User Manual
HD IP
PRO
Professional HD IP NVR
8 Camera
8 Camera
16 Camera
20 Camera
36 Camera
Quick Setup Guide
Thank you purchasing the XRN HD IP NVR from Xvision Pro HD.
Please ensure that you read and understand this Quick Setup Guide before operating the camera.
Please store this Quick Guide in an easily accessible location.
Version 1
Advertisement
Table of Contents
Related Manuals for XVision XRN0808E
Summary of Contents for XVision XRN0808E
- Page 1 36 Camera Quick Setup Guide Thank you purchasing the XRN HD IP NVR from Xvision Pro HD. Please ensure that you read and understand this Quick Setup Guide before operating the camera. Please store this Quick Guide in an easily accessible location.
-
Page 2: Table Of Contents
4.1 Windows ..................5. Adding an IP Camera ................5.1 Auto IP ................... 5.2 Manually Adding A Camera ............5.2.1 Search IP Camera ............5.2.2 Automatic Add ..............5.3 Manual Add ................... 5.4 Camera Setting Adjust ..............5.5 Changing Sub Stream Resolution ........... 5.6 HDD Settings .................. 5.7 Recording Schedule ............... 5.7.1 Record Time ..............5.7.2 Advanced Record ............5.7.3 Motion Detection ............5.8 Video Playback ................5.9 Backup Setting ................6. Device Search Tool ................. 7. Accessing The XRN/XC via IE ..............7. FAQ’s ...................... www.xvision.com... - Page 3 7. When installing the camera, please make sure that it does not face any objects giving out strong lights as this will damage the CCD of the camera. 8. Please do not use the camera in an environment where temperatures that exceed either -20°C to +55°C. www.xvision.com...
-
Page 4: Introduction
XRN Quick Setup Guide 1. Product Overview 1. Introduction This Manual will cover the following: • Install of XRN NVR • Basic setting up of the NVR • Auto IP • Setting a LAN IP address • Recording • Viewing on IE 1.1 Package Contents XRN0808E/XRN0808P XRN0808E NVR or XRN0808P NVR Software CD 5V PSU www.xvision.com... - Page 5 XRN Quick Setup Guide XRN1609/XRN2016/XRN3625 XRN1609 NVR or XRN2016 NVR or XRN3625 NVR Software CD USB Mouse SATA Cables Remote Control Rack Mount Mounting Accesories www.xvision.com...
-
Page 6: Installation
Screenshots used in the instruction are only for indications and explanations. 2.1 Pre-requisites Check you have everything shown in the contents pages, if you do not please contact you place of purchase. You will need the following to begin installation: • HDMI/VGA Cable and Monitor • USB Mouse • ESATA or HDD for recording (Optional) • Router/Switch/Hub for your LAN to connect all network IP equipment together. • Windows PC/Laptop on site and connected to the same LAN (Router) as your equipment • Cat 5 Patch cables • Screw Drivers (Not supplied with the XRN0808E) • Accessories box included with XRN • SATA Hard Drive 2.2 Installating HDD If you purchased the XRN0808E then this unit only accepts USB and ESATA hard drives. If you choose to use anything above 2TB, then you will have to use ESATA. If you purchased your XRN without a HDD you will need to follow these steps. All the units have screws holding the top lids on except the XRN0808E. Once you have removed the screws move the unit so the front panel is facing you. Then, slide the lid away from you and lift off to remove. When installing in the XRN1609, once the screws have been removed this lid will lift off from the sides and away from the front panel. The user needs to be familiar with handling hard drives or get a qualified person to install. -
Page 7: Xrn1609 Hdd Install
XRN Quick Setup Guide 2.3 XRN1609 HDD Install 1. Once the lid is removed you will notice there are holes in the bottom of the case. Remove the Red SATA cables, SATA power Molex and the screw bag from your accessories box, which came with your XRN1609 (pictured below). 2. Remove the HDD from its protective packaging, hold it in place over the 4 screw holes. Turn the XRN1609 over and screw the unit in place. Screw in from the bottom of the DVR 3. When the unit is secured, turn over and connect the SATA and Molex Cables (shown below). www.xvision.com... -
Page 8: Xrn2016/3625 Hdd Install
XRN Quick Setup Guide 2.4 XRN2016/3625 HDD Install 1. When the lid is removed you will see silver racks. Remove the Red SATA cables, SATA power Molex and the screw bag from your accessories box which came with your XRN2016/3625 as pictured below. 2. Take out your screw driver and remove the screws holding the rack in place. 3. The XRN2016 will have one level and the XRN3625 will have two levels for mounting hard drives. Place your hard drive on the underside of the rack (shown below) and secure in place using the screws that came in the accessory box. 4. Once in place, connect your SATA and Molex cable to the hard drove and your XRN motherboard. Please Note The user needs to be familiar with handling hard drives or get a qualified person to install. Y3K will not be liable for any damage caused to the unit in the process of installation. www.xvision.com... -
Page 9: Connection Guide
2.5 Connection Guide... -
Page 10: Wizard Setup
XRN Quick Setup Guide 1. Product Overview 3. Wizard Setup After applying power to the XRN and having a monitor connected, you will see the main screen. Right click on your mouse and select Start > Login. The default user name is ‘admin’ and there is no password. Next, select the desired language. Then, change your video format and resolution (please make sure your monitor can support the resolution that you have selected). www.xvision.com... - Page 11 XRN Quick Setup Guide When the format and resolution has been selected, click ‘Next’ to begin setting up the IP address, subnet and default gateway. 1. Change the IP address to 192.168.1.100 as below. IP address change 2. When finished, click the ‘OK’ button. You will be asked to ‘Set up the IP camera manually’, please select ‘Cancel’. www.xvision.com...
-
Page 12: Network Setup
XRN Quick Setup Guide 1. Product Overview 4. Network Setup Before adding IP cameras and connecting network cables to your XRN, you will firstly have to set an IP address on your XRN NVR. Once this is done, you have the option to either set IP addresses manually on your XC IP cameras or use the Auto IP option. This will be covered after the below section for finding and adding an IP address to your XRN. All of the XRN NVR’s and XC IP cameras will share the same default IP address (192.168.1.188). However, this means that there will be a conflict on your LAN if all equipment is connected at the same time, so you will need to change some of the IP addresses. Firstly, check what your PC and Routers IP address is, to do this please follow the guide 4.1. 4.1 Windows Follow the steps below find an available IP address on an XRN NVR or XC camera to the local network. On your Windows PC keyboard press the windows key and the letter R together. The run bar will appear, as shown in the image to the below. Type: CMD and press the enter key on the keyboard. The command prompt will appear as shown below. Type in ‘ipconfig’ and press the enter key on the keyboard. www.xvision.com... - Page 13 XRN Quick Setup Guide In the picture the below IPv4 also gives you an IP address of 192.168.1.150. This address is the IP address of the computer which is used in the example. Please make a note of what the default gateway and subnet mask is. In this example the default gateway is 192.168.1.1 and subnet mask is 255.255.255.0. In the command prompt type in ping and then an IP address within the range of you network (i.e.192.168.0.X or 192.168.1.X), then press enter. You can pick any number between 192.168.1.2 and 192.168.1.253. If the IP address is free, a message will display with Destination host unreachable from your IP address as shown in the picture below. If the IP address is in use there will be a reply from that IP address. The example below shows a reply if you was to ping command with the routers IP address. When the IP address is available you will need to navigate back to the XRN. Right click your mouse and select Network Setting. Now fill in the fields as follows; IP – 192.168.1.100 Subnet Mask – 255.255.255.0 Default Gateway – 192.168.1.1 This will be already set as shown in section 3 (Setup Wizard), so you will just need to connect your CAT5 Ethernet patch cable. Click the save button at the top of the window, and you should receive the message saying the saving was successful. www.xvision.com...
-
Page 14: Adding An Ip Camera
XRN Quick Setup Guide 1. Product Overview 5. Adding an IP Camera To begin, please make sure you have connected one of the XC IP Cameras or any other Onvif compliant IP Camera to you LAN. 5.1 Auto IP (XC Cameras Only) When the IP has been set up on the XRN, you will be able to use the Auto IP feature. The Auto IP function will take the XRN IP address and automatically add IP address to the XC IP cameras starting from the next IP. For example, if the XRN IP is 192.168.1.100, the first XC IP camera will have the address 192.168.1.101 and the second 192.168.1.102 and so on. 1. To set up the Auto IP function, firstly right click the mouse and go to the ‘IP Channel Setting>Auto’. 2. Confirm that you wish to set up an IP channel automatically. 3. When you click ‘OK’ you will see a progress bar (below). When finished you will be able to see the image from the camera you have added. www.xvision.com... -
Page 15: Manually Adding A Camera
XRN Quick Setup Guide (Onvif) 5.2 Manually Adding a Camera To manually add a camera, right click the mouse and navigate to the ‘IP Channel Setting’ option, then ‘Manual’. 5.2.1 Search IP Camera To search for an IP camera manually, click the ‘Search’ button and all the IP cameras on your LAN will appear. 5.2.2 Add Found IP Cameras You can also add IP cameras automatically from this section. To do this, Click “√” next to the IP Camera you want to add. This will add the IP Camera to the window on the left. This means it is now added to the XRN. To finish, click save in the top right and close the window. To add all cameras, click the ‘ALL’ option on the left hand side of the window. www.xvision.com... -
Page 16: Manual Add
2. Select relevant protocol for our cameras it is I8 or you can use Onvif. 3. Input the IP address 4. Input the port number 5. Input the user name 6. Input the IP Cameras password, 7. Finally click “Save” Please Note You must add the user name and password if the IP camera requires this, or you will get no image. 5.4 Camera Setting Adjust To change any of the settings on the IP camera automatically, double-click the IP cameras in the left window to access the parameters. Then input relevant changes and click ‘Save’ to finish. The following parameters can be changed on the unit: • Enable: Select the relevant channel, check “Enable” • Protocol: ONVIF Standard protocol/ I8 Private protocol/ I9 Private protocol/ RTSP Standard protocol for selection • IP Add: Edit and modify the IP address manually • Port: Edit and set the relevant port number • Stream Type: Select “Main Stream” or “Sub Stream” • Network Type: Select “TCP” or “UDP” • User: Input the user name • Password: Fill the password in the password field www.xvision.com... -
Page 17: Changing Sub Stream Resolution
XRN Quick Setup Guide 5.5 Changing Sub Stream Resolution If you have added your IP camera but are getting no live image or a frozen image you may need to change the Sub Stream resolution and the Stream type on the XRN. The below table will show you all the supported stream types on your XRN unit. 8x[1920*1080]+Sub stream [640*480] + 2Ref. + 1Play XRN0808E 8x[1280*720]+Sub stream [640*360] + 1Ref. + 4Play 16x[1280*960]+sub stream[640*480]+4Ref.+4Play XRN1609 9x[1920*1080]+sub stream[960*576]+4Ref.+1Play 20x[1280*960]+sub[640*480]+4Ref.+4Play 16x[1920*1080]+sub[640*480]+4Ref.+4Play XRN2016 8x[1920*1080]+8x[1280*960]+sub[640*480]+4Ref.+4Play 4x[2048*1536]+sub[960*576]+4Ref.+4Play 36x[1280*960]+sub[720*576]+4Ref.+8Play 25x[1920*1080]+sub[960*576]+4Ref.+4Play 16x[1920*1080]+16x[1280*960]+sub[960*576]+4Ref.+4Play XRN3625 8x[2048*1536]+sub[960*576]+4Ref.+8Play 4x[2592*1920]+sub[960*576]+4Ref.+4Play The values above signify the maximum amount of channels, the maximum supported Main Stream resolution, the maximum supported Sub Stream resolution and the maximum amount of channels that are shown in playback. So for example, the XRN0808E gives you two options of: 8 x [1920*1080] + Sub Stream [640*480] + 2Ref + 1Play 8 x [1280*720] + Sub stream [640*360] + 1Ref. + 4Play If you use the 1st one as an example this means that it will allow 8 channels at a maximum resolution of 1920*1080 with a maximum Sub Stream resolution of 640*480, it will also play back 1 channel at a time when viewing recorded footage. 8 x 1920*1080 + Sub Stream(640*480) + 2Ref + 1Play 1. Channels 2. Maximum Main Stream Resolution... - Page 18 You may have a resolution lower than what is stated but if these resolutions are exceeded then you will not not receive an image or they will freeze up. The XRN1609 will give the following options: 16 x [1280*960] + Sub Stream [640*480] + 4Ref + 4Play 9 x [1920*1080] + Sub Stream [960*576] + 4Ref + 1Play This means that one option will give 16 channels at a maximum Main Stream resolution of 1280*960 or 9 channels with a slightly higher resolution of 1920*1080. Some of the other unit will give you further options, for example: 8 x [1920*1080] + 8 x [1280*960] +Sub Stream [640*480] + 4Ref + 4Play This means that it will allow a total of 16 channels, however, the first 8 channels will have a maximum Main Stream resolution of 1920*1080 and the last 8 channels have a maximum Main Stream resolution of 1280*960. The image above has a table explaining a breakdown of all supported resolutions and maximum amount of cameras that support those resolutions. Amount of Live image at Live image at 1280x960 Live image at 640x480 Simultaneous Playback Cameras 1920x1080 resolution resolution resolution Up to 4 Cameras All 4 Cameras All 4 Cameras All 4 Cameras Up to 4 Cameras All 8 Cameras All 8 Cameras All 8 Cameras Up to 4 Cameras 8 Cameras 8 Cameras All 16 Cameras Up to 4 Cameras To configure the above settings, please follow the steps below: On the main screen, right click and choose the ‘Setting’ option. Then, select the ‘Device’ option and ‘Device Info’ as shown in the right hand image above. www.xvision.com...
- Page 19 XRN Quick Setup Guide On the ‘Device Info’ page at the bottom you will find Stream Type, select the drop down list and pick the required Stream. When you have selected the stream type, the XRN unit will reboot. When rebooted, navigate to the main menu and go the ‘Setting-Channel-Video Parameters’. Then, you can change your main stream and sub stream to match the new stream settings. Under video parameters, change between main stream and sub stream settings for each channel. The XRN1609, XRN2016 and XRN3625, when in 1 or 4 screens use the main stream to display. If the display is set to 9/16/25/36 screens, the sub stream is used. For the XRN0808E, in single view the main stream is used and when display is set to 4/9 split view, the sub stream is used. The recommended Bit rate for main stream is the following: For 720P IP camera: 3072Kbps For 1080P IP camera: 4096Kbps For example, if the XRN2016 is in the mode of 16x [1920*1080] +sub [640*480] +4Ref. +4Play, it supports a sub stream of 640x480 maximum, so the correct resolution of the sub stream you have to setup is 640x480 (VGA), or Q720P/QVGA/CIF. If the resolution is set to higher, there will be no image displayed through HDMI and VGA output when the XRN displays in multi-screens (9/16/25/36 screens). The recommended bit rate under Sub stream is 512Kbps or less. The example below shows live image support for XRN2016. www.xvision.com...
-
Page 20: Hdd Settings
XRN Quick Setup Guide 5.6 HDD Settings To adjust the HDD settings, go into the ‘System Settings’, then click “HDD Setting” to see the screen below. Then check HDD capacity / free space. To format, click “√” in front of HDD No and then selecting format at the bottom of the page. Once, completed formatting, the XRN will reboot. Please Note On the XRN8080E, you have to use the E-SATA port for a HDD larger than 2TB as your HDD capacity will not be fully detected. www.xvision.com... -
Page 21: Recording Schedule
XRN Quick Setup Guide 5.7 Recording Schedule Here you can set the schedule recording for each channel. Remove the tick from “All day recording” to set your own date, time and method of recording. Simply select the method of recording Schedule/ Motion/ Alarm/ Motion\Alarm/ Motion & Alarm. Then left click the mouse over the time and date frame you want the selected recording method. To change this time, double click the coloured area, as shown below. 5.7.1 Record Time Remove the tick from “All day recording” now you can select “Setting” next to “Record Time” to do period time recording on the “Schedule “ interface, as shown in the below picture: www.xvision.com... -
Page 22: Advanced Record
XRN Quick Setup Guide 5.7.2 Advance Record Set Pre and Post Recording by selecting the advanced button. as shown in the picture below. 5.7.3 Motion Detection Please Note The IP camera must support motion detection to use this function. Modify each video channel parameters on the “Motion” interface, as shown below. 1. Click “√” in front of “Enable Motion Detection 2. Set motion areas, Left click and drag on your mouse to select the motion area, you will be left with squares as shown below. To remove an area use the right button and drag on your mouse. The motion area us enabled across all the XR cameras by default. www.xvision.com... -
Page 23: Video Playback
XRN Quick Setup Guide 3. Adjust the Sensitivity of the motion detection. 4. Set an alarm schedule 5. Select trigger mode, as shown in the picture below. 5.8 Video Playback Select “Playback” on the main menu to enter the playback screen. The dates with recorded videos will be highlighted in red. Select one of these to populate the time bar at the bottom of the page, click on the required section to begin playback for that section. 1. Pause: Pause the current playback 2. Stop: Stop the current playback 3. Slow: Slow down the playback speed (1/2, 1/4, 1/8, 1/16 times optional) 4. Fast: Speed up the playback process (2, 4, 8, 16 times optional) 5. Snapshot: Can be snapshot for any playback channel 6. Frame play: Single frame to play 7. Backup: Make video backup for any channel 8. Full screen: Video image playback with full screen 9. Volume: Adjust the volume of playback audio Double-click channel bar or click “Play” button to play the backup video, double-click single channel screen to get full screen display. www.xvision.com... -
Page 24: Backup Setting
XRN Quick Setup Guide 5.9 Backup Setting You can either search and playback the footage as per the Video Playback section and then click on the backup button or Connect your chosen backup device USB. To do this, select “Backup” in the main menu, click” Refresh”, if and when found the device will appear in the drop down box next to refresh. 1. Channel: Select relevant channel in the drop-down list 2. From: Select a start time for video backup 3. To: Select an end time for video backup Click” Start” to start the backup, the process bar at the bottom will show the completion percentage. Once complete, press the unmount button to safely remove the USB. www.xvision.com... -
Page 25: Device Search Tool
XRN Quick Setup Guide 1. Product Overview 6. Device Search Tool This software will install onto you Windows PC and search your LAN for all XRN and XC Devices. The software is included on the CD and also available to download. If you have any problems installing the software, please allow it safe passage through your Antivirus and Firewalls. Once you have installed the software you will get the below window. Select all the tick boxes click on the Discovery button to search for all available XC/XRN devices, once found you will see the below. You can select the device and change any of the settings below. Once changed, click on the Modify button and after a few seconds you can click on Discovery again. Then, the device will have the new IP address. www.xvision.com... -
Page 26: Accessing The Xrn/Xc Via Ie
XRN Quick Setup Guide 1. Product Overview 7. Accessing the XRN/XC via IE Before we can access our newly setup XRN on IE there a few more steps. If there is a reply from the ping (as shown on Section 4) the device can now be accessed on the web browser. Open Internet Explorer and type in your IP address in the address bar and press enter on the keyboard. The correct way to type the address is http://192.168.1.100. You will be prompted for Active X controls to be installed. For this to go successfully we need to change your settings of your IE browser. To setup the ActiveX Controls and Plug-ins, please follow the steps below. 1. Open up Internet options, this can either be done from Control Panel on your PC or through Internet Explorers settings as shown below, click on the cog on the top right of your Internet explorer page. 2. Once open select the Security tab from the top of the page. www.xvision.com... - Page 27 XRN Quick Setup Guide In the security tab you will be given the options for Internet, Local Intranet and Trusted Sites. Select Trusted Sites and then click on the Sites button below. First, click on “Require sever verification (https:) for all sites in this zone” so that it is not ticked, as shown in the image. Then, you can type the IP address of your XRN into the text box at the top and then click Add. www.xvision.com...
- Page 28 XRN Quick Setup Guide Next, click on Custom Level, you will need to locate all the “ActiveX controls and plug-ins”. There will be around 12 items listed with the ‘ActiveX’ icon. Ensure that ALL of these items are either set to Enable or Prompt. Please note that some will have Enable marked as not secure, it is best to ensure that items like this are set to Prompt As you can see below, “Allow ActiveX Filtering” is set to Disable so this would need to be set to Enable. You may need to amend your UAC settings, to do this please follow our UAC guide. Now you can try the IP address again, install the active X controls and view your XRN on IE. Follow the steps below to install this function. 1. Login to the XRN through the browser www.xvision.com...
- Page 29 XRN Quick Setup Guide 2. Follow the steps on the setup wizard to install. 3. Save the program in a folder onto your computer and then click ‘Save’. 4. On the next screen, you will be prompted to click ‘Install’ to finish installation or go back to change previous settings. 5. When finished, you will get a confirmation pop message. You will then be able to view the device through your browser. www.xvision.com...
-
Page 30: Faq's
1. Product Overview 8. FAQ’s 1. I am missing items? Please contact your supplier immediately and report this. 2. No output on XRN NVR? Please check the PSU and monitor out cables (VGA/HDMI). Also, check the power button is pressed down on the XRN0808E. 3. I can’t find any IP cameras? Check the cables, confirm you are only connecting one camera at a time, remember all devices share the same default IP address (192.168.1.188). 4. I can’t backup to my USB? Make sure the USB is formatted as FAT32. 5. The HDD is not detected? Shut down the XRN and check the SATA cables. If you’re using ESATA, confirm the ESATA cable is connected. - Page 31 XRN Quick Setup Guide 1. Product Overview Notes www.xvision.com...
- Page 32 (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase. Xvision UK, Unit 2 Valley Point, Beddington Farm Road, Croydon, Surrey CR0 4WP www.xvision.com...
