Gembird DCAM-002 Manual

Gembird dcam-002 car video registrator
Hide thumbs Also See for DCAM-002:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

See also: User Manual
120
32GB
GSENSOR
1.5
FUNCTION
WIDE VIEW
Thank you for your purchase our vehicle DVR
In order to help you operate it correctly, please read this instruction carefully before usage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCAM-002 and is the answer not in the manual?

Questions and answers

Related Manuals for Gembird DCAM-002

Summary of Contents for Gembird DCAM-002

  • Page 1 32GB GSENSOR FUNCTION WIDE VIEW Thank you for your purchase our vehicle DVR In order to help you operate it correctly, please read this instruction carefully before usage.
  • Page 2 Structure Diagram and Introduction of Vehicle DVR Front View Right View Left View Rear View 1. TF Card Slot 9. LCD Display 17. USB Interface 2. Reset Button 10. Rec Indicator (red) 18. 3M Adhesive Tape 3. Mic 11. Rec Button 19.

  • Page 3: Device Installation

    Device Installation 1. Insert the TF card into the card slot with right direction. 2. Install the device on the wind shield or on the driving instrument board with rack pad. &Use clean and soft cloth to rub away the dirt and moisture on the wind shield or instrument board.
  • Page 4 around the scope, Motion Detection i con on the LCD and REC indicator will flash twice slowly, then the REC indicator goes off and device will in recording mode If the device doesn’t sense objects moving around the scope, the device will automatically stop recording 3.

  • Page 5: Button Function

    *U-disk Mode 1. Turn off the device and connect device thru USB to computer. 2. U disk icon will be shown on LCD display, there will be on removable disk shown on computer. 3. Enter the removable disk, you could replay video file in the removable disk. *PC Camera Function 1.
  • Page 6 Switch sensor Long Press To switch sensor positive shooting Rec Button positive shooting Switch sensor Long Press To switch sensor inverted shooting Mic Button inverted shooting To turn on/off sound recording When turn on sound recording ,the indicator light under Mic Mute Mic Button Short Press...
  • Page 7 The parameters of this recorder are shown as follows: Camera Sensor 1 mega pixels 120 Degrees Viewing Angle of Lens 1.5-inch LCD Display Video Resolution 1280x720 30FPS 4032x3024 Photo Resolution Support Automatically Overwritten Support Cyclic Recording Support Motion detection function Support Night Vision Support...

  • Page 8: Accessories Included

    Accessories included VEHICLE DVR Manual Driver Disk AV Cable Car Charger USB Cable Notes: 1) Please insert the TF card before recording. 2)The device default storage time is 2min. When the storage medium is full, it will record from the beginning again and erase over the previously recorded material automatically.
