- Page 1 User’s Manual 10/100TX to 100FX Industrial Media Converter Model No.: SP373HS World Wide Web: www.micronet.com.tw ; www.micronet.info...
-
Page 2: Ce Mark Warning
FCC Warning This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. -
Page 3: Table Of Contents
Content FCC Warning............i CE Mark Warning ..........i Overview............. 1 Introduction .............. 1 Features ..............3 Packing List.............. 4 Safety Precaution............. 4 Hardware Description ......... 5 Front Panel............... 5 Top View ..............6 Wiring the Power Inputs ........... 6 Wiring the Fault Alarm Contact ........ - Page 4 DIN-Rail Mounting..........12 Wall Mount Plate Mounting ........14 Network Connection ......... 15 Installation Steps............ 15 Troubles shooting ..........17 Technical Specification........18...
-
Page 5: Overview
Overview Introduction The SP373HS Industrial 10/100Base TX to 100BaseFX Media Converter is a cost-effective solution for the converting between 10/100Base-TX and 100Base-FX cabling, it allows you to extend the cabling distance of your 100Base-FX network up to 30 kilometers for single-mode fiber (SC connector). - Page 6 Wide Operating Temperature The operating temperature of the Industrial 10/100Base TX to 100BaseFX Media Converter is between -40 ~ 75 C (wide operating temperature model) or -10 ~ 60 C (standard model). With such a wide range, you can use the Industrial 10/100Base TX to 100BaseFX Media Converter in some of the harshest industrial environments that exist.
-
Page 7: Features
Features Provides 1 x 10/100Mbps Ethernet ports with RJ-45 connector IEEE802.3x Flow Control and Back pressure Provides 1 x SC (single-mode) fiber connector Supports full/half duplex flow control Supports MDI/MDI-X auto-crossover Supports surge (EFT) protection 3,000 V for power line Supports 6,000 V Ethernet ESD protection Supports auto-negotiation... -
Page 8: Packing List
Packing List 1 x Industrial 10/100BaseTX to 100BaseFX Media Converter 1 x User manual 2 x Wall Mounting Bracket and Screws 1 x DIN-rail Mounting Bracket and Screws Safety Precaution Attention IF DC voltage is supplied by an external circuit, please use a protection device on the power supply input. -
Page 9: Hardware Description
In this chapter, you will be given an overview of the Industrial 10/100Base TX to 100BaseFX Media Converter hardware installation procedures. Front Panel The Front Panel of the Industrial 10/100Base TX to 100BaseFX Media Converter is shown as follows. Front Panel of SP373HS 10/100TX to 100FX Industrial Media Converter... -
Page 10: Top View
The top panel of the Industrial 10/100Base TX to 100BaseFX Media Converter is equipped one terminal block connector of two DC power inputs. Top Panel of SP373HS 10/100Base TX to 100BaseFX Industrial Media Converter Wiring the Power Inputs Please follow the steps below to insert the power wire. -
Page 11: Wiring The Fault Alarm Contact
Wiring the Fault Alarm Contact The fault alarm contact is in the middle of terminal block connector as the picture shows below. Inserting the wires, it will detect the fault status including power failure/port link failure and form an open circuit. Insert the wires into the fault alarm contact. -
Page 12: Dip-Switch
Full-duplex mode FDX/COL Amber Flashing Packet collision occurred (fiber port) Half-duplex mode Connected to network LNK/ACT Green Flashing Networking is active (fiber port) Not connected to network Link to 100Mbps network 100M (RJ-45) Amber Link to 10Mbps network Connected to network LNK/ACT Green Flashing... -
Page 13: Ports
immediately after the data being received. And TP port should be forced at 100M in this application. When DIP-Switch is in switching mode (OFF), the converter function is the same as a Switch Hub. Note Please don’t change the DIP-switch setting when UTP or fiber port is transmitting or receiving data. - Page 14 Pin MDI-X Signal Name MDI Signal Name Receive Data plus (RD+) Transmit Data plus (TD+) Receive Data minus (RD-) Transmit Data minus (TD-) Transmit Data plus (TD+) Receive Data plus (RD+) Transmit Data minus (TD-) Receive Data minus (RD-) Straight Through Cable Schematic Cross Over Cable Schematic Fiber Port The fiber port of SC type connector can work in single mode (30Km).
-
Page 15: Cabling
ATTENTION This is a Class 1 Laser/LED product. Don’t stare into the Laser/LED Beam. Cabling Twisted-pair segment can be connected with unshielded twisted pair (UTP) or shielded twisted pair (STP) cable. The cable must comply with the IEEE 802.3u 100Base TX standard for Category 5. The cable between the converter and the link partner (converter, switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long. -
Page 16: Mounting Installation
Mounting Installation DIN-Rail Mounting The DIN-Rail is screwed on the unit when out of factory. If the DIN-Rail is not screwed on the unit, please see the pictures and follow the steps below to screw the DIN-Rail on the unit. Use the screws to screw the DIN-Rail on the rear side of the unit. - Page 17 After the DIN-Rail is screwed on the rear side of the unit, insert the top of DIN-Rail into the track. Then, lightly push the DIN-Rail into the track. Check if the DIN-Rail is tightened on the track or not. To remove the unit from the track, reverse steps above.
-
Page 18: Wall Mount Plate Mounting
Wall Mount Plate Mounting Follow the steps below to mount the unit with wall mount plate. Remove the DIN-Rail from the unit; loose the screws to remove the DIN-Rail. Place the wall mount plate on the top & bottom side of the unit. Use the screws to screw the wall mount plate on the unit. -
Page 19: Network Connection
Network Connection In this paragraph, we will describe how to install the Industrial 10/100Base TX to 100BaseFX Media Converter. Installation Steps Unpack the unit packing. Check the DIN-Rail is screwed on the unit. If the DIN-Rail is not screwed on the unit. Please refer to DIN-Rail Mounting section for DIN-Rail installation. - Page 20 To hang the unit on the DIN-Rail track or wall, please refer to the Mounting Installation section. Power on the Unit. How to wire the power; please refer to the Wiring the Power Inputs section. The power LED on the unit will light up. Please refer to the LED Indicators section for meaning of LED lights.
-
Page 21: Troubles Shooting
Troubles shooting Verify that you are using the right power cord/adapter (DC 12-48V), please don’t use the power adapter with DC output bigger than 48V, or it will burn this converter down. Select the proper UTP/STP cable to construct your network. Please check that you are using the right cable. -
Page 22: Technical Specification
Technical Specification The technical specifications of the unit are listed as follows. Communications IEEE 802.3, 802.3u, 802.3x Compatibility 10/100Base-TX Transmission Distance Single-Mode Fiber 30km Transmission Speed Up to 100 Mbps Interface Fiber : SC (single-mode) Connectors 1 x RJ-45 6-pin removable screw terminal (power &... - Page 23 IP30, Metal shell with solid mounting Enclosure kits Mounting DIN35 rail, Wall Protection ESD (Ethernet) 6,000 V 3,000 V Surge (EFT for power) Power Reverse Environment Operating Temperature -40 ~ 75 C (wide operating temperature model) 5% ~ 95% (non-condensing) Operating Humidity -40 ~ 85 Storage Temperature...
- Page 24 EN61000-3-2 (Harmonics Current) EN61000-3-3 (Voltage Fluctuation & Flickers) Free Fall IEC60068-2-32 Shock IEC60068-2-27 IEC60068-2-6 Vibration...
