Page 3: Compliance Notice Of Fcc
Network Camera WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. COMPLIANCE NOTICE OF FCC: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. -
Page 4: Important Safeguards
User’s Manual Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read Do not overload wall outlets and extension cords as this can before the appliance is operated. result in the risk of fire or electric shock. 2. -
Page 5: Table Of Contents
Network Camera Table of Contents Chapter 1 — Introduction ................1 In This Manual ..................1 Features ....................1 Typical Applications ................. 2 Chapter 2 — Installation................5 Package Contents ..................5 Dimensions ....................5 Front Side View ..................6 Right Side View .................. - Page 6 User’s Manual FTP Upload ..................32 Event ...................... 33 Motion Detection ................34 Trip-Zone ..................35 Tampering ..................36 System Event ................... 37 Chapter 4 — WebGuard ................39 Appendix ....................43 LED Indicators ..................43 Connector Pin Outs ................43 Map of Screens (Remote Setup) ............
-
Page 7: Chapter 1 - Introduction
Network Camera Chapter 1 — Introduction In This Manual This manual is intended for users of the network camera and includes instructions for using and managing the camera on the network. Features This network camera compresses live video and transmits the video over Ethernet connections. -
Page 8: Typical Applications
User’s Manual Typical Applications Remote Monitoring Remote Recording... - Page 9 Network Camera Webcasting...
- Page 10 User’s Manual...
-
Page 11: Chapter 2 - Installation
Network Camera Chapter 2 — Installation Package Contents Network Camera C-Mount Ring DC-Type Auto Iris Lens Connector Socket Protective cover (attached to the unit) Installation CD (INIT/SiRiS Lite software and User’s Manual) Quick Reference Guide ... -
Page 12: Front Side View
User’s Manual Front Side View ① Image Sensor: Converts an optical image of the object to an electric signal. NOTE: Cover the image sensor by using the protective cover provided with the camera when a lens is not mounted on the camera. Right Side View ①... -
Page 13: Factory Reset
Network Camera Factory Reset This will only be used on the rare occasions that you want to return all the settings to the original factory settings. CAUTION: When performing a Factory Reset, you will lose any settings you have saved. -
Page 14: Installation
User’s Manual Network LED: Indicates network connection status. See Appendix – LED Indicators for details. The LED will not light regardless of the status if the Status LED is disabled when configuring the System – General setup. NOTES: Camera surveillance may be prohibited by laws that vary by region. Check the laws in your area before using this product for surveillance purposes. -
Page 15: Manual Iris Lens
Network Camera Manual Iris Lens 1. Remove the protective cover from the camera. 2. Mount the lens on the camera by turning the lens clockwise. 3. Turn the iris ring on the lens to the open position and adjust the iris properly. -
Page 16: Cs-Mount Lens
User’s Manual CS-Mount Lens Remove the protective cover from the camera. Mount the CS-mount lens on the camera by turning the lens clockwise. C-Mount Lens Remove the protective cover from the camera. Mount the C-mount ring on the camera by turning the ring clockwise. -
Page 17: Chapter 3 - Remote Setup
Network Camera Chapter 3 — Remote Setup Remote Setup allows you to change all settings of a camera. Run the INIT program, select a camera and click the Setup icon on the Main screen. Select Remote Setup from the Setup menu and the Remote Setup screen appears. -
Page 18: Quick Setup
User’s Manual Quick Setup The Quick Setup allows you to change a camera’s basic system, network and video settings. System You can change a camera’s system information, import or export all settings, and add users or groups. General Language: Choose the language to be used during remote setup. ... -
Page 19: Date/Time
Network Camera Setup: − Load Default Setup…: Click to return all settings except date/time to the original factory settings. You can select whether or not network settings will be included when the setup is applied. Refer to the Network setup for details of the network settings. -
Page 20: User/Group
User’s Manual − Automatic Sync: Check the box to automatically synchronize the time with a time server. Enter the IP address or the domain name of the time server and set the time interval for synchronization. If the time server uses the DVRNS function, selecting the Use DVRNS box allows you to enter the name instead of the IP address or the domain name of the time server. -
Page 21: Network
Network Camera NOTES: Only users belonging to the Administrator group can make User/Group changes. The default user ID/password is admin with no password or pacom/pacom. The default groups (Administrator, Operator, User) cannot be edited or deleted. The same authority levels are assigned to the user groups in the ONVIF protocol. -
Page 22: Dvrns
User’s Manual − DHCP: Select when the camera is networked via DHCP (Dynamic Host Configuration Protocol). Click the OK button, and a temporary IP address is automatically assigned to the camera. The camera periodically will be issued a new IP address automatically. −... -
Page 23: Port/Qos
Network Camera Camera Name: Enter the camera name to be registered on the DVRNS server. Check whether or not the name is available by clicking the Check button. Help Desk: Choosing the OK button registers the camera on the DVRNS server. Proper DVRNS settings will display the help desk information of the DVRNS server. - Page 24 User’s Manual Use, Port: Check the box to enable and enter the port number. Admin, Watch and Record ports are set to use by default and you cannot change it. Checking the WebGuard or RTSP box allows you to connect to the camera by using the WebGuard program or media players, such as VLC Player, supporting RTSP (Real-Time Streaming Protocol) service.
-
Page 25: Bandwidth Control
Network Camera CAUTIONS: When changing the port settings, you must change the port settings on remote programs too. When using the HTTPS protocol, the ONVIF protocol might not work. Bandwidth Control You can control the network bandwidth by limiting the network bandwidth of the camera depending on the network traffic. -
Page 26: Security
User’s Manual Security IP Filtering: Check the box to use the IP filtering function. You can allow or block connections to the camera by designating IP addresses. − Add: Click the button to add IP addresses to the Allow List or Deny List to allow or block connection to the camera. -
Page 27: Ieee 802.1X
Network Camera IEEE 802.1X Check the IEEE 802.1X box to use the IEEE 802.1X network connection authentication function. Certificates: Uploads a certificate or private key for network connection depending on the authentication type. Entering a private key password might be required depending on the authentication type. -
Page 28: Video
User’s Manual Video You can set up camera setting and features for streaming, webcasting, MAT and privacy masking. Camera Image Sensor: Click the tab to set up image sensor settings. Mirroring: Check the Horizontal or Vertical box to flip images horizontally or vertically. ... - Page 29 Network Camera Noise Filter: Set the degree of the noise filtration. This adjustment can be used to decrease noise in low light conditions. The higher the value is set, the less the noise there is. However, too high of a setting might cause overall image blurring.
- Page 30 User’s Manual Exposure: Click the tab to set up exposure settings. AE Target Gain: Set the target gain for the exposure compensation. The camera compensates the exposure automatically based on the selected target gain. The higher the value is, the brighter the images are.
-
Page 31: Streaming
Network Camera Miscellaneous: Click the tab to set up other settings. Video Output: Select t he video signal for video output Streaming... - Page 32 User’s Manual Primary, Secondary, Tertiary: The camera supports multistream video (priority: Primary > Secondary > Tertiary). Set whether to enable or disable the streams. Some of the settings may change depending on the settings of streams of higher priority and the tertiary stream may not be available (see the table below).
-
Page 33: Webcasting
Network Camera NOTE: Simultaneous connections to the camera might cause the frame rate to decrease due to the network bandwidth overload. Webcasting The camera can stream live video from the camera to a website. HTML Code: Copy the HTML Code that is displayed on the screen and paste it in your web page code. -
Page 34: Mat
User’s Manual Check the MAT box to use the MAT (Motion Adaptive Transmission) function for video streaming and recording. This function is available only when the slow shutter mode is set to off. Refer to the Video – Camera (Exposure tab) setup for details about the slow shutter mode setting. ... -
Page 35: Privacy Masking
Network Camera Privacy Masking Check the Privacy Masking box to restrict monitoring of specific areas for privacy reasons. The privacy masking areas are displayed in the black color during monitoring. Privacy Masking Setup: Set up privacy masking areas (max. 16). -
Page 36: Event Action
User’s Manual Event Action You can set up event actions to be taken when the camera detects events. Email Check the Email box to send an email. SMTP Server, Port: Enter the IP address or domain name and port number of the SMTP server attained from your network administrator. -
Page 37: Remote Callback
Network Camera Remote Callback Check the Remote Callback box to send a callback message to remote systems (Not supported for the WebGuard program). IP Address, Port: Enter the IP addresses and port numbers of the remote systems to send a message. -
Page 38: Ftp Upload
User’s Manual FTP Upload Check the FTP Upload box to upload event detected images in JPEG file format to an ftp server. FTP Server: Click the Add button to register an ftp server. Clicking the Remove button deletes the registered ftp server. When an event is detected, the event detected images will be uploaded in JPEG file format to the ftp server registered as a primary server. -
Page 39: Event
Network Camera − Upload Frequency: Displays only when the upload type is set to Always. Set up the upload rate, and the preset number of images will be uploaded to the ftp server during the preset time. − Upload 1 image per: Displays only when the upload type is set to Event. Set up the upload rate. -
Page 40: Motion Detection
User’s Manual Motion Detection Check the Motion Detection box to set up a motion detection event. When the camera detects a motion in a configured motion detection zone, it considers the motion as an event. Sensitivity: Set the motion sensitivity for daytime and nighttime independently. The higher the number is, the more sensitive it is. -
Page 41: Trip-Zone
Network Camera − Remote Callback: Check the box and select the remote systems to send a message (Not supported for the WebGuard program). − FTP Upload: Check the box to upload images to an ftp server. NOTE: You must properly configure the settings related to each event action when setting them up to enable event actions. -
Page 42: Tampering
User’s Manual Motion Ignoring Interval: Select the motion ignoring dwell time from the drop-down list. The camera will not log or send notifications of motion events occurring during the preset interval after a motion is detected. You can control excessive event logging and remote notifications of motion detection events by adjusting the motion ignoring dwell intervals. -
Page 43: System Event
Network Camera Use Ignoring Time: Set up the event ignoring time. The camera will not consider tampering that occurs during the preset time span as an event. Event Action: Check the box for each action the camera is to take when it detects a tampering. - Page 44 User’s Manual...
-
Page 45: Chapter 4 - Webguard
Network Camera Chapter 4 — WebGuard You can monitor live video images from the camera on the web browser by using the WebGuard program. Computer system requirements for using WebGuard are: ® ® ® ® Operating System: Microsoft Windows... - Page 46 User’s Manual NOTES: There might be a problem with the bottom of the WebGuard page being cropped caused by the address or status bars in Microsoft Internet Explorer 7.0. In this situation, it is recommended that websites open windows without address or status bars by changing Internet setting. (Go to Tools, and Internet Options, and then the Security tab →...
- Page 47 Network Camera ① Log Out: Click to log out of the WebGuard program. ② Version: Position the mouse pointer on the WebWatch logo to see the WebGuard program version. ③ Information: The Information window displays the login information of WebGuard.
- Page 48 User’s Manual...
-
Page 49: Appendix
Network Camera Appendix LED Indicators LED Status Description Unlit No power connected to the unit. Power LED Flicker The unit is booting. The unit is operating. Network LED The unit is connected to a network. Power LED & Flicker The unit is upgrading the software. -
Page 50: Map Of Screens (Remote Setup)
User’s Manual Map of Screens (Remote Setup) Remote Setup Quick Setup System Network Video System General Date/Time User/Group Network IP Address DVRNS Port/QoS Bandwidth Control Security IEEE 802.1X Video Camera Streaming Webcasting Privacy Masking Event Action Email Remote Callback FTP Upload Event Motion Detection Trip-Zone... -
Page 51: Troubleshooting
Network Camera Troubleshooting Problem Possible Solution Check power cord connections. No Power Confirm that there is power at the outlet. Check the ground status of the PoE switch and the connected input/ PoE switch is not output devices to the camera. If they are not grounded, use them recognized. -
Page 52: Specifications
User’s Manual Specifications CAMERA D1 model: 1/4" CMOS Image Sensor HD model: 1/2.7" CMOS Lens Manual iris, DC-type auto-iris (mega pixel recommended) (Optional) Lens CS, C mount Mount Minimum Illumination 0.5 Lux @ F 1.4 (30 IRE) Scanning Mode Progressive scan 45 dB or higher Dynamic Range 90 dB or higher... - Page 53 Network Camera GENERAL Dimensions 2.87" x 2.24" x 5.16" (73mm x 57mm x 131mm) (W x H x D) Shipping Dimensions 7.87" x 4.5" x 5.9" (200mm x 115mm x 150mm) (W x H x D) Unit Weight 0.84 lbs. (382g) Shipping Weight 1.50 lbs.
- Page 54 User’s Manual...
-
Page 55: Index
Network Camera Index A N Admin/Watch/Record Port .... 18 Network Bandwidth Limit .... 19 B O Bitrate Control ........ 26 ONVIF Protocol ........ 12 C Q Camera Name ......... 1 2, 17 Quality .......... 26 Compression ........ 2 6, 27 R D Resolution .......... 26 Date/Time .......... 13 RTSP Port .......... 18 DSCP ............. 18 DVR Name Service ....... 16 S DVRNS Server ........ 16 SSL ............ 20 F T ... - Page 56 WARRANTY INFORMATION Please keep this document in a safe place. DO NOT return this document to Pacific Communications. EQUIPMENT DETAILS MODEL SERIAL NUMBER DATE OF PURCHASE IMPORTANT INFORMATION PLEASE RETAIN ALL MANUALS SUPPLIED WITH THE EQUIPMENT AND PROOF OF PURCHASE. PROOF OF PURCHASE WILL BE REQUIRED IF YOU NEED TO MAKE A WARRANTY CLAIM.
- Page 57 WARRANTY TERMS Pacific Communications provides consumers with the following warranty in relation to this Equipment, in addition to complying with the requirements of any relevant legislation, including the Competition and Consumer Act 2010 (Cth) in Australia and the Consumer Guarantees Act 1993 in New Zealand (the Acts), except where a New Zealand consumer acquires the relevant Product for the purposes of a business.
