Summary of Contents for EVOnet C-FB310
-
Page 3: Compliance Notice Of Fcc
Network Camera WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. -
Page 4: Important Safeguards
Quick Reference Guide Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read Do not overload wall outlets and extension cords as this can before the appliance is operated. result in the risk of fire or electric shock. 2. -
Page 5: Package Contents
Network Camera Package Contents Network Camera C-Mount Ring DC-Type Auto Iris Lens Connector Socket Protective cover (attached to the unit) Installation CD (INIT/SiRiS Lite software and User’s Manuals) Quick Reference Guide (This Document) Mount Kits Dimensions... -
Page 6: Front Side View
Quick Reference Guide Front Side View ① Image Sensor: Converts an optical image of the object to an electric signal. NOTE: Cover the image sensor by using the protective cover provided with the camera when a lens is not mounted on the camera. -
Page 7: Factory Reset
Network Camera Factory Reset This will only be used on the rare occasions that you want to return all the settings to the original factory settings. CAUTION: When performing a Factory Reset, you will lose any settings you have saved. Cut off the power from the camera. -
Page 8: Installation
Quick Reference Guide Network LED: Indicates network connection status. See Appendix – LED Indicators of the User’s Manual for details. The LED will not light regardless of the status if the Status LED is disabled when configuring the System – General setup. NOTES: ... -
Page 9: Dc-Type Auto Iris Lens
Network Camera 2. Mount the lens on the camera by turning the lens clockwise. 3. Turn the iris ring on the lens to the open position and adjust the iris properly. DC-Type Auto Iris Lens 1. If necessary, solder the lens control wires to the connector socket supplied with the lens. NOTE: Please refer to the lens manufacturer’s manual for soldering the lens control wires. -
Page 10: C-Mount Lens
Quick Reference Guide C-Mount Lens Remove the protective cover from the camera. Mount the C-mount ring on the camera by turning the ring clockwise. Mount the C-mount lens on the C-mount ring by tuning the lens clockwise. Running Installation Program (INIT) The INIT (Integrated Network Installation Tool) program is provided with the product for connection to the product. -
Page 11: Connecting To Network Camera
Network Camera Connecting to Network Camera Connecting from Local PC The network camera is set to be automatically assigned a temporary IP address from a DHCP server by default. If there is no DHCP server, the IP address is set to 169.254.x.x. It allows you to connect to the network camera without additional installation procedure. -
Page 12: Dvrns Setup
Quick Reference Guide Type: Select Manual, ADSL (with PPPoE) or DHCP depending on the network connection type. If you select Manual, you need to acquire the IP address, gateway and subnet mask from your network administrator or Internet service provider. The ADSL connection requires ID and password. - Page 13 Network Camera Use DVRNS: Enter the IP address or domain name of the DVRNS server. Port: Set up the port number of the DVRNS server. Use NAT: Check the box when the camera uses a NAT (Network Address Translation) device for network connection.
- Page 14 Quick Reference Guide A success message is displayed if all the current port numbers are available, and recommended port numbers are displayed if any of the current port numbers are not available. Clicking the Apply button applies the recommended port numbers. Configuring Network Camera Run the INIT program →...
- Page 15 Network Camera Monitoring Monitoring video from the network camera is supported on remote programs: PDR-mobile, WebGuard, SiRiS Lite. aPDR-mobile, iPDR-mobile: Monitoring program on an Android or iOS based mobile device WebGuard: Web monitoring program SiRiS Lite: Monitoring, recording and playback program See the User’s Manual of each program on the CD for details.
- Page 16 Quick Reference Guide Description: Enter the device name to use in the aPDR-mobile program. Use DVRNS: If the device uses the DVRNS function, enable the Use DVRNS option. You can set up the information for the DVRNS server by tapping the Settings button in the default menu.
- Page 17 Network Camera General: Enter the device name to use in the iPDR-mobile program. Connection Info: Enter the IP address and port number of the device. If the device uses the DVRNS function, enable the DVRNS option and enter the device name registered on the DVRNS server instead of the IP address.
-
Page 18: Recording And Playing Back
Quick Reference Guide Recording and Playing Back 1. Insert the installation CD. 2. Install the SiRiS Lite installation file on the PC. See the User’s Manual on the CD for details about installation. 3. Run the SiRiS Lite Setup program as follows: Go to the Start menu on the PC → Click SiRiS Lite and then SiRiS Lite Setup →... - Page 19 Network Camera 6. Allocate storage for recording as follows: Go to the Storage menu → Click the button at the bottom → Select a hard disk drive from the list and click the Add button at the bottom → Allocate storage. 7.
- Page 20 Quick Reference Guide 8. Run the SiRiS Lite Client program to monitor or playing back recorded video as follows: Go to the Start menu on the PC → Click SiRiS Lite and then SiRiS Lite Client → Enter login information (Default user ID: Admin, Default password: 12345678) → Click the Live or Play tab on the screen →...
