Page 1: User Guide
Vertriebs- Entwicklungsgesellschaft Genio 10 Automatic Mix-Amplifier User guide User guide GENIO 10 Issue 10/2016... -
Page 2: Table Of Contents
Programmable settings („Presets“)………………………………….……….………………………….8 Use of different settings („Presets“)………………………………………………….………….……….8 Change of existing preset settings………………………………………….…..……………………….8 Advanced features Creating new presets……………………………….……………………………………………………..9 The parameter menu……………………………………………………………………………………10 4.2.1 Presets……………………………………………………………….……………………………………10 4.2.2 Parameters………………………………………………………………………………………………11 4.2.3 Configuration………………………………………………………………………………………….….12 4.2.4 Utility…………………………………………….……………………………………………………….12 Table with all programmable parameters……………………………………………………………..13 Specifications………….………………………………………………………………………………….14 User guide GENIO 10 Page 2... -
Page 3: Introduction
Introduction Thank you for choosing the automatic mix-amplifier Genio 10 form AVE. Genio 10 is a device which is used impressively in medium and large rooms where the acoustic conditions complicate intelligibility. Genio 10 is equipped with 10 inputs: 8 balanced mic/line inputs, 2 switchable CD/Aux inputs with volume, treble and bass controls. -
Page 4: Safety Notices
INTERNAL MODIFICATIONS OR SERVICE WORK SHOULD ONLY BE CONDUCTED BY QUALIFIED SERVICE PERSONNEL. The GENIO 10 comes with an approved power cable. At one end of this cable is a three-pronged AC power connector (IEC plug) and at the other end a CE-standard-compliant Schuko-plug for connecting to a 230V/50 Hz AC voltage source. -
Page 5: Description Of Components And Their Functions
10. LCD Display: The bright display helps with a clear, user-friendly operation of the device. 11. Buttons: Rep, Prev Vol, Play Pause, Next Vol 12. Channel switch CD/Aux: Media selection. The playback devices are connected to the back. User guide GENIO 10 Page 5... - Page 6 10. Level direct OUT: Controls the volume of the direct output 11. Mic/line inputs 12. Rocker switch: Phantom power 48 V, Line, Micro Low, Micro High 13. Terminal for speakers (50, 70, 100 V, 4 Ohm) User guide GENIO 10 Page 6...
-
Page 7: Operation Of The Device
Switch 2 Activated channel Last channel Channel 1 Switch 3 Switch 4 Simultaneously activated channels 1 (input 1 - 8) 2 (input 1 - 8) 3 (input 1 - 8) 4 (input 1 - 8) User guide GENIO 10 Page 7... -
Page 8: Programmable Settings („Presets")
Programmable settings („presets“) The GENIO 10 connects many built-in features with easy to use operability. Even in challenging acoustic environments optimal results can be achieved. During installation a series of presets can be programmed.. 20 presets make it possible for all assignments (for example: „Sunday“, „weekday church“ or even for different speakers) to individually program –... -
Page 9: Advanced Features
(“Saving … do not interrupt”) Pushing the preset dial indicates ”no” and the display will show “Changes discarded!” To change another preset, press briefly the “Volume”-dial. You will enter back to the preset-menu. Now change the designated preset and proceed like described above. User guide GENIO 10 Page 9... -
Page 10: The Parameter Menu
In fact, the entire programming of the Genio 10 is done here with menu-driven user guidance by using the display and merely the “volume” and “preset”-dials. No PC or Laptop is required. In order to enter the parameter menu first turn the unit off. -
Page 11: Parameters
Turning the volume dial by one click, you can turn the limiter either “on” or “off”. By pushing the volume dial you will return back to the parameter menu. In case you have changed any parameters, you will be asked whether you would like to save them. User guide GENIO 10 Page 11... -
Page 12: Configuration
By turning the „volume“ dial the source and target parameter set for the copy process can be determined. When the triangle is on “Copy”, press the “preset” dial. Now the designed parameter set is copied. Firmware: Displays the current firmware version of the unit. User guide GENIO 10 Page 12... -
Page 13: Table With All Programmable Parameters
Name of 2 nd output Utility Copy Parameterset Copies a parameterset to another parameterset Firmware Firmware-Version BEFORE OPENING THE UNIT, TURN IT OFF AND REMOVE THE POWER CORD. ONLY THEN REMOVE THE SCREWS AND THE COVER. User guide GENIO 10 Page 13... -
Page 14: Specifications
AUX input sensitivity: -9 dBu / +4 dBu (OFF) AUX input sensitivity: -14 dBu / +2 dBu (ON) CD input sensitivity: +4 dBu (OFF) CD input sensitivity: - 6 dBu (ON) Frequency response(-3dB) Input CD/AUX: 20 Hz - 20 KHz User guide GENIO 10 Page 14... - Page 15 AVE mbH Corporation. Trademarks AVE mbH and the AVE logo are trademarks or registered trademarks of AVE mbH in the Germany and other countries. Other company and product names may be trademarks of the respective companies with which they are associated.
