Summary of Contents for Squareled Storm 300 RGBW
- Page 2 Manual | Storm 300 RGBW INTRODUCTION Thank you for having chosen our LED lighting. Unpack the device, inside the box you should find: • The fixture device • One power cable • One XLR connection cable • This manual Please check carefully that there is no damage caused by transportation.
-
Page 3: Safety Instructions
Manual | Storm 300 RGBW SAFETY INSTRUCTIONS This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. - Page 4 Manual | Storm 300 RGBW Main menu Sub-menu address DMX Address Setting channel 1Ch Channel 2Ch Channel 3Ch Channel 4Ch Channel 6Ch Channel Mode Channel 8ChF Channel 9ChF Channel 10ChF Channel 10ChD Channel 14ChD Channel 15ChF Set Curve Mode L...
-
Page 5: Main Functions
Manual | Storm 300 RGBW Auto speed 00 - 40 Load Default Firmware Version Vers 5.8 Main functions 1. address:Current DMX address Setting DMX address by button press ENTER button when show the address menu, then adjust the DMX address by pressing... -
Page 6: System Info
Manual | Storm 300 RGBW 2. config Setting DMX mode press ENTER button when show the channel menu, then select the DMX mode by pressing [UP] or [DOWN] button Setting Dimmer Curve press ENTER button when show the dimmer curve menu, then select the dimmer curve... -
Page 7: Color Menu
Manual | Storm 300 RGBW 4. Color menu press ENTER button when show the Color menu, press Enter button to select the color mode, then adjust the color by pressing [UP] or [DOWN] button 5. White balance press ENTER button when show the white balance menu, press Enter button to select the color mode, then adjust the color by pressing [UP] or [DOWN] button 6. - Page 8 Manual | Storm 300 RGBW 4CH Mode Value Function 0-255 0-255 Green 0-255 Blue 0-255 White 6ch Mode Value Function Blackout 8-15 Shutter Open 16-151 Strobe 152-175 Fade In 176-199 Fade Out 200-244 Random Strobe 245-255 Shutter Open 0-255 Master dim...
- Page 9 Manual | Storm 300 RGBW 0-255 Fine Green 0-255 Blue 0-255 Fine Blue 0-255 White 0-255 Fine White 10 chF Mode Value Function 0-255 Master Dimmer 0-255 Fine Master Dimmer 0-255 0-255 Red dimmer fine 0-255 Green 0-255 Green dimmer fine...
- Page 10 Manual | Storm 300 RGBW 14CH Mode Value Function 0-255 Master Dimmer 0-255 Red1 0-255 Green1 0-255 Blue1 0-255 White1 0-255 Red2 0-255 Green2 0-255 Blue2 0-255 White2 0-15 Shutter Open 16-255 Strobe (fast to slow) 0-255 Color macro, color+black...
-
Page 11: Cleaning And Maintenance
Manual | Storm 300 RGBW 0-35 Shutter Open 36-71 Fade Out 72-107 Fade In 108-143 Fade In and Out 144-179 Fade By SIN Curve 180-215 Four Color Flow 216-255 Eight Leds Flow 216-255 Dimmer speed 0-63 Linear 64-127 Square 128-191... - Page 12 Manual | Storm 300 RGBW Das Lichttechnikhaus Vertriebs GmbH Rudolf-Diesel-Str. 3, D-89312 Günzburg Telefon +49 (0) 82 21 207 98-0 +49 (0) 82 21 207 98-69 E-Mail info@lth-gmbh.de www.lth-gmbh.de...
