- Page 1 VECA UTP Video Enhancer Compensator Amplifier Applications and Operation Manual...
- Page 2 It also includes the passive filter for connection directly to UTP CAT3, 4, 5,or 6 cabling. There are two controls on the VECA UTP, one for En- hancing and the other for Gain.
- Page 3 Power The VECA UTP uses a standard 2.1mm x 5.5 mm DC Coax Plug for power. 12VDC @ 100ma is required. Also wired in parallel to this plug is a two ter- minal push clamp connector for direct connection to bare wires. This also allows a power in and out configuration if required.
- Page 4 ASIA AVE (Thailand) Company Limited 147 Soi Onnut 44 (Sampheenong Villa), Sukhumvit Road., Suanluang, Suanluang, Bangkok 10250, Thailand. Tel : 02-331-3964/ 02-331-9285/ 02-742-0221 Fax : 02-331-9365 Email: ave@avethailand.com Website : www.avethailand.com NORTH AMERICA AVE USA 2000 West Governors Circle, Suite E...
