- Page 1 User’s Manual SP362B/SP363B/SP373 Series Twist Pair to Fiber Ethernet Media Converter http://www.micronet.info...
-
Page 2: Package Content
Package Content Thank you for purchasing Micronet Ethernet Media Converter. Before you start installing the Media Converter, verify the following items in the package Media Converter User’s Manual Power Adapter Product Overview The SP362B/SP363B 1000BASE-TX to 1000BASE-SX/LX converter is primarily designed for larger and higher bandwidth demanding workgroups that require expansion of the Ethernet network. - Page 3 Follow the steps to install the media converter. This Converter is a plug-and-play device. Connect the supplied AC to DC power adapter to the receptacle at the back of the converter. Attach the plug into a standard AC outlet. SP362B/SP363B Gigabit Converter This converter provides one TX port and one FX port.
-
Page 4: Led Indication
LED Indication Please refer to the following table for LED indication of SP362B/SP363B Status Indication Steady The Power is on LNKC Steady A valid network connection established on TX port No connection LNKF Steady A valid network connection established on Fiber port No connection FDX/COL Steady... - Page 5 SP373 Series 10/100TX to 100FX Converter This converter provides one TX port and one FX port. For the FX port, it provides options of either multi-mode or single-mode fiber accommodating ST/SC/MT-RJ/VF-45 connector. For the TX port, it uses RJ-45 connector supports auto senses the speed of 10/100Mbps. New features support Auto Uplink on TX port and LFPT (Link-Fault-Pass-Through).
- Page 6 LED Indication Please refer to the following table for LED indication of SP373 Series Status Indication Steady The Power is on The Power is off 100 (Mbps) Steady Connection at speed of 100Mbps Connection at speed of 10Mbps LNK/ACT Steady A valid network connection established Flashing Transmitting or receiving data...
- Page 7 Pin1 Pin2 Pin3 Pin4 Pin5 Pin6 Disable Enable forced TX port forced TX port forced FX port forced Reserved LFPT mode for TX to 10Mbps to half duplex to half duplex port mode mode Enable Enable auto TX port forced TX port forced FX port forced LFPT...
-
Page 8: Ce Mark Warning
SPECIFICATIONS OF SP373 Series MODEL SP373A SP373B SP373C SP373D SP373B-XX STANDARD IEEE802.3 10BASE-T; IEEE802.3u 100BASE-TX/FX TP PORT RJ-45 x 1 (10/100 Mbps) 100BASE-FX PORT MT-RJ VF-45 TP CONNECTIONS 10BASE-T: UTP Category 3,4,5 100BASE-TX : UTP Category 5 FIBER 9 or 10/ CONNECTIONS 62.5/125µm or 50/125µm multi-mode fiber 125µm...
