Summary of Contents for Orion OR-224i
- Page 1 IP CAMERA OR-224i USER MANUAL MODEL: OR-224i MINIATURE BULLET IP CAMERA 2013/8/12...
-
Page 2: Important Safety Instructions
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. USA & CANADA: USE CLASS 2 POWER SUPPLY ONLY OR-224i... -
Page 3: Table Of Contents
4.6.4 E-mail ............................................... 23 4.6.5 DDNS ..............................................24 4.6.6 UPnP ..............................................24 4.7 System ................................................25 4.7.1 User ..............................................25 4.7.2 Date/Time ............................................25 4.7.3 Maintenance ............................................ 26 4.7.4 Information ............................................26 5. Accessory List & Dimensions ..........................................27 OR-224i... -
Page 4: Product Features
Camera via Power over Ethernet (PoE). The camera automatically senses the correct power level when using a PoE (Class 2) switch, router, or injector. Reset Button: Press this button to restore the camera settings to the factory default configuration. OR-224i... -
Page 5: Installation
2. Installation 1. Assemble the sun visor and connect all cables: a. Connect the IP Camera to the network using a shielded network cable. 2. Ports and Buttons: a. Adjust the IP Camera lens up/down/left/right to fit the desired position. OR-224i... - Page 6 3. Ceiling Mount: 4. Surface Mount: OR-224i...
-
Page 7: Accessing The Camera
Once installed, the IP Camera is accessible on the Local Area Network (LAN). Configure the router/firewall to allow incoming data traffic to access the IP Camera from the Internet. For security reasons, this is usually done through a specific port. Please refer to the router/firewall documentation for further information and instructions. OR-224i... -
Page 8: Adjusting The Image
Multicasting: Multicasting is a bandwidth-conserving technology that reduces bandwidth usage by simultaneously delivering a single stream of information to multiple network recipients. This technology is used primarily on delimited networks (intranets) as each user needs an uninterrupted data flow and should not rely on network routers. OR-224i... -
Page 9: How To Stream H.264
Administrators with unrestricted access can configure the IP Camera in the web browser through the Setup tab. 4.1 Analog Output Toggle the Analog Output ON to connect via BNC output or toggle OFF and click SAVE. [Not all IP Cameras have an Analog Output] OR-224i... -
Page 10: Video
IP Camera provides certain subsets of these tools. Using H.264, it is also possible to control the bit rate, which in turn allows the amount of bandwidth usage to be controlled. OR-224i... - Page 11 Video Mirroring: Choose NONE for no video mirroring, HORIZONTAL for horizontal video mirroring, VERTICAL for vertical video mirroring, or FLIP for horizontal and vertical video mirroring. o Bandwidth Limit: If set to ON, the maximum bandwidth can be set from 1000Kbps-30Mbps. OR-224i...
-
Page 12: Camera
These settings affect video image quality and how much noise is in the images. This can be set to ADAPTIVE to control on the fly, ZONE to control a certain zone, or OFF. OR-224i... -
Page 13: Live
Buffering Time: Buffering time can be set for a number between 0-90 times 1/30 seconds, or a range of 1-3 seconds. o Viewer OSD Setup: Resolution: Toggle OSD Resolution ON/OFF. Date/Time: Toggle OSD Date/Time ON/OFF. Event State: Toggle OSD Event State ON/OFF. OR-224i... -
Page 14: Privacy Mask
The IP Camera can support the privacy mask feature so a portion of the frame can be blocked based on personal preference of legal requirements. Select the Area and Color and click Save. Note: if the privacy mask is set, the analog output is automatically toggled off. OR-224i... -
Page 15: Ftp
Port: Enter the desired FTP Server’s Port number. Default: 21, Range 1025-65535. User name: Enter the FTP Server client user name. Password: Enter the FTP Server client password Send Mode: Choose whether the send mode is Active or Passive. OR-224i... -
Page 16: Event
File Prefix: Input the desired file name prefix (for example, alm_). FTP Send Mapping: Choose whether to upload images for either Motion or Tamper events or both. Effective Period: Choose whether to always upload images when an event occurs or during a user-defined schedule. OR-224i... -
Page 17: Periodical
File Prefix: Input the desired file name prefix (for example, per_). Interval: Choose the desired image upload interval, from 10 seconds to 1 hour. Effective Period: Choose whether to always upload images when an event occurs or during a user-defined schedule. OR-224i... -
Page 18: Event
This page is designed to allow a user to select whether or not to have an e-mail notification be sent to specified users if a motion or tamper detection event occurs. The Tamper Detection menu can also be accessed from this page. OR-224i... -
Page 19: Tamper Detection
By default, the IP Camera is set to get the IP address from the DHCP server and UPnP is enabled. If the network has a DHCP server and the UPnP function is enabled on a PC, it is possible to find the IP Camera in “My Network”. OR-224i... - Page 20 Click the ‘Setting’ button to set network information for the IP Camera. When you double-click the camera in the list, the default web browser (Internet Explorer or compatible equivalent) will open and automatically connect to the IP Camera. OR-224i...
-
Page 21: Service Port
UPnP must be supported by the router. External IP: If Port Forwarding is successful, the external IP address for the IP Camera will be displayed. This is the address that can be used to access the IP Camera. OR-224i... -
Page 22: Rtp
Start Port: Enter the desired Start Port number. End Port: Enter the desired End Port number. o Multicast Setup: Enter the IP addresses, Video Port numbers (even values only), Audio Port numbers (even values only), and TTL values for each stream. OR-224i... -
Page 23: E-Mail
User: If not using the default server, input the user name for accessing the e-mail server. Password: If not using the default server, input the user password for accessing the e-mail server. From: Input the name that will display before the e-mail address when receiving a notification. OR-224i... -
Page 24: Ddns
DDNS: Toggle DDNS ON/OFF. User Set URL: Input a domain name to connect to the IP Camera (for example, http://ipcamera.dvrlink.net) 4.6.6 UPnP This page is for toggling UPnP (Universal Plug and Play) on or off. It is ON by default. OR-224i... -
Page 25: System
NTP Server: If ‘Synchronize with NTP server’ is selected, input the NTP server address. Local Time: If ‘User set manually’ is selected, input the time manually or sync with a PC. Time Zone: Select the IP Camera’s time zone. DST: Toggle Daylight Savings Time ON/OFF. OR-224i... -
Page 26: Maintenance
Enable Firmware Upgrade: Must be clicked prior to performing a firmware upgrade. Firmware Updates: Browse the network directory for a firmware file and press OK to update the IP Camera firmware. 4.7.4 Information This page displays some important information about the IP Camera. OR-224i... -
Page 27: Accessory List & Dimensions
Camera Stand Supplied with mounting screws Power Adaptor PoE only User Manual CD, including product documentation, installation tools, and other software Printed Installation Guide Quick Guide for installation Accessories Sun visor, 1EA Camera stand mounting screws, 3EA Screw anchor, 3EA OR-224i... - Page 28 Dimensions (mm) OR-224i...
