hose.

  • Page 12: Features

    Hsp-small frame features Features - Small Frame x-HW2565AR BODY/FRAME: One piece, welded construction, full  roll cage with solid steel axles, lifting  hook and convenient push/pull handle,  protective steel housing cover. PORTABILITY: Four pneumatic tires for easy mobility. Mi-T-M HSP-SERIES Operator's Manual ® FINISH: Powder Coated HIGH PRESSURE HOSE: 3/8” x 50’ TRIGGER GUN ASSEMBLY: Trigger controlled, safety lock off,  insulated lance. DUAL LANCE: Dual Lance, Insulated, w/adjustable  pressure.
  • Page 13 features 1.   Pneumatic Wheels 2.   Protective Rollcage 3.   Protective Cover 4.   Decal-Warning: Hot Surfaces 5.   Center Balanced Lifting Eye 6.   Decal-Caution: Cool before Refueling 7.   Decal-Warning: Allow to Cool 8.   Convenient Push/Pull Handle 9.   Water Inlet 10. Water Strainer 11. High Pressure Pump 12. Beltguard 13. Heat Exchanger Exhaust 14. Decal-Warning: Do Not Modify Plumbing 15. High Pressure Outlet 16. Coil Drain Assembly 17. Decal-Data Plate 18. Burner Fuel Tank 19. Decal-Caution: Risk of Fire 20. Decal-Warning/Caution/Operating 21. Air Shutter Adjusting Arm 22. Burner On/Off Switch 23. Engine Gasoline Tank 24. Wand Holder 25. High Pressure Hose 26. Trigger Safety Lock 27. Trigger Gun 28. Insulated Lance 29. Adjustable Pressure Dual Lance 30. Nozzle...
  • Page 14 features Hsp-large frame features Features - large Frame x-HW3513AR/x-HWE3513AR BODY/FRAME: One piece, welded construction, full  roll cage with solid steel axles, lifting  hook and convenient push/pull handle,  protective steel housing cover. PORTABILITY: Four pneumatic tires for easy mobility. FINISH: Powder Coated HIGH PRESSURE HOSE: 3/8” x 50’ Mi-T-M HSP-SERIES Operator's Manual ® TRIGGER GUN ASSEMBLY: Trigger controlled, safety lock off,  insulated lance. DUAL LANCE: Dual Lance, Insulated, w/adjustable  pressure.
  • Page 15 features 1.   Pneumatic Wheels 2.   Protective Rollcage 3.   Protective Cover 4.   Decal-Warning: Hot Surfaces 5.   Center Balanced Lifting Eye 6.   Decal-Caution: Cool before Refueling 7.   Decal-Warning: Allow to Cool 8.   Convenient Push/Pull Handle 9.   Water Inlet 10. Water Strainer 11. High Pressure Pump 12. Beltguard 13. Heat Exchanger Exhaust 14. Decal-Warning: Do Not Modify Plumbing 15. High Pressure Outlet 16. Coil Drain Assembly 17. Decal-Data Plate 18. Burner Fuel Tank 19. Decal-Caution: Risk of Fire 20. Decal-Warning/Caution/Operating 21. Air Shutter Adjusting Arm 22. Burner On/Off Switch 23. Engine Gasoline Tank 24. Wand Holder 25. High Pressure Hose 26. Trigger Safety Lock 27. Trigger Gun 28. Insulated Lance 29. Adjustable Pressure Dual Lance 30. Nozzle...

  • Page 16: Installation & Preparation

    installation & preparation Installation & Preparation ATTIRE Proper attire is essential to your safety. It is advised to utilize whatever  means necessary to protect eyes, ears, and skin. Additional safety  attire (such as respiratory mask) may be required when using detergent  cleaning agents with this washer. SET-UP 1. This unit should only be placed on a level surface to ensure proper  lubrication for the water pump while operating. NEVER spray water  directly on the unit. 2. Do not use unit in an area: a. with insufficient ventilation. b. where there is evidence of oil or fuel leaks. c. where flammable gas vapors may be present. This unit has multiple ignition sources that could cause an explosion or  fire. 3. Do not allow the unit to be exposed to rain, snow or freezing  temperatures. If any part of the unit becomes frozen, excessive  pressure may build up in the unit which could cause it to burst  resulting in possible serious injury to the operator or bystanders. 4. Be certain to block the wheels to prevent the unit from moving while  operating. 5. Pump oil level should be checked before each use. Check the oil level  indicator on the pump crankcase. Make certain the oil is in the center  of the oil sight glass before each use. If the level appears to be low, fill  with SAE30W non-detergent pump oil. DANGER • DO NOT PLACE UNIT IN AN AREA WHERE  FLAMMABLE GAS VAPORS MAY BE PRESENT. A  SPARK COULD CAUSE AN EXPLOSION OR FIRE! • DO NOT STORE/OPERATE UNIT IN FREEZING  ENVIRONMENTS!
  • Page 17 installation & preparation WARNING • DO NOT OPERATE IN AN ENCLOSED AREA.  USE THIS PRODUCT ONLY IN WELL VENTILATED  AREAS! • THE EXHAUST CONTAINS CARBON MONOXIDE, A POISONOUS, ODORLESS AND INVISIBLE GAS.  BREATHING THIS GAS CAN CAUSE SERIOUS INJURY, ILLNESS & POSSIBLE DEATH. ENGINE/BURNER FUEl TANK DANGER • DO NOT SMOKE WHILE FUELING!  • DO NOT FILL THE FUEL TANK WHILE UNIT IS  RUNNING OR HOT. ALLOW UNIT TO COOL FOR  TWO MINUTES BEFORE RE-FUELING.  • DO NOT FILL FUEL TANK TO POINT OF  OVERFLOWING. ALLOW APPROXIMATELY 1/4” OF  TANK SPACE FOR FUEL EXPANSION. • ALWAYS STORE FUEL AWAY FROM THE WASHER  WHILE THE UNIT IS RUNNING OR HOT. 1. Review “Risk of Explosion or Fire” Warnings pg. 7, before fueling. 2. Locate the Safety Decals on your unit and heed their warnings. 3. Gasoline Engines: When filling tank, gasoline fuel should be a  minimum of 85 octane. DO NOT MIX OIL WITH GASOLINE. Gasoline  fuel should be purchased in quantities that may be used within 30  days. Use of clean, fresh lead-free gasoline is recommended. Leaded  gasoline may be used if lead-free is unavailable. DO NOT use gasoline  containing methanol or alcohol. Burner Fuel: When filling tank, use No. 1 or No 2 fuel oil/diesel or  kerosene. 4. Check the engine oil level before starting the engine. (See Engine  manual.) 5. Refer to the Engine Manual supplied with this unit for proper engine  adjustment procedures. 6. Review the engine manual accompanying this pressure washer for  correct engine start-up and maintenance procedures.

  • Page 18: Dual Lance Connection

    installation & preparation ADJUSTABlE PRESSURE DUAl lANCE This unit features a dual lance assembly with adjustable pressure which  allows the user to select a high or low pressure spray. Simply rotate  the adjustable grip on the dual lance to achieve the desired pressure  selection. 1. Selection of high pressure can be achieved by turning the adjustable  grip on the Dual Lance assembly counterclockwise as shown in the  figure below. 2. Selection of low pressure detergent application can be achieved by  turning the adjustable grip on the Dual Lance clockwise as shown  in the figure below. Once the pressure is low enough, the detergent  injector on the pressure washer will draw detergent into the system. A  INSTALLATION & PREPARATION water/detergent mixture exits from both the spray nozzle and detergent  WARNING nozzle. ANCE ASSEMBLY WITH ADJUSTABLE PRESSURE: RISK OF INJECTION CAUSING features a dual lance assembly with SEVERE INJURY! le pressure which allows the user to NEVER LOOK DIRECTLY AT THE high or low pressure spray.

  • Page 19: Water Supply

    installation & preparation WATER SUPPly 1. Select a water supply hose which is a quality grade of garden hose  measuring at least 3/4” ID and no longer than 50 feet. 2 Check the water inlet strainer to ensure it is clean and free of any  obstructions. As a strainer becomes obstructed, it restricts proper  flow of water to the pump. This can result in cavitations which will  prematurely cause failure of pump packings. a. Using a screwdriver, remove the screen from the water inlet. b. Clean or replace if necessary. 3. Connect the hoses. a. Connect one end of the water supply hose to the water inlet of the  unit. b. Connect the other end of the hose to your pressurized water supply. NOTICE • When connecting the water inlet to the water supply mains, local  regulations of your water company must be observed. In some areas,  the unit must not be connected directly to the public drinking water  supply. This is to ensure there is no feedback of detergents into the  water supply. (Direct connection is permitted if a backflow preventer  is installed. Check with local authorities for approval.) • If there is a high mineral content in your water, it is highly recommend- ed that a water softener and an additional water strainer be added  to the water inlet to help prevent the possibility of excessive scale  buildup inside the heat exchanger coil.  4. Follow the incoming water requirements listed below: a. Water pressure must be a minimum of 20 pounds per square  Inch (PSI) and a maximum of 125 PSI. (A typical outdoor faucet will  generally supply this PSI if turned completely “ON”.) b. Incoming GPM must be approximately one gallon more than the  outgoing GPM stated on the pressure washer nameplate. (You can  check GPM by timing how long it takes to fill a 5 gallon container.) c. Incoming water temperature must not exceed 125°F. Excessive  pump damage may result if the water temperature exceeds this  acceptable level. 5. Never allow the unit to operate without the incoming water line  attached and the water supply is completely turned on. UNlOADER The unloader has been preset at the factory.

  • Page 20: Thermal Relief Valve

    installation & preparation THERMAl RElIEF VAlVE To ensure the water temperature does not exceed acceptable levels,  never allow the pressure washer to operate in the bypass mode (with the  unit running and the trigger closed) for more than three minutes. A thermal relieve valve has been added to this unit to protect the pump.  It may begin to open and release water if the water temperature in the  pump has exceeded 140° F. This will allow fresh, cool water to enter the  system, therefore preventing premature failure of pump packings. PRE-START INSPECTION PROCEDURES Before starting the unit, perform the following procedures: 1. Check the oil level in the pump and engine. 2. Inspect the water inlet strainer. Clean or replace if necessary. See  “Water Supply”, #2, pg 19. 3. Check all hose connections to ensure they are securely tightened. See  “Water Supply”, #3, pg. 19. 4. Inspect for system water leaks, oil leaks and fuel leaks. If a fuel leak is  found, DO NOT START UNIT! See “Risk of Explosion or Fire”, pg. 7.  Be sure that all damaged parts are replaced and that the mechanical  problems are corrected prior to operation of the unit. If you require  service, contact Customer Service. 5. Inspect high pressure hoses for kinking, cuts and leaks. If a cut or leak  is found, DO NOT USE HOSE! Replace hose before starting unit. See  “Risk of Injection” pg. 8. Be sure that all damaged parts are replaced  and that the mechanical problems are corrected prior to operation of  the unit. If you require service, contact Customer Service.

  • Page 21: Operation

    operation Operating Instructions PRIMING THE PUMP It is essential to prime the pump and flush the unit each time the water  supply has been disconnected from the unit OR whenever the unit has  set for any period of time. This unit has a steel coil which, after setting,  will cause the water remaining in the coil from the previous usage to  turn brown or black. This contaminated water must be flushed from the  system before start-up. This procedure should be performed without the  high pressure hose, gun and dual lance assembly installed. DIRECT FEED : All units. 1. Turn on the water supply. 2. Low pressure water will begin flowing from the water outlet. This al- lows the unit to prime and purge any air from the system. The unit is  primed when water flow is uninterrupted by air. 3. Once the unit is primed, turn off the water supply and connect the high  pressure discharge hose to the water outlet of the unit. (Note: The trig- ger gun and dual lance assembly should already be connected to the  high pressure discharge hose at this time.) 4. Turn on the water supply. CAUTION BE CERTAIN THE HOSE, GUN & LANCE ASSY. ARE NOT  CONNECTED TO THE UNIT WHILE PRIMING THE PUMP. PRIMING  ALLOWS MINERAL DEPOSITS TO BE RELEASED FROM THE  SYSTEM WHICH WOULD OBSTRUCT OR DAMAGE THE GUN  AND NOZZLE ASSEMBLY RESULTING IN COSTLY REPAIRS. START-UP/COlD WATER OPERATION WARNING KEEP CLEAR OF NOZZLE! NEVER PLACE HAND OR FINGERS IN  FRONT OF NOZZLE! DO NOT DIRECT DISCHARGE STREAM AT PEOPLE OR PETS! CAUTION DO NOT ALLOW SPRAY PATTERN TO REMAIN ON A FIXED AREA FOR AN EXTENDED PERIOD OF TIME. POSSIBLE DAMAGE MAY OCCUR TO THE AREA.
  • Page 22 operation 1. Refer to the “Safety Precautions” pgs. 7-11 before starting the unit. 2. Locate the Safety Decals on your unit and heed their warnings. 3. Ensure that the switch is in the “OFF” position. 4. Pointing the trigger gun in a safe direction, unlock the trigger gun and  squeeze the trigger. Hold the trigger gun open while starting the en- gine according to the manufacture’s instructions in the engine manual  accompanying this unit. 5. Once the engine has started, ensure the engine throttle is adjusted to  full RPM and perform the following procedures with the trigger gun  open: a. Inspect for system water leaks, oil leaks and fuel leaks. If a fuel leak  is found, TURN UNIT OFF IMMEDIATELY! See “Risk of Explosion  or Fire”, pg. 7. Be sure that all damaged parts are replaced and that  the mechanical problems are corrected prior to operation of the  unit. If you require service, contact Customer Service. b. Inspect high pressure hoses for kinking, cuts and leaks. If a cut or  leak is found, DO NOT TOUCH HOSE AT LEAK!!! TURN UNIT OFF  IMMEDIATELY! Replace hose before starting the unit. See “Risk of  Injection or Severe Cutting Injury” pg. 8. Be sure that all damaged  parts are replaced and that the mechanical problems are corrected  prior to operation of the unit. If you require service, contact Cus- tomer Service. 6.  At this point, the unit is operating as a cold water pressure washer.  Trigger the gun several times and try adjusting the water pressure.  NEVER place hand or fingers in front of the nozzle or look directly into  the nozzle! High pressure water creates a risk of severe injury! 7. Do not allow the machine to operate in the bypass mode (with the  trigger gun closed) for more than three minutes without triggering the  gun. Failure to follow this simple rule can cause premature failure of  the pump packings. 8. Your pressure washer can deliver high pressure spray and a variety  of spray patterns using cold water. If you wish to use the Hot Water  application or Cleaning with Detergents, see page 23 for the correct  procedures.

  • Page 23: Hot Water Operation

    operation HOT WATER OPERATION WARNING THE WATER TEMPERATURE COULD BECOME VERY HOT DURING  HOT WATER OPERATION. BE CAUTIOUS WHEN ADJUSTING  PRESSURE OR CONTROLLING THE TRIGGER GUN/ LANCE  ASSEMBLY. 1. Follow the steps outlined for “START-UP/COLD WATER  OPERATION”. 2. Move the Burner Switch to the ON position. On initial start-up, water  will begin turning hot in approximately 20 seconds and will reach  maximum temperature in approximately 2-1/2 minutes, provided the  trigger remains squeezed. The burner will stop firing when the trigger  is released.  At this point, the unit is operating as a hot water pressure washer.  Be certain to be extremely cautious when adjusting the pressure and  controlling the trigger gun/lance assembly to avoid the possibility of  burns. NOTICE While spraying, it is normal for the burner to fire intermittently. The  high-limit switch will cause combustion to cease when the temperature  of the discharged water exceeds the maximum temperature setting of  the switch. Combustion will begin again when the temperature drops  below the minimum setting. ClEANING WITH DETERGENTS NOTICE This feature is designed for use with mild detergents only. Since the cleaning solution travels through the heat exchanger coil, DO NOT use corrosives as they will cause extensive damage as well as pose a considerable safety hazard. 1. Refer to “Risk of Bodily Injury / Detergents”. Be certain to wear  protective safety attire as stated in warnings. 2. Prepare detergent solution according to label directions. (Never pump  acids, alkalines, abrasive fluids or solvents through the unit. Due to  the unknown and often corrosive characteristics of many detergents  commonly used in the pressure washer cleaning industry, it is  recommended to use only mild detergents with this unit.)

  • Page 24: Shutdown

    operation 3. Fully immerse the detergent strainer into the detergent solution. 4. Adjust the amount of detergent desired by locating the adjustment  knob at the end of the clear vinyl hose. Turn the knob completely  counterclockwise to set at maximum siphon rate. Be certain the  adjustable grip on the dual lance is turned completely clockwise for  low pressure detergent operation. NOTICE This injection system is designed to apply detergents under low pres- sure only. It will not allow detergent solutions to be introduced into the  system unless the dual lance is set in the low pressure mode. 5. To apply solution; unlock the trigger gun and squeeze the trigger. In  a few moments a detergent/water mixture will exit the nozzle. Start  spraying the lower portion of the surface being cleaned and move up,  using long overlapping strokes. Applying from the bottom up helps  avoid streaking. Allow to soak briefly. (Avoid working on hot surfaces  or in direct sunlight to minimize the chances of the detergent drying,  which may result in damaging painted surfaces.) Be certain to rinse a  small section at a time. 6. To rinse; lock the trigger gun in the “OFF” position, rotate the  adjustable grip on the dual lance counterclockwise for high pressure.  Unlock the trigger gun and spray. It will take about 30 seconds to  purge all detergent from the line. For best rinsing results, start at the  top and work down. 7. Siphon a gallon of water through the low pressure detergent injection  system after each use. This prevents the possibility of corrosion or  detergent residue causing mechanical problems during the next use. SHUTDOWN 1. Move the Burner Switch to the OFF position. 2. Squeeze the trigger and discharge the water for a period of three  minutes to cool the heat exchanger and high pressure hose.  (Insufficient cool down period of the high pressure hose will cause  excessive wear and eventual rupturing of the hose.) 3. Do not close the choke to stop the engine. Backfire or engine damage  may occur. Turn the engine “OFF” as directed in the engine manual. 4. Move the engine On/Off Switch to the “off” position. 5. Close the engine fuel shut-off valve. 6. Turn off the water supply and trigger the gun momentarily to relieve  trapped pressure. 7. Disconnect and store hoses. Store unit in a non-freezing environment.

  • Page 25: Maintenance

    maintenance Storage & Maintenance Instructions SPECIFIC MAINTENANCE ENGINE: The engine instructions that accompany your unit detail specific  procedures for maintenance of the engine. Following the engine  manufacturer’s recommendations will extend engine work life. PUMP: Change the pump oil after the first 50 hours of operation. After  initial change, every 3 months or 250 hour intervals are recommended.  If oil appears dirty or milky, changes may be required in greater  frequency. Use SAE20 or 30 non-detergent pump oil and fill only to  the center of the oil sight glass. DO NOT overfill. NOZZLE: Water flow through the spray nozzle will erode the orifice,  making it larger, resulting in a pressure loss. Nozzles should be  replaced whenever pressure is less than 85% of the maximum. The  frequency of replacement will depend upon such variables as mineral  content in the water and number of hours the nozzle is used. COUPLERS: There are o-ring seals inside the couplers which will  deteriorate. To replace, simply install a replacement o-ring to correct  the leak. (Additional o-rings can be purchased from your dealer.) FUEL WATER SEPARATOR: The fuel filter has a built in water separator.  Occasionally the water has to be drained from the separator. Follow  the procedures listed below: 1. Check the collection bowl daily. 2. Ensure the unit is off and place an oil catch basin under the fuel  cartridge. 3. Loosen the drain plug to allow the fuel/water contaminants to flow into  the catch basin. 4. Retighten the drain plug when completed. 5. Dispose of drainage according to environmental regulations in your  area. BURNER AIR ADJUSTMENT: The air shutter has been factory preset  for proper operation between sea level and 2000 feet elevation at  standard conditions (60°F ambient water and air temperatures). To  assure maximum combustion efficiency at colder temperatures and  higher altitudes, it will be necessary to adjust the air supply to the  combustion chamber. A smoke spot test is recommended during  any air shutter adjustment. This will aid in maximizing the burner ...
  • Page 26 maintenance a. SMALL FRAME:  1. If the test is greater than a #3 smoke, turn the shutter arm clockwise  to increase the air flow into the combustion chamber. 2. If the test is yellowish in color, turn the shutter arm counterclockwise  to decrease the air flow into the combustion chamber. b. LARGE FRAME: 1. If the test is greater than a #3 smoke, turn the shutter arm  counterclockwise to increase the air flow into the combustion  chamber. 2. If the test is yellowish in color, turn the shutter arm clockwise to  decrease the air flow into the combustion chamber. 3. Hold onto the air shutter adjusting arm and loosen the locking nut. Move the shutter in 1/8” increments and retighten the locking nut  after each 1/8” movement. 4. Trigger the gun on and off slowly to make sure there is proper ignition. Slight or no puffing on the ignition, and a smoke spot test of less than #3 smoke is good. 5. Repeat steps 2 and 3 until step 4 is attained. LEAKS: Promptly eliminate any leaks found in the pumping system by  removing suspect parts, applying thread sealant to the threads and  reinstalling. NOTICE If using Teflon tape, be certain no tape gets inside any plumbing to prevent the possibility of a plugged spray nozzle.

  • Page 27: Winterizing

    maintenance WINTERIZING For storage and transportation purposes in subfreezing ambient  temperatures, it will be necessary to winterize this unit. This unit must be  protected to the lowest incurred temperature for the following reasons: 1. If any part of the pumping system becomes frozen; excessive pressure  may build up in the unit which could cause the unit to burst resulting in  possible serious injury to the operator or bystanders. 2. The pumping system in this unit may be permanently damaged if  frozen. FREEZE DAMAGE IS NOT COVERED BY WARRANTY. If you must store your unit in an area where the temperature may fall  below 32°F, you can protect your unit by following the procedure outlined  below. 1. Gather the following items: a. Two 5 gallon containers. b. One gallon of antifreeze. (Use an environmentally safe antifreeze.) c. Water supply. d. Three foot hose, 1/2-3/4 I.D. with a 3/4 inch male garden hose  fitting. 2. Procedure: a. To start winterizing, unit must be run according to the “Start-up  Cold Water Operation” listed on page 14. b. After running and priming, shut off the unit and water supply. c. Relieve system pressure by pointing the trigger gun in a safe  direction and squeezing the trigger until water flow ceases to exit the  gun assembly. d. Lock the trigger gun in the OFF position and adjust the collar to the  low pressure mode. e. Remove the water supply hose from the unit and attach the 3 foot  hose securely to the inlet connection. f. Shut off the detergent injector (if applicable). g. Fill one 5 gallon container with water. h. Holding the 3 foot hose in an upright position, completely fill the  hose with water. Then plug the open end of the hose with your thumb  or finger. Place the plugged end into the 5 gallon container of water. i. Start the unit. Trigger the gun several times until all the air is worked  out of the system (unit is primed). j. With the trigger gun held open, siphon enough water out of the 5  gallon container until there is just enough water left to mix with the  antifreeze. NOTICE Proper winterizing is based on the recommended manufacturer’s ...
  • Page 28 maintenance k. Point the trigger gun into the empty container. l. Trigger the gun until the antifreeze begins to exit the trigger gun.  Release the trigger for 3 seconds, then trigger the gun for 3 seconds.  Continue cycling the trigger gun several times until all the antifreeze  mixture is siphoned from the container. m. Stop the unit. n. Detach the 3 foot hose from the unit and drain any excess antifreeze  back into the 5 gallon container. o. Disconnect the hose and trigger gun from the unit and drain any  excess antifreeze back into the 5 gallon container. p. Drain hose and trigger gun assembly. Store with the unit in a safe  nonfreezing area. q. Store antifreeze solution for next use or dispose of according to  state EPA laws. 3. Optional Procedure: a. Shut the unit and water supply off. b. Relieve system pressure by pointing the trigger gun in a safe  direction and squeezing the trigger until water flow ceases to exit the  nozzle. c. Disconnect and drain the hose, trigger gun and adjustable nozzle  assembly. d. Remove the hose from the inlet side of the heat exchanger coil. e. Start the unit and allow it to run until all the water exits the unit.  Once the water has stopped flowing from the unit, turn off. NOTICE When using this procedure, caution should be used as ice chips can  form from drops of water which could cause the unit to burst if starting  before completely thawed. WARNING DO NOT STORE/OPERATE UNIT IN A FREEZING ENVIRONMENT!

  • Page 29: Maintenance Chart

    maintenance MAINTENANCE CHART PROCEDURE DAILY 3  6  9  12  MONTHS MONTHS MONTHS MONTHS Check engine oil level Change engine oil***** Check water pump oil level Change water pump oil ** Oil leak inspection Fuel leak inspection Water leak inspection Hose inspection Water inlet filter inspection Inspect belt Replace high pressure  nozzle*** Replace fuel filter Inspect fuel pump filter* Replace fuel nozzle* Check burner air  adjustment Check burner electrodes* Test water pressure* Test fuel pressure* Test water temperature* Descale coil**** *       Must be performed by an authorized service technician. **     The pump oil must be changed after the first 50 hours of operation  and every 250 hours or 3 months, whichever comes first. ***       High pressure nozzle should be replaced whenever pressure is less  than 85%.

  • Page 30: Troubleshooting

    troubleshooting Troubleshooting TROUBlESHOOTING CHART SYMPTOM PROBABLE CAUSE REMEDY Engine will not start Various engine problems Refer to the Engine Manual  accompanying your unit. Unit components are frozen. Allow to thaw. If any part of the  unit becomes frozen; excessive  pressure may build up in the  unit which could cause the unit  to burst resulting in possible  serious injury to the operator or  bystanders. No discharge at  Inadequate water supply. Ensure hose is 3/4” diameter  nozzle when trigger  and incoming water supply is  mechanism is  turned on. squeezed. Low or fluctuating  Kink in water inlet hose. Remove kink. pressure. Kink in high pressure  Replace kinked high pressure  discharge hose. hose. Water inlet screen  Remove screen, clean or  obstructed. replace. Pump sucking air. (Prime  Tighten all water intake ...
  • Page 31 troubleshooting SYMPTOM PROBABLE CAUSE REMEDY Detergent will not  Detergent strainer is not  Check, submerge if necessary. siphon into Low  completely submerged in  Pressure Detergent  detergent solution. Mode Detergent strainer  Inspect, clean or replace. obstructed. Detergent hose cut,  Inspect, clean or replace. obstructed or kinked. Detergent adjusting knob  Open adjusting knob. Refer to  turned to closed position. “Cleaning with Detergents”. Grip on adjustable nozzle is  Turn grip counterclockwise to  not in low pressure mode. move to low pressure. Nozzle assembly is plugged. Clean or replace. Too many high pressure  Use one extension maximum. hose extensions attached to  the water outlet. Ball & Spring in Venturi  Remove, clean or replace. stuck. Water flows back into  Ball & Spring in Venturi  Remove, clean or replace. detergent container. reversed, missing or  corroded.
  • Page 32 troubleshooting SYMPTOM PROBABLE CAUSE REMEDY Blower runs, but  Dirty or clogged fuel nozzle Replace fuel nozzle. burner will not ignite. Ignition module. Consult your Customer Service. Ignition electrodes  With unit running and trigger  damaged or worn. gun closed, look through burner  sight glass to ensure there is  sparking across electrodes. No voltage. Consult Service Department. Pressure switch override. Pressure should be over 375  High limit switch override. Allow unit to cool down before reigniting. Improper burner air  Adjust. adjustment. Fuel solenoid valve failure. Replace. Burner runs erratically. Water in the fuel oil. Drain fuel filter/water separator.  Drain fuel tank, and replace with  clean fuel. Dirty fuel filter. Replace. Dirty fuel nozzle. Replace. Improper air adjustment  Adjust. setting. Fuel pump malfunctioning.
  • Page 34 If you need assistance with the assembly or operation of this Pressure Washer please call 1-866-770-1711...
