XVision XIP3000NVR User Manual

4 camera mjpeg/mpeg4 nvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XIP3000NVR
Model:
4 Camera MJPEG/MPEG4 NVR

Before you begin

Please unpack the box carefully and identify that all the parts are present
Do not cut the cables, this will void the warranty.
Make sure you use only the recommended power supply. Damage caused to the unit
by incorrect voltage or wiring is not covered by the warranty.
Model:
Model:
XIP3000NVR
VIS238D
Colour Varifocal Dome Camera
4 Camera Wireless Recorder
(NVR) for IP Cameras
CCTV
CCTV
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XIP3000NVR and is the answer not in the manual?

Questions and answers

Related Manuals for XVision XIP3000NVR

Summary of Contents for XVision XIP3000NVR

  • Page 1: Before You Begin

    CCTV CCTV XIP3000NVR Model: 4 Camera MJPEG/MPEG4 NVR Before you begin Please unpack the box carefully and identify that all the parts are present Do not cut the cables, this will void the warranty. Make sure you use only the recommended power supply. Damage caused to the unit by incorrect voltage or wiring is not covered by the warranty.

  • Page 2: Preface

    REFACE Thank you for purchasing the Wireless Network Video Recorder, an IP based device that installed on your network, which can be managed remotely via the Internet or your LAN. Together with the Internet camera, the Wireless Network Video Recorder allows you to remote access and simultaneous record live video streams.

  • Page 3: Table Of Contents

    Table of Contents Preface.........................1 Chapter 1 Introduction To Your Device ............3 Checking the Package Contents ............3 Getting to Know Your Device.............4 Features and Benefits................7 Chapter 2 Hardware Installation.................8 Networking Application...............8 Installing the Hard Disk Drive.............9 Connecting the Network ..............10 Connecting the Power Adapter............11 Chapter 3 Accessing The Device ..............12 Accessing the device via My Network Places......12 Using IPFinder ..................14...

  • Page 4: Chapter 1 Introduction To Your Device

    HAPTER NTRODUCTION EVICE 1.1 Checking the Package Contents Check the items contained in the package carefully. You should have the following: One Wireless Network Video Recorder. One AC Power Adapter with power cord. One Ethernet Cable (RJ-45 type). One External Antenna. Four Screws.

  • Page 5: Getting To Know Your Device

    1.2 Getting to Know Your Device Front View Power Unmount Button Button LED Icons USB Port 1 Power Button – Press to turn on the device. Press and hold for about five seconds to turn off. When you press the button to boot, the button start blinking Blue, and then becomes a steady Blue when the device is ready.
  • Page 6 Icon Description A steady Green light indicates the device is connected to your wireless network. When it blinks, the device is receiving/transmitting data from/to the wireless network. A steady Green (1000 Mbps) or Amber (10/100 Mbps) light indicates the device is connected to your LAN. When it blinks, the device is receiving/ transmitting data from/to the network.
  • Page 7 Rear View Fan and Ventilator Reset Hole Power USB Port 2 Antenna Connector Connector Connector Power Connector – Plug the provided AC Power Adapter. USB Port 2 – Connect the external USB device. Please note that this USB port is used for connecting a USB printer only. LAN Connector –...

  • Page 8: Features And Benefits

    1.3 Features and Benefits Easy to install and use. Remotely access and manage. Support auto-setup while connecting up to four cameras. Simultaneous record the live video streams. Start recording by manual or by schedule. The frame rate for alarm recordings can be specified independently from the frame rate of scheduled recordings.

  • Page 9: Chapter 2 Hardware Installation

    HAPTER ARDWARE NSTALLATION 2.1 Networking Application The following diagram explains the application of the Wireless Network Video Recorder within your network. In the illustration below, the Wireless Network Video Recorder and four Internet cameras are connected to a router/ switch, which minimize the impact of the network traffic for the users within the network.

  • Page 10: Installing The Hard Disk Drive

    2.2 Installing the Hard Disk Drive 1. Disconnect the power cable of the device. 2. Remove two screws on the rear panel, and then remove the rear panel. 3. Pull the bracket out from the disk bay. 4. Place the hard disk drive on the bracket, and then secured with two screws.

  • Page 11: Connecting The Network

    2.3 Connecting the Network Connecting to LAN Plug an Ethernet cable to the LAN connector located on the device’s rear panel, and then connect it to the network or directly to a computer for configuration. Connecting to WLAN When you use the device within your wireless network, you need to attach the included external antenna to the device.

  • Page 12: Connecting The Power Adapter

    2.4 Connecting the Power Adapter Plug the AC power adapter to the power connector located on the device’s rear panel, and then connect it to your local power supply. - 11 -...

  • Page 13: Chapter 3 Accessing The Device

    HAPTER CCESSING EVICE 3.1 Accessing the device via My Network Places Since you have built a connection between the device and your PC, you can easily access the device via My Network Places. 1. On your PC, click Start > My Network Places.
  • Page 14 3. Double-click the device icon. When the login window appears, enter the User name (the default is admin) and password (the default is admin), and then click OK to access the Wireless Network Video Recorder. If you connect an USB device to the device, it will be shown in the window.

  • Page 15: Using Ipfinder

    3.2 Using IPFinder The device comes with a conveniently utility, IPFinder, which is included in the Installation CD-ROM, allowing you to search the device on your network easily. 1. Insert the Installation CD-ROM into your PC’s CD-ROM drive to initiate the Auto-Run program. 2.

  • Page 16: Chapter 4 Configuring The Device

    HAPTER ONFIGURING EVICE You can easily access and manage the Wireless Network Video Recorder via the Web browser of your PC. This chapter describes the Web Configuration Utility, and guides you through the configuration of the device. Since the default configuration of the device is DHCP mode enabled, you are recommended to use IPFinder to search the IP address that is assigned to the device by the DHCP server, and then click Link to access the camera via the Web browser.

  • Page 17: Using The Setup Wizard

    4.1 Using the Setup Wizard The device’s Setup Wizard lets you configure your device easily and quickly. The wizard will guide you through the necessary settings step- by-step. To start the wizard, click Setup Wizard in the menu bar. Step 1. LAN Setup Enter the Hostname for the device.
  • Page 18 Step 2. TCP/IP Setup Select DHCP when your network uses the DHCP server; or select Static IP to assign the IP address for the device directly. For more information of TCP/IP settings, refer to the Lan section in Web Configuration Utility. - 17 -...
  • Page 19 Step 3. Wireless Setup Select Enable and complete the required settings for wireless networking. For more information of wireless settings, refer to the Wireless section in Web Configuration Utility. - 18 -...
  • Page 20 Step 4. Set up Space Type Select Single Disk or RAID for storing the files. For more information of space type, refer to the Storage Setup section in Web Configuration Utility. - 19 -...
  • Page 21 Step 5. Setup Summary Display the configuration of the device. When you complete the Setup Wizard, click Apply to reboot the device. Otherwise, click Back to go back to the previous step(s) and change the settings. - 20 -...

  • Page 22: Using The Web Configuration Utility

    4.2 Using the Web Configuration Utility After completing the Setup Wizard and rebooting the device, you can start to use the Wireless Network Video Recorder within your network environment. However, you can configure the advanced settings through the Web Configuration Utility. The utility contains the following options in the menu bar: System Information, System, Storage Setup, Authorization Setup, Network Service, NVR, Schedule Download, Logout, and Help.

  • Page 23: System Information

    4.2.1 System Information The System Information menu displays the current configuration and events log of the device. Summary This sub-menu displays the hostname and IP address of the device, the date and time, and the network service that you have set up. Status - 22 -...
  • Page 24 This sub-menu displays the firmware version of the device, the networking information, the time zone, and the disk information. This sub-menu displays the events log recorded by the system. - 23 -...
  • Page 25 4.2.2 System The System menu contains the basic system settings for the device, such as the networking settings, time and date setup, etc. - 24 -...
  • Page 26 LAN Setup - Hostname: Enter a descriptive name for the device. - Start UPnP: The device supports UPnP (Universal Plug and Play), which is a set of computer network protocols that enable the device-to-device interoperability. In addition, it supports port auto mapping function so that you can access the device if it is behind an NAT router or firewall.
  • Page 27 - Static IP: Select this option to assign the IP address for the device manually. You can use IPFinder to obtain the related setting values. Enter the IP address of the device. The default IP Address setting is: 192.168.0.20. Enter the Subnet Mask of the device. The default Subnet Mask setting is: 255.255.255.0.
  • Page 28 The device supports WLAN while you use the wireless network. Select the Enable option to enable this feature. Network ID (SSID) Keep the default setting of this option to connect the device to any access point under the infrastructure network mode. To connect the device to a specified access point, set a SSID for the device to correspond with the access point’s ESS-ID.
  • Page 29 - Format: Once you enable the Encryption feature, you need to determine the encryption format by selecting ASCII or HEX. ASCII format causes each character you type to be interpreted as an eight-bit value. Hex format causes each pair of characters you type to be interpreted as an eight-bit value in hexadecimal (base 16) notation.
  • Page 30 Time Time Zone Select the proper time zone for the region from the pull-down menu. NTP Setup Select this option and the time will be synchronized with the NTP Server. When you select this option, you have to enter the IP address of the NTP server.
  • Page 31 Notification This sub-menu contains the required settings for e-mail notification feature. When you complete the settings, click Send a test mail to test the related configuration is correct or not. Once the device connects to the server successfully, click Apply. SMTP Server Enter the mail server (e.g.
  • Page 32 Primary/Secondary E-mail Enter the first and second email address of the user who will receive the email. Configuration Delete all files Select this option and click Apply to delete all files stored on the installed hard disk drives. Format all disks and reset default Select this option and click Apply to format the installed hard disk drives and reset the device to the default configuration.
  • Page 33 Firmware This sub-menu displays the firmware version of the device. In addition, you can upgrade the firmware once you have a latest version of firmware. Firmware file Click Browse to find the firmware file and click Update. NOTE Make sure to keep the device connected to the power source during the process of updating firmware.

  • Page 34: Storage Setup

    4.2.3 Storage Setup The Storage Setup menu provides the information and controls of the installed hard disk drives, including the USB device. NOTE You are not recommended to use the USB device as your major storage device. - 33 -...
  • Page 35 Space Click Add to configure the storage space on the installed hard disk drives: selecting Single Disk or RAID. Then, click Apply to start making file system. If you have two hard disks installed in the device, you can select a disk configuration for RAID: (not recommended) Provide data striping.
  • Page 36 When completed, the related information of the disks is displayed on the screen. Click Add to add a storage space, or click Delete to remove the current storage space. USB Disk If you connect an external USB disk, this sub-menu displays the information of the USB disk.
  • Page 37 To reload the information of the connected USB devices, click refresh. Click format to format the connected USB disk. Share Folder This sub-menu allows you to specify the shared folder of the disks. Click Add and then assign the destination folder from the Share Folder list and give a brief instruction in the Comment box.
  • Page 38 File Management This sub-menu displays the log of file system that you have made in the device. - 37 -...

  • Page 39: Authorization Setup

    4.2.4 Authorization Setup The Authorization Setup menu allows you to manage the users and groups of the device. - 38 -...
  • Page 40 User Click Add and then assign the user name in the Select User box, and give a brief instruction in the User Description box. If you have set up groups for organization, you can assign the user to a group from the Group list. Enter the password twice for the new user in the Password and Confirm Password boxes, and then select the Permission type (Admin or User).
  • Page 41 Group Click Add and then assign the group name in the Group Name box, and then you can add/remove users for the group from the Member option. When completed, click Apply to add the group. To organize the users for the group, click Edit Member. To remove the group, select it from the list and then click Delete.
  • Page 42 Authorization This sub-menu displays the assigned access rules and quotas of the users and groups. - 41 -...

  • Page 43: Network Service

    4.2.5 Network Service The Network Service menu allows you to set up the network services for the device, such as FTP server, UPnP media server, etc. Windows OS - 42 -...
  • Page 44 Windows Network Setup - Workgroup: Enter the workgroup name where the device is installed within your network. - WINS Server: WINS (Windows Internet Name Service) server is used to support NetBIOS over TCP/IP (NetBT). Enter the IP address of the WINS server in the box, otherwise you cannot connect to a remote network resource by using its NetBIOS name.

  • Page 45: Upnp Media Server

    Start FTP Service Select this option to enable the FTP server of the device. Once you start the FTP service, you should assign the FTP Port (the default is port 21) and select to switch to the PASV mode or not. User transmission limitation Specify the maximum upload and download speed (KB/s) by entering the proper values in the related boxes.
  • Page 46 The device features an iTunes Server. It provides the ability to share files to the computer on the local network running iTunes. If the function is enabled, the device will be automatically detected in the iTunes program and the files contained in the specified directory will be available to stream over the network.
  • Page 47 4.2.6 NVR The NVR menu allows you to add Internet cameras and view the live video. IP Camera Backup Click Auto Add to add the camera automatically, or click Add and to add the camera manually through the following setup window: - 46 -...
  • Page 48 Enter the IP address of the camera. HTTP Port Assign the HTTP Port for the camera (the default is 80). RTSP Port Configure the transmission of streaming data within the network. The default RTSP (Real Time Streaming Protocol) port is 554. User ID/Password Enter the user name and password for accessing the camera.
  • Page 49 Space Specify the storage space for the camera. Motion Enable Enable of disable the motion detection of the camera (if have). Recycle Enable of disable the recycling function when the storage space on the device is full. Limit Select Yes to limit the recording file by specifying the storage volume from the list.
  • Page 50 Quad View In the Quad View screen, you can view the live video from the connected camera. You can view up to four cameras simultaneously. - 49 -...

  • Page 51: Schedule Download

    4.2.7 Schedule Download The Schedule Download menu allows you to set up download schedule. Click Add and the following setup window will appear: Please input the file name. - 50 -...
  • Page 52 Login Select Anonymous or Account from the list according to the settings of the target server. If you have to select Account to login, you should enter the correct User name and Password. Enter the URL address of target server. Save To Assign the destination folder from the list to save the downloaded files.
  • Page 53 4.2.8 Logout The Logout menu allows you to exit or shutdown the system. Logout From this sub-menu, click Apply to exit the Web Configuration Utility and go back to the Login window. - 52 -...
  • Page 54 Shutdown From this sub-menu, you can do one of the following: Select Shutdown Now and click Apply to turn off the device. Select Reboot and click Apply to reboot the device. - 53 -...
  • Page 55 4.2.9 Help The Help menu displays the information for each setting option of the device. Click the topic (marked as blue color) to link to the corresponding page and view the related information in detail. - 54 -...

  • Page 56: Appendix

    PPENDIX Specifications System Hardware Microprocessor ARM9, Storlink 3516 16MB Flash ROM 128MB DDR SDRAM Power Requirement DC 12V, 4A, 100-240V; auto-sensing Hard Disk Drive HDD Type SATA (I/II) Disk Bay HDD Configuration Standard, RAD0, RAD1, JBOD User Interface Connectors One power connector, one Ethernet connector (RJ-45 port), two USB 2.0 ports, one antenna connector Buttons...
  • Page 57 Operating Environment Temperature - Operation: 0°C ~ 40°C - Storage: -10°C ~ 70°C Humidity - Operation: 10% ~ 85% non-condensing - Storage: 5% ~ 90% non-condensing FCC Part 15 Class B, CE, VCCI - 56 -...
