- Page 1 F Series Battery Charger Operator’s Manual IGITAL ONTROL dci@digital-control.com NCORPORATED www.DigiTrak.com...
- Page 2 IGITAL ONTROL NCORPORATED 403-2510-00-A, Apr 2015 © 2015 by Digital Control Incorporated. All rights reserved. Trademarks ® ® , are U.S. registered trademarks and F Series™ and FSD™ The DCI logo, DigiTrak , and F5 are trademarks of Digital Control Incorporated. Patents U.S.
- Page 3 IGITAL ONTROL NCORPORATED Contact Us United States 19625 62nd Ave S, Suite B103 DCI Headquarters Kent, Washington 98032, USA +1.425.251.0559 / 1.800.288.3610 +1.425.251.0702 fax dci@digital-control.com Australia 2/9 Frinton Street Southport QLD 4215 +61.7.5531.4283 +61.7.5531.2617 fax dci.australia@digital-control.com China 368 Xingle Road Huacao Town Minhang District Shanghai 201107, P.R.C.
-
Page 4: Table Of Contents
IGITAL ONTROL NCORPORATED Table of Contents General Description AC/DC Power Setup Charging a Battery Pack Battery Charger Status Indicators Warnings and Precautions Temperature ....................4 Power Input ..................... 4 User Serviceability ................... 4 Liquids ......................4 Indoor Use ....................... 5 System Specifications Power Requirements .................. -
Page 5: General Description
F Series Battery Pack Insert a fully charged DigiTrak F Series battery pack so it is flush with the back of the receiver and the tab is securely latched. To remove the battery pack, push down on the battery tab and pull the battery pack out and up from the battery compartment. -
Page 6: Ac/Dc Power Setup
IGITAL ONTROL NCORPORATED An F Series battery charger with a black and silver case labeled for use with DCI Li-ion or NiMH battery packs will also charge SE NiMH battery packs (SBP), although the charging times, battery voltages, and estimated battery lifetimes will be different from F Series Li-ion battery packs. -
Page 7: Battery Charger Status Indicators
IGITAL ONTROL NCORPORATED Battery Charger Status Indicators The battery charger has red, orange, and green LEDs that are on, off, or flashing depending on the charging status. A series of beeps will also sound to indicate a major battery pack or charger fault. -
Page 8: Warnings And Precautions
IGITAL ONTROL NCORPORATED Warnings and Precautions DCI assumes no liability for problems that occur when you do not follow these warnings and precautions, as well as the general precautions outlined in Important Safety Instructions in the operator's manual for your locating system. Warning The charger is designed with safeguards to protect you from shock and other hazards when used as specified in this manual. -
Page 9: Indoor Use
The power requirements, environmental requirements, and equipment maintenance requirements for the FBC F Series Battery Charger are listed below. Power Requirements Device (Model Number) Operational Voltage Operational Current DigiTrak F Series Battery Input 10–28 V 5.0 A max Charger (FBC) Output 19.2 V 1.8 A max... -
Page 10: Storage And Shipping Requirements
IGITAL ONTROL NCORPORATED Storage and Shipping Requirements Temperature Storage and transportation temperature must remain within -40 to 149° F (-40 to 65° C). Packaging Ship in original carrying case or packaging of sufficient durability to prevent mechanical shock to equipment during transportation. Approved for transportation by vehicle, boat, and aircraft. -
