- Page 1 Battery-powered Cable Cutter 45380 —with 120 V Charger 45381—with 220 V Charger Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 99926288 © 2008 Greenlee Textron Inc. IM 1322 REV 8 1/09...
-
Page 2: Table Of Contents
Parts List ........................14–15 Description The Greenlee Battery-powered Cable Cutter is intended to cut up to 750 kcmil copper and aluminum cable. The cable cutter is driven by a 12-volt motor and is powered by a rechargeable NiCd (nickel cadmium) battery. The motor is protected by a circuit breaker. -
Page 3: Important Safety Information
ES750 IMPORTANT SAFETY INFORMATION SAFETY ALERT SYMBOL This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. The signal word, defined below, indicates the severity of the hazard. The message after the signal word provides information for preventing or avoiding the hazard. - Page 4 Failure to observe these warnings could result in severe injury or death. described in this manual can result in injury or property damage. Greenlee replacement parts. A damaged or improperly assembled tool can break and strike nearby personnel. Failure to observe these precautions may result in injury or property damage.
- Page 5 ES750 IMPORTANT SAFETY INFORMATION Battery Do not dispose of battery in a fire. The battery will vent harmful vapors and can explode. Failure to observe this warning could result in severe injury or death. Do not allow any object to contact the battery terminals.
- Page 6 Failure to observe these warnings could result in severe injury or death. Greenlee recommends plugging the charger directly into a receptacle. If an extension cord must be used: Use of an improper or damaged extension cord could result in electric shock or fire.
-
Page 7: Important Safety Information
ES750 IMPORTANT SAFETY INFORMATION Charger Use this charger to charge the supplied 12-volt rechargeable NiCd (nickel cadmium) batteries only. Other batteries may burst if charged with this charger. Failure to observe this warning could result in severe injury or death. -
Page 8: Specifications
Specifications Cutter Weight (with battery) ....................5 lb, 8 oz Weight (with battery, charger, and case) ............9 lb, 10 oz Height ........................13-5/8" Width ........................6-1/2" Depth ........................4-1/8" Wire Type ..................Copper or aluminum Maximum Wire Size ....................750 kcmil Motor ........................12 VDC Battery Type .................. -
Page 9: Operation
ES750 Operation 1. Slide the direction control lever to select either FORWARD or REVERSE. Press the switch to activate the cable cutter. Release the switch after the movable blade is disengaged from the driver. 2. Place the cable to be cut against the stationary blade until it is engaged by the driver. -
Page 10: Charger
Charger The battery charger will recharge the battery in approximately one hour. Do not connect the charger to a generator. Voltage fluctuations may damage the charger. ventilation slots are not blocked. 2. Connect the charger to an appropriate power supply. 3. -
Page 11: Troubleshooting
ES750 Troubleshooting Problem Probable Cause Probable Remedy Cutter does not operate. Battery is discharged. Charge the battery. The internal circuit breaker Reset the circuit breaker. has tripped. Movable blade is not Push movable blade until completely engaged. it is completely engaged with the drive. -
Page 12: Maintenance
Maintenance Replacing Blade Brush 1. Remove the two screws (38) and lift out brush (13). 2. Insert new brush (13). Align hole in brush with holes in housing, install screws (38), and tighten. Replacing Movable Blade 1. Rotate blade so that it is clear of pinion gear (9). 2. -
Page 13: Illustration
ES750 Illustration 24 x 4 20 x 7 39 x 2 40 x 5 13 16 x 7 40 x 5 39 x 3 42 x 6... -
Page 14: Parts List
Parts List Part No. Description 50109910 Housing Kit (includes items 1A - 1B) Left housing..............1 Right housing ..............1 50453335 Stationary blade ..............1 50453343 Moving blade ............... 1 50453351 Gear guides set ..............1 50453360 Shoulder screw M6 .............. 1 50453378 Washer M6 ................ -
Page 15: Parts List
