Triple E COMMANDER Owner's Manual

Hide thumbs Also See for COMMANDER:
Hello, I am your AI assistant. How can I help you?
Table of Contents

Advertisement

Quick Links

COMMANDER & EMBASSY
MOTORHOME
OWNERS MANUAL
Experience the Difference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COMMANDER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triple E COMMANDER

Summary of Contents for Triple E COMMANDER

  • Page 1 COMMANDER & EMBASSY MOTORHOME OWNERS MANUAL Experience the Difference...
  • Page 3 This manual is intended to be a guide- Welcome to the growing number of discerning peo- line. This manual despite our best efforts ple who own and operate a Triple E Motorhome. should not be considered comprehensive in all details. We invite you to use this...

  • Page 4: Table Of Contents

    System Monitor ......4-26 Driving Safety ......... 2-2 4.20 Energy Management System Fuel (Motor and LP Gas) ....2-2 (EMS) - Commander only .... 4-27 Driving ............5-1 Asphyxiation ........2-3 Formaldehyde ........ 2-3 Pre-Trip Inspection ......5-1 LP Gas Leaks ........ 2-3 Emergency Equipment Check List .
  • Page 5 10.1.2 Power Control Center Tank ..........Tank ..........Tank 12-7 (Optional - Commander Only) ..10-2 12.2.3 Dumping Holding Tanks ....12-8 10.1.3 120-Volt Circuit Breakers ..... 10-2 12.2.4 Tank Rinse ........12-9 10.1.4 Ground Fault Circuit Interrupter 12.2.5 Do's And Don'ts Holding Tanks ... 12-9 (GFCI) ..........
  • Page 6 Electric Step (Optional) ....13-13 13.16 Screen Windows ......13-13 13.17 Coffee Maker (Optional) ..... 13-13 13.18 Washer/Dryer Hook-Ups (Optional - Commander only) ..13-14 14 Care And Maintenance ......14-1 14.1 Exterior ......... 14-1 14.2 Interior .......... 14-2 15 Motorhome Maintenance ......15-1 15.1...

  • Page 7: Introduction

    COMMANDER / EMBASSY INTRODUCTION Congratulations on your choice of a Triple E built Motorhome for your travelling and touring comfort and enjoyment. It utilizes the latest design features and manufacturing techniques to insure safe, effi cient and trouble-free operation at all times.

  • Page 8: Vehicle Certifi Cation Label

    1. Chassis manufacturer. 10. Serial Number: 2. Chassis manufacture date. This is the serial number assigned to the com- 3. Month and year of manufacture at Triple E pleted vehicle by Triple E Recreational Vehi- Recreational Vehicles. cles. 4. Gross Vehicle Weight Rating: 11.
  • Page 9 COMMANDER / EMBASSY U.S. Canadian Fig. 1-2 VEHICLE LABELS Fig. 1-3 IDENTIFICATION INFORMATION (LABEL LOCATION)

  • Page 10: Identifi Cation Information

    COMMANDER / EMBASSY IDENTIFICATION INFORMATION Take a few minutes to fi ll in this information. It will be a handy reference for you. (Some appliances may be optional). The label is located on the sidewall to the left of the steering wheel or on the driver's side door.
  • Page 11 EXTERIOR FEATURE IDENTIFICATION - COMMANDER MODEL Composite model shown for illustration purposes only. Actual locations of features depends on coach model and options. Fig. 1-3 EXTERIOR IDENTIFICATION - COMMANDER ONLY (RIGHT) 1. Water Heater Service Access. 12. Utility Service Compartment.
  • Page 12 COMMANDER / EMBASSY EMBASSY MODEL Composite model shown for illustration purposes only. Actual locations of features depends on coach model and options. Fig. 1-5 EXTERIOR IDENTIFICATION - EMBASSY ONLY (RIGHT) 1. Water Heater Service Access. 12. Utility Service Compartment. 2. Refrigerator Service Access.

  • Page 13: Service Assistance

    1.10 DRIVING COMFORT g. Ultraviolet stabilized exterior components to resist fading and deterioration. Triple E has made every effort to design and con- h. Exterior screws and fasteners that resist struct your motorhome for your comfort and safety. streaking. We know that your investment is important to you Heavy duty mud fl...

  • Page 14: Safety

    1. The most important safety feature on this siderations during the design and manufacturing vehicle is the operator. It is the operator's of all Triple E Motorhomes. It is the responsibility responsibility to read, understand and follow all of the owner or operator to read, understand and...

  • Page 15: Driving Safety

    COMMANDER / EMBASSY DRIVING SAFETY FUEL (MOTOR AND LP GAS) 1. Only trained and licensed drivers are allowed 1. Do not smoke when fi lling vehicle/generator to drive this vehicle. fuel tank, or LP gas tank. 2. Observe all applicable road and driving regula- 2.

  • Page 16: Asphyxiation

    COMMANDER / EMBASSY MINIMIZING FORMALDEHYDE FUMES ASPHYXIATION RISK WARNING 1. Do not use portable fuel-burning equipment Formaldehyde based adhesives are used in some including wood and charcoal grills and stoves components in this vehicle and may release small in the vehicle. The use of this equipment can...

  • Page 17: Alarms

    COMMANDER / EMBASSY ALARMS e. Clean and vacuum opening on smoke 1. Each Vehicle Is Equipped With A LP Gas alarm once a month. Alarm: Do not try to repair alarm. Replace it. a. Sounds whenever there is an unsafe g.

  • Page 18: Loose Components

    COMMANDER / EMBASSY LOOSE COMPONENTS 1. Tie, strap or secure all tables, chairs and other furniture before transporting. 2. Close, latch or lock all doors, drawers, panels and gates before travelling. 3. Turn all swivel seats in the forward facing direction and lock before moving.

  • Page 19: Preparation

    COMMANDER / EMBASSY PREPARATION The (CCC) Cargo Carrying Capacity is equal to GVWR minus each of the following: UVW, full fresh (potable) water weight (including water heater), full Refer to information pack supplied with the Mo- LP-Gas weight and SCWR.

  • Page 20: Trailer Towing

    COMMANDER / EMBASSY 3.1.3 TRAILER TOWING A trailer can affect the handling, durability, performance and economy of your mo- torhome. The factory installed towing hitch is rated for: a. 500 lb. - maximum hitch or tongue weight. b. 5000 lb. - maximum trailer weight.

  • Page 21: Parking, Levelling And Blocking

    COMMANDER / EMBASSY 3.1.5 PARKING, LEVELLING AND BLOCKING Fig. 3-2 PARKING Try to pick a spot as level as possible on which to WARNING park your motorhome. You may choose to drive in or back in depending on your personal preference.

  • Page 22: Controls

    COMMANDER / EMBASSY CONTROLS It is the responsibility of each owner, operator, driver or user to be familiar with the positions, functions and settings of all controls. Each new person should be trained in all aspects of motorhome operation prior to starting. Review this section as often as required to understand the controls. Contact your dealer if you have any other questions.

  • Page 23: Dash Controls

    An optional cas- sette deck is also available. b. Climate Control: This is the standard climate con- trol used for all Class A Triple E and includes both the heating and cooling functions for the driving section of the vehicle.
  • Page 24 COMMANDER / EMBASSY d. Mirror Adjustment - Command- er only: This cluster of switches controls the position of the rear view mirrors on both sides. Use the center switch to select the left or right mirror. Depress and hold the four outer switches as re- quired to move the mirror to the desired position.

  • Page 25: Drivers Door - Commander Only

    Fig. 4-5 UNDER DASH DRIVERS DOOR - Commander only This rocker switch sets the position of the drivers door window. Depress and hold the foward portion of the switch to raise the window and back portion to lower.

  • Page 26: Drivers/Co-Pilot Seat

    COMMANDER / EMBASSY DRIVERS/CO-PILOT SEAT 1. Forward-Back Position: Both the drivers and co- pilot seats are designed with a sliding base to allow the seat to be moved forward or backward for occupant com- fort. a. Commander: A spring loaded latch is located at the end of the left hand arm rest to release the sliding base.

  • Page 27: Cocktail Seat

    COMMANDER / EMBASSY COCKTAIL SEAT A cocktail chair is located behind the co-pilots seat and is part of the living room furniture. 1. Swivel Lock: This latch releases the swivel base. Push the latch to release the lock and allow the chair to swivel. When the seat returns to this position, the lock will again engage.
  • Page 28 COMMANDER / EMBASSY 2. Lap Belts: Only seats equipped with seat belts are approved for use by occupants while the vehicle is moving. Never travel in a seat that is not equipped with a lap or shoulder belt. a. Sit in the seat and rotate the chair to its locked position.

  • Page 29: Front Upper Cabinets

    VCR: signal to TV 2(bedroom). This push button switch selects the VCR output as the source of the input signal to TV 1 or the one mounted in the front console. Fig. 4-11 TV INPUT SELECTOR AND VCR (COMMANDER ONLY)

  • Page 30: Bedroom Tv

    COMMANDER / EMBASSY BEDROOM TV - (OPTIONAL, N/A Embassy A-27) A motorhome can be equipped with a TV in the bedroom. Although it func- tions like a standard TV, it is recom- mended that the operator's manual in the information pack be reviewed prior to use.

  • Page 31: Side Entry

    COMMANDER / EMBASSY SIDE ENTRY The side entry doorway left wall is equipped with a switch panel that controls the following functions: 1. Porch Light: This 2 position rocker switch controls the power to the outside porch light. Depress the upper...

  • Page 32: Refrigerator

    COMMANDER / EMBASSY 4.10 REFRIGERATOR The refrigerator control panel is located directly above the fridge and includes switches and several indica- tor lights. 1. Master ON/OFF Switch: Schematic This latching push button switch controls the power to the refrig- erator. Depress the switch and it will latch in the depressed posi- tion for the power to be on.

  • Page 33: Light Switches

    COMMANDER / EMBASSY 4.11 LIGHT SWITCHES Many rocker, slider or standard light switches are used throughout the motorhome to turn lights on and off. If there is any confusion as to which switch and light work together, try the switch.

  • Page 34: Comfort Control Center

    COMMANDER / EMBASSY 4.12 COMFORT CONTROL CENTER A comfort control center is located in the motorhome (living area or bedroom) to control the heating and cooling systems in the vehicle. The control center is customized to the speci- fi cations of your vehicle and will control one or more furnaces and air conditioners.

  • Page 35: Furnace

    COMMANDER / EMBASSY 4.13 FURNACE Each motorhome is equipped with one or two furnaces depending on the confi guration. They are controlled by the comfort control center. Review the operator's manuals for the furnace and comfort control centre in the information...

  • Page 36: Thermostatically 7.4 Controlled Celing Fan

    COMMANDER / EMBASSY 4.14 THERMOSTATICALLY CONTROLLED CEILING FAN (Optional on Embassy) Each motorhome is equipped with a roof vent with a reversible fan to pro- vide a controlled air fl ow through the vehicle. Use the vent fan in conjunc- tions with an open window to provide a fl...

  • Page 37: Plumbing

    All water heaters are designed to operate using ei- Fig. 4-20 WATER HEATER ther LP gas, motor aid (Commander only) or 120 volt electric power. Both electric and gas power sources require water in the tank before starting IMPORTANT to heat water or the element or tank will burn out.

  • Page 38: Water Heater Bypass

    COMMANDER / EMBASSY 4.15.2 WATER HEATER BYPASS The water heater is equipped with a valve that sets its plumbing circuit for normal or winterize. The valve is accessed from inside the mo- torhome by opening the bottom cab- inet next to the refrigerator. Howev- er, the location can vary depending on your specifi...

  • Page 39: Water Pump

    A master switch is lo- cated above the coach doorway to turn the pump on or off as desired. In addition, the Commander is equipped with optional auxiliary switches in the intake compartment, kitchen and bathroom.

  • Page 40: Utility Module

    COMMANDER / EMBASSY 4.15.4 UTILITY MODULE (COMMANDER ONLY) Access the water system compartment through the door on the left side of the vehicle. Review the oper- ating instructions and control functions before trying to use the system. 1. Exterior Shower: a.
  • Page 41 COMMANDER / EMBASSY 5. Black Water Tank Flush Fitting: This fi tting directs water directly into the black water tank and can be used to rinse the tank when re- quired. Be sure the sewer valve (black water tank valve) is open before the water is turned on.

  • Page 42: Water System Access (Embassy Only)

    COMMANDER / EMBASSY 4.15.5 WATER SYSTEM (EMBASSY ONLY) Access the water system compartment through the door on the right side of the vehicle. Review the oper- ating instructions and control functions before trying to use the system. 1. Exterior Shower (optional) (Fig 4-27): a.
  • Page 43 COMMANDER / EMBASSY 3. Black and Grey Tank Dis- charge Valves: a. Black Water Tank Valve: This is the discharge valve for the black water tank. Pull out to open valve and push in to close. Always empty black water tank fi rst and use the gray water tank to fl...

  • Page 44: Tv Antenna

    COMMANDER / EMBASSY 4.16 TV ANTENNA Each motorhome is equipped with an extendable TV antenna on top of the unit to provide reception at remote locations. Always fully retract antenna whenever vehicle is moved or transported. 1. Extending Retracting: This crank controls the position of the an- tenna assembly on top of the roof.

  • Page 45: Battery Disconnect

    The indicator light will not be lit. Fig. 4-31 BATTERY DISCONNECT (COMMANDER) 4.17.2 EMBASSY This key switch located under the hood discon- nects the coach batteries from the electrical system to prevent battery discharge when the motorhome is in storage.

  • Page 46: Slide-Out Room (Optional)

    Fig. 4-34 ROOM LOCKS transport. Embassy: located at the ceiling of NOTE the room on each end, Commander: located Refer to section 9.3 for detailed on the fl oor. Turn clockwise to secure lock operating instructions.

  • Page 47: System Monitor

    COMMANDER / EMBASSY 4.19 SYSTEM MONITOR A system monitor is located on the wall next to the doorway. 1. Status LED's: Five LED's are used to indicate the status of the tanks and bat- tery. The tank scale registers EMPTY, 1/4, 1/2, 3/4 or FULL.

  • Page 48: Energy Management System

    COMMANDER / EMBASSY 4.20 ENERGY MANAGEMENT SYSTEM (EMS) OPTION AVAILABLE - COMMANDER ONLY This system prioritizes and distributes the power from the shoreline or generator to the appliances or other 120 V users. This system disconnects selected “postpone-able” power draws to elimi- nate or minimize the tripping of circuit breakers.

  • Page 49: Driving

    (See Department Fridge). Check for LP gas leaks regularly us- of Transport sticker located on the drivers door ing soapy water. inside panel(Commander) on the sidewall to the left of the drivers seat(Embassy)). WARNING 3. Check All Fluids: a.

  • Page 50: Emergency Equipment Check List

    COMMANDER / EMBASSY EMERGENCY EQUIPMENT CHECK LIST Use this list as a guide to identify the minimum amount of emergency or safety equipment. Take more as appropriate for your travel or personal needs. 1. First Aid Kit 2. Emergency Flares 3.

  • Page 51: Driving Characteristics

    COMMANDER / EMBASSY b. Descending a Hill: DRIVING CHARACTERISTICS It is a good idea to select a lower gear on your transmission when descending 1. Controls: a hill to avoid prolonged application of The motorhome driver controls are automotive the brakes. Extended application of the...

  • Page 52: Travel Tips

    COMMANDER / EMBASSY TRAVEL TIPS As you travel with your motorhome you will learn much from your own experiences. Share with other mo- torhome owners and learn from them. Read RV, outdoor and camping magazines for camping and travel tips. Here are a few basic suggestions to make your travel and your camping easier and more enjoyable: 1.

  • Page 53: Quick Loading Check List

    COMMANDER / EMBASSY QUICK LOADING 6. Personal: a. Credit Cards CHECK-LIST b. Traveller's Checks c. Cash 1. Bedding: d. Driver's License a. Sleeping Bag e. Birth Certifi cate b. Sheets Sunglasses c. Pillow Cases and Pillows g. Vehicle Registration d. Mattress Pads e.

  • Page 54: Severe Weather Information

    COMMANDER / EMBASSY SEVERE WEATHER INFORMATION As a motorhome traveller you will fi nd the desire to explore new and out-of-the-way places irresistible. These recreational areas can be vulnerable to unusual and severe weather conditions that could endan- ger your safety. A few suggestions and safety precautions may help in case you ever fi nd yourself in this situation.

  • Page 55: Safety Equipment Operation

    SAFETY EQUIPMENT OPERATION Triple E has made every effort to design the vehicle to promote safe driving, use and occupancy. In addi- tion, it has several pieces of safety equipment that the drivers and users should be aware of and trained in their use.

  • Page 56: Fire Extinguisher

    COMMANDER / EMBASSY 6.1.2 FIRE EXTINGUISHER 1. Operation: a. Stay at least 6 feet away from the fi re and near an exit. The chemical from the fi re extinguisher will shoot at least 10 feet. Stay close to the fl...

  • Page 57: Emergency Escape

    COMMANDER / EMBASSY EMERGENCY ESCAPE Each motorhome is designed with an alternate emergency exit via a window in the sleeping area. 1. Emergency Exit: Release the red latches of the emergency egress window and push out the window. (The egress window has hinges on top).

  • Page 58: Alarms

    COMMANDER / EMBASSY ALARMS Each motorhome is equipped with an LP Gas, CO and smoke alarm as standard safety equipment. An intruder alarm is available as optional equipment on some models. Refer to alarm manual(s) for more detailed instructions. Keep all alarms in good working order.

  • Page 59: Carbon Monoxide Alarm

    COMMANDER / EMBASSY 6.3.2 CARBON MONOXIDE This alarm is located in the up- per cabinets in the living area and sounds when there is an unsafe amount of carbon monoxide in the vehicle. Fig. 6-4 CARBON MONOXIDE MONITOR WARNING Carbon Monoxide gas is a odorless and colorless gas that is lethal to people.

  • Page 60: Smoke Alarm

    COMMANDER / EMBASSY 6.3.3 SMOKE ALARM This alarm is located in the cabin and sounds whenever there is smoke in the cabin. Always use the exhaust fan, over the stove when cook- ing. Smoke from cooking may trigger the alarm.

  • Page 61: Intruder Alarm (Optional - Commander Only)

    COMMANDER / EMBASSY 6.3.4 INTRUDER ALARM (OPTIONAL - COMMANDER ONLY) The optional intruder alarm can be connected to the entry doors of your vehicle to protect it from theft or uninvited intrusion. Arm and disarm it using the remote transmitter supplied with the vehi- cle.

  • Page 62: Rear View Camera/Monitor System

    COMMANDER / EMBASSY REAR VIEW CAMERA/ MONITOR SYSTEM (OPTIONAL) An optional rear view camera/monitor system is available to mount on the back of the unit to provide a view of the back of the unit. 1. Camera: The camera is mounted to pick-up a...

  • Page 63: Travelling

    COMMANDER / EMBASSY TRAVELLING The motorhome has been designed to provide the driver and passengers maximum comfort and conven- ience while travelling safely from one place to another. It is the responsibility of the owner/operator/driver to review the safety section at the front of this manual and the chassis manual before travelling in the motorhome.

  • Page 64: Vehicle Weight-Loaded

    Gross Vehicle Weight Rating (GVWR) and the GCWR (Gross Combined Weight Rating) are Triple E ensures that the number of seat belts on not exceeded. Check your Vehicle Certifi cation board equals the sleeping capacity of the unit. You Label for weights.

  • Page 65: Seat Belts

    COMMANDER / EMBASSY SEAT BELTS 7.6.1 LAP BELTS Seats intended for passenger use when travelling are equipped with seat belts. Make sure lap belts are adjusted to a snug fi t and as low on the hips as possible for maximum safety and protection.

  • Page 66: Care And Cleaning

    2. Check belts and hardware from time to time. The power electric mirrors ( Commander only) may Replace any damaged parts. Do not modify or be adjusted using the multi-directional switch locat- remove the belt system.

  • Page 67: Free Standing Dinette

    COMMANDER / EMBASSY FREE STANDING DINETTE (Optional) Your motorhome may be equipped with a free standing dinette. While travelling, these should always be secured with the harness provided to prevent the table and chairs from moving forward in case of sudden braking or a collision and to keep them from sliding around on the fl...
  • Page 68 COMMANDER / EMBASSY 3. Fuel Tank Capacity: Check in the Chassis Manual for capacities. Commander Commander Embassy Embassy Fuel Fuel 75 (284) 75 (284) 75 (284) 75 (284) Capacity Capacity Gal (litre) Gal (litre) Table 1 Fuel Tank Capacities 4. Fuel Type: Use only gasoline with this vehicle.

  • Page 69: Emergencies While Driving

    COMMANDER / EMBASSY EMERGENCIES WHILE DRIVING The Triple E Motorhome is designed with features that allow the driver/occupants to resolve emergencies or failures when travelling. Review this section to be familiar with the recommended procedure to resolve these conditions or situations. Review this section with all new drivers and before each trip.

  • Page 70: Towing

    COMMANDER / EMBASSY TOWING OVERHEATING 1. Emergency Starting: If the engine overheats while driving: Do not tow the motorhome in an attempt to start it. The powertrain is not designed to 1. Pull off the side of the road and stop immedi- transmit torque to turn the engine over for ately.

  • Page 71: Jump Starting

    COMMANDER / EMBASSY JUMP STARTING When the vehicle batteries do not have suffi cient charge to start the engine, there are two ways to start the unit: 1. Coach Batteries: Depress and hold the switch on the left side of the dash to connect the coach batteries into the starter circuit to use all batteries for starting.

  • Page 72: Home Use

    COMMANDER / EMBASSY HOME USE MOTORHOME LEVELLING SYSTEM (OPTIONAL) The motorhome is designed to be your home on wheels while traveling in comfort. This section will If the occupants want to use any of the appliances, cover the items that must be done or considered in...
  • Page 73 COMMANDER / EMBASSY c. Operate the joy stick controls to level the motorhome. d. Check that all jacks are down. Place pads under each jack if ground conditions require it. Fig. 9-2 JACK EXTENDED h. If the system fails and the jacks do not e.

  • Page 74: Slide Out Room (Optional)

    A motorhome may be equipped with an optional slide out room to provide more living area for the oc- cupants. Triple E supplies a video explaining the operation of the slide out system with each slide out equipped model. Please use this video to familiarize yourself with the operations of this system.
  • Page 75 COMMANDER / EMBASSY WARNING Make sure travel locks are removed be- fore extending the slide-out. Make sure travel locks are fastened se- curely before moving the motorhome. IMPORTANT The hydraulics that operate the slide-out are run by a 12- volt pump. When operating...

  • Page 76: Slide Out Room Emergency Operation

    SLIDE OUT ROOM EMERGENCY OPERATION The slide out room and optional bedroom slide out can be manually retracted in case of sys- tem failure. Refer to the Triple E supplied video and the HWH or Power Gear manual for further information.

  • Page 77: Slide Out Room Troubleshooting

    DO NOT use petro- leum products on these seals as they can cause premature seal deterioration. CENTRAL VACUUM SYSTEM - (OPTIONAL ON COMMANDER Your Commander can be equipped with an optional central vacuum system eliminating the need for a portable unit.

  • Page 78: Electrical Systems

    COMMANDER / EMBASSY ELECTRICAL SYSTEMS Your Commander / Embassy is equipped with two electrical systems operating on separate volt- ages - a 12 Volt DC System and a 120 Volt AC System. The 12 Volt DC System draws its power either from the engine's charging system while driving or from the coach batteries when parked.

  • Page 79: Power Control Center (Optional - Commander Only)

    COMMANDER / EMBASSY 10.1.2 POWER CONTROL CENTER - COMMANDER ONLY (OPTIONAL) 12V Fuse Panel 120V Breaker Panel 120V Breaker Panel This panel contains the fuses for the 12 volt sys- tem, circuit breakers for the 120 volt system. 120V power to 12V DC converter is mounted in compart- ment behind the panel.

  • Page 80: Ground Fault Circuit Interrupter (Gfci)

    COMMANDER / EMBASSY 10.1.4 GROUND FAULT CIRCUIT INTERRUPTER (GFCI) Various outlets in the motorhome, particularly those near sinks and water supplies, are con- nected to a GFCI which is a very sensitive circuit breaker that will protect you from electrical shock if a severe ground fault develops.

  • Page 81: Auxiliary 120-Volt Generator

    COMMANDER / EMBASSY 10.2 AUXILIARY 120 VOLT GENERATOR (OPTIONAL) Refer to the Generator Owner Operator's Manual for more detailed instructions. 10.2.1 GENERATOR SAFETY 1. Electrical: WARNING Extreme care and caution should be exercised when handling the generator and its components.

  • Page 82: Generator Operation

    For Embassy, plug in the power cord into the generator receptical in the power cord compartment. (Fig. 10- Dash Board (Commander) 7) On the Commander, the switch is done by an automatic power transfer switch. (See Section 10.2.3) c. Disconnect all electrical loads. (Turn off all lights, appliances, equipment, etc.).

  • Page 83: Automatic Power Transfer Switch (Commander Only)

    COMMANDER / EMBASSY 10.2.3 AUTOMATIC POWER TRANSFER SWITCH (COMMANDER ONLY) This Commander model is equipped with an automatic power transfer switch that transfers the electrical load between the shoreline or genera- tor power source. It automatically transfers all the load to shoreline whenever it is plugged in. The shoreline must be unplugged to utilize power from the generator.

  • Page 84: 12-Volt Dc System

    COMMANDER / EMBASSY 10.3 12 VOLT DC SYSTEM The DC voltage system in your motorhome consists of two separate and yet connected battery systems: 1. The automotive batteries(or chassis battery) 2. The auxiliary or motorhome batteries (or coach battery) 10.3.1 AUTOMOTIVE BATTERIES...

  • Page 85: 12-Volt Coach Fuses

    COMMANDER / EMBASSY 10.3.3 12 VOLT COACH FUSES All 12-volt circuits are protected by either a circuit breaker or a fuse in the control panel. When a breaker trips or a fuse blows, shut off all applianc- 12 Volt Fuses...
  • Page 86 COMMANDER / EMBASSY WARNING Remove rings, metal watchbands, and other metal jewellery before working around a battery. Use caution when using metal tools. If atool contacts the battery terminals or metal connected to them, a short circuit could occur which could cause personal injury or fi...

  • Page 87: Battery Condition Meter

    COMMANDER / EMBASSY 10.3.5 BATTERY CONDITION METER On your control panel you will fi nd a gauge which tells you the level of charge in your coach or auxiliary batteries. Fig. 10-13 BATTERY CONDITION METER 10.4 TRAILER WIRING CONNECTOR Your motorhome is ready for trailer or car towing.

  • Page 88: Electrical Schematics

    COMMANDER / EMBASSY 10.5 ELECTRICAL SCHEMATICS 10-11...
  • Page 89 COMMANDER / EMBASSY 10-12...

  • Page 90: Vehicle Fuse Panels

    COMMANDER / EMBASSY 10.6 VEHICLE FUSE PANELS Access Panel Fig. 10-18 VEHICLE FUSE PANEL Commander 10-13...
  • Page 91 COMMANDER / EMBASSY THIS PAGE LEFT INTENTIONALLY BLANK 10-14...

  • Page 92: Lp Gas System

    LP gas sys- complete. To ensure proper service and tem. safety, always take your motorhome to an authorized Triple E service center. 9. Do not lock LP tank compartments. Recrea- tional vehicle industry standards require that all 11.1...

  • Page 93: Selecting Fuel Types

    COMMANDER / EMBASSY 11.3 SELECTING FUEL TYPES Butane burns at a much higher temperature than propane but will not change from a liquid to a gas at temperatures below 32 degrees F or 0 degrees C. Propane, on the other hand, burns at a lower...

  • Page 94: Refi Lling Lp Tank

    COMMANDER / EMBASSY 11.6 REFILLING LP TANK WARNING Never overfi ll the LP gas tank. Make sure your vehicle is level when fi lling the tank. Make sure all pilot lights are OFF before refuelling any of the gas tanks on your motorhome.

  • Page 95: Travelling Lp Gas

    COMMANDER / EMBASSY After tank has been fi lled: dealers to prevent this from happening). To help avoid this situation, keep the control valve closed 1. Check all container and line connections peri- when not in use even when the tank is empty. This odically to be sure they are tight.

  • Page 96: Lp Gas Leaks

    COMMANDER / EMBASSY 11.10 LP GAS LEAKS 11.11 LP GAS DETECTOR If you ever smell LP gas in the vehicle or the detec- A standard LP gas detector has been installed in tor alarm sounds, follow the instructions carefully. your unit.

  • Page 97: Water/Plumbing System

    An automatic Fig. 12-1 DRIVERS SIDE UTILITY MODULE (COMMANDER ONLY) pressure switch, located in the water pump maintains a positive line pressure.

  • Page 98: Fresh Water Tank Filling Procedure

    When fi lling fresh water tank: 1. Connect water hose to the city water inlet connection. Fig. 12-2 FRESH WATER TANK FILLING (INLET)(Commander shown, Embassy fi ll inlet located on sidewall of unit) 2. Set the water pump switch for the motorhome system to the off position.

  • Page 99: Water Pump Switch

    A slow leak in a faucet or con- nection could drain both the water tank and the battery. External Compartment (Commander only) Bathroom (Commander only) Galley (Commander only) Fig. 12-3 WATER PUMP SWITCHES...

  • Page 100: Water Pump

    Access Hole Fig. 12-5 ACCESS HOLE (COMMANDER ONLY) 12.1.6 WATER PUMP INITIAL START-UP 6. Close each faucet (cold and hot) as soon as 1. Make sure all drain valves are closed including water fl...

  • Page 101: Water Pump Troubleshooting

    COMMANDER / EMBASSY 12.1.7 WATER PUMP 12.1.8 DISINFECTION OF WATER TANK TROUBLESHOOTING 1. If pump will not prime: It is recommended that fresh water systems be a. Make sure there is water in the tank. disinfected. b. Make sure the battery is not run down.

  • Page 102: External Water Supply

    fi ll selection valve. Turn the water selector valve to "city water". c. Turn on external water supply. Fig. 12-6 WATER CONNECTION (COMMANDER ONLY) IMPORTANT After connecting to the exter- nal water supply, open the faucets in your motorhome slowly and cautiously.

  • Page 103: Waste System

    COMMANDER / EMBASSY 12.2 WASTE SYSTEMS 12.2.1 GREY WATER - WASTE HOLDING TANK The drainage from the kitchen sinks, bathtub and shower pan is collected in a separate grey water holding tank. This tank has its own dump valve but ties into the same termination valve outlet as the waste holding tank.

  • Page 104: Dumping Holding Tanks

    Move hose about gently to ensure fl ow of waste materials. When tank is empty, close valve. Fig. 12-8 STORAGE COMPARTMENT (COMMANDER ONLY) 5. After tank has been drained, run several gallons of fresh water into the black water tank through the toilet.

  • Page 105: Tank Rinse

    Make sure the black tank drain valve is open when using the water tank rinse system. Fig. 12-10 FLUSH CONNECTION (COMMANDER ONLY) 12.2.5 DO'S AND DON'TS HOLDING TANKS 1. DO keep your holding tank clean using any 12.2.6 USING ON-SITE SEWER...

  • Page 106: Holding Tank Level Indicators

    COMMANDER / EMBASSY 12.2.7 HOLDING TANK LEVEL INDICATORS The holding tank levels may be checked on the monitor panel. Press the corresponding switch to check the level in each tank. Fig. 12-11 TANK LEVEL INDICATORS 12.2.8 TANK CAPACITIES Commander Commander...

  • Page 107: Toilet

    Check to see that the levers return all the way to the left. Sticking may be caused by foreign 3. Motor Aid Water Heater (Commander Only): material on the waste valve blade or blade seal Your motorhome is equipped with a system at the bottom of the bowl.

  • Page 108: Exterior Shower (Optional)

    COMMANDER / EMBASSY 12.3.4 EXTERIOR SHOWER (STANDARD ON COMMANDER OPTIONAL ON EMBASSY) Your motorhome may be equipped with and exterior auxiliary shower to allow you to rinse off sand and dirt, to clean muddy footwear or to bathe pets before entering the vehicle. It...

  • Page 109: Plumbing Schematics

    COMMANDER / EMBASSY 12.4.2 PLUMBING SCHEMATICS DRAINAGE SYSTEM 12-13...

  • Page 110: Appliances And Interior Features

    COMMANDER / EMBASSY APPLIANCES AND INTERIOR FEATURES Refer to the operator's manuals in the information package for more detailed instructions if required for each appliance, component or system. 13.1 REFRIGERATOR The refrigerator in your motorhome can be oper- ated on either: 1.

  • Page 111: Exterior Refrigerator

    COMMANDER / EMBASSY 13.1.3 EXTERIOR REFRIGERATOR COMPARTMENT This compartment allows access to the refrigerator for cleaning, inspection, maintenance and service. It is a good practice to open the compartment door once in a while to make sure that the area is clean and free of any debris that might hinder air circula- tion.

  • Page 112: Safety Tips

    COMMANDER / EMBASSY 13.2.2 SAFETY TIPS 1. Always wait 5 minutes before relighting range/ oven to allow gas to dissipate. 2. The range/oven is not designed for and should never be used as a space heater. 3. Do not operate range/oven while travelling or while refuelling your vehicle at a gasoline serv- ice station.

  • Page 113: Operating Oven Control

    COMMANDER / EMBASSY 13.2.5 OPERATING OVEN CONTROL To adjust the oven temperature, push in the knob and turn it counterclockwise to the desired temper- ature setting. There may be a delay of 45 seconds before the burner is ignited. This is normal. To keep the oven temperature at the set temperature, the burner will cycle on and off.
  • Page 114 COMMANDER / EMBASSY THIS PAGE LEFT INTENTIONALLY BLANK 13-5...

  • Page 115: Lp Gas Furnace

    COMMANDER / EMBASSY 13.4 LP GAS FURNACE The furnace(s) should not be operated when the 2. To Shut Down: vehicle is underway, and the LP gas should be a. Slide the thermostat to the off position. turned off at the LP container at any time the mo- b.

  • Page 116: Roof Air Conditioners

    COMMANDER / EMBASSY 13.5 ROOF AIR CONDITIONERS The roof air conditioner(s) are controlled by the climate control center. Adjust the control to cool- ing. Select the temperature and the fan speed to suit your needs. 1. Maintenance: We recommend that the fi lters by cleaned or changed at least every two weeks when the air conditioner is in operation.

  • Page 117: Signal Amplifi Er

    COMMANDER / EMBASSY 3. Rotating the Antenna: After antenna is in the up position, pull down the rotating knob until it disengages the ceiling plate. Rotate the antenna for best sound and picture. 4. Lowering the Antenna: Rotate the antenna until the pointer on the rotating knob and the ceiling plate align.

  • Page 118: Video Cassette Recorder

    Fig. 13-9 VIDEO CONTROL CENTER (COMMANDER ONLY) 13.11 PHONE AND CABLE TV HOOK-UPS The Commander phone and cable TV hook-ups are located in the shoreline storage compartment. On the Embassy they are located on the vehicles exterior sidewall. For the Commander,open the compartment, raise the covers and connect the terminals for the signals.

  • Page 119: Sleeping Facilities

    SLEEPING FACILITIES WARNING Do not use sleeping facilities while motorhome is in motion. 1. Bedroom Heater (Commander and Embas- sy XL only): Standard sleeping facilities with a bed are located at the rear of the coach. The control for the Embassy heater are as shown in fi gure 13-11 and is “push/pull”...
  • Page 120 COMMANDER / EMBASSY THIS PAGE LEFT INTENTIONALLY BLANK 13-11...

  • Page 121: Fresh Water Toilet

    COMMANDER / EMBASSY 13.14 FRESH WATER TOILET The toilet in your motorhome is very much like the one on your home except that it uses a much smaller amount of water for fl ushing. When the levers are moved to the right for fl ushing, a high velocity stream of water produces a swirl effect that should effectively cleanse the toilet.

  • Page 122: Electric Step (Optional)

    COMMANDER / EMBASSY 13.15 ELECTRIC STEP (OP- TIONAL ON EMBASSY) Normal Operation - Step switch in “on” position (located on switch panel beside door entrance). Open the door. The step should descend and lock in extended position with the understep light on. Close the door. The step should retract and lock in up position.

  • Page 123: Washer/Dryer Hook-Ups (Optional - Commander Only)

    COMMANDER / EMBASSY 13.18 WASHER/DRYER HOOK-UPS - COMMANDER ONLY (OPTIONAL) Your motorhome may be equipped with the wa- ter, drain and power requirements to allow the use of a washer and dryer. This feature works best when the unit is connected to city water, sewer and shoreline.

  • Page 124: Care And Maintenance

    COMMANDER / EMBASSY CARE AND MAINTENANCE 14.1 EXTERIOR After polishing apply a automotive wax. Do not 1. Roof: use this polish on the painted or decaled areas The roof is made of with an aluminium frame on the front of the vehicle.Carefully inspect all...

  • Page 125: Interior

    Any major cleaning fi nish cleaning product available from your problems should be undertaken by profes- Triple E dealer or other RV centers. IMPORTANT sional cleaners. Direct sunlight will cause fading of The beauty of the wood is in the natural vari- upholstery and fabrics.
  • Page 126 COMMANDER / EMBASSY 11. Refrigerator: 14. Micro/Convection Oven: The cabinet interior should be cleaned regu- Consult owners manuals for detailed instruc- larly. Remove shelves and wash the lining tions. Keep the door and inside of your micro- with lukewarm water to which a mild soap may wave oven clean.
  • Page 127 COMMANDER / EMBASSY 15. Bathroom: a. General: As a general rule, use warm water and mild soap to clean walls and surfaces in your bathroom. On glass doors and mirrors a good quality glass cleaner may be used. Harsh cleaners, detergents or abrasives should never be used.

  • Page 128: Motorhome Maintenance

    COMMANDER / EMBASSY MOTORHOME MAINTENANCE 15.1 CHASSIS CUSTOMER SERVICE Chassis service is a concern for every vehicle owner. Ford and Workhorse custom chassis have recognized this and have developed nationwide Service Centers. Each service center has the fa- cilities, technicians, equipment and part availability to properly service your motorhome chassis.

  • Page 129: Storing Your Rv

    COMMANDER / EMBASSY STORING YOUR RV All systems, components and appliances should be inspected and repaired prior to storage. Checklist: 13. Add RV anti-freeze (1/2 cup each) to the 1. Fill fuel tanks to reduce excessive build-up of moisture in the fuel tanks.

  • Page 130: Winterization

    COMMANDER / EMBASSY WINTERIZATION 17.1 COLD TEMPERATURE 17.1.3 FURNACE OPERATION During below freezing temperatures, the furnace must be operating at all times. Remember, al- All motorhomes are built for year-round travel though the furnace runs on LP gas, it is powered including: by 12-volt electrical.

  • Page 131: Cold Temperature Storage

    COMMANDER / EMBASSY 17.2 COLD TEMPERATURE STORAGE 17.2.1 WATER SYSTEM WINTERIZATION 1. a.) Commander: Place the anti-freeze pick up line (located under rear bed) into a con- tainer of potable water anti-freeze. b.) Embassy: Remove the suction hose from the water pump (located under the rear bed).

  • Page 132: Water Purifi Er

    COMMANDER / EMBASSY 17.2.3 WATER PURIFIER (OPTIONAL COMMANDER ONLY) To winterize: 1. Shut off in-line water valve located under the galley sink. 2. Unscrew the plastic water lines from the puri- fi er. 3. Remove and drain the unit. 4. Store water purifi er in an area where tempera- ture is above the freezing point.

  • Page 133: Warranty Policy

    C. Coach Warranty: Triple E Recreational Vehicles warrants the specifi ed new vehicle to be free from defects in material and workmanship under normal use and service. Obligation under this warranty shall be limited to twelve (12) months or 20,000 kilometers, whichever occurs fi rst, after the date of purchase by the original retail purchaser from an authorized dealer and shall be limited to making good at our factory, any part or parts thereof upon return to the factory.
  • Page 134 This warranty does not cover any component which is not manufactured by Triple E Recreational Vehicles or any component under separate warranties from its manufacturer (tires, batteries, re- frigerator, stove, heaters, chassis, powertrain, etc for example).
  • Page 135 It may become necessary for you (the retail owner) to have warranty work done at a site other than an authorized Triple E RV Dealer. If this is the case the repair center must obtain prior authorization from Triple E Recreational Vehicles before the warranty work can begin to ensure warranty coverage is available and that the rates are acceptable.
  • Page 136 COMMANDER / EMBASSY Attachment A – Major Component Listing for 2 Year Warranty Attachment A – Major Component Listing for 2 Year Warranty Refrigerator Furnace Water Heater Roof Air Conditioners TV Antenna Range and Oven Microwave Water pump Power Converter...

  • Page 137: Index

    Seat/Shoulder Belts ............4-6 Parking ...............9-1 Side Entry Prolonged Occupancy ............9-6 (Optional - Commander and Embassy XL oly) .....4-10 Slide Out Room (Optional) ..........9-3 Slide-Out Room (Optional) ...........4-25 Slide Out Room - Emergency Operation .....9-5 System Monitor ............4-26 Slide Out Room - Powered ..........9-3 TV Antenna ..............4-23...

  • Page 138: Water Heater

    Trailer Towing ..............3-2 Exterior Shower (Optional) ........12-12 Vehicle Loading ............3-1 Shower ..............12-11 Toilet ..............12-11 Water Heater ............12-10 Water Purifi er (Optional - Commander only) ...12-12 Safety ..................2-1 Waste System ..............12-7 Alarms ...............2-4 Black Water - Waste Holding Tank ......12-7 Asphyxiation ..............2-3 Do's And Don'ts Holding Tanks .........12-9...

This manual is also suitable for:

Embassy

Table of Contents

Save PDF
