Pidion BIP-6000 Quick Manual

1

Package

The pictures shown below may differ from the actual products. To purchase
additional or optional products, contact our customer center.
[Battery (High Capacity)]
[USB Cable]
For more detailed information, refer to the corresponding user manual on our homepage.
2

Closed View of Your Phone

Barcode Scanner Window
Stylus Pen Power Button
Speaker
Power LED
Communication LED
Side
Scanner
Button LCD Screen
Front scanner Button
Direction/Send/
End/Number/
Character/Function
Buttons
[BIP-6000 Main Body]
Mice
USB Cable Connector
Stylus Pen Strap
Hand strap holder - Top
Flash
Earphone Jack
Camera
Speaker
[Desktop Cradle] [Stylus Pen]
Side
Scanner
Reset Button
Button
IrDA
Battery
Battery Fixing Pin
Hand strap holder - Bottom
[Adaptor] [Spring Wire]
3

Connecting/Disconnecting Battery

4

Inserting/Extracting USUM/USAM Card

To connect the battery To insert the USIM/USAM
1 Align the battery to the Insert the USIM card (or USAM
groove and insert in the
card) in the direction of the
direction of the arrow.
arrow.
2 Turn the fixing pins on both
sides of the battery pins
inward until the battery is
secured.
To remove the USIM
To disconnect the battery
Remove the USIM card (or
1 Power off the PDA.
USAM card) in the direction of
the arrow.
2 Turn the fixing pins on both
sides of the battery pins
outward to disconnect the
battery.
3 Pull out the battery after
lifting it in the direction of
the arrow.
What is a USIM card?
The USIM card is the combination of a SIM card with subscriber information and a
Removing battery without power off may cause a technical problem. Universal IC card (UICC) accommodating communication and financial information
and implements various functions including user authentication, global roaming,
Turn off a PDA by using [Power] button on PDA completely to prevent
e-commercial functions as a single card.
causing problem of PDA.
When PDA is failing to turn on due to removing battery witout turn off,
What is a USAM card?
please make hard-reset the PDA.
The USAM card is an embedded application module of a smart card mounted
inside of a card reader to authenticate the validity of cards and stations, prevent
Please press (# button + Enter button + Reset button) at the same time.
information disclosure by encrypting communication data and authenticate and
All information from Memory (RAM) will be all deleted after hard-reset.
validate communication messages.
