- Page 1 ACTIVATED CARBON WATER FILTER SYSTEM SERIES INSTALLATION, OPERATION, AND MAINTENANCE MANUAL...
-
Page 2: Table Of Contents
Table of Contents 1. INTRODUCTION ..........................1 2. SYSTEM SPECIFICATIONS ......................1 3. GENERAL INSTALLATION INSTRUCTIONS ..................2 3.1. LOCATION ..........................2 3.2. MECHANICAL ........................2 3.3. ELECTRICAL ...........................4 4. GENERAL START-UP INSTRUCTIONS ....................4 5. CONTROL VALVE INSTRUCTIONS ....................6 5.1. TO SET TIME OF DAY ......................6 5.2. -
Page 3: Introduction
WATER FILTER SYSTEM 1. INTRODUCTION The Diamond H O Filter System produces high quality Filtered Water. 2. SYSTEM SPECIFICATIONS MODEL # DCF6-100-100 DCF6-150-100 DCF6-200-100 DCF6-250-100 Tank Size 10” X 44” 10” x 54” 12” x 52” 13” X 54” Filter Media... -
Page 4: General Installation Instructions
NOTE: Please verify that you have the proper amount of gravel and media on site before proceeding. If the amounts of gravel and media on site differs from what is listed in the Systems Specification table contact Diamond H2O for the correct amount. NOTE: The control valve and bypass are designed to accommodate minor plumbing misalignments but are not designed to support the weight of a system or the plumbing. - Page 5 Valve Inlet Valve Outlet Drain Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 3 Ph: (920) 757-5440 / (866) 757-9287 / Fax: (920) 757-5819...
-
Page 6: Electrical
Enters 4. Connect power to the unit. 5. Set control valve time and day. Refer to Control Valve Instructions or page 6 for programming and set up. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 4... - Page 7 11. If the Filter is operating properly, close the outlet valve of the control valve. Connect the facility plumbing to the control valve outlet following all local codes. 12. Startup is now complete. Diamond H2O N1022 Quality Drive PO Box 170...
-
Page 8: Control Valve Instructions
3. Set Regeneration Time Minutes. Press the SET button to go to the next step. 4. Set number of Days between regeneration cycles. 5. Press SET to complete and return to normal operation. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942... -
Page 9: Control Valve Function And Cycles Of Operation
If a regeneration is to occur today an arrow will point to REGEN. For immediate regeneration, simultaneously press and hold the ▲ and ▼ buttons for three seconds. When in regeneration, step through the different regeneration cycles by pressing the▲ or ▼ buttons. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942... -
Page 10: Oem General Instructions
See Valve Body Compliance Table in the WS1 and WS1.25 Drawings and Service Manual. Press SET button to go to Step 3SS. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942... - Page 11 Press SET button to go to Step 4SS. Note: For each minute of fill 0.5 gallons of water is added to the solution tank. With Sodium Chloride, each 0.5 gallon of water will dissolve 1.5 pounds of salt. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942...
- Page 12 DP Input (Item A). A. Differential pressure switch connection B. Motor wire connection C. AC adapter wire connection Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 10 Ph: (920) 757-5440 / (866) 757-9287 / Fax: (920) 757-5819...
- Page 13 2 Monday day 3 Tuesday day 4 Wednesday day 5 Thursday day 6 Friday day 7 Saturday Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 11 Ph: (920) 757-5440 / (866) 757-9287 / Fax: (920) 757-5819...
- Page 14 Regen a regeneration will not occur on Saturday. Press SET to exit Installer Displays & Settings. NOTE: If all arrows are turned off in d1-d7, the program will default to d7. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942...
-
Page 15: User Displays
An arrow will also point to Regen. The system will run through the steps automatically and will reset itself to provide treated water when the regeneration is completed. Diamond H2O N1022 Quality Drive PO Box 170... -
Page 16: Manual Regeneration
5.6.6. ERROR MESSAGE If “E1,” “E2”, “E3” or “E4” appears on the display contact the OEM for help. This indicates that the valve did not function properly. Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 14... -
Page 17: Filter Application Guide
HAC has been successful for many years in the reduction of free chlorine from water supplies. The water to be filtered should be relatively free of iron and turbidity for maximum service life Diamond H2O N1022 Quality Drive PO Box 170... -
Page 18: Spare Parts List
O-ring 337 V3180 1” O-ring 215 (Distributer Tube 1”) V3105 1 ¼” O-ring 219 (Distributer Tube, 1.32”) V3358 Diamond H2O N1022 Quality Drive PO Box 170 Greenville, WI 54942 Page 16 Ph: (920) 757-5440 / (866) 757-9287 / Fax: (920) 757-5819...
