- Page 1 RGBW- - - - 18L 18L 18L 18L RGBW RGBW DIRECT DIRECT DIRECT DIRECT POWER POWER POWER POWER LIGHTING LIGHTING LIGHTING LIGHTING MANUAL MANUAL MANUAL MANUAL Coloronix, Inc. 5461 West Jefferson Boulevard Los Angeles, California 90016 (323) 677-4242 http://www.rgbw.com Summary Summary Summary Summary...
-
Page 2: Additional Supplies
4x4 inch electrical junction box rated for the application (optional) Controller (DMX512 compatible) Proper mounting bolts, washers and lock washers to secure the fixture to the mounting surface. Page 2 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1... -
Page 3: Specifications
• AC Power and DATA cables may NOT run in the same conduit or within one foot due to possible induced errors. • 32 DMX DATA links max per run Page 3 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1... - Page 4 DMX working mode to Mode 1 ， DMX Working Mode 1: 4-CHANNEL (For individual color dimming control) Channel Value Function 0-255 0-255 Green 0-255 Blue 0-255 Cool White Page 4 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1...
- Page 5 Secure the fixtures to a solid mounting surface using three threaded fasteners minimum • of 3/8 inch (10mm) stainless steel complete with flat and locking washer. Rotate the fixtures using tilt method into the desired position. • Page 5 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1...
- Page 6 • Page 6 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1...
- Page 7 The cable must have the following characteristics: Type: shielded, 2-conductor twisted pair Maximum capacitance between conductors: 30 pF/ft Maximum capacitance between conductor and shield: 55 pF/ft Maximum resistance: 20 ohms/1000ft Normal impendance: 140 ohms Page 7 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1...
- Page 8 B. In order that they may be easily accessed once construction is complete, secure data cables in the immediate proximity of the fixtures. Note: To avoid signal transmission problems and interference, it is always advisable to connect to a DMX signal terminator. Page 8 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1.0.1...
-
Page 9: Maintenance
Maintenance Maintenance Maintenance Coloronix recommends periodic cleaning of the heat sink and lens. Over time these components can become dirty or full of debris. This can result in lack of cooling or can limit the capabilities of the fixture. Lens Maintenance Clean the front Lexan®...
