Accusplit Eagle 1691M17 Operating Instructions

ACCUSPLIT®
Congratulations on taking the first step to wellness
with your purchase of an ACCUSPLIT pedometer.
It's easy to set up your new pedometer.
Just follow the steps below, and start walking!
SETTING UP YOUR PEDOMETER
To record your distance and calories accurately, you will need
to set your stride length and body weight.
CHOOSING A MEASUREMENT SYSTEM
This unit is initially set to use English measurement units
(Miles and Pounds). To change the unit back and forth
between English and Metric units (Kilometers and
Kilograms), press the green RESET button for 5 seconds.
Finding Your Stride Length: Your stride length is the length of
one of your steps, measured from "toe to toe. " To measure,
walk 10 steps with your normal stride and measure the
TOTAL DISTANCE from the toe of your starting step to the
toe of your 10 step (see diagram below). Divide the TOTAL
th
DISTANCE by 10. This is your stride length. Example: If you
walk 22 feet, your stride length is 2.2 feet.
Setting Your Stride Length: Press the yellow MODE button
until arrow on bottom of display points to "DIST. " Press the
dark blue SET button once to enter setting mode. Display will
shift to show stride (for example, "F 1.95" means stride is set
to 1.95 feet). Press the dark blue SET button( + ) to increase
stride length. Press the green RESET button( – ) to reduce stride
length. Press the yellow MODE button to exit setting mode.
Setting Your Weight: Press the yellow MODE button until
arrow on bottom of display points to "CAL. " Press the dark
blue SET button once to enter setting mode. Display will
shift to show weight in pounds. For example, "L 165" means
weight is set to 165 lbs. Press the dark blue SET button( + ) to
increase weight setting. Press the green RESET button( – ) to
reduce weight setting. Press the yellow MODE button to exit
setting mode.
Setting the Clock: Press the yellow MODE button until the
arrow on the bottom of the display points to the clock icon
Press the dark blue SET button to enter clock setting mode
(clock readout will flash). Press the green RESET button to
advance Hours. Press the dark blue SET button to advance
Minutes. Press the aqua WK-DAY MEMORY button to shift
between 12 and 24 hour mode. ("H" will show in display
for 24 hour mode.) Press the cream LAST WEEK MEMORY
button to change the day of the week setting. Press the
yellow MODE button to exit clock setting mode, or wait
a few seconds for pedometer to automatically exit clock
setting mode.
10 steps
ACCUSPLIT, Inc. • 6120 Stoneridge Mall Rd., Suite 210 • Pleasanton, CA 94588 USA
800-965-2008 • 925-226-0888 • FAX 925-463-0147 • www.ACCUSPLIT.com • support@ACCUSPLIT.com
EAGLE
MEMORY PEDOMETER
OPERATING INSTRUCTIONS
.
1691M17
™
WEARING YOUR PEDOMETER
While gently holding the belt clip open, slide the pedometer
onto your belt or the top edge of your pants or skirt. It should fit
snugly and level, above one knee.
Note: The pedometer should be as vertical as possible. Walkers
with larger stomachs may find it helpful to wear the pedometer
farther back on the body, toward one hip.
The cover must be closed for the pedometer to work. To avoid
losing or dropping your pedometer, use the included leash and
clip to fasten the pedometer securely to your clothing.
Attaching the Leash: Attach the pedometer to the leash by
looping the leash around the pedometer belt clip. Next, clasp
the waistband of your clothing with the attached metal clip. You
can also use a safety pin to fasten the leash to your clothing, or
loop the leash through your belt or belt loop.
First, loop the
pedometer clip
Next, loop the metal
clip, then clasp clothing
Or, loop a belt
or belt loop
VIEWING YOUR RESULTS
Once you put on your pedometer with the cover closed, it will
automatically begin to record your steps, distance, calories
burned, and activity time. Repeatedly press the yellow MODE
button to cycle through the pedometer modes:
SCAN → STEPS → DISTANCE → CALORIES → ACTIVITY
TIME → TIME OF DAY → RATE → SCAN
Eat Right! Walk More! Live Well!
The ACCUSPLIT Lifestyle
Or, loop a
badge holder, then
put into pocket
(Badge holder
not included)
970-070
