Summary of Contents for Squareled Non-Plus-Ultra Violet
-
Page 2: Safety Instruction
Manual | Non-Plus-Ultra Violet 1. Summary Thank you for purchasing our PS1212. Please read these instructions carefully before begin and ope- rate the fixtures according to these instructions to avoid any possible damages and accidents causes by misusage Products introduction: LED PS1212 light uses casting aluminum housing, designed in a fashion of hydrodynamic form. -
Page 3: Outside Size Picture
Manual | Non-Plus-Ultra Violet 3. outside Size Picture ... -
Page 4: Main Function
Manual | Non-Plus-Ultra Violet 4. Main Function » high quality LED: low consumption, brightness, stable capability and long life » each color of LED with 16666 dimming. RGB can make over 16.7 million colors, adding W can achieve many effects. - Page 5 Manual | Non-Plus-Ultra Violet DMX Channel (8CH): channel DMX value Control Function Remarks Priority 0-255 General dimming 0-255 R 0-100% 0-255 G 0-100% 0-255 B 0-100% 0-255 A 0-100% 0-255 W 0-100% 0-255 UV 0-100% 0-10 Close Strobe 11-255 Adjust Strobe Speed (1-20Hz)
- Page 6 Manual | Non-Plus-Ultra Violet 64-66 67-69 B+UV 70-72 73-75 A+UV 76-78 W+UV 79-81 R+G+B 82-84 R+G+A 85-87 R+G+W 88-90 R+G+UV 91-93 R+B+A 94-96 R+B+W 97-99 R+B+UV 100-102 R+A+W 103-105 R+A+UV 106-108 R+W +UV 109-111 G+B+A 112-114 G+B+W 115-117 G+B+UV 118-120...
-
Page 7: Display Operation
Manual | Non-Plus-Ultra Violet 187-189 R+G+B+A+UV 190-192 R+G+B+W+UV 193-195 R+G+A+W+UV 196-198 R+B+A+W+UV 199-201 G+B+A+W+UV 202-204 R+G+B+A+W+UV auto -run effect(the more value,the faser 205-255 speed) 0-15 Invalid 10CH Multi-colors jumping change(the more 16-255 value,the faser speed) Set by LCD display DIMMER0-4... -
Page 8: Menu Instruction
Manual | Non-Plus-Ultra Violet 7. Menu Instruction... - Page 9 Manual | Non-Plus-Ultra Violet 1. Operating instruction: MENU (UP/DOWN)+ENTER+(UP/DOWN)+ENTER Remark: Exp: Select the DMX mode, Here are the operation details: » Press the MENU, go back to the initial setting » Press UP/DOWN, display “Addr” » Press ENTER to change the content, the display will glinting at this moment »...
-
Page 10: Operating Control Instruction
Manual | Non-Plus-Ultra Violet 8. Operating Control Instruction Master/Slave: Master: The master should always work as a master as long as it is not set in a DMX mode whatever other modes it is. And it send out the signal so that the slave synchronous with it. To avoid the host signal and DMX512 signals interfere with each other, should cut off the DMX512 signals. - Page 11 Manual | Non-Plus-Ultra Violet The Conversion between 3 pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable 10. Connecting picture Light connecting picture:...
-
Page 12: Troubleshooting
Manual | Non-Plus-Ultra Violet 11. Trouble Shooting Problem Checking Way • Check the power source plug is in normal or not Can not turn on the light • Check the switch of the lights is off or on • Check the fuse if in normal •... -
Page 13: Technical Specification
Manual | Non-Plus-Ultra Violet 12. Technical Specification • Input voltage: AC 100V-264V/47-63HZ • Output voltage: DC24V • Consume: 144W • Lamp Type: High Power LED (12W) • Lamp Spec: 6-in-1 12W (112PCS) • Constant current driver: 500MA • PWM Dimmer: 400HZ(16666 grades) •... - Page 14 Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
