Page 3: Compliance Notice Of Fcc
Network Camera WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. -
Page 4: Important Safeguards
User’s Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read Do not overload wall outlets and extension cords as this can before the appliance is operated. result in the risk of fire or electric shock. 2. -
Page 5: Table Of Contents
Network Camera Table of Contents Chapter 1 — Introduction ................1 In This Manual ..................1 Features ....................1 Typical Applications ................. 2 Remote Monitoring ................2 Remote Recording ................3 Webcasting ..................3 Chapter 2 — Installation................5 Package Contents ..................5 Dimensions .................... - Page 6 User’s Manual Audio ...................... 34 Input/Output ..................34 Event Action ................... 35 Alarm Out ..................35 Email ....................36 Remote Callback ................37 Audio Alarm ..................38 FTP Upload ..................39 Record ....................40 Event ...................... 43 Alarm In .................... 44 Motion Detection ................
-
Page 7: Chapter 1 - Introduction
Network Camera Chapter 1 — Introduction In This Manual This manual is intended for users of the network camera and includes instructions for using and managing the camera on the network. Features This network camera compresses live video and transmits the video over Ethernet connections. -
Page 8: Typical Applications
User’s Manual NOTES: In this manual, a “remote system” refers to a PC that the remote program (SiRiS Lite or WebGuard) is running. Remote monitoring and recording through multistream are available by using the SiRiS Lite program provided with the camera. Typical Applications Remote Monitoring... -
Page 9: Remote Recording
Network Camera Remote Recording Webcasting... - Page 10 User’s Manual...
-
Page 11: Chapter 2 - Installation
Network Camera Chapter 2 — Installation Package Contents Network Camera Installation CD (INIT/SiRiS Lite software and User’s Manual) Quick Reference Guide Mount Kits Dimensions Illustrated Parts List Vandal Dome Model < Dome Cover > < Dome Cover – Bottom Side View >... -
Page 12: Plastic Dome Model
User’s Manual < Shield Case > < Body > ① IR LED ② Lens ③ Heater ④ Rotation Base ⑤ Pan Base ⑥ SD Memory Card Slot ⑦ Factory Reset Switch ⑧ Safety Wire Setscrew Hole ⑨ Wall/Ceiling Mounting Hole ⑩... -
Page 13: Factory Reset
Network Camera Side Cable Access Hole, Cable Access Hole: Allows you to feed wires and cables for connection to power, devices, and Ethernet. Safety Wire, Safety Wire Setscrew Hole: Allows you to connect the safety wire to the dome cover and to the bottom cover by using the screw provided with the camera. -
Page 14: Lens
User’s Manual Cut off the power from the camera. → Poke a straightened paperclip into the factory reset switch hole. → Turn on the power while holding the reset switch → Release the switch in about 5 seconds after the Power LED blinks. → The camera resets to factory defaults and restarts after completing the factory reset. - Page 15 Network Camera − IN: Connect an alarm-in device. Mechanical or electrical switches can be wired to the IN and GND (Ground) connectors. The voltage range is from 0V to 5V. When the electrical switch is wired, the threshold voltage for NC (Normally Closed) is above 4.3V and for NO (Normally Open) is below 0.3V, and it should be stable at least 0.5 seconds to be detected.
-
Page 16: Mounting
User’s Manual WARNING: ROUTE POWER CORDS SO THAT THEY ARE NOT A TRIPPING HAZARD. MAKE CERTAIN THE POWER CORD WILL NOT BE PINCHED OR ABRADED BY FURNITURE. DO NOT INSTALL POWER CORDS UNDER RUGS OR CARPET. USE THE POWER CORD THAT HAS A GROUNDING PIN. IF YOUR POWER OUTLET DOES NOT HAVE A GROUNDING PIN RECEPTACLE, DO NOT MODIFY THE PLUG. -
Page 17: View Angle
Network Camera View Angle Three-axis lens positioning is supported. ① Rotation: Adjusts the rotation angle. Move the rotation base clockwise or counterclockwise. ② Tilt: Adjusts the tilt angle. Loosen the tilt adjustment screws, move the lens up and down and tighten the screws to lock the angle. - Page 18 User’s Manual...
-
Page 19: Chapter 3 - Remote Setup
Network Camera Chapter 3 — Remote Setup Remote Setup allows you to change all settings of a camera. Run the INIT program, select a camera and click the Setup icon on the Main screen. Select Remote Setup from the Setup menu and the Remote Setup screen appears. -
Page 20: Quick Setup
User’s Manual Quick Setup The Quick Setup allows you to change a camera’s basic system, network, video and audio settings. System You can change a camera’s system information, import or export all settings, and add users or groups. General Language: Choose the language to be used during remote setup. ... -
Page 21: Date/Time
Network Camera − Status LED: Check the box to enable LEDs. If LEDs are not enabled, the LEDs on the product panel will not light regardless of the status. Setup: − Load Default Setup…: Click to return all settings except date/time to the original factory settings. -
Page 22: User/Group
User’s Manual Time Sync − Automatic Sync: Check the box to automatically synchronize the time with a time server. Enter the IP address or the domain name of the time server and set the time interval for synchronization. If the time server uses the DVRNS function, selecting the Use DVRNS box allows you to enter the name instead of the IP address or the domain name of the time server. -
Page 23: Network
Network Camera NOTES: Only users belonging to the Administrator group can make User/Group changes. The default user ID/password is admin with no password or pacom/pacom. The default groups (Administrator, Operator, User) cannot be edited or deleted. The same authority levels are assigned to the user groups in the ONVIF protocol. -
Page 24: Ip Address
User’s Manual IP Address Type: Select the type of network configuration. Remote Setup closes after saving the changes. − Manual: Select when the camera is using a static IP address for network connection, and set up LAN parameters manually. −... -
Page 25: Dvrns
Network Camera DVRNS Check the DVR Name Service box to use the DVRNS function. DVRNS Server: Enter the IP address or domain name of the DVRNS server. Port: Set up the port number of the DVRNS server. Use NAT: Check the box when the camera uses a NAT (Network Address Translation) device for network connection. -
Page 26: Port/Qos
User’s Manual NOTES: When using a NAT (Network Address Translation) device, refer to the NAT manufacturer’s instructions for the proper network settings. The camera name you entered in the Camera Name field should be checked by clicking the Check button, otherwise the DVRNS changes will not be saved. - Page 27 Network Camera Use UPnP: Check the box to connect to the camera without manually setting up port forwarding on the NAT device when the camera uses a NAT (Network Address Translation) device for network connection. The UPnP function must also be enabled in the NAT device for this function to work.
-
Page 28: Bandwidth Control
User’s Manual Bandwidth Control You can control the network bandwidth by limiting the network bandwidth of the camera depending on the network traffic. Check the Network bandwidth limit box and set the desired maximum bandwidth. When the network is busy with traffic, the camera cannot use more than the maximum bandwidth. NOTE: When limiting the network bandwidth, the frame rate might decrease to lower than the frame rate set during the Video –... -
Page 29: Security
Network Camera Security IP Filtering: Check the box to use the IP filtering function. You can allow or block connections to the camera by designating IP addresses. − Add: Click the button to add IP addresses to the Allow List or Deny List to allow or block connection to the camera. -
Page 30: Ieee 802.1X
User’s Manual IEEE 802.1X Check the IEEE 802.1X box to use the IEEE 802.1X network connection authentication function. Certificates: Uploads a certificate or private key for network connection depending on the authentication type. Entering a private key password might be required depending on the authentication type. -
Page 31: Video
Network Camera Video You can set up camera setting and features for streaming, webcasting, MAT and privacy masking. Camera Image Sensor: Click the tab to set up image sensor settings. Mirroring: Check the Horizontal or Vertical box to flip images horizontally or vertically. - Page 32 User’s Manual Noise Filter: Set the degree of the noise filtration. This adjustment can be used to decrease noise in low light conditions. The higher the value is set, the less the noise there is. However, too high of a setting might cause overall image blurring. White Balance: Click the tab to set up white balance settings.
- Page 33 Network Camera Exposure: Click the tab to set up exposure settings. AE Target Gain: Set the target gain for the exposure compensation. The camera compensates the exposure automatically based on the selected target gain. The higher the value is, the brighter the images are.
- Page 34 User’s Manual Day & Night: Click the tab to set up day & night settings (IR LED non-supported model only). B&W Mode: When in the black and white mode, images are displayed in black and white and are clearer in low light conditions. This feature will be disabled if the Day & Night Mode event action is enabled during the Event –...
- Page 35 Network Camera Miscellaneous: Click the tab to set up other settings. Video Output: Select t he video signal for video output Smart IR: Set the brightness of the IR LED (IR LED supported model only). Check the box to adjust the brightness automatically.
-
Page 36: Streaming
User’s Manual Streaming Primary, Secondary, Tertiary: The camera supports multistream video (priority: Primary > Secondary > Tertiary). Set whether to enable or disable the streams. Some of the settings may change depending on the settings of streams of higher priority and the tertiary stream may not be available (see the table below). -
Page 37: Webcasting
Network Camera Multi-View Streaming: It allows you to set up a streaming area to stream specific area of video (supported only for the secondary and tertiary stream). Click the Setup button and set up the streaming area. Checking the On box allows you to set up the streaming area. -
Page 38: Mat
User’s Manual The camera can stream live video from the camera to a website. HTML Code: Copy the HTML Code that is displayed on the screen and paste it in your web page code. Stream: Select a stream to use for webcasting. Only the streams in use are available. NOTE: To use the webcasting service, you must check the Allow Anonymous Login option during 3.2 System –... -
Page 39: Privacy Masking
Network Camera NOTE: The MAT (Motion Adaptive Transmission) function allows you to reduce bandwidth overload and to save storage capacity by reducing the frame rate when no motion is detected. The camera considers that no motion is detected when no change is detected between two consecutive images based on the sensitivity setting. -
Page 40: Audio
User’s Manual − (Select) or (Clear): Click to select or clear a block for privacy masking area. You can select or clear the several blocks of an area using the mouse dragging. − No. / Name: Displays a list of the preset privacy masking areas. The number indicates the number displayed in the privacy masking area. -
Page 41: Event Action
Network Camera Event Action You can set up event actions to be taken when the camera detects events. Alarm Out Check the Alarm Out box to activate alarm out. Dwell Time: Select the alarm-out dwell time. An alarm out is activated for the preset dwell time after detecting an event. -
Page 42: Email
User’s Manual Email Check the Email box to send an email. SMTP Server, Port: Enter the IP address or domain name and port number of the SMTP server attained from your network administrator. You can use the domain name instead of the IP address if you set up the DNS server when setting up the network. -
Page 43: Remote Callback
Network Camera Remote Callback Check the Remote Callback box to send a callback message to remote systems (Not supported for the WebGuard program). IP Address, Port: Enter the IP addresses and port numbers of the remote systems to send a message. -
Page 44: Audio Alarm
User’s Manual Audio Alarm Check the Audio Alarm box to sound by playing back an audio file. List: Displays the audio file to be played back. You can add or delete an audio file (.wav) (16 bits/16 KHz encoded file only) by clicking the Add or Remove button. Selecting an audio file in the list and clicking the Play or Stop button allows you to test the sound by playing back the selected audio file. -
Page 45: Ftp Upload
Network Camera FTP Upload Check the FTP Upload box to upload event detected images in JPEG file format to an ftp server. FTP Server: Click the Add button to register an ftp server. Clicking the Remove button deletes the registered ftp server. When an event is detected, the event detected images will be uploaded in JPEG file format to the ftp server registered as a primary server. -
Page 46: Record
User’s Manual − Upload Frequency: Displays only when the upload type is set to Always. Set up the upload rate, and the preset number of images will be uploaded to the ftp server during the preset time. − Upload 1 image per: Displays only when the upload type is set to Event. Set up the upload rate. - Page 47 Network Camera Check the Record box to enable recording on an SD memory card. Ensure that the SD memory card (Class 6 or higher) is inserted properly. Total Capacity: Displays the total capacity of the SD memory card when an SD memory card is inserted properly.
- Page 48 User’s Manual Settings: Click the tab to set up recording settings. Recording Stream: Select a stream to use for recording. − Time-Lapse/Pre-Event, Event: Allows using a different stream depending on the recording mode. Time-Lapse/Pre-Event: Select the stream to use for recording when in the time-lapse recording mode or for pre-event recording when in the event recording mode.
-
Page 49: Event
Network Camera NOTES: Searching and playing back video recorded on the SD memory card is supported by using a remote program. Refer to the User’s Manual for the remote program for details. Searching and playing back video recorded on the SD memory card might not be very smooth when using a remote program while also recording video on the SD memory card. -
Page 50: Alarm In
User’s Manual Alarm In IR LED Supported Model IR LED Non-Supported Model Check the Alarm In box to set up an alarm-in event. When the camera senses an input on the alarm input connector, it considers it as an event. -
Page 51: Motion Detection
Network Camera Title: Enter the alarm-in device’s name. Type: Select the alarm-in type. Event Action: Check the box for each action the camera will take whenever it detects an alarm-in event. − Day & Night Mode: Check the box to disable the IR cut filter during the event detection (not supported for IR LED supported model). - Page 52 User’s Manual Sensitivity: Set the motion sensitivity for daytime and nighttime independently. The higher the number is, the more sensitive it is. Minimum Blocks for Detection: Adjust the minimum number of detection blocks that must be activated in order to be considered as a motion event for daytime and nighttime independently. ...
-
Page 53: Trip-Zone
Network Camera Trip-Zone Check the Trip-Zone box to set up a trip-zone event. When the camera detects a moving to or from the preset trip-zone, it considers the moving as an event. Sensitivity: Set the moving sensitivity for daytime and nighttime independently. The higher the number is, the more sensitive it is. -
Page 54: Audio Detection
User’s Manual − Remote Callback: Check the box and select the remote systems to send a message (Not supported for the WebGuard program). − Audio Alarm: Check the box and select the audio file (.wav) to sound. − FTP Upload: Check the box to upload images to an ftp server. −... -
Page 55: Tampering
Network Camera − Send Email: Check the box to send an email. Selecting Image Attachment attaches an event detected image file (.JPG) to the email. − Remote Callback: Check the box and select the remote systems to send a message (Not supported for the WebGuard program). -
Page 56: System Event
User’s Manual − Remote Callback: Check the box and select the remote systems to send a message (Not supported for the WebGuard program). − Audio Alarm: Check the box and select the audio file (.wav) to sound. − FTP Upload: Check the box to upload images to an ftp server. −... - Page 57 Network Camera − Remote Callback: Check the box and select the remote systems to send a message when the SD memory card is inserted to or removed from the camera (Not supported for the WebGuard program) NOTE: You must properly configure the Email and Remote Callback settings when setting them...
- Page 58 User’s Manual...
-
Page 59: Chapter 4 - Webguard
Network Camera Chapter 4 — WebGuard You can monitor live video images from the camera or search recorded image saved in the SD memory card on the web browser by using the WebGuard program. Computer system requirements for using WebGuard are: ®... - Page 60 User’s Manual NOTES: There might be a problem with the bottom of the WebGuard page being cropped caused by the address or status bars in Microsoft Internet Explorer 7.0. In this situation, it is recommended that websites open windows without address or status bars by changing Internet setting. (Go to Tools, and Internet Options, and then the Security tab →...
-
Page 61: Web Monitoring Mode
Network Camera Web Monitoring Mode ① Log Out: Click to log out of the WebGuard program. ② Search: Click to access to the web search mode. ③ Version: Position the mouse pointer on the WebWatch logo to see the WebGuard program version. - Page 62 User’s Manual ⑪ Remote Setup: Click to change the settings of the camera by using the Remote Setup screen. ⑫ Event Status Window: The event status window at the bottom displays a list of events that were detected in the camera. Alarm In On/Off Motion Detection Trip-Zone...
-
Page 63: Web Search Mode
Network Camera Web Search Mode ① Log Out: Click to log out of the WebGuard program. ② Watch: Click to access to the web monitoring mode. ③ Version: Position the mouse pointer on the WebSearch logo to see the WebGuard program version. - Page 64 User’s Manual ⑧ Event Search: Click to enter the event search mode which allows you to search for event log entries using specific conditions and play back the images associated with those event entries. ⑨ Setup: Click to set up the image drawing mode and OSD display. You can adjust the display speed by changing the image drawing mode, and select OSD information to be displayed on the screen.
-
Page 65: Appendix
Network Camera Appendix LED Indicators LED Status Description Unlit No power connected to the unit. Power LED Flicker The unit is booting. The unit is operating. Network LED The unit is connected to a network. Power LED & Flicker The unit is upgrading the software. -
Page 66: Map Of Screens (Remote Setup)
User’s Manual Map of Screens (Remote Setup) Remote Setup Quick Setup System Network Video Audio System General Date/Time User/Group Network IP Address DVRNS Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Webcasting Privacy Masking Audio Input/Output Event Action Alarm Out Email Remote Callback Audio Alarm... -
Page 67: Troubleshooting
Network Camera Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. Check the ground status of the PoE switch and the connected input/ PoE switch is not output devices to the camera. If they are not grounded, use them recognized. - Page 68 User’s Manual CAMERA Image Sensor 1/2.7" CMOS IR LED On: 0 Lux @ F 1.6 (30 IRE) IR LED supported model: 0 Lux @ F 1.2 (30 IRE) Minimum Illumination IR LED non-supported model: 0.5 Lux @ F 1.6 (30 IRE) 0.5 Lux @ F 1.2 (30 IRE) Scanning Mode Progressive scan...
- Page 69 Network Camera INPUTS/OUTPUTS Video Output 1 Composite, 1 Vp-p Audio Input 1 line in Audio Output 1 line out 1 TTL, NC/NO programmable, 4.3V (NC) or 0.3V (NO) threshold, Alarm Input 5 VDC Alarm Output 1 TTL open collector, 30mA @ 5 VDC...
- Page 70 User’s Manual...
-
Page 71: Index
Network Camera Index A N Admin/Watch/Record/Search Port .. 20 Network Bandwidth Limit .... 22 B O Bitrate Control ........ 30 ONVIF Protocol ........ 14 C Q Camera Name ......... 1 4, 19 Quality .......... 30 Compression ........ 3 0, 32 R D Resolution .......... 30 Date/Time .......... 15 RTSP Port .......... 20 DSCP ............. 20 DVR Name Service ....... 19 S DVRNS Server ........ 19 SSL ............ 23 ... - Page 72 WARRANTY INFORMATION Please keep this document in a safe place. DO NOT return this document to Pacific Communications. EQUIPMENT DETAILS MODEL SERIAL NUMBER DATE OF PURCHASE IMPORTANT INFORMATION PLEASE RETAIN ALL MANUALS SUPPLIED WITH THE EQUIPMENT AND PROOF OF PURCHASE. PROOF OF PURCHASE WILL BE REQUIRED IF YOU NEED TO MAKE A WARRANTY CLAIM.
- Page 73 WARRANTY TERMS Pacific Communications provides consumers with the following warranty in relation to this Equipment, in addition to complying with the requirements of any relevant legislation, including the Competition and Consumer Act 2010 (Cth) in Australia and the Consumer Guarantees Act 1993 in New Zealand (the Acts), except where a New Zealand consumer acquires the relevant Product for the purposes of a business.
