Page 2: Safety Instruction
Manual | Froggy 10W Miniatur LED Movinghead 1. Caution Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! Keep this device away from rain and moisture! Make sure it is grounded when using it! Unplug mains lead before opening the housing! For your own safety, please read this user manual carefully before you initial start-up. -
Page 3: Installation
Manual | Froggy 10W Miniatur LED Movinghead 3. Installation On the rear panel of the item you can find an 3pin XLR-jack (DMX Out) and an 3pin XLR-plug (DMX In), which can be used for connecting several devices. Choose the device which is to control the effects. -
Page 4: Control Menu Map
Manual | Froggy 10W Miniatur LED Movinghead 4. Control menu map... -
Page 5: Operation
Manual | Froggy 10W Miniatur LED Movinghead 5. Operation Projector DMX starting address selection All fixtures should be given a DMX starting address when using a DMX signal,so that the correct fixture responds to the correct control signals. This digital starting address is the channel number from which the fixture starts to listen to the digital control information sent out from the DMX controller. -
Page 6: Function Control
Manual | Froggy 10W Miniatur LED Movinghead 6. DMX Protocol OVATION Froggy White Channel DMX Table: 10 Channel mode Function Function Control Dimmer 0-255 Dimming 0%-100% Shutter 0-255: shutter 0%-100% Strobe 0-255: Strobe from slow to fast 0-255: Tilt 0°-540°... - Page 7 Manual | Froggy 10W Miniatur LED Movinghead 7. Attention: How to set master-slave without connecting to DMX 1.The Sound Master-slave : Link all fixtures. Don’t connect the DMX Controller, set the address to A001, choose one fixture as Master, and set the one to Sound model(so 1,so 2). Then sound master-slave mode is achieved.
-
Page 8: Specifications
Manual | Froggy 10W Miniatur LED Movinghead 8. Specifications • Physical Length: 14cm Width: 11cm Height: 25cm Weight: 1.9kg without accessories • Dynamic effects Beam color wheel:13 color + open Beam color temperature: CTO， 8000K Electronic dimming: 0-100% linear dimming... - Page 9 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
