HD IP CAMERA
User Manual
221i, 621i, 821i & 881i
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 221i and is the answer not in the manual?

Questions and answers

Summary of Contents for Orion 221i

  • Page 1 HD IP CAMERA User Manual 221i, 621i, 821i & 881i - 1 -...
  • Page 2: Table Of Contents

    Contents Chapter 1 Summary ........................... 4 Chapter 2 JRE Configuration ........................4 2.1. PC Configuration Requirements ......................4 2.2. Operation System Configuration Requirements ................4 2.3. IE Browser Version Requirements ..................... 4 2.4. Browser Configuration Requirements ....................4 Chapter 3 Login ............................6 Chapter 4 Main Interface ..........................
  • Page 3 5.3. Configure Media ..........................20 5.3.1. Streaming Configuration......................20 5.3.2. Image Setup ..........................21 5.3.3. OSD ............................21 5.3.4. Privacy Mask ..........................22 5.3.5. 5.3.5 Video System ........................23 5.3.6. ROI ............................23 5.4. Device I/O ............................24 5.4.1. 5.4.1 Audio In ........................... 24 5.4.2.
  • Page 4: Chapter 1 Summary

    Chapter 1 Summary IE interface client main includes video surveillance, video parameter setup, network parameter setup and so on basic function. Also equipped with privacy mask, receiving and handling alarm, two-way voice communication and other advanced application. It is a comprehensive IE client which has compact interface, multi-function, reliable performance and be easy to operate.
  • Page 5 Please close install guide after accomplishing plug-in installation. - 5 -...
  • Page 6: Chapter 3 Login

    Chapter 3 Login 1. Open IE, input IP address in address bar, the device default IP address is: 192.168.12.100 or 192.168.1.30 If no DHCP Server found Notice: if no 12 network segment in PC end Please add 12 network segment to PC(The detailed instruction as following).
  • Page 7 2. After inputting address,press ENTER. 3. The user is able to select language, enter user name and password(default user name and password is: admin) and click[Login]to log in. - 7 -...
  • Page 8: Chapter 4 Main Interface

    Chapter 4 Main Interface 4.1. 4.1 Main Interface Display Status 4.2. Operation Of Live View Interface Click[Live View]to enter into real-time preview interface.  [Listen]Control device can receive outside voice. Click[Talk]to realize two-way audio communication.  Click[Snapshot]to get current picture , click[Snap shot success open]at the right bottom of picture to preview saved picture.
  • Page 9: Alarming Output

    4.3. Alarming Output This software provide 4 channel alarming output, and switch by click in page table. 4.4. PTZ Control Notice: PTZ control only effective for the device which own PTZ. 4.4.1. Preset Control Add preset: select [Setup] at pull-down menu of preset. Select setting position on PTZ direction key of the PTZ page and click [Add].Select preset ID and give a name to this preset.
  • Page 10: Track Control

    4.4.4. Track Control Add track: click [Setup] in the main interface to enter into track configuration interface. Track function enable device move repeatedly on defined track ‘start → end→start point→end point’ to control part region. Enter into track configuration interface, click [Add], then click [Start], setup device’s path must be passed by PTZ direction key, at last, click [Stop] to complete configuration.
  • Page 11: Chapter 5 Setting Interface Instruction Manual

    Chapter 5 Setting interface Instruction Manual 5.1. Device Information Show the basic information of connect device such as name, ID, version etc. User can set up personal device name through[Device Name]. Under the Video user menu interface. Users can check IP information of others who also login the device. CPU: look CPU use ratio . - 11 -...
  • Page 12: Device Management

    5.2. Device Management Click[Device Management ]to enter into configuration interface. 5.2.1. IP Settings Click [IP Settings] to enter into configuration interface. User can configure IP selection, select IPv4 or IPv6. Can select ‘Obtain An IP Address Automatically (From DHCP)’ or ‘Static IP’. Notice: when choose IPv4, please keep consistency of IP address that has set and default gateway.
  • Page 13: Pppoe

    5.2.2. PPPoE Click [PPPoE] to enter into configuration interface Select [Enable PPPoE], and enter right user name, password and IP address, click set and save set item. Then you can use PPPoE. 5.2.3. Port Settings Click [Port settings]to enter into configuration interface . In this interface, user can check info and set info of Http, Https,RTSP and control port.
  • Page 14: Date & Time

    Mobile phone port: A mapping port between phone side and the camera. Obtain video information to look the video in phone. Http Stream Port: Only for research engineer. SSH:Enable SSH service to start it. 5.2.4. Date & Time Click [Date & Time] to enter into configuration interface. NTP (Network Time Protocol) synchronize device time with Internet every a period of time.
  • Page 15: Upnp

    5.2.6. UPnP Click [UPnP], enter into UPNP configuration interface. Select [Enable UPnP] to start UPNP function, click to modify UPnP port. Click [Add] to add other ports to UPNP, click [Save]. 5.2.7. DDNS Click [DDNS] to enter into DDNS configuration interface. User selects DDNS,can release device’s DDNS on the internet to realize remote control.
  • Page 16: Smtp

    Enter account and password that you apply from dynamic domain name website at [Account] and [Password]. Enter number whose interval is 0-60 at [Check Interval] to ensure communication between device and dynamic domain name website during “check interval” time. Tip: Modify Http port that is non-80 at [Port Setting] and start UPNP at [UPnP]. Click [Save] to complete DDNS configuration.
  • Page 17: Mobile View

    5.2.9. Mobile View Click [Mobile View] to enter into mobile view controlling interface. Select [Enable Mobile Monitoring], click save to save settings. You can use internet to download mobile view client by scanning QR CODE. User could use UID code to log in by mobile client.
  • Page 18: Snmp

    5.2.10. SNMP Click [SNMP] to enter into SNMP configuration interface. SNMP is webmaster tool based on TCP protocol. Select [Enable SNMP] to start webmaster system. Set up SNMP port, user enable to monitor IP camera by webmaster tool. 5.2.11. Identification Click [Identification] to enter into identification configuration interface.
  • Page 19: Bonjour

    Choose the Onvif in OFF or ON.It is no need to obtain device account and password if under OFF.So need login account and password in Onvif ON status.The function is for safety. RTSP, CGI are similar to that . 5.2.12. Bonjour Enable Bonjour, then can search our device under the content in the apple’s browser.
  • Page 20: Configure Media

    5.3. Configure Media Click [Configure Media] to enter into media configuration interface. 5.3.1. Streaming Configuration Click [Streaming] to enter into streaming configuration interface. User select resolution by [Resource Solution] pull-down menu to select resolution you need and click [Save] to save. User can promptly adjust streaming 1 and streaming 2 basic parameter at [Stream ID] menu to realize promptly control of device streaming.
  • Page 21: Image Setup

     Resolution: Control current image resolution of device.  I frame interval: Control intervals between two key-frame when device records.  Frame Rate: I frame frequency.  Bit rate model: Support VBR(Variable Bit-Rate), CBR(Constant Bit-Rate) and LBR.  Streaming: Limit real-time streaming max value. ...
  • Page 22: Privacy Mask

    User can choose device name and time display or not, adjust their position at [System Setup]. Can add text in any region at [User Defined]. Click [Save] to complete OSD configuration. 5.3.4. Privacy Mask Click [Privacy Mask] to enter into privacy mask configuration interface. Privacy mask function can use black opaque object to mask the part of image that need privacy and will not be seen by other people.
  • Page 23: Video System

    3%. If user drag region mistakenly, cancel it by clicking right mouse button. You can also delete all image mask position by [Delete] button. 5.3.5. 5.3.5 Video System Click [Video System] to enter into video system configuration interface. User set up output video system PAL or NTSC by selecting following pull-down menu. PAL:25 frame per second, used in China, country in Europe.
  • Page 24: Device I/O

    Select [Enable ROI] to start ROI function and set up corresponding streaming info. Drag left mouse button to region, click save to complete configuration. Notice: If user drag wrongly when set up region, user can cancel one region by clicking right mouse button.
  • Page 25: Rs485

    5.4.2. RS485 Click [RS485] to enter into RS485 configuration interface. User set up external PTZ in this interface. 5.4.3. Alarm I/O Click [Alarm I/O] to enter into configuration interface. User input the name of alarm in at [Name] bar of [Alarm In]. Enter into ‘high’ or ‘low’ at [Valid signal] Configure delay alarm output time at [Alarm Delay] after device alarming Configure length of alarm output at [Alarm Period], the unit is ms.
  • Page 26: Alarm Trigger

    Alarm Trigger 5.5. Click [Alarm Trigger] to enter into alarm trigger configuration interface. 5.5.1. Motion Alarm Click [Motion Alarm] to enter into motion alarm configuration interface. Select [Enable Motion Detection] to start motion detection, and then click [Schedule] and [Area] to configure.
  • Page 27 Drag left mouse button to region, setup sensitivity at [Sensitivity] bar. Provide 10 sensitivity level, the higher number the higher sensitivity. Setup the [threshold] Click [Save] to complete configuration. Notice: You only select 5 regions at most in configuration area including overlap. If user select one mistakenly, cancel it by clicking left mouse button or click [Delete] to delete total motion detection region.
  • Page 28: Alarm Trigger

    5.5.2. Alarm Trigger Click [Alarm Trigger] to enter into I/O alarm configuration interface. User select [Enable Alarm In] to start I/O alarm. Click [Schedule] to set up I/O alarm time. Select [All time] to set up motion detection all time. And can also select time at schedule.
  • Page 29 Select [All time] to set up motion detection as all time detection. Or configure time at schedule to complete time setup. At last click [Save] to finish time setup. User set up shaking detection sensitivity at [Sensitivity] item. There are 5 grades sensitivity for user. User select [Enable E-mail] at [E-mail] item to start motion detection trigger E-mail reminder, then user will receive E-mail prompting after motion detection trigger.
  • Page 30: Recording

    5.6. Recording Click [Recording] to enter into recording configuration interface. 5.6.1. Record Click [Record] to enter into record policy configuration interface. Select [Enable Recording] to start recording. Recording can provide stable, exhaustive, convenient, customized whole-day service. [Continuous Recording] to start device recording all the day. [Start Recording When Network Failed] to start.
  • Page 31: Recording Path

    Select [Enable Audio Recording] at [Recording Parameters] to start recording video with sound. Click [Save]. User can modify recording streaming by [Streaming ID]. User can select two ways at [Save mode]--keep days or auto rewrite storage when full. Choose the keep day mode, you can also enter the exact days.
  • Page 32: Local Recording

    Select [Enable Dir] to start FTP recording storage. Fill in IP address, user, password, confirm password, port and usable space of FTP in configuration interface. Click [Save] to save settings. Select [Disk Name] pull-down menu, set up recording disk type as NAS storage . Click [Modify] to enter into NAS recording configuration interface .
  • Page 33: Snapshot Path

    5.6.4. Snapshot Path Click [Snapshot Path] to enter into alarm snapshot FTP path configuration interface. Configuration method is same as FTP configuration of ‘Record Path’. 5.6.5. Snapshot Policy Click [Snapshot Policy] to enter into linked snapshot configuration interface. Select [Number] pull-down menu, enter snapshot quantity as trigger snapshot each time and user can choose 1-6pcs image.
  • Page 34: Account

    5.7. Account Click [Account] to enter into authority control interface. 5.7.1. 5.7.1 Authority Click [Authority] to enter into authority configuration interface. User can distribute authority of each group in the sheet, click [Save] to complete settings. 5.7.2. User Click [User] to enter into user configuration page. Click [Add] to add user configuration interface.
  • Page 35: Maintenance

    User define user name and set up password. Adjust [Group] pull-down menu to setup user group and limit user authority. 5.8. Maintenance Click [Maintenance] to enter into maintenance interface. 5.8.1. Reboot Click [Reboot] to enter into reboot interface. User can configure auto reboot time at [Reboot]. - 35 -...
  • Page 36: Reset

    5.8.2. Reset [Auto Reboot], and can reboot directly at Click [Reset] to enter into reset interface . User can click reset button to reset parameter of device in this interface and also can select[Reset IP Address]to reset device totally. 5.8.3. Event Log Click [Event Log] to enter into event log interface.
  • Page 37: Chapter 6 Faq And Solution

    Chapter 6 FAQ and Solution 1. The video is always lag and then delay more, when viewing video as device connect PC directly, Answer: Please check if the network access is standard. For example, change another qualified network cable that have been tested. 2.
